Light Sky SUNNY MINI User manual

SUNNY MINI
E-mail:
n
Address: No. 43, Yunfeng Road, Xiuquan Street,
Huadu District, Guangzhou, China

1. Safety information........................................................................................................2
2. Technical information...................................................................................................4
3. Attachment and body size.........................................................................................5
4. Installation and connecting.......................................................................................6
5. Control panel..............................................................................................................9
6. Menu setting...............................................................................................................10
7. Channel function.........................................................................................................12
8. Circuit connecting diagram.......................................................................................21
9. Cleaning and maintenances.......................................................................................22
10.Troubeshooting..........................................................................................................23
11.Duty exonerative and copyright protection............................................................24
Congratulations on choosing our company product! We thank you for your custom.
◆Please note that this product, as all the others in the rich my company range, has
been designed and made with total quality to ensure excellent performance and
best meet your expectations and requirements.
◆Carefully read this user manual in its entirety and keep it safe for future reference.
It is essential to know the information and comply with the instructions given in this
manual to ensure the fitting is installed, used and serviced correctly and safely.
◆My company disclaims all liability for damage to the fitting or to other property or
persons deriving from installation, use and maintenance that have not been carried
out in conformity with this user manual, which must always accompany the fitting.
◆My company reserves the right to modify the characteristics stated in this user
manual at any time and without prior notice.
Contents

2
SAFETY IN FORMATION
Please do not install the fixture onto combustible surface.
The double insulation between the LV power supply and the control conductor on the fixture.
■Mounting surface and fire protection
Keep all combustible materials at least 20 cm away from the fixture.
■This lighting fixture is for professional use only - it is not for household use.
Make sure all parts for fixing the projector are in a good state of repair.
Make sure the point of anchorage is stable before positioning the projector.
Enhanced care has to be considered during the installation.
The safety chain must be prgperly hooked onto the fitting and secured to the framework.
The unit can be placed directly on the stage floor which can support 10 times
of the unit’s weight.
Make sure there are no flammable materials close to the unit while operating,
as it is fire hazard.
ta 40℃
This fixture is suitable for indoor use and wet locations. Do not immerse in water.

3
The products referred to in this manual conform to the European Community Directives to which
they are subject:
Low Voltage 2014/35/EU
Electromagnetic Compatibility 2014/30/EU
Never look directly into the light source. You risk injury to your retina, which may induce blindness.
Do not look at LEDs with magnifiers, telescopes, binoculars or similar optical instruments that may
concentrate the light output.
Protection optical radiation
Protection against explosion
The protection screen, lens or ultraviolet screen on the lamp can be damaged to the degree
of failure if visible damage, such as a crack or deep mark, should be replaced。
The light source in this xture shall be replaced by the manufacturer or its service agent or
similar qualication.
Always disconnect from mains before replacing the light.
tc 80℃ The maximun temperature that can be reached on the external surface of the fitting,
in a thermally steady state,is 80℃ 。
Avoid contact bypersons and materials.
Allow the fixture to cool for at least 5 minutes before handling.
■The light source
Avoid any inflammable liquids, water or metal objects entering the unit. Once it happen,
cut off the mains power immediately.

4
TECHNIC AL INFORMATION
● 100-240V ~，50/60 HzPower supplies available：
● Rated power 507W PF : 0.96：
● DMX Connector IP66 waterproof signal line.：
● Power Connector IP66 waterproof Power input line.：
● Light source 36×15W RGBL（Red、Green、Blue、Lime） LED：LUMILEDS
● 30000hAverage life：
● Luminous flux of light source 20758 lm：
● Luminaire flux 17921 lm：
● Lens Angle 6°：
● Material of lens PMMA：
● Beam Angle standard 14°, optional 25° and 45°：
● Vertical tilt Angle ±90°：
● CCT 2500K -7000K：
● CRI Ra 75 ： ≥
● Color：
RGBL macro color system.soft and no flicker,Single ring can be controlled separateiy,
fast marco color system.
● ：1-30 times second electronic strobe and random strobe.Strobe /
：16Bit，0-100％The linear dimming，provides four dimming options.●Dimmer
● Control Mode：DMX512, RDM, Stand-alone mode ,Wireless DMX512(optional).
：Standard channel:8C ; ● HChannel
channel: 24CH、20CH、16CH、1CH、3CH、4CH1、4CH2、5CH、7CH.
● Display panel OLED black and white display. ：
● Built-in program yes ：
● Intelligent temperature control yes ：
● Software upgrade：Update via DMX link Channel.
● RDM two-way transmission of RDM data.：
● Data connection 3-core waterproof signal transfer input line/output line ：
(5-core waterproof line connector is optional).
Maximum number of signal connections dmx@ 25.
●Aluminum alloy, toughened glass. Outlooking：
●Surface treatment Gray-green fine sand, anti - salt spray corrosion. ：
●IP protection level IP66 ：
●Heat dissipation mode natural heat dissipation. ：
●Working environment temperature -40 ~ +45℃ ：
● Light size：916X275X397MM
Packing Size (1sets)：1000X390X370●
N.W.：31.5Kg ，G.W.：44Kg
Flycase Size (1sets)：1025X360X525MM●
N.W.：31.5Kg ，G.W.：52.9Kg

