NEC NEAX2400 ICS Specification sheet

NDA-24245
ISSUE 2
STOCK # 200890
Hotel Features and Specifications
®
MAY, 2000
NECAmerica,Inc.

LIABILITY DISCLAIMER
The information contained in this document is specific to Dterm Series E only.
Throughout this document, references to “Console” or “Attendant Console”
imply a Hotel Console. Most features described in this manual require a Hotel
Console. However, some features (including A-57, A-73, I-23, P-34, and V-16)
can also be performed using a Business Console.
Minimum firmware may be required. Contact NEC Engineering for additional
information.
NEC America, Inc. reserves the right to change the specifications, functions, or
features, at any time, without notice.
NEC America, Inc. has prepared this document for use by its employees and
customers. The information contained herein is the property of NEC America,
Inc. and shall not be reproduced without prior written approval from NEC
America, Inc.
NEAX and Dterm are registered trademarks of NEC Corporation.
Copyright 1998, 1999, 2000
NEC America, Inc.
Printed in the U.S.A

ISSUE 1 ISSUE 2 ISSUE 3 ISSUE 4
DATE DECEMBER, 1998 DATE MAY, 2000 DATE DATE
ISSUE 5 ISSUE 6 ISSUE 7 ISSUE 8
DATE DATE DATE DATE
NEAX2400 IMX
Hotel Features and Specifications Revision Sheet 1/2
NDA-24245 ISSUE 2
PAGE No. ISSUE No.
12345678
i 1 2
ii 1 2
iii 1 2
iv 1 2
v 1 2
vi 1 2
vii 1 2
viii 1 2
1 1 2
2 1 2
3 1 2
4 1 2
5 1 2
6 1 2
7 1 2
8 1 2
9 1 2
10 1 2
11 1 2
12 1 2
13 1 2
14 1 2
15 1 2
16 1 2
17 1 2
18 1 2
19 1 2
20 1 2
21 1 2
22 1 2
23 1 2
24 1 2
25 1 2
26 1 2
27 1 2
28 1 2
29 1 2
30 1 2
31 1 2
32 1 2
33 1 2
34 1 2
35 1 2
36 1 2
37 1 2
38 1 2
39 1 2
40 1 2
41 1 2
42 1 2
43 1 2
44 1 2
45 1 2
46 1 2
47 1 2
48 1 2
49 1 2
50 1 2
51 1 2
52 1 2
53 1 2
54 1 2
55 1 2
56 1 2
57 1 2
58 1 2
59 1 2
60 1 2
61 1 2
62 1 2
63 1 2
64 1 2
65 1 2
66 1 2
67 1 2
68 1 2
PAGE No. ISSUE No.
12345678

ISSUE 1 ISSUE 2 ISSUE 3 ISSUE 4
DATE DECEMBER, 1998 DATE MAY, 2000 DATE DATE
ISSUE 5 ISSUE 6 ISSUE 7 ISSUE 8
DATE DATE DATE DATE
NEAX2400 IMX
Hotel Features and Specifications Revision Sheet 2/2
NDA-24245 ISSUE 2
69 1 2
70 1 2
71 1 2
72 1 2
73 1 2
74 1 2
75 1 2
76 1 2
77 1 2
78 1 2
79 1 2
80 1 2
81 1 2
82 1 2
83 1 2
84 1 2
85 1 2
86 1 2
87 1 2
88 1 2
89 1 2
90 1 2
91 1 2
92 1 2
93 1 2
94 1 2
95 1 2
96 1 2
97 1 2
98 1 2
99 1 2
100 1 2
101 1 2
102 1 2
103 1 2
104 1 2
105 1 2
106 1 2
PAGE No. ISSUE No.
12345678
107 1 2
108 1 2
109 1 2
110 1 2
111 1 2
112 1 2
113 1 2
114 1 2
115 1 2
116 1 2
117 1 2
118 1 2
119 1 2
120 1 2
121 1 2
122 1 2
123 1 2
124 1 2
125 1 2
126 1 2
127 1 2
128 1 2
129 1 2
130 1 2
131 1 2
132 1 2
133 1 2
134 1 2
135 1 2
136 1 2
137 1 2
138 1 2
139 1 2
140 1 2
141 1 2
142 1 2
143 2
144 2
PAGE No. ISSUE No.
12345678

