Optimum 600XL User manual

USERMANUAL
OPTIMUM 600XL
THE ULTIMATE COLD PRESS
BIG MOUTH SLOW JUICER

CONTENT S
WELCOME TO YOUR NEW KITCHEN ASSISTANT 1
SAFETY FIRST 1
GETTING TO KNOW YOUR 600XXL BIG MOUTH COLD PRESS JUICER 3
FIRST-TIME USE INSTRUCTIONS 3
ASSEMBLY 4
USING YOUR OPTIMUM 600XXL COLD PRESS JUICER 5
DISASSEMBLY INSTRUCTIONS 6
CLEANING AND MAINTENANCE 7
STORAGE 8
USEFUL TIPS / IMPORTANT REMINDERS 9
TROUBLESHOOTING 11
PRODUCT SPECIFICATIONS 12
WARRANTY TERMS & CONDITIONS 13
CONTACT US 14

WELCOME TO YOUR NEW KITCHEN ASSISTANT
Congratulations on investing in a professional quality Optimum 600XXL Big Mouth Slow Juicer.
Create delicious fruit juices, vegetable juices and much more.
JUICE, SNAP, POST!
We want you to show us your freshly made juice :)
All you need to do is follow us on Facebook and Instagram, make some fresh juice, snap a photo
and post with the hashtags #froothie #optimum600xxl
We give spontaneous prizes to our favourite pics!
SAFETY FIRST
WHEN USING ELECTRICAL APPLIANCES, YOU SHOULD ALWAYS BE AWARE OF
AND FOLLOW BASIC SAFETY PRECAUTIONS INCLUDING:
1. Read and follow all instructions and warnings in this manual carefully.
2. To protect against the risk of injury due to electric shock, do not immerse the 600XXL Big Mouth
Cold Press Juicer in water or any other liquid.
3. Only connect the appliance to a grounded power outlet. Always make sure the power plug is
inserted into the power outlet properly.
4. The input voltage of this appliance is between 220-240V, at 50-60Hz. Ensure the power source is
compatible with the appliance before connecting it to avoid damage.
5. This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they are supervised or have
been given instruction concerning the use of the appliance by a person responsible for their safety.
6. Do not operate the juicer if the power cord or plug are damaged, or if it malfunctions or is damaged
in any way. Return the appliance to the nearest authorised service facility for inspection or repair.
Do not attempt to repair the appliance yourself to avoid the risk of injury.
7. Do not operate the appliance with wet hands.
8. If you have any issues operating the juicer, first refer to the troubleshooting section. If the problems
persist, contact and return the appliance to distributor for inspection or repair. Do not disassemble
the juicer yourself.
9. Unplug the power cord from the power outlet before assembling, disassembling, cleaning or putting
your hands near any moving parts of the appliance to avoid injury.
FOR BE
INSTRUCTIONS IN THIS MANUAL CAREFULLY.
ST RESULTS, AND TO ENSURE YOUR SAFETY, PLEASE READ THE
FOR ADDITIONAL INSPIRATIONAL IDEAS FOR DELICIOUS RECIPES, PLEASE
CHECK OUT OUR FROOTHIETV YOUTUBE CHANNEL.O
1 // OPTIMUM600XXL