14°Lux(fc) R
G
B
L
RBGL
2600(242)
4000(378)
583(54)
5530(514)
12470(1159)
293(27.2)
460(42.8)
68(6.3)
625(58.1)
1450(135)
32(3)
42(3.9)
6.3(0.6)
58(5.4)
127(11.8)
648(60.3)
1005(93.4)
148(13.8)
1340(125)
3150(293)
165(15.3)
255(23.7)
38(3.5)
319(29.7)
765(71.1)
43(4)
65(6)
9.8(0.9)
88.5(8.2)
200(18.6)
75(7)
110(10.2)
17.3(1.6)
152(14.1)
352(32.8)
IPL3615 Distance,spot diameter and illumination diagram
10 20 30 40 500
Distance(m)
Diameter 10％(m) 4.36 8.85 13.6 17.8 21.5
5
2.16
15
6.76
0
5
10
5
10
14°
5

ATTACHMENT AND BODY SIZE
power cord
1
916
345
275
916 275
397
6

● After doing the above operation and making sure all the devices had been
installed with natural operate, press the power switch to check whether every
-thing is working normally.
● connection to the eiectricty mains must be carried out by a qualified electrical
installer.
7
or
L
N
black
blue
brown
yellow-green
white
green
Conductor Symbol
live
neutral
ground(earth)
Wire Color
(EU models)
Wire Color
(US models)
Wire color-coding and power connections：
POWER IN
N(White/Blue)
(Green/Yellow Green)
L(Black/Brown)
3
3

8
DMX - output
1 - Shield
2 - Signal (-)
- Signal (+)
- Not connected
- Not connected
3
1
2
3
DMX-input
- Shield
-Signal (-)
- Signal (+)
- Not connected
- Not connected
4
5
4
5
PIN3
PIN2
DMX IN
OUT
IN
OUT
IN
OUT
CONNECTOR
CABLE
I O P
V
CONNECTOR
CABLE
I O P
V
CONNECTOR
CABLE
I O P
V
4
4

CONTROL PANEL
9
Up arrowhead : page up
Down arrowhead : page down
Left arrowhead : reduce
Right arrowhead : increase
Enter : OK function
Exit : in the choice screen
UP
DOWN
LEFT RIGHT
ENTER
5

MENU SET T ING
10
Main menu Ⅰ menu Ⅱ menu Ⅲ menu Ⅰ
V
menu
Dmx Set
Dmx Addr Edit A001~AXXX
DMX Function
Hold（Default）
Black
Red
Green
Blue
Lime
Red&Green
Red&Blue
Red&Lime
Green&Blue
Green&Lime
Blue&Lime
Program1~12
Auto Run Mode Alone（Default）
Master
Auto Run Sp Speed = 01--99（Default：
88）
Addr Edit（Auto） Yes/No
Information
Total Time Total Time:****(H)
Total LED :****(H)
Fixture Time Fixture:****(H)
Led Open:****(H)
Soft Version V1.00A...
Clr Fixture Time Yes/No
DMX Info Strobe.Dimmer...........
Box Info Box Temp=
Humidity=
RDM Set
RDM UID =xxxxxxxxxxxx;
MANU..LABEL = LIGHTSKY
DEVICE LABEL = SUNNY MINI
Personal
Set Channel Mode
08CH （Default）
24CH
20CH
16CH
01CH
03CH
04CH1

11
Personal
Set
Channel Mode
04CH2
05CH
07CH
Standby Key Lock On/Off （Default：Off）
SelectDimmer Hz
Select 24K Hz （Default）
Select 12K Hz
Select 6K Hz
Select 3K Hz
DimmerCurve
Linear （Default）
Square
I-Square
SCurve
Manual
Control Channel Strobe.Dimmer...........
Service
Calibration Red，Green,Blue,Lim
Factory Set
Reset Default Yes/No
ClearTotalTime Yes/No
Developer Yes/No
Temp To Power On/Off
（Default On)
：
Manual Or Dmx
LOGO Display
Reset Address Yes/No
Language English
Chinese （Default）
Dis
Rotation
Normal （Default）
Rotate 180
Temperature Temp1;Temp2;
Main menu Ⅰ menu Ⅱ menu Ⅲ menu ⅠV menu
On/Off
（Default On)
：
On/Off
（Default On)
：
Special key function description:Press UP and DOWN buttons at the same time,keep 3
seconds,Show direction reversal;Press Left and Right buttons at the same time.
Hold for 3 seconds and switch between Chinese and English

