Makita HM1242C Quick start guide

Parts Breakdown HM1242C
Page 1 of 3 2/8/2008

Parts Breakdown HM1242C
Fig # Part ID Part Name Quantity
1 286252-9 TOOL HOLDER CAP, HM1140C 1
2 231998-2 RING SPRING 29, HM1242C 1
3 256156-9 PIN 6, HK1800 1
4 323960-2 ROLLER GUIDE, HM1242C 1
5 417127-3 TOOL HOLDER COVER, HM1242C 1
6 267735-8 CUP WASHER 45, HR5001C 1
10 233218-0 COMPRESSION SPRING 55, HR5001C 1
11 323876-1 STEEL BALL GUIDE, HM1202C-T1 1
11 324131-4 STEEL BALL GUIDE, HM1202C 1
12 231988-5 RING SPRING 34, HM1242C 1
13 267197-0 FLAT WASHER 37, HM1242C 1
13 267197-0 FLAT WASHER 37, HM1242C 1
14 416934-1 CHANGE RING, HM1202C 1
15 231989-3 RING SPRING 46, HM1202C 1
16 416938-3 HOUSING COVER, HM1202C 1
17 265439-6 HEX BOLT M8X150, HM1100C 1
18 417003-1 SIDE HANDLE, HM1202C 1
19 252640-2 WING NUT M8, HM1100C 1
20 951166-8 SPRING PIN 5-24, UM140D 1
21 417002-3 SIDE HANDLE CAM, HM1202C 1
22 317223-6 SIDE HANDLE BASE 82A, HM1202C 1
23 317224-4 SIDE HANDLE BASE 82B, HM1202C 1
24 417002-3 SIDE HANDLE CAM, HM1202C 1
25 213670-8 O RING 58, HM1202C 1
26 310087-7 BARREL, HM1202C 1
27 216011-7 STEEL BALL 5.6, 6222DWE 4
28 922451-6 H.S.H. BOLT M8X30, LS1013 4
29 213720-9 O RING 67, HR2400 1
30 213508-7 O RING 38, HM0810B 1
30 213510-0 O RING 36, HR2010 1
31 262083-0 URETHANE RING 43, HM1202C 1
31 262095-3 URETHANE RING 41, HM1202C 1
32 323961-0 TOOL HOLDER, HM1242C 1
32 323961-0 TOOL HOLDER, HM1242C 1
33 323860-6 ROLLER 12, HM1140C 1
34 213431-6 FLUORIDE RING 28, HR5001C 2
35 213394-6 O RING 23, HR5001C 2
36 323908-4 IMPACT BOLT, HM1242C 1
37 323909-2 IMPACT BOLT GUIDE, HM1202C 1
38 421691-8 RUBBER RING 25, HM1202C 1
39 323875-3 COLLARED SLEEVE 24, HM1202C 1
40 416927-8 GUIDE RING, HM1202C-T1 1
40 417600-3 GUIDE RING, HM1242C 1
41 344790-8 FLAT WASHER 49, HM1202C-T1 1
41 344998-4 FLAT WASHER 49, HM1202C 1
42 331554-9 CYLINDER LINER 44, HM1202C-T1 1
42 331608-2 CYLINDER LINER 44, HM1202C 1
43 416928-6 SLIDE SLEEVE 49, HM1202C 1
44 257224-1 RING 49, HM1202C 1
45 213508-7 O RING 38, HM0810B 1
46 233246-5 COMPRESSION SPRING 50, HM1202C 1
47 416935-9 CRANK CAP, HM1202C 1
48 213806-9 O RING 90, HM1500 1
49 323910-7 STRIKER, HM1202C 1
50 213485-3 O RING 34, HM1202C 1
51 213485-3 O RING 34, HM1202C 1
52 213523-1 O RING 36, HM1202C 1
53 257693-6 SLEEVE 9, HM1202C 1
54 416929-4 PISTON, HM1202C 1
55 416930-9 ROD, HM1202C 1
Page 2 of 3 2/8/2008

Parts Breakdown HM1242C
56 323877-9 CRANK SHAFT, HM1202C 1
57 211327-5 BALL BEARING 63604LLU, HR5000 1
58 212113-7 N. BEARING 1212, LS1440 1
59 317225-2 CRANK HOUSING, HM1202C 1
59 318102-1 CRANK HOUSING, HM1202C 1
60 416940-6 CONTROLLER COVER, HM1202C 1
61 415692-6 STOPPER, HM1100C 1
62 421507-7 HANDLE, HM1100C 1
63 922361-7 H.S.H. BOLT M6X40, HM1303B 2
64 922353-6 H. S. H. BOLT M6X30,HR5001C 2
65 922353-6 H. S. H. BOLT M6X30,HR5001C 4
66 416932-5 ACRYLIC PIN 5, HM1202C 2
67 416931-7 SWITCH LEVER, HM1202C 1
68 211228-7 BALL BEARING 6202DDW, HM1303B 1
68 211235-0 BALL BEARING 6202DDW, HM1202C-T1 1
68 211238-4 BALL BEARING 6202LLU, HR4500C 1
69 213273-8 OIL SEAL 17, HM1202C 1
70 516801-1 ARMATURE ASS'Y 115V, HM1202C 1
71 681642-5 INSULATION WASHER, LS1013 1
72 211088-7 BALL BEARING 6000DDW, 9005B 1
73 416936-7 BAFFLE PLATE, HM1202C 1
74 266095-5 TAPPING SCREW 5X55, 5044KB 2
75 526091-8 FIELD ASS'Y 115V, HM1202C 1
76 151795-9 MOTOR HOUSING CPL., HM1202C 1
76 158581-9 N/A 1
77 852090-7 NAME PLATE, HM1242C 1
78 263002-9 RUBBER PIN 4, HR2400 1
79 819064-1 MAKITA MARK, HM1100C 2
80 651481-7 SWITCH STE215K, HM1100C 1
81 631274-8 CONTROLLER, HR5001C 1
82 181048-2 CARBON BRUSH 155, HR5000 1
83 643650-4 BRUSH HOLDER CAP 6.5-13.5, 5402A 2
84 922364-1 H.S.H. BOLT M6X40, HM1100C 4
85 415695-0 FIX ROD, HM1100C 1
86 687052-4 STRAIN RELIEF, HM1500B 1
87 265995-6 TAPPING SCREW 4X18, 4323K 2
88 416937-5 REAR COVER, HM1202C 1
89 265995-6 TAPPING SCREW 4X18, 4323K 2
90 682560-0 CORD GUARD 10, HM1202C 1
91 664471-1 CORD, 2X14X16;SJ, HM1500 1
92 241908-1 FAN 80, HM1242C 1
93 213508-7 O RING 38, HM0810B 2
94 421914-4 CONTROLLER PROTECTOR, HM1202C 1
95 267809-5 N/A 1
1,001 181573-3 BIT GREASE, HR2400 1
1,001 181573-3 BIT GREASE, HR2400 1
1,002 824564-8 PLASTIC TOOL CASE, HM1202C 1
2,001 134885-3 SIDE HANDLE ASS'Y, HM1202C 1
5,001 810134-9 N/A 1
Page 3 of 3 2/8/2008
