Multi-Unit Charger
User Guide
NNTN6899, NNTN6900, NNTN6901, NNTN6902, NNTN6903, NNTN6904,
NNTN6907, NNTN6908, NNTN6910, NNTN6911, NNTN6912, NNTN6913,
NNTN6914, NNTN6915, NNTN6916, NNTN6918, NNTN6919, NNTN6920,
NNTN7724, NNTN7725, NNTN7726, NNTN7727, NNTN7730, NNTN7731,
NNTN7732, NNTN7733, NNTN7680, NNTN7681, NNTN7679, NNTN7723,
NNTN7736, NNTN7935, NNTN7939, NNTN8144, NNTN8145, NNTN8146,
NNTN8147, NNTN8148, NNTN8149, NNTN8150, NNTN8151, NNTN8152,
NNTN8153, NNTN8155, NNTN8156, NNTN8157
fr-CA
en-US zh-CN zh-TW ko-KR de-DE
es-ES it-IT nl-NL pt-PT ru-RU
sv-SE

1
English
IMPORTANT
SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
This document contains important safety and
operating instructions. Please read these instructions
carefully and save them for future reference.
Before using the battery charger, read all the instructions and
cautionary markings on (1) the charger, (2) the battery, and (3)
on the radio using the battery.
WARNINGS
2. Use of accessories not recommended by Motorola
Solutions may result in risk of fire, electric shock, or
injury.
3. To reduce risk of damage to the electric plug and cord,
pull by the plug rather than the cord when
disconnecting the charger.
4. An extension cord should not be used unless absolute
necessary. Use of an improper extension cord could
result in risk of fire and electric shock. If an extension
cord must be used, make sure that the cord size is
18 AWG for lengths up to 100 feet (30.48 m), and
16 AWG for lengths up to 150 feet (45.72 m).
5. To reduce risk of fire, electric shock, or injury, do not
operate the charger if it has been broken or damaged
in any way. Take it to a qualified Motorola Solutions
service representative.
!
W A R N I N G
!
1. To reduce risk of injury, charge only the
rechargeable Motorola Solutions
authorized batteries listed in Table 1.
Other batteries may explode, causing
personal injury and damage.
English

2
English
OPERATION SAFETY GUIDELINES
• Turn radio off when charging battery.
• This equipment is not suitable for outdoor use. Use only
in dry locations/conditions.
• Connect equipment only to an appropriately fused and
wired supply of the correct voltage (as specified on the
product).
• Disconnect from line voltage by removing mains plug.
• The socket outlet to which this equipment is connected
should be close by and easily accessible.
• In equipment using fuses, replacements must comply
with the type and rating of the original equipment.
• Maximum ambient temperature around the power supply
equipment must not exceed 40 °C (104 °F).
• Make sure the cord is located where it will not be
stepped on, tripped over, or subjected to water, damage,
or stress.
7. To reduce risk of electric shock, unplug the charger
from the AC outlet before attempting any maintenance
or cleaning
WARNINGS (CONTINUED)
!
W A R N I N G
!
6. Do not disassemble the charger. It is
not repairable and replacement parts
are not available. Disassembly of the
charger may result in risk of electrical
shock or fire.

3
English
MOTOROLA SOLUTIONS AUTHORIZED RADIOS
AND BATTERIES
The Multi-Unit Charger is compatible with both the standard
and high capacity battery. The radios and batteries listed in
Table 1 are approved for use with the Multi-Unit Charger.
Table 1. Authorized Radios and Batteries
Part
Number Description Charging Pocket
MTP850–All
Models TETRA Hand Portable Terminal NNTN6845* NNTN6848*
MTH800–All
Models
TETRA Hand Portable
Terminal
NNTN7006*
NNTN7010*
FTN6573 Lithium Ion Battery for MTP850
– Standard (950 mAh)
NNTN6846*
FTN6574 Lithium Ion Battery for MTP850
– High Capacity (1850 mAh) NNTN6846*
SNN5705
NNTN6922
Lithium Ion Battery for MTH800
– Standard (800 mAh)
NNTN7007*
PMNN4351 Lithium Ion Battery for MTP850
–Standard CE (1840 mAh)
NNTN6846*
NNTN4655
NNTN6923 Lithium Ion Battery for MTH800 – High Capacity (1500 mAh) NNTN7007*
PMNN4084 Lithium Ion Battery for
TCR1000 Extended Battery –
Standard (1800 mAh)
NNTN7648*