CHANNEL F UNCTION
Standard channel（ 8CH）
Channel Value Percentage Function Note
1
Shutter
0..9 No function
10..255 Strobe effect slow to fast
2Dimmer
0..255 Dimmer 0%...100%
3Red
0..255 0-100% Red dimmer from dark to bright
4Green
0..255 0-100% Green dimmer from dark to bright
5Blue
0..255 0-100% Blue dimmer from dark to bright
6Lime
0..255 0-100% Lime dimmer from dark to bright
7
Pixel
Macro
0..4 No
function
5..28 Marcro 1
29..55 Marcro 2
53..76 Marcro 3
77..100 Marcro 4
101..124 Marcro 5
125..148 Marcro 6
149..172 Marcro 7
173..196 Marcro 8
197..220 Marcro 9
221..244 Marcro 10
245..250 Marcro 11
251..255 Marcro 12
8Macro
Speed
0..255 Macro Speed from slow to fast
12
No t e: Af ter su cce s sfu lly w r iti ng the a ddr e ss co de in ba tch , the li ght s w ill t urn on r ed, g r een , blu e
an d lemo n suc ces siv ely, a nd fi nal ly st robe t wic e, an d the n swit ch ba ck to t he or igin al li ght s tat e.

13
channel（ 24CH）
Channel Value Percentage Function Note
1
Shutter
0..9 No function
10..255 Strobe effect slow to fast
2Dimmer
0..255 Dimmer 0%...100%
3Red
0..255 0-100% Red dimmer from dark to bright
4Green
0..255 0-100% Green dimmer from dark to bright
5Blue
0..255 0-100% Blue dimmer from dark to bright
6Lime
0..255 0-100% Lime dimmer from dark to bright
7
Pixel Macro
0..4 No function
5..28 Marcro 1
29..55 Marcro 2
53..76 Marcro 3
77..100 Marcro 4
101..124 Marcro 5
125..148 Marcro
6
149..172 Marcro
7
173..196 Marcro
8
197..220 Marcro 9
221..244 Marcro 10
245..250 Marcro 11
251..255 Marcro 12
8Macro
Speed
0..255 Macro Speed from slow to fast
9Red
in Pixel 1
0..255 Red in pixel 1 saturation control (0-100%)
10 Green
in Pixel 1
0..255 Green in pixel 1 saturation control (0-100%)
11 Blue in Pixel 1
0..255 Blue in pixel 1 saturation control(0-100%)
12 Lime in pixel 1
0..255 Lime in pixel 1 saturation control(0-100%)

14
Channel Value Percentage Function Note
13 Red
in pixel 2
0..255 Red in pixel 2 saturation control(0-100%)
14 Green
in pixel 2
0..255 Green in pixel 2 saturation control(0-100%)
15 Blue
in pixel 2
0..255 Blue in pixel 2 saturation control(0-100%)
16 Lime
in pixel 2
0..255 Lime in pixel 2 saturation control(0-100%)
17 Red
in Pixel 3
0..255 Red in pixel 3 saturation control (0-100%)
18 Green
in pixel 3
0..255 Green in pixel 3 saturation control(0-100%
19 Blue
in pixel 3
0..255 Blue
in pixel 3 saturation
control(0-100%)
20 Lime
in pixel 3
0..255 Lime in pixel 3 saturation control(0-100%)
21 Red
in Pixel 4
0..255 Red in pixel 4 saturation control (0-100%)
22 Green
in pixel 4
0..255 Green in pixel 4 saturation control(0-100%)
23 Blue in pixel 4
0..255 Blue in pixel 4 saturation control(0-100%)
24 Lime in pixel 4
0..255 Lime in pixel 4 saturation control(0-100%)

