Mitel 6863i User manual

Mitel 6800i Series SIP Phones
41-001562-00 REV01
RELEASE 4.0.0 SP1 TR-069 CONFIGURATION GUIDE

NOTICE
The information contained in this document is believed to be accurate in all respects but is not warranted
by Mitel Networks™ Corporation (MITEL®). The information is subject to change without notice and should
not be construed in any way as a commitment by Mitel or any of its affiliates or subsidiaries. Mitel and its
affiliates and subsidiaries assume no responsibility for any errors or omissions in this document. Revisions
of this document or new editions of it may be issued to incorporate such changes.
No part of this document can be reproduced or transmitted in any form or by any means - electronic or
mechanical - for any purpose without written permission from Mitel Networks Corporation.
Trademarks
Mitel is a trademark of Mitel Networks Corporation.
Other product names mentioned in this document may be trademarks of their respective companies and
are hereby acknowledged.
Mitel 6800i Series SIP Phones Release 4.0.0 SP1 TR-069 Configuration Guide
41-001562-00 REV01 - December 2014
®,™ Trademark of Mitel Networks Corporation
© Copyright 2014, Mitel Networks Corporation
All rights reserved

Table of Contents
iii
Welcome. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
TR-069 Protocol Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Pre-Staging SIP Phones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
TR-069 Functionality Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Behaviors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
TR-069 Parameter Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Support for Getting Capabilities, General Profiles, and Other Static Parameters . . . . . . . . . . . .6
Voice Profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Handling Dynamic Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
TR-111 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Periodic Inform Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Configuring Periodic Inform Using the Configuration Files . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Inform Upon Receipt of SIP NOTIFY Check-Sync Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Configuring the Inform Upon Receipt of SIP NOTIFY Check-Sync Feature
Using the Configuration Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Configuration Backup and Restore . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Log File Download from CPE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Firmware Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Passive and Active Notification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Secured Connection Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
privateKey.pem Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Factory Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Device Data Model Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
OUI and Product Class . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Appendix A - Sample Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Appendix B - XML Data Model Schema . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Appendix C - Standard Supported TR-069 Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Mitel 6800i Series SIP Phones Release 4.0.0 SP1 TR-069 Configuration Guide
1
WELCOME
This document provides information about Technical Report (TR)-069 protocol support for the
6800i Series (6863i, 6865i, 6867i, and 6869i) SIP IP Phones.
TR-069 PROTOCOL SUPPORT
The IP Phones support the TR-069 protocol. This protocol is a bi-directional HTTP-based
protocol that provides a means of communication between Customer-Premises Equipment
(CPE) (e.g. IP phones) and Auto Configuration Servers (ACSs) over DSL/broadband
connections.Itincludesbothsafeautoconfiguration andthecontrolofotherCPEmanagement
functions within an integrated framework.
Service providers can, through TR-069, use one common platform to manage (through the
internet) all of their customer premise devices, regardless of the device or manufacturer. If
TR-069 is enabled on the phones, when the remote ACS boots the phones, they contact the
ACS and establish the configuration automatically.
In addition to configuring the phone with TR-069, you can also do the following:
• Reboot the phone
• Reset to factory defaults
• Update the firmware of the device
• Backup/restore configuration
• Upload the log file
An Administrator can configure the TR-069 parameters using the configuration files only. For
more information about the TR-069 parameters, see “TR-069 Parameter Descriptions” on
page 3.
PRE-STAGING SIP PHONES
There are two options available to enable TR-069 support for the phones:
a. An Administrator can provide a configuration file (that can be taken from theTFTP site
or during RCS provisioning) with parameters that are specified in “TR-069 Parameter
Descriptions” on page 3.
b. The phones can be branded and the branded default configuration file can contain all
the necessary parameters.
After phones (with correct firmware) receive this configuration file, they will start a bootstrap
procedure and connect to the ACS server.
Note: Implementation of the TR-069 protocol follows TR-104 and TR-106 standards to
the extent of data sets applicable to SIP IP phones.