4
English
SNN5784 Lithium Ion Battery for
TCR1000 – Standard
(880 mAh)
NNTN7648*
MTP3100
MTP3200
MTP3250
MTP6550
MTP8750
MTP8850
TETRA Hand Portable
Terminal NNTN8144 NNTN8145
NNTN8146
NNTN8147
NNTN8148
NNTN8149
NNTN8150
MXP600 PMNN4801 Lithium Ion Battery
IMPRES 2 IP68 1900T
PMNN4802 Lithium Ion Battery
IMPRES 2 IP68 3400T
PMNN4582 Lithium Ion Battery
IMPRES 2 IP68 2900T
NNTN8144
NNTN8145
NNTN8146
NNTN8147
NNTN8148
NNTN8149
NNTN8150
NNTN8020 Lithium Ion Battery For –
Standard (1650 mAh) NNTN8151 NNTN8152
NNTN8153
NNTN8155
NNTN8156
NNTN8157
Table 1. Authorized Radios and Batteries (Continued)
Part
Number Description Charging Pocket

5
English
NNTN8023 Lithium Ion Battery For – High
Capacity (2150 mAh)
NNTN8151
NNTN8152
NNTN8153
NNTN8155
NNTN8156
NNTN8157
PMNN4522 IMPRES 2 Lithium Ion Battery
For – High Capacity (3400
mAh)
NNTN8151
NNTN8152
NNTN8153
NNTN8155
NNTN8157
* This is a class A equipment. In a domestic
environment this product may cause radio
interference in which case the user may be required
to take adequate measures.
Table 1. Authorized Radios and Batteries (Continued)
Part
Number Description Charging Pocket

6
English
Power Sources
Only Motorola Solutions authorized line cords listed in Table 2
should be used with the Multi-Unit Charger.
Table 2. Authorized Line Cords
Line Cord Part
Number Description
3087791G16 Korean Line Cord
3087791G07 UK Line Cord
3087791G04 Euro Line Cord
3087791G10 Australia Line Cord
3087791G13 Argentina Line Cord
3087791G01 US Line Cord
3087791G20 AC Power Cord, JP, 125VAC 7A
CB000460A01 Power Cord, China

7
English
DESCRIPTION
The Multi-Unit Charger comprises of a base unit which
accommodates six charging locations. Each charging location
is fitted with a charging pocket. The kit contains:
• 1 Multi-Unit Charger Base unit
•6Radio pockets or 6 Battery pockets *
• 1 Regional line cord
•1UserGuide
* To mix and match battery and radio charging, individual
charging pockets have to be ordered separately from your
local Motorola Solutions dealer to retrofit the Multi-Unit
Charger. See Table 1 for approved charging pocket part
numbers.
OPERATING INSTRUCTIONS
The Multi-Unit Charger will charge only Motorola Solutions
authorized radios and batteries listed in Table 1. Prior to
operating the charger, check that all radio and battery inserts
are in place and properly latched.
The Multi-Unit Charger can charge up to six radios or
batteries (in any combination) listed in Table 1.
Note: Prior to charging a battery with radio, turn the
radio off.

8
English
Setting Up the Charger:
1. Install the desired combination of radio or battery
pockets securely into the six available locations on the
charger. To install, place the tabs on the bottom of the
pocket into the slots on the charger base and press the
top of the pocket into the latch until a positive click is
heard and felt. Any combination of six pockets may be
selected and installed.
Note: To ensure proper installation, press the latch
down into position to seat the insert into the
MUC base, make sure all six locations have
pockets installed. Attempting to use the charger
with missing pockets will allow foreign objects
to cause the charger to malfunction.
2. Plug the line cord into the rear of the Multi-Unit Charger
and the plug into an appropriate AC outlet. The charger
performs a quick power-up routine during which the
LED indicators of each of the six charger pockets will
flash once to indicate a successful power-up of that
pocket.
Note: The cooling fan begins running when the unit is
plugged in and will remain running while the
unit is powered.

9
English
For Radio Charging:
3. Insert a radio with battery (radio turned off) into the
charger pocket and press down firmly until the
connector on the bottom of the radio is mated to the
connector on the charger. You will feel a slight snap
when connection is made. Once the radio is properly
engaged, the pocket LED illuminates. After 15 seconds,
the LED will indicate that charging has started. To
remove the radio after charging, hold down on the
charger base and lift the radio straight up out of the
pocket. The connector will automatically release.
Note: To ensure the radio is properly charged, make
sure the radio is inserted into the plug by firmly
pushing down the radio into the base.
General Limitations:
• Radio will not start in Charge Mode (no
charging) if the radio is OFF and battery voltage
is above 4.1 V
• Radio will not start in Charge Mode (but trickle
charging will run in the background) if the radio
is OFF and battery voltage is below 3.4 V