2 // OPTIMUM600XXL
SAFETY FIRS T
12.
13. If the appliance is overloaded or blocked during juicing, it will stop automatically after a few seconds.
You can restart the appliance after hearing the ‘beep’ sound. If the blockage still remains, unplug the
juicer and remove any food debris or pulp and restart the appliance
14. Do not squeeze lemon juice directly into the appliance.
15. Always ensure the appliance conforms to food safety and hygiene standards by following the
cleaning and maintenance instructions in this manual.
16. Use water to clean the appliance and all detachable parts, which come into direct contact with the
ingredients, after every use. Do not use abrasive materials, harsh cleansers or corrosive liquids (e.g.
acids, acetone, etc.) to clean the appliance.
17. Exercise extra care when handling parts of the appliance with sharp edges, emptying the cups of
their contents, and during the cleaning of the appliance.
20.
18..
19. Never use anything but the tamper to push ingredients into the juice
Switch o and unplug the appliance during long periods of inactivity.
r.
Never use any objects (e.g. chopsticks) to remove blockages in the outlets. Follow proper cleaning
procedures instead.
21. The appliance is intended to be used in household and similar applications such as:
22.
23.
24.
25.
26.
27.
28.
Children being supervised not to play with the appliance.
This unit is intended for household use only. Do not use the unit at outdoors or for other purpose than
intended.
Use the unit only as described in this manual.
Do not touch or move any moving parts during operation of the machine.
Do not open the unit when it is operating.
Do not let the cords hang over the edge of table or the like.
To avoid damaging the unit, do not overload the machine and also do not run the juicer without fruits
or vegetables being inserted into the chute.
farm houses;
sta kitchen areas in shops, oces, and working environments;
by clients in hotels, motels and other residential type environments;
bed and breakfast type environments.
FAILURE TO FOLLOW SAFETY INSTRUCTIONS AND WARNINGS COULD RESULT IN
SERIOUS INJURY. MISUSE OF YOUR COLD PRESS JUICER MAY DAMAGE YOUR
APPLIANCE AND VOID YOUR WARRANTY.
appliance after 20 minutes of juicing. To increase the lifespan of the appliance, always allow 20—30
The appliance is equipped with an intelligent protection chip, which automatically switches o the
minutes for the motor to cool down between uses.
10.
11.
Ensure the detachable parts of the appliance are installed properly before use. The pulp extractor
and feeding chute should be in the ‘lock’ position to prevent leakage, spillage, or parts from
becoming loose during juicing.
Place the appliance on a flat, stable and level surface, away from any water or heat sources. Do not
use the appliance on carpets, towels, plastic, paper, or flammable surfaces.

GETTING
600XXL BIG MOUTH COLD PRESS JUICER
T O KNO W Y O U R
1. Feeding Chute / Hopper with Filter
2. Auger / Juicing Screw
3. Juicing Bowl (800ml)
4. Motorbase
5. Juice Cup (1000ml)
6. Pulp Cup (900ml)
7. Tamper / Pusher
8. Cleaning Brush
9. On/O Switch
3 // OPTIMUM600XXL
CAUTION: The appliance will
work only when the power
plug is connected and the lid
assembly is properly put together,
as shown.
FIRST-TIME USE INSTRUCTIONS
1. Remove all packaging materials and labels.
2. Ensure that the electricity supply is 220-240V, 50-60Hz.
3. Clean the feeding tube cover, the auger, juice cup, pulp cup, juicing bowl, and pusher with
soapy water. Then rinse and dry them thoroughly.
NOTE: DO NOT IMMERSE THE POWER BASE UNIT IN WATER.
4. Assemble the parts according to the instructions in the assembly method section.
5. Connect the power cord to the power source.
6. The unit is now ready to be used.

ASSEMB LY
Please ensure that the unit is not plugged in and the switch is turned to the "O" setting before
assembling the machine.
1 .
3 .
2 .
4 .
Position the juice container and the pulp
container under the relevant spouts. (Fig 4)
Firmly push the squeezing auger into the centre
of the bowl, ensuring that it touches the bottom;
otherwise, the cover cannot be closed. (Fig 2)
Place the juicing bowl on the motor base,
aligning the position of the spouts and the axle.
(Fig 1)
Align the ▲ on the chute with the " " on the bowl
and twist it clockwise until it clicks into the safety
lock. Make sure that the arrow ▲ on the cover
aligns with the Lock graphic on the bowl. (Fig 3)
4// OPTIMUM600XXL

