Motorola solutions IMPRES 2 User manual

IMPRES 2 Adaptive Single
Unit Charger PMPN4523
User Guide
*MN006348A01*
MN006348A01-AB
JANUARY 2021
© 2021 Motorola Solutions, Inc. All rights reserved
en-US fr-CA es-LA pt-BR zh-CN
zh-HK ko-KR de-DE es-ES ru-RU
EU Contact: Motorola Solutions, Czerwone Maki 82, 30-392 Krakow, Poland
uk-UA

Copyrights
The Motorola Solutions products described in this document may include copyrighted Motorola
Solutions computer programs. Laws in the United States and other countries preserve for Motorola
Solutions certain exclusive rights for copyrighted computer programs. Accordingly, any copyrighted
Motorola Solutions computer programs contained in the Motorola Solutions products described in this
document may not be copied or reproduced in any manner without the express written permission of
Motorola Solutions.
© 2021 Motorola Solutions, Inc. All Rights Reserved
No part of this document may be reproduced, transmitted, stored in a retrieval system, or translated
into any language or computer language, in any form or by any means, without the prior written
permission of Motorola Solutions, Inc.
Furthermore, the purchase of Motorola Solutions products shall not be deemed to grant either directly
or by implication, estoppel or otherwise, any license under the copyrights, patents or patent
applications of Motorola Solutions, except for the normal non-exclusive, royalty-free license to use that
arises by operation of law in the sale of a product.
Disclaimer
Please note that certain features, facilities, and capabilities described in this document may not be
applicable to or licensed for use on a specific system, or may be dependent upon the characteristics of
a specific mobile subscriber unit or configuration of certain parameters. Please refer to your Motorola
Solutions contact for further information.
Trademarks
MOTOROLA, MOTO, MOTOROLA SOLUTIONS, and the Stylized M Logo are trademarks or
registered trademarks of Motorola Trademark Holdings, LLC and are used under license. All other
trademarks are the property of their respective owners.
Open Source Content
This product contains Open Source software used under license. Refer to the product installation
media for full Open Source Legal Notices and Attribution content.
European Union (EU) Waste of Electrical and Electronic Equipment (WEEE)
directive
The European Union's WEEE directive requires that products sold into EU countries must have
the crossed out trash bin label on the product (or the package in some cases).
As defined by the WEEE directive, this cross-out trash bin label means that customers and end-users
in EU countries should not dispose of electronic and electrical equipment or accessories in household
waste.
Customers or end-users in EU countries should contact their local equipment supplier representative or
service centre for information about the waste collection system in their country.
MN006348A01-AB
Copyrights
2

Contact Us
The Solutions Support Center (SSC) is the primary contact for technical support included in your
organization's service agreement with Motorola Solutions.
Service agreement customers should be sure to call the SSC in all situations listed under Customer
Responsibilities in their agreement, such as:
• Before reloading software
• To confirm troubleshooting results and analysis before taking action
Your organization received support phone numbers and other contact information appropriate for your
geographic region and service agreement. Use that contact information for the most efficient response.
However, if needed, you can also find general support contact information on the Motorola Solutions
website, by following these steps:
1Enter motorolasolutions.com in your browser.
2Ensure that your organization's country or region is displayed on the page. Clicking or tapping the
name of the region provides a way to change it.
3Select "Support" on the motorolasolutions.com page.
Comments
Send questions and comments regarding user documentation to
[email protected].
Provide the following information when reporting a documentation error:
• The document title and part number
• The page number or title of the section with the error
• A description of the error
Motorola Solutions offers various courses designed to assist in learning about the system. For
information, go to https://learning.motorolasolutions.com to view the current course offerings and
technology paths.
MN006348A01-AB
Contact Us
3