TR-069 Protocol Support
2
TR-069 FUNCTIONALITY SUPPORT
XML-RemoteProcedureCall(RPC)isaprotocolwhichusesXML toencodeitscallsandHTTP
as a transport mechanism to make requests to Internet-based servers. The following table
identifies the XML-RPC methods supported for the TR-069 functionality on the phones in
Release 4.0.0 SP1.
LIMITATIONS
The following is a list of limitations with TR-069:
• TR-111 Part 1 is not supported (only Part 2 - STUN)
• The current release does not have support for the following RPC function calls:
•AddObject
• DeleteObject
• GetQueuedTransfers
• GetAllQueuedTransfers
• ScheduleInform
XML-RPC METHOD CPE
REQUIREMENT SUPPORTED IN THIS RELEASE 4.0.0 SP1
GetRPCMethods Required Yes
SetParameterValues Required Limited to parameters specified in “TR-069
Parameter Descriptions” on page 3.
Note: Users are limited to parameters that are
specified by Mitel. Please contact Mitel for a list of
these parameters.
GetParameterValues Required Limited to parameters specified in “TR-069
Parameter Descriptions” on page 3.
GetParameterNames Required Yes
SetParameterAttributes Required Yes
GetParameterAttributes Required Yes
AddObject Required No
DeleteObject Required No
Reboot Required Yes
Download Required Yes
Upload Optional Yes
FactoryReset Optional Yes
GetQueuedTransfers Optional No
GetAllQueuedTransfers Optional No
ScheduleInform Optional No
SetVouchers Optional No
GetOptions Optional No

Mitel 6800i Series SIP Phones Release 4.0.0 SP1 TR-069 Configuration Guide
3
• SetVouchers
• GetOptions
• Inform Retry Policy with increasing intervals is not supported (only constant intervals are
supported)
• Active Notification is supported only for limited list of parameters
• A subset of Mitel configuration parameters are supported through TR-069
• Only a TR-069 active session is supported (single IP address)
• CPE Identification is made based on OUI + Product Class + MAC (not serial number)
• Each Voice Profile has only 1 line
• VoiceService.X_Aastra_GlobalVoiceProfile corresponds to Mitel Sip Global Settings and
has only 1 line object
• VoiceService.1.VoiceProfile.{1} corresponds to Mitel SIP settings per line i and has only 1
line object
• Constant number of lines mapped to the number of Voice Profile (profile remove is not
supported)
BEHAVIORS
The following is a list of behaviors with TR-069:
• WebandphoneUIarestillavailableforconfigurationandcanoverride whatwasconfigured
through TR-069
• The phones will notify ACS though the Active notification process for a limited subset of
parameters (as defined)
• Loading of new configuration through TR-069 will require a CPE reboot
TR-069 PARAMETER DESCRIPTIONS
An Administrator can enable/disable and configure the TR-069 protocol using the following
parameters in the configuration files:
•tr69
• tr69 server
• tr69 server port
• tr69 server path
• tr69 username
•tr69password
• tr69 connection request path
• tr69 connection request port

TR-069 Protocol Support
4
Each of these parameters are described as follows:
PARAMETER –
tr69 CONFIGURATION FILES startup.cfg, mac.cfg
DESCRIPTION Enables/disables TR-069 communciation.
FORMAT Boolean
DEFAULT VALUE 0
RANGE 0-1
0 (disabled)
1 (enabled)
EXAMPLE tr69: 1
PARAMETER –
tr69 server CONFIGURATION FILES startup.cfg, mac.cfg
DESCRIPTION Specifies the IP or domain name of the TR-069
Auto-Configuration Server (ACS). This is the server to
which the phone sends TR-069 messages.
Contact your System Administrator for the applicable
server to specify for this parameter.
FORMAT String
DEFAULT VALUE Empty
RANGE Not Applicable
EXAMPLE tr69 server: http://10.30.105.127
PARAMETER –
tr69 server port CONFIGURATION FILES startup.cfg, mac.cfg
DESCRIPTION Specifies the server port of the TR-069 Auto-Configuration
Server (ACS). This is the server to which the phone sends
TR-069 messages.
Contact your System Administrator for the applicable port
to specify for this parameter.
FORMAT String
DEFAULT VALUE Empty
RANGE Not Applicable
EXAMPLE tr69 server port:10301