15
channel（ 20CH）
Channel Value Percentage Function Note
1
Shutter
0..9 No function
10..255 Strobe effect slow to fast
2Dimmer
0..255 Dimmer 0%...100%
3
Pixel Macro
0..4 No function
5..28 Marcro 1
29..55 Marcro 2
53..76 Marcro 3
77..100 Marcro 4
101..124 Marcro 5
125..148 Marcro 6
149..172 Marcro 7
173..196 Marcro 8
197..220 Marcro 9
221..244 Marcro 10
245..250 Marcro 11
251..255 Marcro
12
4Macro
Speed
0..255 Macro Speed from slow to fast
5Red
in Pixel 1
0..255 Red in pixel 1 saturation control (0-100%)
6Green
in Pixel 1
0..255 Green in pixel 1 saturation control (0-100%)
7Blue
in Pixel 1
0..255 Blue in pixel 1 saturation control(0-100%)
8Lime
in pixel 1
0..255 Lime in pixel 1 saturation control(0-100%)
9Red
in pixel 2
0..255 Red in pixel 2 saturation control(0-100%)
10 Green
in pixel 2
0..255 Green in pixel 2 saturation control(0-100%)
11 Blue in pixel 2
0..255 Blue in pixel 2 saturation control(0-100%)
12 Lime in pixel 2
0..255 Lime in pixel 2 saturation control(0-100%)

16
Channel Value Percentage Function Note
13 Red
in Pixel 3
0..255 Red in pixel 3 saturation control (0-100%)
14 Green
in pixel 3
0..255 Green in pixel 3 saturation control(0-100%
15 Blue
in pixel 3
0..255 Blue in pixel 3 saturation control(0-100%)
16 Lime
in pixel 3
0..255 Lime
in pixel 3
saturation control(0-100%)
17 Red
in Pixel 4
0..255 Red in pixel 4 saturation control (0-100%)
18 Green
in pixel 4
0..255 Green in pixel 4 saturation control(0-100%)
19 Blue
in pixel 4
0..255 Blue in pixel 4 saturation control(0-100%)
20 Lime
in pixel 4
0..255 Lime in pixel 4 saturation control(0-100%)

channel（ 16CH）
17
Channel Value Percentage Function Note
1Red
in Pixel 1
0..255 Red in pixel 1 saturation control (0-100%)
2Green
in Pixel 1
0..255 Green in pixel 1 saturation control (0-100%)
3Blue
in Pixel 1
0..255 Blue in pixel 1 saturation control(0-100%)
4Lime
in pixel 1
0..255 Lime in pixel 1 saturation control(0-100%)
5Red
in pixel 2
0..255 Red in pixel 2 saturation control(0-100%)
6Green
in pixel 2
0..255 Green in pixel 2 saturation control(0-100%)
7Blue
in pixel 2
0..255 Blue in pixel 2 saturation control(0-100%)
8Lime
in pixel 2
0..255 Lime in pixel 2 saturation control(0-100%)
9Red
in Pixel 3
0..255 Red in pixel 3 saturation control (0-100%)
10 Green
in pixel 3
0..255 Green
in pixel 3 saturation control(0-100%
11 Blue
in pixel 3
0..255 Blue in pixel 3 saturation control(0-100%)
12 Lime
in pixel 3
0..255 Lime in pixel 3 saturation control(0-100%)
13 Red
in Pixel 4
0..255 Red in pixel 4 saturation control (0-100%)
14 Green
in pixel 4
0..255 Green in pixel 4 saturation control(0-100%)
15 Blue
in pixel 4
0..255 Blue
in pixel 4 saturation control(0-100%)
16 Lime
in pixel 4
0..255 Lime in pixel 4 saturation control(0-100%)

18
channel（ 1CH）
channel（ 3CH）
channel（ 4CH 1）
Channel Value Percentage Function Note
1ALL
Dimmer
0..255 Dimmer 0%...100% Control all LED
Channel Value Percentage Function Note
1
Red
0..255 0-100%
Red
dimmer from dark to bright
2
Green
0..255 0-100%
Green dimmer from dark to bright
3
Blue
0..255 0-100%
Blue dimmer from dark to bright
Channel Value Percentage Function Note
1Dimmer
0..255 Dimmer 0%...100%
2Red
0..255 0-100%
Red
dimmer from dark to bright
3Green
0..255 0-100% Green dimmer from dark to bright
4Blue
0..255 0-100% Blue dimmer from dark to bright

19
channel（ 4CH 2）
channel（ 5CH）
Channel Value Percentage Function Note
1Red
0..255 0-100% Red dimmer from dark to bright
2Green
0..255 0-100%
Green
dimmer from dark to bright
3Blue
0..255 0-100% Blue dimmer from dark to bright
4Lime
0..255 0-100% Lime dimmer from dark to bright
Channel Value Percentage Function Note
1Dimmer
0..255 Dimmer 0%...100%
2Red
0..255 0-100%
Red dimmer
from dark to bright
3Green
0..255 0-100% Green dimmer from dark to bright
4Blue
0..255 0-100% Blue dimmer from dark to bright
5Lime
0..255 0-100% Lime dimmer from dark to bright