Icon Conventions
The documentation set is designed to give the reader more visual clues. The following graphic icons
are used throughout the documentation set.
DANGER: The signal word DANGER with the associated safety icon implies information that, if
disregarded, will result in death or serious injury.
WARNING: The signal word WARNING with the associated safety icon implies information that,
if disregarded, could result in death or serious injury, or serious product damage.
CAUTION: The signal word CAUTION with the associated safety icon implies information that,
if disregarded, may result in minor or moderate injury, or serious product damage.
CAUTION: The signal word CAUTION may be used without the safety icon to state potential
damage or injury that is not related to the product.
IMPORTANT: IMPORTANT statements contain information that is crucial to the discussion at
hand, but is not CAUTION or WARNING. There is no warning level associated with the
IMPORTANT statement.
NOTICE: NOTICE contains information more important than the surrounding text, such as
exceptions or preconditions. They also refer the reader elsewhere for additional information,
remind the reader how to complete an action (when it is not part of the current procedure, for
instance), or tell the reader where something is on the screen. There is no warning level
associated with a notice.
MN006348A01-AB
Icon Conventions
4

Important Safety Instructions
This document contains important safety and operating instructions. Please read these instructions
carefully and save them for future reference.
Before using the battery charger, read all the instructions and cautionary markings on the charger, the
battery, and the radio using the battery.
WARNING:
• To reduce the risk of damage to the power cord, pull the plug rather than the cord when
disconnecting power cord from the AC outlet or the charger.
• To reduce the risk of fire or electric shock, avoid using an extension cord. If an extension cord must
be used, ensure that the cord size is 18 AWG for lengths of up to 6.5 feet (2 m), and 16 AWG for
lengths up to 9.8 feet (3 m).
• To reduce the risk of fire, electric shock, or injury, do not operate the charger if it is broken or
damaged in any way. Take it to a qualified Motorola Solutions service representative.
• To reduce the risk of fire or electric shock, do not disassemble the charger. It is not repairable and
replacement parts are not available.
• To reduce the risk of electric shock, unplug the charger power adapter from the AC outlet before
attempting any maintenance or cleaning.
• To reduce the risk of injury, charge only the rechargeable authorized batteries. Other batteries may
explode, causing personal injury and damage.
• To reduce the risk of fire, electric shock, or injury, only use the accessories recommended by
Motorola Solutions.
• Changes or modifications made to this device, not expressly approved by Motorola Solutions, could
void the authority of the user to operate this equipment.
MN006348A01-AB
Important Safety Instructions
5

Class B Digital Device
NOTICE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
MN006348A01-AB
Class B Digital Device
6

Operating Guidelines
The followings are the operating guidelines for the charger.
• This equipment is not suitable for outdoor use. Use only in dry locations and conditions.
• Maximum ambient temperature around the charger must not exceed 40 °C (104 °F).
• Recommended to turn off the radio while charging, unless the radio is transmitting data wirelessly
(through Wi-Fi).
• Connect the charger to an AC outlet using only a Motorola Solutions Authorized Power Supply. See
Motorola Solutions Authorized Power Supplies on page 12.
• The AC outlet to which the power supply is connected must be nearby and easily accessible.
• Ensure that the power supply cord connected to the charger is not easily stepped on, tripped over,
or subjected to water, damage, or stress.
• Connect the power supply only to an appropriately fused and wired AC outlet with the correct
voltage, as specified on the product.
• Disconnect from the line voltage by removing the power supply from the AC outlet.
• Connect not more than the appropriate number of charger power supplies to a 15A and 20A circuit,
as limited by any certified power strip used.
• The equipment shall be connected to a nearby and easily accessible socket outlet.
MN006348A01-AB
Operating Guidelines
7

