1 Foreword
INFORMATION
Last update: 2015-05-18
►Please read this document carefully before using the product.
►Follow the safety instructions to avoid injuries and damage to the product.
►Instruct the user in the proper and safe use of the product.
►Please contact the manufacturer if you have questions about the product (e.g.regarding the start-up, use,
maintenance, unexpected operating behaviour or circumstances). Contact information can be found on the
back page.
►Please keep this document in a safe place.
The product "Kenevo 3C60/3C60=ST" is referred to as the product/prosthesis/knee joint below.
These instructions for use provide you with important information on the use, adaptation and handling of the
product.
Only put the product into use in accordance with the information contained in the accompanying documents sup
plied.
2 Product Description
2.1 Design
The product consists of the following components:
1. Proximal pyramid adapter
2. LED (blue) as indicator for the Bluetooth connec
tion
3. Battery and cover caps
4. Hydraulic unit
5. Receiver of the inductive charging unit
6. Distal tube clamp screws
7. Connecting cable for tube adapter
2.2 Function
This product features microprocessor control of the stance and swing phase.
The microprocessor uses the measurements of an integrated sensor system as a basis to control a hydraulic unit
that influences the damping behaviour of the product.
These sensor data are updated and evaluated 100 times per second. As a result, the behaviour of the product is
adapted to the current motion situation (gait phase) dynamically and in real time.
Thanks to the microprocessor-controlled stance and swing phase, the system can be individually adapted to the
needs of the patient.
For this purpose, the product is configured with the "K-Soft" adjustment software.
Through the adjustment software, it is possible to choose from three activity modes that make the various functions
of the product available. This permits optimum adaptation of the product to the corresponding mobility grade of the
patient. The configured activity mode cannot be changed by the patient.
In case of a system malfunction, safety mode makes restricted operation possible. Predefined resistance paramet
ers are configured in the product for this purpose (see Page28).
The microprocessor-controlled hydraulic unit offers the following advantages
• Stability while standing and walking
Ottobock | 7Kenevo 3C60/3C60=ST
Foreword

• Smooth, harmonious, quiet initiation of the swing phase
• Automatic recognition of sitting down. Manual unlocking of the joint not required.
• Support while sitting down with individually adaptable resistance
• Support while standing up. The knee joint can be loaded even before reaching full extension.
• Approximation of the physiological gait pattern
• Adaptation of product characteristics to various surfaces, inclines, gait situations and walking speeds
2.3 Combination Possibilities
This product can be combined with the following Ottobock components:
Adapters
• Double adapter: 4R72=32
• Double adapter: 4R72=45
• Double adapter: 4R72=60
• Double adapter: 4R72=75
• Double adapter: 4R76
• Double adapter: 4R78
• 4R104=60 double adapter, sliding
• 4R104=75 double adapter, sliding
• 4R57, 4R57=ST rotation adapter
• 4R89 lamination anchor with pyramid adapter
• 4R41 lamination anchor with pyramid receiver
• Lamination anchor with pyramid receiver and
angled arm: 4R119
• 4R43 lamination anchor with threaded connector
• 4R40 torsion adapter
• 4R118 adapter plate
AXON tube adapter
AXON tube adapter: 2R17
Cosmetic cover
• Foam cover: 3S26
Prosthetic feet
The maximum allowable patient weight depends on the foot size.
• Cosmetic light foot: 1G6
• Pedilan single axis foot, light: 1G9
• Single axis foot without toes: 1H32 or 1H34
(depending on the heel height)
• Single axis foot with toes: 1H38 or 1H40 (depend
ing on the heel height):
• SACH foot with toes: 1S49, 1S66, or 1S67
(depending on the heel height and foot shape):
• SACH Foot with toes and abducted big toe: 1S90
• 1D10 Dynamic foot
• Dynamic foot without adapter: 1D10
• 1D11 Dynamic foot (women)
• 1M10 Adjust
• 1A30 Greissinger plus
• Terion: 1C10
• 1C30 Trias
• 1D35 Dynamic Motion
3 Application
3.1 Indications for use
The product is to be used solely for lower limb prosthetic fittings.
3.2 Area of Application
Area of application according to the MOBIS mobility system:
Activity mode A (locked mode)
°
kg
Recommended for mobility grade1(indoor walker). Approved for a body weight of max.125kg.
8 | Ottobock
Application
Kenevo 3C60/3C60=ST