Mitel 6800i Series SIP Phones Release 4.0.0 SP1 TR-069 Configuration Guide
5
PARAMETER –
tr69 server path CONFIGURATION FILES startup.cfg, mac.cfg
DESCRIPTION Specifies the server path of the TR-069 Auto-Configuration
Server (ACS). This is the path to which the phone sends
TR-069 messages.
Contact your System Administrator for the applicable path
to specify for this parameter.
FORMAT String
DEFAULT VALUE Empty
RANGE Not Applicable
EXAMPLE tr69 server path: acs/
PARAMETER –
tr69 username CONFIGURATION FILES startup.cfg, mac.cfg
DESCRIPTION Username for HTTP authentication against the ACS
FORMAT String
DEFAULT VALUE Empty
RANGE Not Applicable
EXAMPLE tr69 username: Joe
PARAMETER –
tr69 password CONFIGURATION FILES startup.cfg, mac.cfg
DESCRIPTION Password for HTTP authentication against the ACS
FORMAT String
DEFAULT VALUE Empty
RANGE Not Applicable
EXAMPLE tr69 password: 12345
PARAMETER –
tr69 connection request
path
CONFIGURATION FILES
startup.cfg, mac.cfg
DESCRIPTION Path for tr69 connection url
FORMAT String
DEFAULT VALUE tr69
RANGE Not Applicable
EXAMPLE tr69 connection request path: mitel

TR-069 Protocol Support
6
Thefollowingsubsectionsprovideadditionalinformationandparametersthatarerequirements
for the TR-069.
SUPPORTFORGETTINGCAPABILITIES,GENERALPROFILES, AND
OTHER STATIC PARAMETERS
When the phone boots up for the first time, it will send an Inform message with the event code
BOOTSRAP to the ACS server. The ACS server will ask for the supporting parameters on the
phone. After this initial contact, the ACS server can read or write parameters on the phone.
VOICE PROFILE
There is one global Voice Profile called X_Aastra_GlobalVoiceProfile that corresponds to the
global line on the phone. For example:
Device.VoiceService.X_Aastra_GlobalVoiceProfilecorrespondstoGlobalontheMitelWeb
UI
Depending on the phone model, there are also up to 9 other Voice Profiles that correspond to
a specific line on the phone. They are always located on the VoiceService SubTree, and on
each line a SIP account can be configured. For example:
Device.VoiceService.VoiceProfile.1 corresponds to Line 1 on the Mitel Web UI.
Once a SIP account is fully configured, the line will be registered. Administrators also have the
option to delete the Voice Profile. When a Voice Profile is deleted, the corresponding line is
restored to the default.
HANDLING DYNAMIC PARAMETERS
If the ACS modifies a parameter, the SIP line is automatically configured and will register to the
server.
PARAMETER –
tr69 connection request
port
CONFIGURATION FILES
sstartup.cfg, mac.cfg
DESCRIPTION Port for tr69 connection url
FORMAT Integer
DEFAULT VALUE 7547
RANGE Not Applicable
EXAMPLE tr69 connection request port:12345