BENEFITS OF THE DRIPSTOP COVER
USING YOUR OPTIMUM 600XXL COLD PRESS JUICER
OPEN & CLOSE OF JUICE SPOUT DRIPSTOP COVER
5// OPTIMUM600XXL
• Connect the unit to the power supply.
• Check and ensure that all parts are properly assembled in the correct position.
• Make sure the machine is switched o and set to the "O" position.
• Ensure that the juice and pulp containers are correctly positioned.
• Ensure that the juice spout cover is closed.
• Prepare the fruits or vegetables by cutting them into pieces no larger than 5cm x 3cm strips
or 5cm x 5cm cubes.
• Place the fruit strips or cubes into the chute.
• Press the switch to the "-" setting to start the juicing operation.
• Use the pusher to gently push the food down.
• If any food gets stuck inside the bowl stop the juicer and then switch to the reverse function "R".
To ensure an uninterrupted and ecient flow of juice into the juice container, it is important to keep
the juice tap open throughout the juicing process. This helps maintain a consistent flow, prevents
excessive pressure buildup, and safeguards the optimal performance of the juicer.
Fig 5
Juicer spout is closed
NOTE: PLEASE DO NOT USE THE JUICER CONTINUOUSLY FOR LONGER
THAN 20 MINUTES.
1. Prevents dripping at the end of juicing.
2. Allows for mixing juices with dierent fruits and vegetables.
Juicer spout is opened

6// OPTIMUM600XXL
Fig 6 Fig 7 Fig 8 Fig 9
NOTE: IF THE JUICER OVERHEATS, IT WILL AUTOMATICALLY SHUT OFF TO
PROTECT THE MACHINE. IN SUCH CASES, PLEASE SWITCH OFF THE JUICER
BY TURNING THE SWITCH TO THE "O" POSITION. ALLOW THE JUICER TO
COOL DOWN FOR 10 MINUTES BEFORE TURNING IT ON AGAIN.
To disassemble the unit after use and before cleaning, please turn the juicer to the "O" position and
disconnect it from the power source.
Then, follow the steps below:
1. Remove the juice and pulp containers. (Fig 6)
2. Turn the chute anti-clockwise until the ▲ aligns with the " " sign, and then remove the chute. (Fig 7)
3. To remove the squeezing auger, pull it out upward. If it is dicult to remove, gently swing it back
and forth while pulling. (Fig 8)
4. Lift the squeezing bowl upward vertically to remove it. (Fig 9)
DISASSEMBLY INSTRUCTIONS

7// OPTIMUM600XXL
CLEANING AND MAINTENANCE
Fig 11
Pull to open
Silicone valve
Fig 10
NOTE: IT IS IMPORTANT TO WASH THE JUICING PARTS IMMEDIATELY
AFTER EACH USE. FAILURE TO DO SO MAY RESULT IN THE PULP
STICKING TIGHTLY TO THE JUICING BOWL AND SQUEEZING AUGER,
WHICH CAN AFFECT DISASSEMBLY, CLEANING, AND JUICING PERFORMANCE.
1. Switch o the juicer and unplug it.
2. Wash the disassembled parts (Fig 10) with water. If the meshes are clogged with pulp, please use
the provided cleaning brush to remove any residue.
ATTENTION:
• Do not use an iron wire brush, abrasive materials, or sharp objects to clean the unit.
• Please avoid using water above 40°C.
3. If there are any residues remaining in the mouth of the pulp spout, please pull out the silicone
valve as shown in (Fig 11) below and clean it under running water.