10
English
For Battery Only Charging:
4. Insert a battery into the battery pocket by placing the
top of the battery into the pocket and engage the
holding features in the pocket. Press down on the
bottom of the battery to engage the latch. After 15
seconds, the LED will indicate that charging has
started. To remove the battery after charging, hold
down on the charger base and lift the battery up via its
top latch.
LED Indicator Status
When the radios and batteries are properly seated in the
pockets, the charger LED will light to indicate the charging
status as shown below:
Charger Status
(Radio and/or Battery) Indicator
Power On Single Blink Green
Rapid Charging Steady Red
Top-off Charging Blinking Green
Charge Complete Steady Green
Battery Not Chargeable Blinking Red
Waiting to Charge (Either the
battery temperature is too
hot or too cold, or battery
voltage is too low or too high
to allow Rapid Charging)
Blinking Orange

11
English
Optional Equipment
A wall mount bracket (part number: NNTN6844) or charger
base tray (part number: NNTN7560) is available for the
Multi-Unit Charger. Contact your local dealer to order this
item. Installation is shown in the following image.
Mounting Multi-Unit Charger to Wall Bracket
1. Mount bracket to wall using appropriate fasteners in
four locations (fasteners not included in kit).
2. Install two M4x25 screws (included in kit) through
bracket into charger base as shown. Do not over
tighten the screws.
Mounting Multi-Unit Charger to Charger Base
Tray
1. Mounting holes are available at the back of Charger
Base Tray for direct mounting to wall surfaces.
2. Position the base tray in the desired position and mount
the base tray to wall using appropriate fasteners in four
locations (fasteners not included in kit).
Attach to wall in four
locations (fasteners not
provided)
M4x25 screw -
two locations
(provided)

12
English
3. Pull out the locking plates at the two sides to align with
the charger’s base screw holes.
4. Assemble two pieces of M4 screws (included in the
package through the locking plates into the charger
base as shown in the picture below. Do not overtighten
the screws.
Mounting holes
Mounting hardware
(Not included)
Wall Mount Bracket
Note: The Charger Base Tray
can also be mounted with the
Wall Mount Bracket
(NNTN6844).
M4 Screw
(Included)
Locking
Plates

13
English
TROUBLESHOOTING
Problem Solution
Charger LED status
does not turn on
when radio or battery
is inserted
1. Verify no foreign objects or debris under
charging pocket or in contacts.
2. Ensure charging pocket is properly
latched into the charger base.
3. Verify radio or battery is properly
inserted into pocket.
LED status changes
unexpectedly or is
inconsistent
1. Charger function and LED status may
appear inconsistent if a radio is
operated in or near the charger.
Discontinue use of the radio. The
charger will automatically resume
proper operation.
Charge time appears
longer than usual 1. Ensure all radios are turned off.
2. Normal charge times for lithium ion
batteries are 3 to 8 hours, depending
on battery capacity.
Radio or battery is
not charged 1. Radio or battery is not seated properly
into pocket. Reinstall and verify charge
status 15 seconds after insertion into
charger.
2. Ensure radio is turned off.

14
English
SERVICE
The Multi-Unit Charger is not user repairable. Chargers that
are not operable should be sent to an authorized Motorola
Solutions Repair Center. Contact your local dealer for
locations. Replacements for damaged chargers should be
ordered from your local dealer as necessary.
The following user replacement items are available for order
from your local dealer.
Table 3. User Replacement Items
Part Number Description
NNTN6845 Charger Radio Pocket for MTP850
NNTN6846 Charger Battery Pocket for MTP850
NNTN6848 Charger Radio Pocket With Remote
Programming USB Port for MTP850
NNTN7006 Charger Radio Pocket for MTH800
NNTN7007 Charger Battery Pocket for MTH800
NNTN7010 Charger Radio Pocket With Remote
Programming USB Port for MTH800
NNTN7648 Charger Battery Pocket for TCR1000
NNTN8036 Charger Radio Pocket with Remote
Programming USB Port for MTP3100,
MTP3200, MTP3250, MTP6550, MTP8750,
and MTP8850
NNTN8037 Charger Battery Pocket for NNTN8020
and NNTN8023
MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M logo are trademarks or
registered trademarks of Motorola Trademark Holdings, LLC and are used under license. All
other trademarks are the property of their respective owners.
© 2006 and 2021 Motorola Solutions, Inc.
All rights reserved.