Activity mode B (semi-locked mode)
°
kg
Recommended for mobility grades 1and2 (indoor walkers and restricted outdoor walkers).
Approved for a body weight of up to 125kg.
Activity mode C (yielding mode)
°
kg
Recommended for mobility grade 2 (restricted outdoor walker). Approved for a body weight of
up to 125kg.
3.3 Conditions of use
The product was developed for everyday use and should not be used for walking speeds over 3km/h or unusual
activities. These unusual activities include, for example, extreme sports (free climbing, parachuting, paragliding,
etc.).
Permissible ambient conditions are described in the technical data (see Page33).
The prosthesis is intended for use exclusively on the patient for whom the adjustment was made. The manufac
turer does not authorise use of the prosthesis on another person.
3.4 Indications
• For patients with knee disarticulation and transfemoral amputation
• For unilateral amputation
• Dysmelia patients with residual limb characteristics corresponding to knee disarticulation or a transfemoral
amputation
• The patient must fulfil the physical and mental requirements for perceiving visual/acoustic signals and/or mech
anical vibrations.
3.5 Qualification
The product may be fitted only by qualified personnel authorised by Ottobock after completing the corresponding
training.
4 Safety
4.1 Explanation of Warning Symbols
WARNING Warning regarding possible serious risks of accident or injury.
CAUTION Warning regarding possible risks of accident or injury.
NOTICE Warning regarding possible technical damage.
4.2 Structure of the safety instructions
CAUTION
The heading describes the source and/or the type of hazard
The introduction describes the consequences in case of failure to observe the safety instructions. Consequences
are presented as follows if more than one consequence is possible:
> E.g.: Consequence 1 in case of failure to observe the hazard
> E.g.: Consequence 2 in case of failure to observe the hazard
►This symbol identifies activities/actions that must be observed/carried out in order to avert the hazard.
Ottobock | 9Kenevo 3C60/3C60=ST
Safety

4.3 General Safety Instructions
WARNING
Use of damaged power supply unit, adapter plug or battery charger
Risk of electric shock due to contact with exposed, live components.
►Do not open the power supply unit, adapter plug or battery charger.
►Do not expose the power supply unit, adapter plug or battery charger to extreme loading conditions.
►Immediately replace damaged power supply units, adapter plugs or battery chargers.
CAUTION
Failure to observe warning/error signals
Falling due to unexpected product behaviour because of changed damping behaviour.
►The warnings/error signals (see Page32) and corresponding change in damping settings must be observed.
CAUTION
Independent user manipulation of system components
Falling due to breakage of load-bearing components or malfunction of the product.
►Manipulations to the product other than the tasks described in these instructions for use are not permitted.
►The battery may only be handled by Ottobock authorised, qualified personnel (no replacement by the user).
►The product and any damaged components may only be opened and repaired by authorised, qualified
Ottobock personnel.
CAUTION
Mechanical stress on the product
> Falling due to unexpected product behaviour as the result of a malfunction.
> Falling due to breakage of load-bearing components.
> Skin irritation due to defects on the hydraulic unit with leakage of liquid.
►Do not subject the product to mechanical vibrations or impacts.
►Check the product for visible damage before each use.
CAUTION
Use of the product when battery charge level is too low
Falling due to unexpected behaviour of the prosthesis because of changed damping behaviour.
►Check the current charge level before use and charge the prosthesis if required.
►Note that the operating time of the product may be reduced at low ambient temperatures or due to ageing of
the battery.
CAUTION
Risk of pinching in the joint flexion area
Injuries due to pinching of body parts.
►Ensure that fingers and other body parts are not in this area when bending the joint.
CAUTION
Penetration of dirt and humidity into the product
> Falling due to unexpected product behaviour as the result of malfunction.
> Falling due to breakage of load-bearing components.
►Ensure that neither solid particles, foreign objects nor liquids penetrate into the product.
►Do not expose the product to splashed water.
►In the rain, thick clothing should be worn over the product as a minimum.
10 | Ottobock
Safety
Kenevo 3C60/3C60=ST

