3
English
IMPORTANT
SAFETY INSTRUCTIONS
Save This Instructions
This document contains important safety and operating instructions.
Please read these instructions carefully and save them for future
reference.
Before using the battery charger, read all the instructions and
cautionary markings on (1) the charger, (2) the battery, and (3) the
radio using the battery.
1. To reduce risk of damage to the power supply electric
plugs and cords, pull the plug rather than the cord
when disconnecting from the AC outlet or the charger.
2. An extension cord should not be used unless
absolutely necessary. Use of an improper extension
cord could result in risk of fire and electric shock. If an
extension cord must be used, make sure that the cord size is
18 AWG for lengths of up to 6.5 ft (2.0 m), and 16 AWG for lengths
up to 9.8 ft (3.0 m).
3. To reduce risk of fire, electric shock, or injury, do not operate the
charger if it has been broken or damaged in any way. Take it to a
qualified Motorola Solutions service representative.
4. Do not disassemble the charger. It is not repairable and
replacement parts are not available. Disassembly of the charger
may result in risk of electric shock or fire.
5. To reduce risk of electric shock, unplug the charger power supply
from the AC outlet before attempting any maintenance or
cleaning.
6. To reduce risk of injury, charge only the rechargeable Motorola
Solutions Authorized Batteries listed in Table 3. Other batteries
may explode, causing personal injury and damage.
7. Use of accessories not recommended by Motorola Solutions may
result in risk of fire, electric shock, or injury.
WARNING
English
MN004592A01.book Page 3 Thursday, December 19, 2019 9:55 AM

4
English
Operational Safety Guidelines
• This equipment is not suitable for outdoor use. Use only in dry
locations and conditions.
• Maximum ambient temperature around the charger must not exceed
40 °C (104 °F).
• Turn ON the radio only when the radio is transmitting data wirelessly,
such as using Wi-Fi. Otherwise, turn OFF the radio.
• Connect the charger only to an appropriate power supply as listed in
Table 4.
• Connect the power supply only to an appropriate power cord as
listed in Table 5.
• The AC outlet to which the power supply is connected should be
close and easily accessible.
• Make sure the power supply cord to the charger is located where it
will not be stepped on, tripped over, or subjected to water, damage,
or stress.
• Connect the power cord only to an appropriately fused and wired AC
outlet with the correct voltage, as specified on the product.
• Connect no more than the appropriate number of power supplies and
chargers to a 15 A circuit or 20 A circuit, as limited by any certified
power strip being used.
Note: Daisy chaining power strips is NOT RECOMMENDED. Limit cir-
cuit loading below 80 % of the circuit rating.
• Disconnect from line voltage by removing the power cord from the
AC outlet.
• Multi-Unit Chargers will charge the batteries listed in Table 3, when
used in conjunction with Pockets in Table 2.
MN004592A01.book Page 4 Thursday, December 19, 2019 9:55 AM

5
English
Supported Models
Charger specifications:
Input: 15 V 13.4 A
Battery Pocket
Output: 3.0 V–11.2 V 13.1 W (max) per Pocket
Device Pocket
Output: 4.3 V–5.5 V 7.5 W (max) per Pocket
Table 1: Multi-Unit Charger (MUC)
Kit
Number Description Type Display Charging Pockets
Communication
Module
Ethernet
Module
NNTN8895_
APX and
Si500/Si700
MUC
IMPRES
21-Display
6 APX
Batteries
and 6
Si500/
Si700
Devices/
Batteries
Charger
Reprogramming
and Fleet
Management
N/A
NNTN8910_ Si500/Si700
MUC
12
Devices/
Batteries
NNTN9020_
APX and
Si500/Si700
MUC
6 APX
Batteries
and 6
Si500/
Si700
Devices/
Batteries
N/A
Ethernet
Data
Download
for Si500/
Si700
NNTN9063_ Si500/Si700
MUC
12
Devices/
Batteries
PMPN4095_ ST7000 MUC Standard No 12 Devices
Only Not supported Not supported
PMPN4340_ LEX L11
MUC
IMPRES
21-Display
12
Devices/
Batteries
Charger
Reprogramming
and Fleet
Management
N/A
MN004592A01.book Page 5 Thursday, December 19, 2019 9:55 AM