1
Français
IMPORTANT
NOTICE DE SÉCURITÉ
CONSERVEZ CES INSTRUCTIONS
Ce document contient d’importantes directives
relatives à la sécurité et au fonctionnement de
l’appareil. Veuillez lire attentivement cette notice et la
conserver pour vous y référer ultérieurement.
Avant d’utiliser le chargeur de batterie, lisez toutes les
directives et les marquages d’avertissement sur (1) le
chargeur, (2) la batterie et (3) la radio associée à la batterie.
AVERTISSEMENTS
2. L’utilisation d’accessoires non recommandés par
Motorola Solutions pourrait occasionner des risques
d’incendie, de décharge électrique ou de blessure.
3. Afin de réduire la possibilité d’endommager la fiche et
le cordon d’alimentation, débranchez le chargeur en
tirant sur la fiche et non sur le cordon.
!
W A R N I N G
!
AVERTISSEMENT
1. Afin de réduire les risques de blessure, ne
chargez que les batteries rechargeables
approuvées par Motorola Solutions
apparaissant à la section Tableau 1. Les
batteries non approuvées pourraient
exploser et causer des blessures
corporelles et d’autres dommages.
Français (Canada)

2
Français
5. Pour réduire le risque d’incendie, de décharge
électrique ou de blessure, n’utilisez pas le chargeur s’il
est brisé ou endommagé de quelque manière que ce
soit. Portez-le chez un représentant de service
Motorola Solutions.
6. Ne désassemblez pas le chargeur. Il ne peut pas être
réparé et aucune pièce de rechange n’est disponible.
Le désassemblage du chargeur pourrait occasionner
des risques de décharge électrique ou d’incendie.
7. Pour réduire les risques de décharge électrique,
débranchez le chargeur de la prise c.a. avant de
procéder à une maintenance ou à un nettoyage.
AVERTISSEMENTS (SUITE)
!
W A R N I N G
!
AVERTISSEMENT
4. Il n’est pas recommandé d’utiliser une
rallonge, sauf en cas de nécessité
absolue. L’utilisation d’une rallonge
inappropriée pourrait causer un risque
d’incendie et de décharge électrique.
Si une rallonge doit être utilisée, assurez-
vous que le format du cordon est de
calibre 18 lorsque sa longueur est
de 30,48 m (100 pi) ou moins et de
calibre 16 lorsque sa longueur atteint
jusqu’à 45,72 m (150 pi).

3
Français
DIRECTIVES D’UTILISATION SÉCURITAIRE
• Éteignez la radio lorsque vous chargez la batterie.
• Cet équipement n’est pas conçu pour une utilisation à
l’extérieur. Ne l’utilisez que dans des emplacements
secs et sous des conditions de nature semblable.
• Ne branchez l’équipement qu’à un bloc d’alimentation à
fusible câblé approprié de tension prescrite (telle que
spécifiée sur le produit).
• Débranchez le chargeur de la tension de secteur en
retirant la fiche principale.
• La prise de courant à laquelle cet équipement est
branché doit se trouver à proximité et être facilement
accessible.
• Pour les appareils utilisant des fusibles, les pièces de
rechange devront être conformes aux instructions
fournies dans la documentation.
• La température ambiante maximale autour du bloc
d’alimentation ne doit pas dépasser 40 °C (104 °F).
• Assurez-vous que le cordon est placé à un endroit où il
ne sera pas écrasé ou endommagé, ne gênera pas le
passage, ne sera pas tendu de façon anormale et ne
sera pas exposé à une source d’humidité.

4
Français
RADIOS ET BATTERIES APPROUVÉES PAR
MOTOROLA SOLUTIONS
Le multichargeur est compatible avec les batteries standards
et haute capacité. Les radios et les batteries énumérées dans
le Tableau 1 sont approuvées pour une utilisation avec le
multichargeur.
Tableau 1. Radios et batteries autorisées
Numéro de
pièce Description Logement de charge
MTP850 –
Tous les
modèles
Terminal portatif TETRA NNTN6845*
NNTN6848*
MTH800 –
Tous les
modèles
Terminal portatif TETRA NNTN7006*
NNTN7010*
FTN6573 Batterie au lithium-ion pour
MTP850 – Standard
(950 mAh)
NNTN6846*
FTN6574 Batterie au lithium-ion pour
MTP850 – Haute capacité
(1 850 mAh)
NNTN6846*
SNN5705
NNTN6922 Batterie au lithium-ion pour MTH800 – Standard
(800 mAh)
NNTN7007*
PMNN4351 Batterie au lithium-ion pour
MTP850 – CE standard
(1 840 mAh)
NNTN6846*
