OSIM uZap Gun Mini User manual

uZap Gun Mini
OS-2221 Operation Manual
Developed in Singapore by OSIM International Pte Ltd. (A subsidiary of V3 Group) Rev C
© 2022 All rights reserved. www.OSIM.com

1) English
2) Simplified Chinese 简体中文
3) Traditional Chinese 繁體中文

1
Thank you for purchasing the OSIM uZap Gun Mini. Please read the
operation manual thoroughly for the correct methods of usage and
take special notice of the safety section before you start.
This manual should be kept on hand for easy reference. It is your
guide to a safe and efficient operation.
OS-2221 uZap Gun Mini
ENGLISH
Contents | Safety 2
Names of parts and functions 5
Preparation for operation 7
Recommended muscle group area 9
Product care and storage 11
Troubleshooting 12
Specifications 14

2
IMPORTANT SAFETY INSTRUCTIONS
When using the product, please TAKE SPECIAL NOTICE of the following basic
precautions:
Read all instructions before using the product:
DANGER – To reduce the risk of electric shock:
Always unplug this product from the electrical outlet /USB cable immediately after
use and before cleaning.
WARNING – To reduce the risk of fire, burns, electric shock, or injury to
persons:
1) Use this product only for its intended use as described in this manual. Do not
use attachments not recommended by the manufacturer.
2) The product should never be left unattended when plugged in. Unplug from
electrical outlet /power source when the product is not in use, and before
putting on or taking off parts.
3) Do not operate the product under a blanket or pillow. Excessive heating may
occur and cause fire, burns, electric shock, or injury to persons.
4) Do not use the product if the electrical outlet /power source is loose.
5) Do not connect or disconnect the power plug /USB cable from the electrical
outlet /power source with wet hands.
6) When disconnecting the power plug /USB cable, remove it by holding the plug
/USB cable head, and not by the cord /cable.
7) Do not operate the product if it has a damaged cord or plug /USB cable, a
malfunction, a power failure, or it is dropped into the water. Injury may occur
when power is restored unexpectedly. Return the product to OSIM Service
Centre for examination and repair.
8) If the power plug /USB cable or power cord is damaged, it must be replaced by
OSIM Service Centre or its authorized service agents.
9) Do not carry this product by the power cord /USB cable or use the power cord /
USB cable as a handle.
10) Keep the product power cord /USB cable away from heated surfaces.
11) Do not place the power cord /USB cable under the product or any other heavy
objects.

3
12) Do not wind the power cord /USB cable around the product.
13) Do not operate the product with the air openings blocked. Keep the air
openings free of lint, hair, and the like.
14) Remove power plug /USB cable from the electrical outlet /power source
immediately should liquid be spilled onto the product as this may result in
electric shock.
15) Do not operate where aerosol (spray) products are being used or where
oxygen is being administered.
16) To stop using the product, turn off all controls and remove the power plug /
USB cable from the electrical outlet /power source.
17) Do not drop or insert any object or flammable material into any openings of
the product. This may result in electric shock, malfunction or risk of fire.
18) Children should be supervised to ensure that they do not play with the product.
19) This product can be used by children aged from 18 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved. Keep children away when the product is in operation.
20) Cleaning and user maintenance of the product shall not be made by children.
21) Do not use or operate the product when your body or hands are wet.
22) Do not use this product outdoors.
23) Do not use the product in an excessively humid or dusty environment as it may
result in malfunction.
24) Do not use the product in temperatures higher than 40˚C.
25) Do not expose the product to heaters, stoves or direct sunlight.
26) Do not cover the product during operation. This may result in a rise in motor
temperature and subsequent malfunction or fire.
27) If you should use the product in a cold room, do not increase the room
temperature abruptly. It is recommended that you increase the temperature
gradually to a normal level.
28) If the product is brought into a warm environment from a cold place where
it was stored, wait for an hour before use as there may be water droplets
on mechanical parts due to condensation. Using the product under such
condition may result in malfunction.