Mitel 6800i Series SIP Phones Release 4.0.0 SP1 TR-069 Configuration Guide
7
TR-111
The phones support the TR-111 protocol as a requirement for TR-069. TR-111 applies the
TR-069 to remote manage home networking devices (i.e. it can access a phone that is inside
a private network from a server outside). The TR-111 standard defines two ways of managing
CPE located behind Network Address Translation (NAT) routers. The parameters are
automatically configured for the Administrator.
PERIODIC INFORM SUPPORT
The TR069 stack provides a function that sets up periodic inform support. On the phone, the
periodic inform is done so that the phone can periodically send an inform message to the ACS
server. For example, for passive notification, the phone will inform the ACS server that one or
more parameters is/are modified and will send the new value in the inform message.
CONFIGURING PERIODIC INFORM USING THE CONFIGURATION FILES
PARAMETER –
tr69 periodic inform enable CONFIGURATION FILES startup.cfg, mac.cfg
DESCRIPTION Enable or disable the periodic inform functionality.
FORMAT Boolean
DEFAULT VALUE Empty
RANGE 0 - 1
0 (Disable)
1 (Enable)
EXAMPLE tr69 periodic inform enable: true
PARAMETER –
tr69 periodic inform
interval
CONFIGURATION FILES
startup.cfg, mac.cfg
DESCRIPTION The duration in seconds of the interval for which the CPE
must attempt to connect with the ACS and call the inform
method.
FORMAT Integer
DEFAULT VALUE Empty
RANGE Not Applicable
EXAMPLE tr69 periodic inform interval: 600

TR-069 Protocol Support
8
INFORM UPON RECEIPT OF SIP NOTIFY CHECK-SYNC SUPPORT
ConfigurationparametersareavailableallowingAdminstratorstheabilitytospecifythebehavior
of the phones when they receive a SIP NOTIFY containing a check-sync event. In such
scenarios, the phones can be configured to behave in one of the following ways:
• Check the configuration files and reboot if changes are detected.
• Redirect the SIP NOTIFY with the check-sync event to the ACS to perform a TR-069
request.
• RedirecttheSIPNOTIFYwiththecheck-synceventtotheACStoperformaTR-069request
and trigger an HTTP GET to a defined Action URI (allowing some settings to be changed
via XML that cannot be changed through TR-069). A Job ID can be specified as well,
allowing the ACS to link the HTTP GET to the initiated TR-069 request.
PARAMETER –
tr69 periodic inform time CONFIGURATION FILES startup.cfg, mac.cfg
DESCRIPTION An absolute time reference in UTC to determine when the
CPE will initiate the periodic inform method calls.
FORMAT String
DEFAULT VALUE 1970-01-01T00:00:00
RANGE The STRING is specified in the following form:
“YYYY-MM-DDThh:mm:ss” where:
• YYYY (year)
• MM (month)
•DD(day)
• T (start of the required time section)
• hh (hour)
• mm (minute)
• ss (second)
EXAMPLE tr69 periodic inform time: 0001-01-01T00:00:00

Mitel 6800i Series SIP Phones Release 4.0.0 SP1 TR-069 Configuration Guide
9
CONFIGURING THE INFORM UPON RECEIPT OF SIP NOTIFY
CHECK-SYNC FEATURE USING THE CONFIGURATION FILES
CONFIGURATION BACKUP AND RESTORE
Administrators can backup andrestore the TR-069 configuration on the ACS server. The ACS
server makes a request for a configuration file upload and the phone responds to the request.
For a configuration file upload, the server sends the following parameters:
• URL
• File type
• Username
• Password
PARAMETER –
tr69 check sync CONFIGURATION FILES startup.cfg, mac.cfg
DESCRIPTION Specifies the behavior of the phone when it receives a SIP
NOTIFY containing a check-sync event.
FORMAT Integer
DEFAULT VALUE 0
RANGE 0 (When a SIP NOTIFY containing a check-sync event is
received the phone will check the configuration files and
reboot if changes are detected).
1 (When a SIP NOTIFY containing a check-sync event is
received the phone will redirect the SIP NOTIFY with the
check-sync event to the ACS to perform a TR-069 request.
2 (When a SIP NOTIFY containing a check-sync event is
received the phone will redirect the SIP NOTIFY with the
check-sync event to the ACS to perform a TR-069 request
and trigger an HTTP GET to the URI configured via the
“action uri tr69 check sync” parameter.
EXAMPLE tr69 check sync: 2
PARAMETER –
action uri tr69 check sync CONFIGURATION FILES startup.cfg, mac.cfg
DESCRIPTION Specifies the URI to be called when the “tr69 check sync”
parameter is defined as “2”. A Job ID can be specified
allowing the ACS to link the HTTP GET to the initiated
TR-069 request.
FORMAT HTTP(s) server path or Fully Qualified Domain Name
DEFAULT VALUE Not Applicable
RANGE Not Applicable
EXAMPLE action uri tr69 check sync:
https://acs.example.com/test.php?JobID=$$JOBID$$