NDA-24245
ISSUE 2
MAY, 2000
NEAX2400 IMX
Hotel Features and Specifications
Feature List
Page
NEAX2400 IMX Hotel Features and Specifications
NDA-24245, Issue 2 Page i
A-10 Automatic Wake-Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
A-10D Automatic Wake-Up Dterm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
A-15 Announcement Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
A-25 Attendant Console With Hotel Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
A-26 Audit Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
A-48 Automatic Message Waiting Lamp Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
A-57 Alert Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
A-58 Automatic Wake-up – Hotel Attendant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
A-73 Automatic Multiple Attendant Recall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
A-74 Answering Camp-On/Call Hold Calls By Switchhook Flash . . . . . . . . . . . . . . . . . 39
A-75 Automated Guest Station Voice Mail Retrieval . . . . . . . . . . . . . . . . . . . . . . . . . . 41
B-26 Busy Status – Hotel Attendant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
C-19 Calendar Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
C-23 Check-In/Checkout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
C-32 Calling Station Number Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
C-71 Called Number Display – Hotel Attendant Console . . . . . . . . . . . . . . . . . . . . . . . 49
C-72 Connecting Room Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
C-147 Call Information Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
D-11 Do Not Disturb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
D-11D Do Not Disturb - Dterm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
D-15 Day/Night Class of Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
D-23 Direct Page Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
D-24 Direct Paging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
D-25 Direct Service Set/Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
D-26 Direct Station Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
D-88 Directory Assistance Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
D-89 Direct Selection – Outside . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
D-105D Dterm With Hotel Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
D-107 Direct Data Entry – Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
D-150 Double Suite Room . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
D-151 DND/MW Lamp Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
E-21 Emergency Call Monitor – Attendant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
G-1 Guest/Administrative Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
G-4 Group Service Through PMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
G-5 Guest Name Display Through PMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
G-6D Guest Name Display – Dterm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
G-7D Guest Information Display – Dterm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
G-8 Guest Information Display – Hotel Attendant Console . . . . . . . . . . . . . . . . . . . . . 89
G-9 Guest Information Display – PMS Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

NEAX2400 IMX Hotel Features and Specifications
Page ii NDA-24245, Issue 2
Feature List (Continued)
Page
G-11 Guest Room Calling – Hotel Attendant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
G-21 Group Restriction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
G-24 Guest Station - Dterm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
H-8 House Phone/Hot Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
H-22 Feature Transparency Over CCIS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
I-23 Inter-Position Transfer 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
L-27 Language Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
M-6 Message Waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
M-22 Maid Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
M-51 Manual Switching Of C.O. Incoming Call Destination . . . . . . . . . . . . . . . . . . . . . 112
M-68 Maid Status - Answerback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
O-6 Off-hook Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
O-9 Overtime Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
P-8 Printer Control – Hotel Attendant Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
P-27 PMS Interface – BISYNC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
P-29 PMS Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
P-34 Paging Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
R-9 Room Cutoff . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
R-10 Room Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
R-17 Room Numbering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
S-17 Split Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
S-32 Screening (Split Hold) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
S-49 Service Call Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
S-74 Secretarial Service – Guest Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
S-75 Suite Room Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
S-128 2nd Wake-up Call – Same Guest Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
T-13 Toll Terminal Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
T-21 Timing Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
V-16 Voice Mail Service Via Message Center Interface (MCI) . . . . . . . . . . . . . . . . . . . 141
W-2 Wake-up Announcement – Headstart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143