CAUTION
Overloading due to unusual activities
> Falling due to unexpected product behaviour as the result of malfunction.
> Falling due to breakage of load-bearing components.
> Skin irritation due to defects on the hydraulic unit with leakage of liquid.
►The product was developed for everyday use and must not be used for unusual activities. These unusual activ
ities include, for example, extreme sports (free climbing, paragliding, etc.).
►Careful handling of the product and its components not only increases their service life but, above all, ensures
the patient's personal safety!
►If the product and its components have been subjected to extreme loads (e.g. due to a fall, etc.), then the
product must be inspected for damage immediately. If necessary, forward the product to an authorised
Ottobock Service Centre.
CAUTION
Mechanical stress during transport
> Falling due to unexpected product behaviour as a result of a malfunction.
> Falling due to breakage of load-bearing components.
> Skin irritation due to defects on the hydraulic unit with leakage of liquid.
►Only use the transport packaging for transportation.
CAUTION
Signs of wear to system components
Falling due to damage or malfunction of the product.
►In the interest of the patient's safety and in order to maintain operating reliability, the product should be ser
viced at regular intervals.
NOTICE
Improper product care
Damage to the product due to the use of incorrect cleaning agents.
►Only clean the product with a damp cloth and mild soap (e.g. 453H10=1 Ottobock DermaClean).
INFORMATION
When using exoprosthetic knee joints, servomotor, hydraulic, pneumatic or brake load dependent control func
tions can cause movement noise. This kind of noise is normal and unavoidable. It generally does not cause any
problems. If movement noise increases noticeably during the lifecycle of the knee joint, the knee joint should be
inspected by an authorised Ottobock Service Centre immediately.
4.4 Information on the Power Supply/Battery Charging
CAUTION
Charging the prosthesis without taking it off
Falling due to unexpected behaviour of the prosthesis because of changed damping behaviour.
►Instruct the patient that the prosthesis must be taken off before it is charged.
CAUTION
Charging the product with damaged power supply unit/charger/charger cable
Falling due to unexpected behaviour of the product caused by insufficient charging.
►Check the power supply unit, charger and charger cable for damage before use.
►Replace any damaged power supply unit, charger or charger cable.
Ottobock | 11Kenevo 3C60/3C60=ST
Safety

NOTICE
Use of incorrect power supply unit/battery charger
Damage to product due to incorrect voltage, current or polarity.
►Use only power supply units/battery chargers approved for this product by Ottobock (see instructions for use
and catalogues).
4.5 Battery charger information
NOTICE
Penetration of dirt and humidity into the product
Lack of proper charging functionality due to malfunction.
►Ensure that neither solid particles nor liquids can penetrate into the product.
NOTICE
Mechanical stress on the power supply/battery charger
Lack of proper charging functionality due to malfunction.
►Do not subject the power supply/battery charger to mechanical vibrations or impacts.
►Check the power supply/battery charger for visible damage before each use.
NOTICE
Operating the power supply unit/charger outside of the permissible temperature range
Lack of proper charging functionality due to malfunction.
►Only use the power supply unit/charger for charging within the allowable temperature range. The section
"Technical data" contains information on the allowable temperature range (see Page33).
NOTICE
Independent changes or modifications carried out to the battery charger
Lack of proper charging functionality due to malfunction.
►Have any changes or modifications carried out only by Ottobock authorised, qualified personnel.
NOTICE
Contact of the battery charger with magnetic data storage devices
Wiping of the data storage device.
►Do not place the battery charger on credit cards, diskettes, audio or video cassettes.
4.6 Information on Alignment/Adjustment
CAUTION
Use of unsuitable prosthesis components
Falling due to unexpected behaviour of the product or breakage of load-bearing components.
►Use the product only in combination with components listed in the section "Combination possibilities" (see
Page8).
CAUTION
Improper assembly of the screw connections
Falling due to breakage or loosening of the screw connections.
►Clean the threads before every installation.
►Apply the specified installation torque values.
►Observe the instructions for securing the screw connections and the use of the correct length.
CAUTION
Incorrect alignment or assembly
Falling due to damage to the prosthesis components.
►Observe the alignment and assembly instructions.
12 | Ottobock
Safety
Kenevo 3C60/3C60=ST