TR-069 Protocol Support
10
When the phone receives the request to backup, it uploads the local.cfg or server.cfg file to the
server depending on the FileType argument defined (i.e. “1 Vendor Configuration File” =
local.cfg, “X_Aastra Server Configuration File” = server.cfg). The protocol supported for
configuration file upload from the CPE are HTTP, TFTP, and FTP.
LOG FILE DOWNLOAD FROM CPE
TheACS server can make a request for a logfileupload.For alogfileupload,theserversends
the following parameters:
• URL
• File type
• Username
• Password
When the phone receives this request, it will send the file to the server with the name
“MACADDRESS_TIME_crash.log”. The protocol supported for log file upload from CPE are
HTTP, TFTP, and FTP.
FIRMWARE MANAGEMENT
At any point, the ACS can trigger the CPE to upgrade its firmware image. The ACS sends
asynchronous connection requests, triggering the CPE to establish a transaction session to
receive a download method to upgrade its firmware. The ACS is only responsible for sending
the download RPC and retrieving the TransferComplete RPC. The actions taken by the CPE
itself depend on the firmware upgrade mechanism, which is not defined by TR-069.
The Administrator can schedule a firmware upgrade from the ACS by properly configuring the
ACS server. Once the ACS server is configured, the phone will automatically upgrade the
firmware.
The following is the process of how the phone upgrades the firmware:
• The phone receives a download RPC from the ACS.
• IftheFileTypeargumentissetto“1FirmwareUpgradeImage”,afirmwareupgradeisstarted
• The phone checks the version of firmware:
• Iftheversionisidenticaltotheactualversion,thephonewillabortthefirmwareupgrade
• If the version is different of the actual version, the phone will upgrade/downgrade the
firmware
• If the firmware upgrade is successful, a reboot is initiated

Mitel 6800i Series SIP Phones Release 4.0.0 SP1 TR-069 Configuration Guide
11
PASSIVE AND ACTIVE NOTIFICATION
The phones support active and passive notification. If a parameter is configured to "Active
notification", when this parameter is modified through the Mitel Web UI, an inform message
withthenewvalueoftheparameteris sent to the ACS (thephone does not wait for the periodic
inform).
If a parameter is configured to "Passive notification", when this parameter is modified through
the Mitel Web UI, the new value of the parameter is sent to the ACS with the periodic inform.
If there is no notification set, no inform message is sent to inform the ACS when the value of
the parameter is modified.
For any parameter, the notification type (Active, Passive, or None) is set on the ACS server.
Active and Passive notification is currently supported for the following parameters:
• Global parameters:
• sip user name
• sip proxy ip
• sip proxy port
• sip registrar ip
• sip registrar port
• sip auth name
• sip password
• sip stun ip
•sipstunport
•dhcp
•ip
• Parameters for Line 0 to 9 (where N is the line number):
• sip lineN user name
• sip lineN proxy ip
• sip lineN proxy port
• sip lineN registrar ip
• sip lineN registrar port
• sip lineN auth name
• sip lineN password