NEAX2400 IMX Hotel Features and Specifications
NDA-24245, Issue 2 Page iii
List of Figures
Figure Page
1 Key Allocations of Desk Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
2 Display Area of Attendant Console and Desk Console . . . . . . . . . . . . . . . . . . . . . . . 49
3 Console Lamps Used for Connecting Suites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
4 Key Pattern on the Attendant Console. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
5 Key Pattern on the Desk Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
6 Example of 16-Button Dterm on a Front Desk Console. . . . . . . . . . . . . . . . . . . . . . . . 71
7 Example of Single/Double Suite Room . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
8 LCD display on Special Administration Station Dterm. . . . . . . . . . . . . . . . . . . . . . . . . 83
9 DSS Key/Station Correspondence and Lamp Indications . . . . . . . . . . . . . . . . . . . . . 92
10 Example of Display for Call Origination —
from Attendant Console and Desk Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
11 Example of Display for Call Origination from Dterm . . . . . . . . . . . . . . . . . . . . . . . . . . 99
12 Call Termination on Attendant Console, Desk Console,
Special Administration Dterm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
13 Example of Service Feature Setting — Attendant Console
and Desk Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
14 Check-In/Checkout Keys Replaced by Secretary
Service Set/Reset (SCS, SCR) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
15 DSS Busy Lamps on Attendant Console and Desk Console . . . . . . . . . . . . . . . . . . . 133

NEAX2400 IMX Hotel Features and Specifications
Page iv NDA-24245, Issue 2
List of Tables
Table Page
1 Special Services Requiring Access Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2 Example of Dial Access Numbering Plan for Administration Station . . . . . . . . . . . . . 6
3 Example of Dial Access Numbering Plan for Guest Station. . . . . . . . . . . . . . . . . . . . 7
4 Standard Service Abbreviations on Dterm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
5 Available Hospitality Service Over CCIS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102

NEAX2400 IMX Hotel Features and Specifications
NDA-24245, Issue 2 Page v
NEAX2400 IMX Hotel Features
LEGEND
X – Available
— – Not Applicable
N – Not Available
→
→→
→– Feature carried over to next software series
Index Feature Description Series 7300 Series 7400
Non-
Network FCCS Non- Network FCCS
A-10 Automatic Wake-Up XX→→
A-10D Automatic Wake-Up Dterm XX→→
A-15 Announcement Service X—→—
A-25 Attendant Console With Hotel Functions XN→N
A-26 Audit Reports XX→→
A-48 Automatic Message Waiting Lamp Off XX→→
A-57 Alert Service XN→N
A-58 Automatic Wake-up – Hotel Attendant XN→→
A-73 Automatic Multiple Attendant Recall XN→N
A-74 Answering Camp-On/Call Hold Calls By Switchhook Flash X—→—
A-75 Automated Guest Station Voice Mail Retrieval X—→—
B-26 Busy Status – Hotel Attendant XX→→
C-19 Calendar Display X—→—
C-23 Check-In/Checkout XX→→
C-32 Calling Station Number Display XX→→
C-71 Called Number Display – Hotel Attendant Console XX→→
C-72 Connecting Room Service XN→N
C-147 Call Information Display XN→N
D-11 Do Not Disturb XX→→
D-11D Do Not Disturb - Dterm
Note: Different from Business. XX→→
D-15 Day/Night Class of Service XN→N
D-23 Direct Page Connection X—→—
D-24 Direct Paging X—→—
D-25 Direct Service Set/Reset XX→→
D-26 Direct Station Selection X—→—
D-88 Directory Assistance Interface XN→N
D-89 Direct Selection – Outside X—→—
D-105D Dterm With Hotel Function XX→→

NEAX2400 IMX Hotel Features and Specifications
Page vi NDA-24245, Issue 2
D-107 Direct Data Entry – Station XN→N
D-150 Double Suite Room XN→N
D-151 DND/MW Lamp Control XX→→
E-21 Emergency Call Monitor – Attendant XN→N
G-1 Guest/Administrative Service XX→→
G-4 Group Service Through PMS XX→→
G-5 Guest Name Display Through PMS XX→→
G-6D Guest Name Display – Dterm XX→→
G-7D Guest Information Display – Dterm NNNN
G-8 Guest Information Display – Hotel Attendant Console XN→N
G-9 Guest Information Display – PMS Terminal XN→N
G-11 Guest Room Calling – Hotel Attendant XX→→
G-21 Group Restriction XN→N
G-24 Guest Station - Dterm XX→→
H-8 House Phone/Hot Line X—→—
H-22 Feature Transparency Over CCIS X—→—
I-23 Inter-Position Transfer 2 XN→N
L-27 Language Service XX→→
M-6 Message Waiting XX→→
M-22 Maid Status XX→→
M-51 Manual Switching Of C.O. Incoming Call Destination XN→N
M-68 Maid Status - Answerback XN→N
O-6 Off-hook Alarm XX→→
O-9 Overtime Call XX→→
P-8 Printer Control – Hotel Attendant Console XX→→
P-27 PMS Interface – BISYNC XX→→
P-29 PMS Interface XX→→
P-34 Paging Console X—→—
R-9 Room Cutoff XX→→
R-10 Room Status XX→→
NEAX2400 IMX Hotel Features (Continued)
LEGEND
X – Available
— – Not Applicable
N – Not Available
→
→→
→– Feature carried over to next software series
Index Feature Description Series 7300 Series 7400
Non-
Network FCCS Non- Network FCCS