Chapter 1
IMPRES Batteries and Chargers
The IMPRES™ 2 energy solution is an advanced energy system developed by Motorola Solutions. The
system includes:
• IMPRES battery
• IMPRES adaptive charger
• IMPRES radio
Features and Benefits
Charging IMPRES/IMPRES 2 batteries using an IMPRES 2 Adaptive Charger, which periodically
calibrates and reconditions the battery, yields the following benefits:
• Maximize battery life by significantly reducing heat during the trickle and post-charge cycles.
• Determines the current battery status, giving the radio user an indication of effective use time.
• Provide higher-rate IMPRES/IMPRES 2 Lithium-Ion battery charging.
• Automatically performs calibration and reconditioning when needed.
• Minimizes IMPRES/IMPRES 2 battery heating, regardless of how long the battery is left in the
charger pocket.
• Periodically charges a battery stored in the charger, maintaining a high state of readiness for the
user.
• Eliminates Nickel battery memory effect, eliminating the need to purchase special equipment or
train personnel in tasks to maintain battery life cycle.
Using this unique patented system, there is no requirement to track and record IMPRES 2 battery,
conduct manual calibration and reconditioning, or remove batteries from chargers after charging
completion.
1.1
Charging Radios and Batteries
The IMPRES Adaptive Charger System is a fully automated system. The charger pockets
accommodate either a radio with an attached IMPRES or an IMPRES battery alone. Batteries charge
best at room temperature.
Prerequisites:Note that the radio can only be turned on when the radio is transmitting data wirelessly.
Otherwise, turn off the radio.
Procedure:
1Plug the charger end of the power supply cord into the DC inlet (1) at the back of the charger.
MN006348A01-AB
Chapter 1: IMPRES Batteries and Chargers
8

1
2Plug the wall power adapter into the appropriate Alternating Current (AC) outlet.
A successful power-up sequence is indicated by a single green blink on the charger indicator.
Refer to the IMPRES Battery Charging Indicators on page 9.
3Insert an IMPRES battery, or a radio with an IMPRES battery into the charger pocket.
aAlign the battery contacts with the charger contacts.
bPress the battery into the pocket, ensuring complete contact.
Once the IMPRES battery is properly seated into the pocket, the charger indicator illuminates,
indicating the charger has recognized the presence of the battery.
4To remove a radio or IMPRES battery from the charger, pull straight up until the battery
completely clears the charger housing.
1.2
IMPRES Battery Charging Indicators
Table 1: IMPRES Battery Charging Indicators
Status LED Status Comments
Charger Power On Green for approx. 1
sec
Successful charger
power-up.
Rapid Charging Steady red Battery in rapid
charge mode.
Charged to 90 % or
more
Flashing green Battery is charged to
90 % or greater ca-
pacity.
Charged to 95 % or
more
Steady green Battery is charged to
95 % or greater ca-
pacity.
Calibration Steady amber Battery is in recondi-
tion or calibration
mode.
Fault Flashing red Not chargeable; re-
move and re-insert ra-
dio or battery.
MN006348A01-AB
Chapter 1: IMPRES Batteries and Chargers
9

Status LED Status Comments
Standby Flashing amber • Battery is waiting
to rapid charge.
• Battery may be too
hot, too cold, or
low voltage.
• Charger may be
too hot.
End of Service Life Alternating red and
green
Battery remains usa-
ble but may be near-
ing the end of its rated
service life.
Recalibration Alternating amber and
green
Calibrate the battery.
1.3
IMPRES Battery Initialization
For a full IMPRES functionality, a new IMPRES battery must be initialized by the charger.
The charger automatically detects the new IMPRES battery, and automatically starts initialization.
Initialization is the first calibration and reconditioning of an IMPRES battery.
Phases of Battery Initialization
The first phase is a battery discharge, indicated by a steady amber LED. The second phase is a full
charge, indicated by a steady green LED. Refer to IMPRES Battery Charging Indicators on page 9.
NOTICE: This process may take up to 12 hours or more to complete, depending on the state of
charge and capacity of the battery. Interruption of either phase delays initialization until the next
charging opportunity.
1.4
IMPRES Pocket-to-Pocket
When charging IMPRES batteries, the IMPRES charger records charging information in the battery
memory.
Charging can resume if the user remove IMPRES battery from one IMPRES charger pocket and within
30 minutes, insert it into the same or a different IMPRES charger pocket.
1.5
Automatic IMPRES Calibration and Recondition
The IMPRES charger automatically assesses the condition of an IMPRES battery.
Based on the condition, the charger automatically calibrates and reconditions the battery. Interruption
of either the discharge phase or the full charge phase delays calibration until the next charging
opportunity.
NOTICE: The IMPRES battery must be outside from the IMPRES charger pocket for more than
30 minutes for an automatic calibration and recondition.
MN006348A01-AB
Chapter 1: IMPRES Batteries and Chargers
10