6
English
Table 2: Multi-Unit Charger Pockets
(compatible with charger(s) in Table 1)
Part Number Description
AS000030A01 ST7000 Charging Pockets, iTM-enabled
AS000062A01 APX Battery Charging Pockets (stand-alone battery or attached to
radio)
AS000063A01 Si500/Si700 Charging Pockets (stand-alone battery or attached to
device)
AS000065A01 Si500/Si700 Charging Pockets with USB Type A Port (stand-alone
battery or attached to device)
AS000109A01 LEX L11 Charging Pockets (stand-alone battery or attached to device)
Table 3: Motorola Solutions Authorized Batteries
Part Number Description Charging Pocket
PMNN4510 Battery IMPRES 2 Lithium-ion 2300 mAh ST7000
PMNN4507 Lithium-ion 1950 mAh
Si500PMNN4508 Lithium-ion 2925 mAh
PMNN4530 IMPRES Lithium-ion 3750 mAh
PMNN4579 IMPRES Lithium-ion IP68 3850T APX
MN004592A01.book Page 6 Thursday, December 19, 2019 9:55 AM

7
English
NNTN7033 IMPRES Lithium-ion FM (HazLoc) IP67
4100 mAh
APX
NNTN7034 IMPRES Lithium-ion IP67 4200 mAh
NNTN7035 IMPRES Nickel Metal Hydride FM (HazLoc)
Ruggedized 2000 mAh
NNTN7036 IMPRES Nickel Metal Hydride FM (HazLoc) IP67
2000 mAh
NNTN7037 IMPRES Nickel Metal Hydride IP67 2100 mAh
NNTN7038 IMPRES Lithium-ion IP67 2900 mAh
NNTN7573 IMPRES Nickel Metal Hydride Ruggedized
2100 mAh
NNTN8092 IMPRES Lithium-ion FM (HazLoc) Ruggedized
2300 mAh
NNTN8182 IMPRES Lithium-ion Ruggedized 2900 mAh
NNTN8921 IMPRES 2 Lithium-ion TIA4950 (HazLoc)
Ruggedized IP67 3700 mAh
NNTN8930 IMPRES 2 Lithium-ion TIA4950 (HazLoc)
Ruggedized IP67 2700 mAh
PMNN4403 IMPRES Lithium-ion IP67 2150 mAh
PMNN4485 IMPRES 2 Lithium-ion Ruggedized IP67
2500 mAh
PMNN4486 IMPRES 2 Lithium-ion Ruggedized IP67
3400 mAh
PMNN4487 IMPRES 2 Lithium-ion Ruggedized IP67
4400 mAh
PMNN4494 IMPRES 2 Lithium-ion Ruggedized IP67
5000 mAh
PMNN4504 IMPRES 2 Lithium-ion DIVISION 2 (HazLoc)
Ruggedized IP67 3400 mAh
PMNN4505 IMPRES 2 Lithium-ion DIVISION 2 (HazLoc)
Ruggedized IP67 4850 mAh
Table 3: Motorola Solutions Authorized Batteries (Cont.)
Part Number Description Charging Pocket
MN004592A01.book Page 7 Thursday, December 19, 2019 9:55 AM

