OSIM uZap Body User manual

1) English
2) Simplified Chinese 简体中文
3) Traditional Chinese 繁體中文

1
Thank you for purchasing the OSIM uZap Body. Please read the
operation manual thoroughly for the correct methods of usage and
take special notice of the safety section before you start.
This manual should be kept on hand for easy reference. It is your
guide to a safe and efficient operation.
OS-9220 uZap Body
ENGLISH
Contents | Safety 2
Names of parts and functions 5
Operation 7
Product care and storage 11
Troubleshooting 12
Specifications 13

2
IMPORTANT SAFETY INSTRUCTIONS
When using the product, please TAKE SPECIAL NOTICE of the following basic
precautions:
Read all instructions before using the product:
DANGER – To reduce the risk of electric shock:
Always unplug this product from the electrical outlet /USB cable immediately after
use and before cleaning.
WARNING – To reduce the risk of fire, burns, electric shock, or injury to
persons:
1) Use this product only for its intended use as described in this manual. Do not
use attachments not recommended by the manufacturer.
2) The product should never be left unattended when plugged in. Unplug from
electrical outlet /power source when the product is not in use, and before
putting on or taking off parts.
3) Do not operate the product under a blanket or pillow. Excessive heating may
occur and cause fire, burns, electric shock, or injury to persons.
4) Do not use the product if the electrical outlet /power source is loose.
5) Do not connect or disconnect the power plug /USB cable from the electrical
outlet /power source with wet hands.
6) When disconnecting the power plug /USB cable, remove it by holding the plug
/USB cable head, and not by the cord /cable.
7) Do not operate the product if it has a damaged cord or plug /USB cable, a
malfunction, a power failure, or it is dropped into the water. Injury may occur
when power is restored unexpectedly. Return the product to OSIM Service
Centre for examination and repair.
8) If the power plug /USB cable or power cord is damaged, it must be replaced by
OSIM Service Centre or its authorized service agents.
9) Do not carry this product by the power cord /USB cable or use the power cord /
USB cable as a handle.
10) Keep the product power cord /USB cable away from heated surfaces.
11) Do not place the power cord /USB cable under the product or any other heavy
objects.

3
12) Do not wind the power cord /USB cable around the product.
13) Do not operate the product with the air openings blocked. Keep the air
openings free of lint, hair, and the like.
14) Remove power plug /USB cable from the electrical outlet /power source
immediately should liquid be spilled onto the product as this may result in
electric shock.
15) Do not operate where aerosol (spray) products are being used or where
oxygen is being administered.
16) To stop using the product, turn off all controls and remove the power plug /
USB cable from the electrical outlet /power source.
17) Do not drop or insert any object or flammable material into any openings of
the product. This may result in electric shock, malfunction or risk of fire.
18) Children should be supervised to ensure that they do not play with the product.
19) This product can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved. Keep children away when the product is in operation.
20) Cleaning and user maintenance of the product shall not be made by children.
21) Do not use or operate the product when your body or hands are wet.
22) Do not use this product outdoors.
23) Do not use the product in an excessively humid or dusty environment as it may
result in malfunction.
24) Do not use the product in temperatures higher than 40˚C.
25) Do not expose the product to heaters, stoves or direct sunlight.
26) Do not cover the product during operation. This may result in a rise in motor
temperature and subsequent malfunction or fire.
27) Do not use the product in the event of a lightning storm.
28) If you should use the product in a cold room, do not increase the room
temperature abruptly. It is recommended that you increase the temperature
gradually to a normal level.
29) If the product is brought into a warm environment from a cold place where
it was stored, wait for an hour before use as there may be water droplets
on mechanical parts due to condensation. Using the product under such
condition may result in malfunction.