8// OPTIMUM600XXL
Fig 12a Fig 12b Fig 12c
CLEANING AND MAINTENANCE
STORAGE
Press the silicone valve firmly to ensure proper closure after cleaning.
4. To clean the seal ring in the center of the juicing bowl, please follow these steps:
a. Turn the juicing bowl upside down for easier handling. Use your thumb to push the seal ring
out (Fig 12a), and clean it with water.
b. After cleaning, place the seal ring back into the center hole. Ensure that the small ribbed surface
faces upward (Fig 12b). Make sure the groove of the seal ring fits snugly in the squeezing bowl.
c. The big flat side of the seal ring should be on the inside, while the small and ribbed side should be
on the outside of the juicing bowl (Fig 12c).
5. Do not immerse the motor base in water for cleaning. Only wipe it with a damp cloth.
6. After cleaning, ensure that all parts are thoroughly dried and store them in a dry, cool place.
1. Follow the cleaning instructions to properly maintain the unit before storing it.
2. Neatly arrange the power cord.
3. Keep the unit out of reach of children.
4. Store the unit and its accessories in a dry and cool place.
NOTE: Please ensure that the unit and its parts are completely dry before storing them.

9 // OPTIMUM600XXL
USEFUL TIPS / IMPORTANT REMINDERS
WHAT FRUITS SHOULD I AVOID PUTTING IN MY JUICER?
• Remove hard pits or seeds before pressing to avoid potential damage to the squeezing screw.
• When making mixen juices start with softer fruits and then juice the harder ones.
• Allow the juicer to run for 30 seconds after the last ingredient has been fed.
ATTENTION: The juicer is not suitable for juicing very hard, fibrous, or starchy fruits or vegetables,
such as sugar cane. Some fruits, like avocado, bananas, figs, mango, papaya, dragon fruit, strawberry,
and seedless grapes, contain too much starch and can clog up the stainless steel sieve.
• Do not use ice cubes. Ice cubes are too hard and can damage the squeezing parts of the juicer.
• Ingredients with long fibres should be cut into thin strips of 5-10 cm or cubes of 3 x 3 cm.
Long-fiber foods are prone to tangling and can block the spout.
• Oranges, lemons, grapefruits, and melons must be peeled and have their pits/seeds removed
before juicing. The hard pits or seeds can damage the squeezing parts, and the peel can block
the pulp spout.
• Do not use any other accessory as a pusher. Using non-designated objects as pushers can cause
damage to the juicer and result in injury.
• Each juicing cycle should not exceed 20 minutes. Extended use beyond this time can cause damage
to the motor.
• Never insert a spoon or similar item into the chute opening, juice spout, or pulp spout.
Doing so can damage the juicer.
• It is best to alternate between the juicier and more fibrous fruits and vegetables. For example, you
can alternate between juicier ingredients like apples, carrots, cucumber and citrus fruits and the more
fibrous ingredients like greens such as kale and spinach, celery and wheatgrass. We also suggest
saving the carrot for last, as this helps push out the last of the pulp.
• Tips for juicing apples: Dry or floury apples are often found in winter because apples have been
stored for a long time and have lost a lot of their moisture content. If you juice floury apples, chances
are you will get pulp rather than juice. This happens with every juicer - regardless of whether it is a
centrifuge or masticating/cold press.
• Only juice firm apples. Be sure to juice slowly and alternate with other produce such as carrots to
keep the strainer clean.
• We recommend using Granny Smith apples - they are firmer and keep their quality for much longer.
Sometimes people are surprised that their juicer cannot handle certain types of fruit such as apples,
avocados or bananas. The reason for this isn't that there is something wrong with your juicer, but more
about the properties of such fruit that make them poor options for juicing.
BANANAS
Bananas have their own composition. They are so rich in Potassium that can benefit the body in
multiple ways, but unfortunately bananas do not have enough water in them, thus making it impossible
for juicing. Bananas are much better suited for smoothies or other blended desserts!