8
English
Charger, Pocket, and Communications Module
The standard Multi-Unit Charger System charges wide variety of
Motorola Solutions battery types. It has pocket that accommodates
either a radio with attached battery or a stand-alone battery.
The IMPRES 2™ Adaptive Charger System is a fully automated
IMPRES 2 battery care system that is equipped with additional
features:
• Adaptive charging to accommodate a wide variety of battery types,
including IMPRES 2, IMPRES™, and other authentic Motorola
Solutions batteries.
PMPN4545 IMPRES 2 Lithium-ion 2500 mAH
LEX L11
PMNN4546 IMPRES 2 Lithium-ion 5000 mAH
PMNN4575 IMPRES 2 Lithium-ion 2500 mAH
PMNN4576 IMPRES 2 Lithium-ion 5000 mAH
Table 4: Motorola Solutions Authorized Power Supply
Part Number Description
PS000212A01 External 201 W Power Supply
Table 5: Motorola Solutions Authorized Power Cords
Part Number Description
3087791G01 Power Cord, UNITED STATES/NORTH AMERICA
3087791G04 Power Cord, EUROPE
3087791G07 Power Cord, UNITED KINGDOM/HONG KONG
3087791G10 Power Cord, AUSTRALIA/NEW ZEALAND
3087791G13 Power Cord, ARGENTINA
3087791G16 Power Cord, KOREA
3087791G20 Power Cord, JAPAN
3087791G22 Power Cord, BRAZIL
CB000199A01 Power Cord, CHINA
CB000805A01 Power Cord, TAIWAN
Table 3: Motorola Solutions Authorized Batteries (Cont.)
Part Number Description Charging Pocket
MN004592A01.book Page 8 Thursday, December 19, 2019 9:55 AM

9
English
• Pocket that accommodates either a stand-alone battery or a radio
with attached battery.
• Red/Amber/Green LED indicating charger pocket status.
• Communications Module
- Programming for charger reprogramming.
- IMPRES battery data upload to an IMPRES Battery Fleet
Management System.
• Keypad Menu
- Charger Setup.
- Battery Analysis.
• Information Display on Pocket #1.
• Energy Efficiency Features
- European Standby Current Limits (European Charger Kit): The
Charger Pockets will automatically turn off when there is no
activity for a period of time, but pressing any Keypad button will
re-power these pockets.
- Compliant with California Energy Commission appliance
standards for small battery charging systems. The Charger
Pockets will automatically sleep, then wake to respond to user
action, or to a service a battery in the pocket.
• Preparation of a stand-alone IMPRES 2 or IMPRES battery for long-
term storage or preparation of a stand-alone Motorola Solutions
Lithium-ion battery for shipment. DO NOT leave batteries in the
charger after preparation for long-term storage or Lithium-ion
shipment is complete.
There are additional advantages when charging an IMPRES 2
Lithium-ion battery with an IMPRES 2 Adaptive Charger:
• Higher-rate IMPRES 2 Lithium-ion battery charging.
• Faster charging.
• Extended life cycle.
Operation of a radio while in the charger is not recommended.
During the charging process, radio operation may result in minimally
reduced radio performance and extended battery charge time.
During Calibration/Reconditioning, the battery is fully discharged
before being fully charged. As a result, the radio may shut down during
the discharge phase.
MN004592A01.book Page 9 Thursday, December 19, 2019 9:55 AM

10
English
Charger Overview
Figure 1: Charger overview.
IMPRES 2 and IMPRES Batteries and Chargers
Features and Benefits
The IMPRES 2 energy solution is an advanced Tri-Chemistry energy
system developed by Motorola Solutions. This system includes:
1. IMPRES 2 and IMPRES Batteries
2. IMPRES 2 Adaptive Charger
3. IMPRES Radios
Charging IMPRES 2 or IMPRES batteries using an IMPRES Adaptive
Charger, with the charger periodically Calibrating/Reconditioning the
battery, yields the following benefits:
• Extends battery life cycle.
1 - 6 Pocket #1 through Pocket #6
7 - 12 Pocket #7 through Pocket #12
13 Menu Selection Keypad
14 Keypad Display
15 LED Status Indicator (one per Pocket)
16 Communications Module
17 DC Inlet Socket
16
17
14 13
123 456
789 101112
15