4
29) Do not dismantle, drop, or subject the product to shock or vibration.
30) Do not use the product in combination with other therapeutic equipment or
electric blanket, etc., as this may result in ineffectiveness or injury.
31) Do not rest or place heavy objects on the product as this may result in
malfunction.
32) The product must only be serviced or repaired by the OSIM Service Centre. Do
not attempt to disassemble or repair the product.
33) Some noise may be heard from the product while in use. This is due to the
structure of the product and is normal.
34) Please do not use the product if you are not feeling well or under the influence
of alcohol.
35) Stop using immediately should you experience discomfort and consult your
doctor if you experience any abnormal or severe pain.
36) This product is not intended for self-diagnosis or self-treatment of conditions
that should be managed by a qualified health care provider.
37) If you are under any medication or have any medical conditions, please
consult your health care provider first before use.
38) Avoid food intake for at least an hour before massage /usage.
39) This product contains lithium battery that is only replaceable by a skilled
technician. Do not attempt to assemble or repair the product. Contact OSIM
service centre for any repair.
40) The battery must be removed from the product before it is discarded. The
product must be powered off when the battery is removed, and the battery
should be safely disposed of. To remove the battery:
1. Ask the service personnel to remove the battery case.
2. Remove the fixing screws from the battery case.
3. Open the battery case and remove the battery.
4. The battery must be safely disposed of.
41) Do not overcharge otherwise it may damage the battery and affect usage.
SAVE THESE INSTRUCTIONS
This product is intended for household use only.
Warranty is subjected to cancellation if the product is used for commercial
purposes.

5
Names of parts and functions
1. Power button
2. Charging status LED indicator
3. Speed mode LED indicator
4. Lanyard
5. Massage head
6. Handle grip
7. Type-C USB jack
*Product images are for illustrative purposes only and are not drawn to scale.
Main Unit
1
2
3
33
4
5
6
7

6
Names of parts and functions
Accessory
Note
•Product will have its own USB cable, please use only this cable for
charging.
•Product comes with 4 massage heads , do NOT use other massage
heads that are NOT intended for this product.
1
2
1. 4 types of massage head (Ball, Bullet, Flat, U-Shape)
2. USB cable

7
Preparation for Operation
•Product should be fully charged prior to using it for the first time.
•Connect the USB cable to electronic devices such as laptop, USB
wall power adaptor or portable charger.
•Insert the USB cable into the USB jack of the product.
•Do not operate the product while charging or in environment
with water.
•Each full charge (approximately 4 hours) lasts up to 4 hours of
usage (Usage time varies base on the program selected).
•The charging status LED indicator will emit a solid red light when
the battery is running low.
•The charging status LED indicator will emit a blinking red light
while charging.
•The charging status LED indicator will emit a solid white light
when the battery is fully charged.
•Only available at 5 V as indicated on the product.
Charging the product

8
Caution
•Press and hold the power
button [ ] for 2 seconds, to
power ON the product and it
will be at ‘Low’ speed mode.
The speed Low LED indicator
will light up.
•Press again [ ] for ‘Med’
speed mode. The speed Med
LED indicator will light up.
•Press again [ ] for ‘High’
speed mode. The speed High
LED indicator will light up.
•Press again [ ] for stop
product.
•Press again [ ] for ‘Low’
speed mode, cycle repeat.
•Press and hold the power
button [ ] for 2 seconds, to
power OFF the product.
•If you do not operate product
for more than 30 seconds,
product will power OFF
automatically.
•Place uZap Gun Mini against
your tired muscles.
Start/Stop the
massage function
Preparation for Operation
•Using ‘High’ speed mode
upon switching on the product
may cause muscle pain. It
is recommended to start on
‘Low’ speed mode before
changing to higher speeds.
•Only use the provided USB
cable to charge product.

9
Recommended muscle group area
•Do not use the product to massage on one spot for more than 30
seconds.
Note

10
Caution
Recommended muscle group area
•Do not massage on the any muscle group for more than 10 mins.
•Recommend to start with low intensity and slowly increase to
max intensity after the muscle group “loosen” up.
•Do not use product on neck, head or any hard areas of the body.
Do not use on bones. Use the product only on soft tissue of body.
•Stop operation immediately if you experience any discomfort.
•It is recommended that you wear proper workout attire when
using product.
•To avoid injury, do not touch the parts as shown below while the
product is in operation.

11
Product care and storage
Product placement and storage
Environmental factors can strongly affect the product physically and mechanically.
Do not expose the product to direct sunlight or in places with extreme heat or
air-conditioning vents. These can cause the handle grip to dry up, crack or the color
to fade.
If the product is not to be used for a long period of time, cover it with a dust cover.
Clean the product using a dry cloth regularly
Before cleaning, ensure that the product is turned OFF and the USB cable is
disconnected from the product.
The massage head of the product is customarily exposed to the natural body oils of
users. The whole unit can be cleaned thoroughly with a piece of soft, dry cloth. The
common micro-fibre cleaning materials or gloves are very well suited for this routine
maintenance process. Such materials and gloves are available for sale in most DIY
shops.
Do NOT use wet elements for cleaning
The product is made up of electrical components and mechanical parts, which are
all very sensitive to moisture. Under no circumstances should they be exposed to
any form of water or moisture.
Do NOT use cleaning solvents
Under no circumstances should you use any cleaning agents, like benzene or
thinner to clean the product. This may cause the color of the product to fade.
Do NOT attempt to repair your product
Under no circumstances should you attempt to repair the product, for safety
reason.
If you suspect a malfunction, always call the OSIM Service Center for further
assistance and information.