NEAX2400 IMX Hotel Features and Specifications
NDA-24245, Issue 2 Page vii
R-17 Room Numbering X—→—
S-17 Split Access XX→→
S-32 Screening (Split Hold) XN→N
S-49 Service Call Routing XX→→
S-74 Secretarial Service – Guest Station XN→N
S-75 Suite Room Service XX→N
S-128 2nd Wake-up Call – Same Guest Station XX→→
T-13 Toll Terminal Access XX→→
T-21 Timing Start XX→→
V-16 Voice Mail Service Via Message Center Interface (MCI) XX→→
W-2 Wake-up Announcement – Headstart XN→N
NEAX2400 IMX Hotel Features (Continued)
LEGEND
X – Available
— – Not Applicable
N – Not Available
→
→→
→– Feature carried over to next software series
Index Feature Description Series 7300 Series 7400
Non-
Network FCCS Non- Network FCCS

NEAX2400 IMX Hotel Features and Specifications
Page viii NDA-24245, Issue 2
This page is for your notes.

NEAX2400 IMX Hotel Features and Specifications
NDA-24245, Issue 2 Page 1
INTRODUCTION
CHAPTER 1 INTRODUCTION
General Description
This manual covers the Office Data Design of the Hotel System, the Numbering Plan and a description of Service
features.
How to Follow the Manual
This manual is organized as follows:
•CHAPTER 2 - NUMBERING PLAN
This chapter explains the numbering plan in the hotel system.
•CHAPTER 3 - DESCRIPTION OF SERVICE FEATURES
This chapter explains how to use the hotel service features.

NEAX2400 IMX Hotel Features and Specifications
Page 2 NDA-24245, Issue 2
This page is for your notes.

NEAX2400 IMX Hotel Features and Specifications
NDA-24245, Issue 2 Page 3
NUMBERING PLAN
CHAPTER 2 NUMBERING PLAN
General Description
Access Codes for various service features are determined according to the Dial Access Numbering Plan. This
chapter explains the Numbering Plan, and commands related to the Numbering Plan in the Hotel System.
Dial Access Numbers
There are three types of Dial Access Numbers:
•Station Access Numbers
•Special Service Access Numbers
•Trunk Access Numbers
This section explains the procedure for determining these Dial Access numbers and precautions.
Basic Knowledge of Dial Access Numbers
a.) A Dial Access Number consists of an Access Level and a Number of Digits as shown below:
b.) For the Hotel System, the service to be performed is determined according to the specific Dial
Access Number.
c.) The Hotel System can have two Numbering Plan Development tables; one is for Administration
stations and the other for Guest stations.
Therefore, the Dial Access Number for Administration stations and the Dial Access Number for
Guest stations can be provided independently.
Examples:
•Dial Access Number for Administration Station
Dial Access Number Access To
“0” Split Access (Operator Call)
“10” Speed Calling – System
“12” Call Hold
“2XXXX” Guest Station (4 or 5 digits) of Main Building
“3XXXX” Guest Station (4 or 5 digits) of Annex
“4XXX” Administration Station (4 digits)
“5XXX” Special Administration (4 digits)
“8X” 2-Digits Trunk
“9” C.O. Trunk
“6” and “7” Vacant Level
A B C D E F
Dial Access Number:
Access Level (0 through 9, *, #)
Number of Digits (maximum 6 digits)