TR-069 Protocol Support
12
SECURED CONNECTION SUPPORT
The following parameters are available allowing Administrators the ability configure a secure
connection between the CPE and ACS:
• tr69 trusted certificates
• tr69 private key
• tr69 server authentication required
Each of these parameters are described as follows:
PARAMETER –
tr69 trusted certificates CONFIGURATION FILES startup.cfg, mac.cfg
DESCRIPTION Specifies a file name for a .PEM file located on the
configuration server. This file contains the User-provided
certificates in PEM format. These certificates are used to
validate peer certificates.
Note: The parameter “tr69server authentication required”
must be enabled in order for the phone to do a
Client-authenticated TLS handshake.
FORMAT Alphanumeric String
DEFAULT VALUE Empty
RANGE Not Applicable
EXAMPLE tr69 trusted certificates:
ftp://admin:[email protected].3.4:50/path/tr69CA.pem
Note:Intheaboveexample,“path”representsthedirectory
and “tr69CA.pem” represents the filename.
PARAMETER –
tr69 private key CONFIGURATION FILES startup.cfg, mac.cfg
DESCRIPTION Specifies the file to download. This file contains the private
key and the associated certificate.
Note: Refer to “privateKey.pem Example” on page 13 for
an example of what is contained in the privateKey.pem file.
FORMAT Alphanumeric String
DEFAULT VALUE Empty
RANGE Not Applicable
EXAMPLE tr69 private key:
ftp://admin:[email protected].4:50/path/privateKey.pem

Mitel 6800i Series SIP Phones Release 4.0.0 SP1 TR-069 Configuration Guide
13
PRIVATEKEY.PEM EXAMPLE
The following is an example of the contents of a privateKey.pem file:
-----BEGIN CERTIFICATE-----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-----END CERTIFICATE-----
-----BEGIN RSA PRIVATE KEY-----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-----END RSA PRIVATE KEY-----
PARAMETER –
tr69 server authentication
required
CONFIGURATION FILES
startup.cfg, mac.cfg
DESCRIPTION If this parameter is set to 0, Simple TLS handshake will be
enabled. If this parameter is set to 1, Client-authenticated
TLS handshake will be enabled..
FORMAT Boolean
DEFAULT VALUE 0
RANGE 0 - 1
0 (Simple TLS handshake)
1 (Client-authenticated TLS handshake)
EXAMPLE tr69 server authentication required: 1

TR-069 Protocol Support
14
FACTORY RESET
The purpose of a factory reset is to restore the configuration to default when it is requested by
the ACS server. From the ACS server, make a “factory reset” request. This will set all the
parameters to the default value.
DEVICE DATA MODEL SUPPORT
For this release, the phones support only the configuration parameters listed in the section,
“TR-069 Functionality Support” on page 2, for remote management through the TR-069
Protocol. Some ACSs (e.g. a specific home management device) requires a vendor-specific
device data model in XML format before the IP phones can connect to it. See “Appendix B -
XML Data Model Schema” for an example of an XML data model schema.
As defined in this data structure, some parameters have write privileges and can be changed
remotely(e.g.DNSServer).However,youmayhavetorebootthephoneinorderforthechange
to take effect.
OUI AND PRODUCT CLASS
The above data structure is common across all the TR-069 supported Mitel SIP phones. The
tablebelowsummarizesthesupportedphonesandtheircorrespondingOUIandProductClass.
Note: A factory reset will result in the phone clearing out all configured parameters,
including the TR-069 configured settings.
SUPPORTED MITEL MODELS OUI PRODUCT CLASS
6863i 00085D 6863i
6865i 00085D 6865i
6867i 00085D 6867i
6869i 00085D 6869i