10 // OPTIMUM600XXL
BERRIES
Strawberries, blueberries, raspberries and currants are very soft and have little liquid content.
Furthermore, the pulp in these fruits can clog the sieve. However, fret not — the solution is to mix the
berries with other high-water-content produce.
How to juice berries?
• Use fresh and juicy berries
• Alternate berried with other fruit such as oranges, apples or watermelons. Berry juice has a very
intense taste and is often better as an addition and not as a main ingredient. Mix the dierent
types of fruit together while juicing.
AVOCADO
Avocado is a great source of omega-3 fatty acids and, when ripe, it blends nicely, making smoothies
and dips creamy and smooth. But if you try to juice it, it will only jam your juice machine. You can add
avocado to fresh juice, though — here’s how: In a blender, combine 1 cup of fresh juice with 1/2 avocado,
cut into chunks. Blend until smooth. Pour this mixture into the rest of your juice and mix well.
The avocado will make the juice thick and creamy.
RHUBARB
Rhubarb leaves are high in oxalic acid and inedible, but the stalks contain such tiny amounts of the toxic
acid that most people can eat small amounts of rhubarb stalks in pie and jam without experiencing
problems. However, because of the amount of fresh rhubarb required to make one glass of juice, the
amount of nutrients and the toxic oxalic acid is concentrated and much higher than if you eat the stalks
raw. Juicing rhubarb could cause a reaction of stomach irritation and kidney problems, so you’re better
o leaving it for smoothies and rhubarb pie.
CHERRIES
Like berries, cherries have a soft, mushy consistency, so it takes a lot of cherries to make just one glass
of juice. The main reason people tend not to juice cherries is because they need to be deseeded
before being juiced. Alternative: You can add cherries to smoothies and other blended drinks or use a
small amount of their juice in your juice recipe.
MANGO
Mangos are a very mushy fruit that is not optimal for juicing.
Alternative: Frozen mangoes are perfect for smoothies and add a great creamy flavour. If you’re looking
for some type of thick, mango juice-like beverage, we recommend using a blender to puree the mangos,
which you can then add to any juice. This method also works well for papayas.
WHAT FRUITS SHOULD I AVOID PUTTING IN MY JUICER?

11 // OPTIMUM600XXL
TROU B L ESH O O TING
PROBLEM P OSSIBLE C A U S E SOL U TION
The juicer stops
running suddenly.
The juicer has too many
ingredients put into it.
Switch to the "R" position instantly to make the
ingredients return upwards. If the machine still
stops running, please clean it before use.
Hard fruits or vegetables have
not been cut into small pieces.
Hard fruits and vegetables, such as carrots,
should be cut into thin strips or small cubes
before being placed into the chute.
The juice yield is
low, or juice flows
out of the main
housing.
The bowl and the silicone
valve are not installed
properly.
Please re-install the bowl silicone valve by
referring to the installation method on page 7
Abnormal noise
The chute &
strainer assembly
cannot be
opened
The container &
accessories are
stained after use.
Parts are causing extrusion
sound during squeezing.
The sound is caused by the extrusion of fruits
and vegetables, which is a normal phenomenon.
There is too much pulp
inside the bowl.
Press the switch to the "R" setting to eject the
pulp backward.
There are hard foods stuck
inside.
The pulp is stuck or there is
a pulp mess.
The minerals from fruits,
produce, and leafy greens
can cause a film on your
juicer parts.
In general, discolouration is
normal, happens over time
depending on what fruits and
veggies are juiced.
Dark leafy vegetables like Kale
and Spinach contain a green
pigment, present in all green
plants called chlorophyll.
Press the switch to the "R" setting to eject the
content backward.
Pour water into the chute to moisten the stuck
pulp mess overnight.
Ensure that you hand wash each component and
promptly dry them after washing to eliminate any
residue and avoid watermarks.
If you wish to perform a more thorough cleaning,
you can follow the instructions provided below:
Submerge the components(except the base) in
warm water until they are fully covered.
Add 100g of citric acid and 100g of baking soda
to the water, maintaining a 1:1 ratio. Let the
components soak overnight in the mixture.
Utilize the cleaning brush to scrub away any
marks or stains.