CAUTION
Errors during prosthesis alignment
Falling due to breakage of load-bearing components.
►At maximum flexion (reached under full load!), it is essential to maintain a minimum distance of 3 mm (1/8")
between the hydraulic unit and the socket.
►At maximum flexion and insofar as contact with the frame of the knee joint cannot be avoided (in case of volu
minous residual limbs), the socket must lie flat on the frame. Soft cushioning at the socket will assist in main
taining the socket flat.
CAUTION
Disconnecting/establishing the connection during the adjustment process with the adjustment software
Falling due to unexpected behaviour of the product.
►When wearing the product, the patient must not remain unattended during the configuration process while
connected to the adjustment software.
►Observe the maximum range of the Bluetooth connection.
►During the data transfer (PC to product), the patient must stand or sit without moving.
►If the connection fails while making adjustments, the prosthetist must immediately warn and secure the
patient.If the connection fails while making adjustments, the prosthetist must immediately warn and secure the
patient.
►The connection to the product must always be disconnected after adjustments have been completed.
CAUTION
Insufficient insertion depth of the tube adapter
Falling due to breakage of load-bearing components.
►Insert the tube adapter at least 40mm to ensure operational safety.
►The patient must be seated for length adjustments.
CAUTION
Operator errors during the adjustment process with the adjustment software
Falling due to unexpected behaviour of the product.
►Participation in an Ottobock product training course is mandatory prior to using the product. Additional
product training courses may become necessary to qualify for software updates.
►Correctly entering the foot size, the prosthesis dimensions and the body weight are important criteria for the
quality of the fitting. If the values are too high, the prosthesis may not switch to the swing phase. If the values
are too low, the prosthesis may trigger the swing phase at the wrong time.
►Always enter the weight in the specified unit.
►Ensure that the required dimensions are selected and entered correctly.
►If the patient uses walking aids (e.g. crutches or walking canes) during the adjustment process, readjustment
is required as soon as the patient stops using these walking aids.
CAUTION
Error during optimisation of damping behaviour
Falling due to unexpected behaviour of the product.
►Note that the patient must stand very securely during this procedure to ensure safety.
Ottobock | 13Kenevo 3C60/3C60=ST
Safety

4.7 Information on Proximity to Certain Areas
CAUTION
Distance to HF communication devices is too small (e.g. mobile phones, Bluetooth devices, WiFi
devices)
Falling due to unexpected behaviour of the product caused by interference with internal data communication.
►Therefore, keeping the following minimum distances to these HF communication devices is recommended:
• Mobile phone GSM 850/GSM 900: 0.50m
• Mobile phone GSM 1800/GSM 1900/UMTS: 0.35 m
• DECT cordless phones incl. base station: 0.18 m
• WiFi (routers, access points,…): 0.11 m
• Bluetooth devices (third-party products not approved by Ottobock): 0.11 m
CAUTION
Proximity to sources of strong magnetic or electrical interference (e.g. theft prevention systems, metal
detectors)
Falling due to unexpected behaviour of the product caused by interference with internal data communication.
►Ensure that the patient is not in the vicinity of sources of strong magnetic and electrical interference during tri
al fitting (e.g. computer tomographs, magnetic resonance tomographs ...).
If this cannot be avoided, ensure at least that the patient is able to walk or stand securely (e.g. by using a
handrail or the support of another person).
CAUTION
Remaining in areas outside the allowable temperature range
Falling due to malfunction or the breakage of load-bearing product components.
►Ensure that the patient is not in areas outside the permissible temperature range (see Page33) during trial fit
ting.
4.8 Information on Use
CAUTION
Walking up stairs
Falling due to foot being placed incorrectly on stair as a result of changed damping behaviour.
►Inform the patient that the handrail always has to be used when walking up stairs, and that most of the sole of
the foot has to be set onto the stair surface.
►Particular caution is required when carrying children up the stairs.
CAUTION
Walking down stairs
Falling due to foot being placed incorrectly on stair as a result of changed damping behaviour.
►Inform the patient that the handrail always has to be used when walking down stairs, and that the patient has
to roll over the edge of the step with the middle of the shoe.
►The warnings and error signals have to be observed (see Page32).
►Notify the patient that resistance in the flexion and extension direction can change in case of warnings and
error signals.
►Particular caution is required when carrying children down the stairs.
14 | Ottobock
Safety
Kenevo 3C60/3C60=ST