4
30) Do not dismantle, drop, or subject the product to shock or vibration.
31) Do not use the product in combination with other therapeutic equipment
or electric blanket, etc., as this may result in ineffectiveness or injury.
32) Do not rest or place heavy objects on the product as this may result in
malfunction.
33) The product must only be serviced or repaired by the OSIM Service Centre.
Do not attempt to disassemble or repair the product.
34) Some noise may be heard from the product while in use. This is due to the
structure of the product and is normal.
35) Please do not use the product if you are not feeling well or under the
influence of alcohol.
36) Stop using immediately should you experience discomfort and consult
your doctor if you experience any abnormal or severe pain.
37) This product is not intended for self-diagnosis or self-treatment of
conditions that should be managed by a qualified health care provider.
38) If you are under any medication or have any medical conditions, please
consult your health care provider first before use.
39) Avoid food intake for at least an hour before massage /usage.
For Remote Control
40) Check for correct polarity (+/-). Do not disassemble, recharge, dispose of in
fire, swallow or remove battery label.
Do not mix used and new batteries, different brands, different expiration
dates or battery types.
Keep out of reach of children, if swallowed, consult doctor at once.
Batteries may explode or leak. Follow instructions of your batteries and
devices.
WARNING: Use only with the detachable supply unit provided with
this appliance. (model: DZ048BDL240200F)
SAVE THESE INSTRUCTIONS
This product is intended for household use only.
Warranty is subjected to cancellation if the product is used for commercial
purposes.

5
Names of parts and functions
1. Vibration platform
2. Rubber stand
3. Adapter jack connector
4. Remote control
5. Power adapter*
6. Adapter jack * Power adapter will vary according to country
*Product images are for illustrative purposes only and are not drawn to scale.
1
5
6
2
3
4
Main unit

6
Names of parts and functions
Remote Control
1. LED indicator
2. Power/Stop button
3. Manual Program button
(10 vibration intensity levels)
4. Volume adjustment button
(5 levels)
5. Chi Auto Program button
6. Relax Auto Program button
7. Fitness Auto Program button
8. Music Sync Auto Program button
5
1
6
2
3
4
7
8

7
Operation
Caution
Note
•Connect the adapter jack to the adapter jack connector.
•Connect the power adapter to the electrical outlet. Turn on the
main switch.
•The uZap Body will be on standby mode.
•Turn on the Bluetooth on your smart device.
•In the Bluetooth settings, select ‘OS9220 XXXX XXXX’ (XXXX
XXXX can be any alphanumerical values) and ensure that it is
connected.
•Do not apply more than 120 kg load on product as it may cause
significant overheating and subsequent damage to the product.
•Keep hands and fingers away from the gaps between the
vibration platform and base while in use.
•Always place the uZap Body on a flat and non-slip floor.
•It is recommended to operate the uZap Body on an anti-slip PVC
mat (at least 8mm thick) to protect the floor from scratch marks,
as well as to enhance the usage experience.
•Due to interference, user may need to attempt to pair their smart
device with the product more than once.
•The uZap Body can only be paired with one smart device at a
time. If there is an existing pairing, you will need to unpair the
current pairing before attempting to pair a new smart device
with the uZap Body.
To turn on the power
Pairing smart devices with uZap Body via Bluetooth

8
Operation
•Step on the vibration platform of the uZap Body.
•Press the Power/Stop button [ ] on the remote control to turn
on the uZap Body (1 ‘’Beep’’).
•Press the Auto Program button [ ] to select your desired
program (Chi, Relax or Fitness) for workout (1 ‘’Beep’’). The
default timer is 15 minutes.
•To customize your desired program for workout, press the Manual
Program button [ ] to adjust the vibration intensity (10 levels)
to suit individual workout preference (1 ‘’Beep’’ for level 1 to 9;
2 ‘’Beep’’ for level 10; press and hold for 2 seconds to reset to
level 1 with 3 ‘’Beep’’).
•When the timer has lapsed, the uZap Body will switch to standby
mode if no program is selected within 3 minutes.
To commence workout
Note
•It is recommended to begin your workout at low intensity and then
gradually increase the intensity.
•Make sure that you are standing comfortably on the vibration
platform before you begin your workout.
•Do not lock your joints and you should always keep your knees
slightly bent for all exercises.
•Please consult a doctor before embarking on any new exercise routine.
•The uZap Body is equipped with motor protection system and will stop
operation in the event of improper operation such as overloading.
•It is recommended that you wear proper workout attire and footwear
when using the uZap Body.
•Do not wear high heels while working out on the uZap Body.
•The recommended usage time is 30 minutes per session.
•Stop operation immediately if you experience any discomfort.
•When using Chi Auto Program, you will experience pauses of 8 seconds
for every 75 seconds.