12// OPTIMUM600XXL
800ml
Optimum 600XXL Big Mouth Cold Press Juicer
250W
13 x 22.8cm
Juicing bowl capacity
Product
Power
Feeding chute size
Australia Standard: AS/NZS 60335.2.14:2017
At the end of its service life, this product may not be disposed of in the normal household waste,
but rather must be disposed of at a collection point for recycling electrical and electronic devices.
The material are recyclable according to their labelling. You make an important contribution to
protecting our environment by reusing, recycling or utilizing old devices in other ways. Please ask
the municipal administration where the appropriate disposal facility is located.
PRODUCT SPECIFICATIONS
20.8 x 20.7 x 43.7cm
36-42 RPM
less than 60db
Product size
Speed
Average noise
900ml
4.9kg
1000ml
Pulp cup capacity
Weight
Juice cup capacity
Food grade BPA freeMaterial

This warranty as outlined below solely covers distributors of the Optimum range of products. Please
contact your distributor for full product warranty.
1. Optimum® warranties this product against defects in materials and workmanship for a period of 2
years from the original date of purchase when used in accordance with the accompanying instruction
manual.
2.
distributor and claimable only though that provider.
3. Defects that occur within this manufacturer’s warranty period, under normal use and care will be
repaired or replaced at our discretion only if the selling distributor is unable to do so. This is done
solely at our option with no charge for parts. This warranty does not extend to accessories included
distributor and at their own discretion.
4. In the event that the goods requiring repair are under warranty, and this distributor is unable to
provide the repairs; the customer is responsible for any freight charges to or from Optimum® (or their
approved service provider).
5. Whilst in transit the goods are at the owner’s risk and any further damage during this transportation is
not covered under warranty.
6. Customers should ensure that the product being returned is properly packaged so as to ensure that
no damage occurs to the product during transit. To be able to process the warranty claim ensure
you have included an explanation of any problem, Optimum® will not fault-find and will only repair
described faults as covered under warranty.
7. This full warranty is void if this product has been subject to abuse, negligence, accident, alteration,
failure to follow operating instructions, or the product has been exposed to abnor-mal or extreme
conditions.
8.
considered defects. The cleaning or removal of food products along with any damage caused by
allowing them to build up is not covered by this full warranty.
9. This warranty does not cover normal wear and tear of the product or parts.
10. This warranty does not cover any defect caused by an accident, misuse, abuse, improper installation
or operation, lack of reasonable care, unauthorized medication, loss of parts, tampering or attempted
repair by a person not authorized by Optimum®.
11. The warranty will not apply if damage, malfunction or failure resulting from alterations, accident,
misuse, abuse, fire, liquid spillage, maladjustment of customer controls, use on an incorrect voltage,
power surges and dips, thunderstorm activity, acts of God, voltage supply problems, tampering or
unauthorized repairs by any persons, use of defective or incompati-ble accessories, exposure to
abnormally corrosive conditions or entry by any insect, vermin or foreign object in the product.
12. This warranty does not cover damage resulting from the use of an alternate power source (e.g. solar,
inverter, generator) and the use of these devices to power your appliance is not recommended.
13 // OPTIMUM600XXL

14 // OPTIMUM600XXL
13. You must keep your purchase receipt as proof of purchase and as proof of the date on which the
purchase was made. The purchase receipt must be presented when making a claim under this
warranty.
14. In the event the receipt of purchase is not presented, then this warranty is invalid. Consumer Law
allows us to request reasonable proof of purchase to service a warranty claim.
15. This warranty does not imply, intend to or detract from any consumer rights listed in and able to
be enforced from Regulated Consumer Law, any condition which is found to be in breach of the
consumer law, the single condition shall be void only and all other conditions remain in place.
CONT A CT US
Please contact the distributor located in the country where you made your original purchase for all
Support, Servicing and Warranty.

Optimum 400 Evolve Big-Mouth Cold Press Juicer