12
Troubleshooting
If you encounter problems operating the product, please check the following
points for rectification. If the problems persist, please switch off the product,
and contact the OSIM Service Center* for servicing.
Do not disassemble or attempt to repair the product yourself. Doing
so will void the warranty and OSIM will not be responsible for any
subsequent consequences.
•Ensure that the you press and hold power
button [ ] for 2 seconds.
•The battery level is low. Recharge the
battery before attempting to use the
product.
•The overcurrent protection device may
have been activated. Turn OFF the
product and allow it to cool down for at
least 30 minutes before using it again.
Problem Possible causes / actions
•Product will not start.
•The massage stops
midway.
•The auto timer of 10 minutes may have
lapsed.
•The battery level is low. Recharge the
battery before attempting to use the
product.
•The force applied on muscle is too strong
and cause the safety features to activate.
Please restart the device.
•The overcurrent protection device may
have been activated. Turn OFF the product
and allow it to cool down for at least 30
minutes before using it again.

13
* Please visit us at www.OSIM.com for information on the nearest service center.
Product warranty is valid only in the country of purchase.
•Stop use product immediately. The
overcurrent protection device may have
been activated. Turn OFF the product
and allow it to cool down for at least 30
minutes before touch it again.
•If the same problem persists, contact
OSIM Service Center immediately.
Problem Possible causes / actions
•Product gets hot in
hand.
• Power cord and plug are
abnormally hot.
Troubleshooting

14
Model name OSIM uZap Gun Mini
Model number OS-2221
Rated Input 5 V 2 A
Auto timer 10 minutes
Dimension: 80 (L) x 40 (W) x 147 (H) mm
Net weight Approx. 390 g
Gross weight Approx. 813 g
Specifications

15
Notes

16
Notes

1
感谢您购买 OSIM uZap Gun Mini 按摩器（傲胜劲速筋膜枪
Mini）。使用前请仔细阅读操作手册，并特别注意安全事项，
以便正确操作和使用本产品。
本手册提供使用者安全及有效的操作方式，请在阅毕后妥为
收藏，以便日后参考查询。
OS-2221 uZap Gun Mini
简体中文
目录 | 安全事项 2
配件名称与功能 5
操作方式 7
建议适用的肌肉群 9
产品保养及收纳 11
故障排除 12
规格说明 13

2
重要安全事项说明
使用本产品时，请特别注意并遵守下列安全事项：
使用本产品前，请先详阅所有的说明。
危险- 为降低触电风险，请遵照下列指示：
使用完毕后或清洁前，请将电源线插头 /USB 电缆由插座中拔除。
警告- 为降低火灾、灼伤、触电、或是造成他人受伤的风险，请遵照下列
指示：
1） 请务必依照使用手册中所叙述的用途使用本产品。请勿使用非制造商所推
荐的零配件。
2) 接通电源后，请看顾好产品。不使用产品时或组装和拆卸配件前，请切断
电源。
3) 请勿在毯子或枕头下使用产品。过热可能会造成火灾、灼伤、触电或人员
受伤。
4) 如果电源接口松动，请勿使用产品。
5) 手上潮湿时，请勿开关电源或碰触电源插头 /USB 电缆与电源插座/电源。
6) 切断电源后，请握住插头 /USB 电缆接头将其拔出，请勿拉扯电源线/电
缆。
7) 如果产品的电源线或插头/USB电缆出现损坏故障、电源故障或掉入水中，
请勿使用产品。电源意外恢复时，可能会造成人员伤害。请将产品退回
OSIM 傲胜服务中心进行检查和维修。
8) 如果电源插头/USB 电缆或电源线出现损坏，必须由 OSIM 傲胜服务中心
或其授权服务代理更换。
9) 请勿拉扯或把电源线/USB 电缆当作握把使用。
10) 请勿将电源线/USB 电缆放在加热表面上。
11) 请勿将电源线/USB 电缆放在产品或任何重物下方。
12) 请勿将电源线 /USB 电缆缠绕在产品上。
13) 若产品出气口阻塞，请勿使用产品。请保持出气口通畅无阻，不被棉屑，
毛发等阻塞。