NEAX2400 IMX Hotel Features and Specifications
Page 4 NDA-24245, Issue 2
NUMBERING PLAN
Basic Knowledge of Dial Access Numbers (cont’d)
•Dial Access Number for Guest Station
Note: For the Access Level (1st digit of the Dial Access numbers) different numbers are assigned for Station Access numbers,
Special Service Access numbers, and Trunk Access numbers.
Station Access Numbers
a.) One through six-digit station numbers are supported.
b.) The system can provide Timing Start Service. The Timing Start Service allows single-digit and
multi-digit stations to use the same Access levels.
Examples:
2101: Guest Station Number of No. 1 Room on the 1st floor of the main building.
21001: Guest Station Number of No. 1 Room on the 10th floor of the main building.
3101: Guest Station Number of No. 1 Room on the 1st floor of the annex.
31001: Guest Station Number of No. 1 Room on the 10th floor of the annex.
c.) The same station number cannot be assigned twice within the same system, even if it is assigned
to different tenants or to an Administration Station and a Guest Station.
Special Service Access Numbers
a.) Special Service Access numbers of one through six digits can be assigned for each Access Level.
Usually, one through three digits are used.
b.) The Hotel System can provide the Same Number Access (Split Access) service.
The Same Number Access service can provide both Administration and Guest stations with the
different service feature by the same number.
It can also provide the same or a different service feature by the same number according to Tenant
Class, Route Restriction Class (RSC) and Service Feature Class (SFC) concerned.
Examples:
c.) The Hotel System can provide the Floor Service. The Floor Service is a service function to call
the Room Service station on each floor by the same Access code.
Dial Access Number Access To
“0” Split Access (Special Administration Station (STN 5000) Call
“13” Automatic Wake Up; Set
“14” Automatic Wake Up; Cancel
“2XXXX” Guest Station (4 or 5 digits) of Main Building
“3XXXX” Guest Station (4 or 5 digits) of Annex
“7” Floor Service
“9” C.O. Trunk
“4”, “5”, “6”, and “8” Vacant Level
Dial Code Service Feature for Administration
Station Service Feature for Guest Station
“0” Operator Call Special Administration Station Call

NEAX2400 IMX Hotel Features and Specifications
NDA-24245, Issue 2 Page 5
NUMBERING PLAN
Special Service Access Numbers (cont’d)
Examples:
Guest Station on the 1st Floor of the main building
dial “7” Calling
→ Room Service Station (STN 4801) on the 1F
Guest Station on the 2nd Floor of the main building
dial “7”
→ Calling Room Service Station (STN 4802) on the 2F
Guest Station on the 3rd Floor of the main building
dial “7”
→ Calling Room Service Station (STN 4803) on the 3F
d.) Table 2-1 shows a listing of special services which require Access numbers.
Note: In a case where both Entry and Cancel are specified for the same special service, different Access numbers must be
assigned for Entry and for Cancel.
Trunk Access Numbers
a.) Trunk Access numbers ranging from one through six (1-6) digits may be assigned on an
individual basis. Usually, one through three (1-3) digits are used.
Table 1 Special Services Requiring Access Numbers
Name of Special Service Remarks Name of Special Service Remarks
Account Code Dial Faulty Trunk Report
Attendant Manual Override Flash Signal Sending (CAS Main
Station)
Authorization Code/Forced
Account Code Dial Floor Service
Automatic Wake Up – Set
Automatic Wake Up – Cancel Group Announcement – Entry
Group Announcement – Cancel
Busy Out – Entry (UCD) Guest/Administration Service
Busy Out – Cancel (UCD)
Hotel Service
Call Back – Entry
Call Back – Cancel Individual Speed Calling: Entry
C.F. – All Calls – Entry Individual Speed Calling: Access
C.F. – All Calls – Cancel Individual Trunk Access
C.F. – Busy Line – Entry
C.F. – Busy Line – Cancel Line Load Control: Entry
C.F. – Don’t Answer – Entry Line Load Control: Cancel
C.F. – Don’t Answer – Cancel