9
Operation
•Press the Power/Stop button [ ] to end the workout at
anytime, and uZap Body will switch to standby mode (1 long
‘’Beep’’).
•In the event that a workout has ended due to the timer has
lapsed, uZap Body will switch to standby mode if no program is
selected within 3 minutes.
•Once Bluetooth pairing with uZap Body is successful, you may
play music on your smart device.
•Press the volume adjustment button [ ] on the remote control
to adjust the volume (5 levels) of the music to your desired level
(1 ‘’Beep’’ for level 1 to 4; 2 ‘’Beep’’ for level 5; press and hold
for 2 seconds to reset to level 1 with 3 ‘’Beep’’).
•Press the Music Sync button [ ] on the remote control to start
the music synchronization (1 ‘’Beep’’). The vibrating action will be
synchronized with your music input.
•When the uZap Body is paired with the smart device, music can
be played on Auto and Manual Program without synchronization
function.
•When using Music Sync Auto Program, the product’s synchronized
vibrations to the music will be more significant when music is
adjusted to a higher volume.
To end workout
Play music on uZap Body
To start the Music Sync Auto Program
Note
•The uZap Body will switch to standby mode/music will stop if no
program is selected within 3 minutes.

10
Operation
•The uZap Body is paired to the original remote control by default.
•If there is a replacement of the remote control, user is required
to pair the new remote control to the uZap Body to use the
product.
•Turn off the uZap Body for about 30 seconds and turn it on
again.
•Within 5 seconds after product is turned on, press and hold both
the Power/Stop button and Manual Program button. Series of
“Beep” will be heard, and pairing is complete once “Beep” ends.
Pairing uZap Body with remote control

11
Product care and storage
Product placement and storage
Environmental factors can strongly affect the product physically and mechanically.
Do not expose the product to direct sunlight or in places with extreme heat or air-
conditioning vents. These can cause the upholstery to crack or the color to fade.
If the product is not to be used for a long period of time, cover it with a dust cover
and disconnect the power adapter from the electrical outlet.
Clean the product using a dry cloth regularly
Before cleaning, ensure that the main switch is turned off and the power adapter
is disconnected from the electrical outlet.
The product is customarily exposed to the natural body oils of users. The main
unit structure can be cleaned thoroughly with a piece of soft, dry cloth. The
common microfiber cleaning materials or gloves are very well suited for this routine
maintenance process. Such materials and gloves are available for sale in most DIY
shops.
Do NOT use wet elements for cleaning
The product is made up of electrical components and mechanical parts, which are
all very sensitive to moisture. If you use water (eg a wet cloth) to clean the product,
the coating may be eroded and the protection for the product will be diminished.
As for the power button, it may result in malfunction if you use a wet cloth to clean.
Do NOT use cleaning solvents and abrasive cleaners
Under no circumstances should you use any cleaning agents, like benzene or
thinner to clean the product. This may cause the product color to fade.
Do NOT attempt to repair your product
For safety reasons, under no circumstances should you attempt to repair the
product.
If you suspect a malfunction, always call the OSIM Service Center for further
assistance and information.