CAUTION
Overheating of the hydraulic unit due to uninterrupted, increased activity (e.g. extended walking down
hill)
> Falling due to unexpected behaviour of the product because of switching into overheating mode.
> Burns due to touching overheated components.
►Be sure to pay attention when pulsating vibration signals start. They indicate the risk of overheating.
►As soon as these pulsating vibration signals begin, the activity level has to be reduced so the hydraulic unit
can cool down.
►Full activity may be resumed after the pulsating vibration signals stop.
►If the activity level is not reduced in spite of the pulsating vibration signals, this could lead to the hydraulic ele
ment overheating and, in extreme cases, cause damage to the product. In this case, the product should be
inspected by an authorised Ottobock Service Centre.
CAUTION
Overloading due to unusual activities
> Falling due to unexpected product behaviour as the result of a malfunction.
> Falling due to breakage of load-bearing components.
> Skin irritation due to defects on the hydraulic unit with leakage of liquid.
►The product was developed for everyday use and must not be used for unusual activities. These unusual activ
ities include, for example, sports that require continuous high walking speeds (running ...) or extreme sports
(free climbing, parachuting, paragliding, etc.).
►Careful handling of the product and its components not only increases their service life but, above all, ensures
the patient's personal safety!
►If the product and its components have been subjected to extreme loads (e.g. due to a fall, etc.), then the
product must be inspected for damage immediately. If necessary, forward the product to an authorised
Ottobock Service Centre.
4.9 Notes on the safety modes
CAUTION
Using the product in safety mode
Falling due to unexpected product behaviour because of changed damping behaviour.
►The warnings/error signals (see Page32) have to be observed.
CAUTION
Safety mode cannot be activated due to malfunction caused by water penetration or mechanical damage
Falling due to unexpected product behaviour because of changed damping behaviour.
►Using the product when it is defective is prohibited.
►The product must be inspected by an authorised Ottobock Service Centre.
CAUTION
Safety mode cannot be deactivated
Falling due to unexpected product behaviour because of changed damping behaviour.
►If safety mode cannot be deactivated by recharging the battery, a permanent error has occurred.
►Using the product when it is defective is prohibited.
►The product must be inspected by an authorised Ottobock Service Centre.
CAUTION
Safety signal occurs (ongoing vibration)
Falling due to unexpected product behaviour because of changed damping behaviour.
►Observe the warning/error signals (see Page32).
►After the safety signal has been emitted, further use of the product is prohibited.
►The product must be inspected by an authorised Ottobock Service Centre.
Ottobock | 15Kenevo 3C60/3C60=ST
Safety

5 Scope of Delivery and Accessories
Scope of Delivery
• 1pc. Kenevo 3C60=ST (with threaded connector) or
• 1pc. Kenevo 3C60 (with pyramid connector)
• 1 pc. AXON tube adapter 2R17
• 1 pc. 757L16* power supply
• 1pc. 4E70* inductive charger
• 1pc. 647G947 instructions for use (qualified personnel)
• 1pc. 646D700, 646D700=1 instructions for use (user)
• 1pc. cosmetic case for battery charger and power supply
• 1 pc. 647F507 prosthesis passport
• 1 pc. card holder for prosthesis passport
Accessories
The following components are not included in the scope of delivery and may be ordered separately:
• 3S26 cosmetic foam cover
• Kenevo Protector 4X840
• "K-Soft 4X445=*" adjustment software
6 Charging the prosthesis battery
The following points must be observed when charging the battery:
• The capacity of a fully charged battery is sufficient for one full day.
• We recommend charging the product overnight when used by the patient on a daily basis.
• When used daily, the complete charging unit (power supply – battery charger) may remain plugged into the
wall socket.
• The battery should be charged for at least 3 hours prior to initial use.
• Note the permissible temperature range for charging the battery (see Page33).
• Use the 757L16* power supply and 4E70* battery charger to charge the battery.
• The tube adapter must be connected before disconnecting the battery charger, otherwise an error message
will result (see Page32).
6.1 Connecting the power supply and battery charger
1 2 3
1) Slide the country-specific plug adapter onto the power supply until it locks into place (see fig.1).
2) Connect the round, three-pin plug of the power supply to the receptacle on the inductive charger so that the
plug locks into place. (see fig.2)
INFORMATION: Ensure correct polarity (guide lug). Do not use force when connecting the cable plug
to the battery charger.
3) Plug the power supply unit into the outlet (see fig.3).
→The green LED on the back of the power supply lights up.
→The yellow LED on the inductive charger lights up briefly to indicate the correct connection to the power
supply.
→If the green LED on the power supply does not light up and the yellow LED on the inductive charger does not
light up briefly while connecting the cable, there is an error (see Page32).
16 | Ottobock
Scope of Delivery and Accessories
Kenevo 3C60/3C60=ST