NEAX2400 IMX Hotel Features and Specifications
Page 6 NDA-24245, Issue 2
NUMBERING PLAN
a.) Trunk Access numbers are required on an individual route basis.
b.) When Least Cost Routing (LCR) is utilized, LCR Access is regarded as access to an individual
route; therefore an Access Number must be assigned.
c.) If Answer Service is provided for Speaker and/or Radio Paging, a Paging Answer code must be
assigned.
Examples of a Dial Access Numbering Plans are shown in Table 2, Example of Dial Access
Numbering Plan for Administration Station and Table 3, Example of Dial Access Numbering Plan
for Guest Station.
Call Hold Message Reminder
Call Park Access Code
Call Park Local Retrieval Code Priority Call 1
Call Park Remote Retrieval Code Priority Call 2
Call Pickup Priority Call 3
Call Pickup – Direct Priority Paging
Call Waiting
Speed Calling Access
Data Privacy – Entry Same Number Access
Data Privacy – Cancel
Dial Access to Attendant TAS Answer
Trunk Queuing: Entry
Executive Right-of-Way Trunk Queuing: Cancel
Voice Call
Table 2 Example of Dial Access Numbering Plan for Administration Station
Access Number Function Remarks
0 Same Number Access (Dial Access to Attendant) Operator Call
10 Call Hold
11 Call Back (Entry) Cancel Number is “19”
12 Executive Right of Way
13 Speed Calling System
14
Vacant Numbers
15
16
17
18
Table 1 Special Services Requiring Access Numbers (Continued)
Name of Special Service Remarks Name of Special Service Remarks

NEAX2400 IMX Hotel Features and Specifications
NDA-24245, Issue 2 Page 7
NUMBERING PLAN
19 Call Back (Cancel) Entry Number is “11”
2000 – 2018 4-digit Administration Station Number
3000 – 3011 4-digit Guest Station Number
4
Vacant Numbers
5
6
7
80 Vacant Numbers
81 Access to Area A Route Number: 2
82 Access to Area B Route Number: 3
83 Access to Area C Route Number: 4
84 Access to Area D Route Number: 5
85 Access to Area E Route Number: 6
86 Vacant Numbers
87
88 Access to Paging Equipment Route Number: 10
89 Vacant Number
9 Access to Central Office Route Number: 1
Table 3 Example of Dial Access Numbering Plan for Guest Station
Access Number Function Remarks
0Same Number Access (Special Administration
Station Call) Special Administration Station Number “2000”
10
Vacant Numbers
11
12
13
14 Automatic Wake Up (Entry) Cancel Number is “15”
15 Automatic Wake Up (Cancel) Entry Number is “14”
Table 2 Example of Dial Access Numbering Plan for Administration Station (Continued)
Access Number Function Remarks

NEAX2400 IMX Hotel Features and Specifications
Page 8 NDA-24245, Issue 2
NUMBERING PLAN
Commands Related to the Numbering Plan
This section explains the commands related to the Numbering Plan and also explains command assignment
procedure.
For details of command, refer to the NEAX2400 IMX Office Data Specification Manual.
1. ASYD (Assignment of System Data)
The system data pertaining to the Numbering Plan is as follows:
•SYS1 INDEX 160 b6
This datais for determining whether the Numbering Plan Development Table is to be provided in common
or separately for Administration and Guest stations. The commands to be used vary with the value
assigned to the data as follows:
a.) When the Table is to be provided in common for Administration and Guest stations.
(b6= 1)
16
Vacant Numbers
17
18
19
2 Vacant Level
3000 – 3011 4-digit Guest Station Number
4
Vacant Level5
6
7 Floor Service IF: STN = 2001 Call,
2F: STN = 2002 Call
8 Vacant Level
9 Access to Central Office Route Number: 1
Table 3 Example of Dial Access Numbering Plan for Guest Station (Continued)
Access Number Function Remarks
AANP AASP ASPS (Common)
(Common)(Common)ASPF (Common)
AAST (for Administration)
AGST (for Guest)