12
Troubleshooting
If you encounter problems with the operation of the uZap Body, please
check the following points to see if they can be rectified. If the uZap Body still
malfunctions or does not work, please turn off the uZap Body and remove
the power adapter from the electrical outlet. Contact OSIM Service Center*
for servicing.
Do not dismantle or attempt to repair the uZap Body yourself. Doing so
will void the warranty and OSIM will not bear any responsibility for any
subsequent consequences.
* Please visit us at www.OSIM.com for information on the nearest service center.
Product warranty is valid only in the country of purchase.
•Ensure that the power adapter is securely
connected to the electrical outlet.
•Ensure that the main switch is turned on.
Problem Possible causes / actions
•The uZap Body will not
start.
•The workout stops midway. •Check that the adapter jack has not been
disconnected from the uZap Body.
•The auto timer of 15 minutes may have
lapsed.
•The Power/Stop button [ ] on the
remote control was pressed accidentally.
•The motor protection system will trigger
in an event to prevent improper operation
such as overloading. Press the Power/Stop
button [ ] to restart the product.
•The overheat protection device may have
been activated. Turn off the main switch
and allow the uZap Body to cool down for
at least 60 minutes before using it again.

13
Model name uZap Body
Model number OS-9220
Power adapter 100-240V ~ 50/60Hz 1.5A(Input)
24.0V 2.0A (Output)
(Kindly ensure that the local Alternating Current
(AC) voltage corresponds with product specified voltage)
Auto timer 15 minutes
Dimension: 550 (L) x 330 (W) x 132 (H) mm
Net weight Approx. 13 kg
Gross weight Approx. 15 kg
Specifications

14
Notes

15
Notes

16
Notes

1
感谢您购买 OSIM uZap Body 健身器 (傲胜动姿板)。使用前请
仔细阅读操作手册，并特别注意安全事项，以便正确操作和使
用本产品。
本手册提供使用者安全及有效的操作方式，请在阅毕后妥为
收藏，以便日后参考查询。
OS-9220 uZap Body
目录 | 安全事項 2
配件名称与功能 5
操作方式 7
产品保养及收纳 11
故障排除 12
规格说明 13

2
重要安全事项说明
使用本产品时，请特别注意并遵守下列安全事项：
使用本产品前，请先详阅所有的说明。
危险 - 为降低触电风险，请遵照下列指示：
使用完毕后或清洁前，请将电源线插头 /USB 电缆由插座中拔除。
警告 - 为降低火灾、灼伤、触电、或是造成他人受伤的风险，请遵
照下列指示：
1） 请务必依照使用手册中所叙述的用途使用本产品。请勿使用非制造
商所推荐的零配件。
2) 接通电源后，请看顾好产品。不使用产品时或组装和拆卸配件
前，请切断电源。
3) 请勿在毯子或枕头下使用产品。过热可能会造成火灾、灼伤、触
电或人员受伤。
4) 如果电源接口松动，请勿使用产品。
5) 手上潮湿时，请勿开关电源或碰触电源插头 /USB 电缆与电源插
座/电源。
6) 切断电源后，请握住插头 /USB 电缆接头将其拔出，请勿拉扯电源
线/电缆。
7) 如果产品的电源线或插头/USB电缆出现损坏故障、电源故障或
掉入水中，请勿使用产品。电源意外恢复时，可能会造成人员伤
害。请将产品退回 OSIM 傲胜服务中心进行检查和维修。
8) 如果电源插头/USB 电缆或电源线出现损坏，必须由 OSIM 傲胜服
务中心或其授权服务代理更换。
9) 请勿拉扯或把电源线/USB 电缆当作握把使用。
10) 请勿将电源线/USB 电缆放在加热表面上。
11) 请勿将电源线/USB 电缆放在产品或任何重物下方。
12) 请勿将电源线 /USB 电缆缠绕在产品上。
13) 若产品出气口阻塞，请勿使用产品。请保持出气口通畅无阻，
不被棉屑，毛发等阻塞。