Mitel 6800i Series SIP Phones Release 4.0.0 SP1 TR-069 Configuration Guide
15
APPENDIX A - SAMPLE CONFIGURATION
The following is an example detailing how the TR-069 parameters can be defined within the
configuration files:
# enable tr69
tr69: 1
#username and password for the ACS
tr69 username: ACS1234
tr69 password: ACS1234
#to modify the path, add the two following parameter
tr69 connection request path: mitel
tr69 connection request port: 12345
#TR-069 ACS URL for secured connection
tr69 server: https://10.10.10.2
tr69 server port: 443
tr69 server path: acs/
#private key, this must contain the private key and the certificate
tr69 private key: http://10.10.10.2/private.key
tr69 trusted certificates: tftp://10.10.10.5/asterisk/ca.crt
tr69 server authentication required: 1

Appendix B - XML Data Model Schema
16
APPENDIX B - XML DATA MODEL SCHEMA
The following is a schema that can be used as a template for a customized XML data model:
<?xml version=”1.0” encoding=”UTF-8” standalone=”yes”?>
<xsi:tr69model xmlns:xsi=”http://www.w3.org/2001/XMLSchema-instance”>
<entry xsi:type=”tr69Object” write=”” mode=”1”>
<name>Device.</name>
<description></description>
<parameter write=”” mode=”1”>
<name>DeviceSummary</name>
<description></description>
</parameter>
<child write=”” mode=”1”>
<name>DeviceInfo.</name>
<description></description>
<parameter write=”” mode=”1”>
<name>HardwareVersion</name>
<description></description>
</parameter>
<parameter write=”” mode=”1”>
<name>Manufacturer</name>
<description></description>
</parameter>
<parameter write=”” mode=”1”>
<name>ManufacturerOUI</name>
<description></description>
</parameter>
<parameter write=”” mode=”1”>
<name>ProductClass</name>
<description></description>
</parameter>
<parameter write=”” mode=”1”>
<name>SerialNumber</name>
<description></description>
</parameter>
<parameter write=”” mode=”1”>
<name>SoftwareVersion</name>
<description></description>
</parameter>
</child>
<child write=”” mode=”1”>
<name>GatewayInfo.</name>
<description></description>
<parameter write=”” mode=”1”>
<name>ManufacturerOUI</name>
<description></description>
</parameter>
<parameter write=”” mode=”1”>
<name>ProductClass</name>
<description></description>
</parameter>
<parameter write=”” mode=”1”>
<name>SerialNumber</name>
<description></description>
</parameter>
</child>

Mitel 6800i Series SIP Phones Release 4.0.0 SP1 TR-069 Configuration Guide
17
<child write=”” mode=”1”>
<name>LAN.</name>
<description></description>
<parameter write=”W” mode=”1”>
<name>AddressingType</name>
<description></description>
</parameter>
<parameter write=”W” mode=”1”>
<name>DNSServers</name>
<description></description>
</parameter>
<parameter write=”W” mode=”1”>
<name>DefaultGateway</name>
<description></description>
</parameter>
<parameter write=”W” mode=”1”>
<name>IPAddress</name>
<description></description>
</parameter>
<parameter write=”” mode=”1”>
<name>MACAddress</name>
<description></description>
</parameter>
<parameter write=”W” mode=”1”>
<name>SubnetMask</name>
<description></description>
</parameter>
<child write=”” mode=”1”>
<name>Stats.</name>
<description></description>
<parameter write=”” mode=”1”>
<name>ConnectionUpTime</name>
<description></description>
</parameter>
<parameter write=”” mode=”1”>
<name>TotalBytesReceived</name>
<description></description>
</parameter>
<parameter write=”” mode=”1”>
<name>TotalBytesSent</name>
<description></description>
</parameter>
<parameter write=”” mode=”1”>
<name>TotalPacketsReceived</name>
<description></description>
</parameter>
<parameter write=”” mode=”1”>
<name>TotalPacketsSent</name>
<description></description>
</parameter>
</child>
</child>