6.2 Connect battery charger to the product
INFORMATION
Do not move the knee joint while it conducts the self-test immediately after disconnecting the charger. Otherwise,
an error may occur; if this happens, the problem can be corrected by reconnecting and then disconnecting the
charger.
1) Connect the inductive charger to the receiver of the charging unit on the rear of
the product. The charger is held in place by a magnet.
→The correct connection of the battery charger to the product is indicated by
feedback (see Page33).
2) The charging process starts.
→Once the product battery is fully charged, the LED on the battery charger
lights up green.
3) After the charging process is complete, hold the product still and remove the
inductive charger from the receiver.
→A self-test is performed. The joint is operational only after corresponding
feedback (see Page33).
INFORMATION
To make the operating time of the prosthesis as long as possible, the charger should not be removed until imme
diately before the prosthesis is used.
Indication of the charging process:
Charger
Battery is charging.
The on time of the LED indicates the current battery charge level.
The on time of the LED gets longer as the charge level increases. It only flashes briefly at the start
of the charging process and stays on continuously at the end of the charging process.
Battery is fully charged, or the temperature fell above/below the permissible range during charging.
Check current charge level (see Page17).
6.3 Display of the current charge level
1) Turn the prosthesis 180° (the sole of the foot has to face up).
2) Hold still for 2 seconds and wait for beeps.
Beep signal Vibration signal Battery charge level
5x short more than 80%
4x short 66% to 80%
3x short 51% to 65%
2x short 36% to 50%
1x short 3x long 20% to 35%
1x short 5x long less than 20%
Ottobock | 17Kenevo 3C60/3C60=ST
Charging the prosthesis battery

7 Preparation for Use
7.1 Alignment
7.1.1 Shortening the Tube Adapter
CAUTION
Incorrect processing of tube
Falling due to damage to the tube.
►Do not clamp the tube into a vice.
►For shortening the tube, use only a tube cutter.
CAUTION
Damage to the cable while shortening the tube adapter
Falling due to unexpected product behaviour as the result of switching into safety mode.
►When shortening the tube adapter, make sure the cable does not get damaged.
1) Determine the required length of the tube adapter using the configuration assistant in the adjustment software.
2) Shorten the tube adapter to the determined value with the 719R3 tube cutter.
3) Smooth the cutting surface with a deburring knife (e.g. 718S2) and sandpaper.
NOTICE! In case of raised material at the outer edge due to shortening the tube adapter, smoothing
this by machine is mandatory. Carefully deburr the inside to prevent damage to the tube adapter
cable.
7.1.2 Installing the Tube Adapter
CAUTION
Improper assembly of the screw connections
Falling due to breakage or loosening of the screw connections.
►Clean the threads before every installation.
►Apply the specified installation torque values.
►Observe the instructions for securing the screw connections and the use of the correct length.
1) Install the prosthetic foot on the tube adapter and tighten the set screws on the tube adapter to a torque of
15Nm.
INFORMATION: The printed scale on the tube adapter has to face forward.
2) Connect the cable of the tube adapter to the cable of the knee joint.
3) Push the protruding cable loop back into the tube adapter. When the tube adapter has been shortened to the
minimum length, the plug must be inserted in the cavity. The cable loop must then be stored carefully.
4) Insert the tube adapter about 60mm into the knee joint (for the exact value, consult the configuration assistant
in the adjustment software).
INFORMATION: Corrections in the insertion depth between 40mm and 73mm are permissible (slide
in 13mm and pull out 20mm).
5) Turn the foot outwards slightly and tighten the two distal tube clamp screws lightly (approx. 4Nm).
INFORMATION: After alignment optimisation, these two screws must be gradually tightened, alternat
ing between them, until a torque of 7Nm is reached. When loosening the screws, it is also necessary
to alternate between them and proceed gradually.
INFORMATION
A calibration procedure must be performed after each change to the tube adapter, prosthetic foot or knee joint
using the adjustment software.
INFORMATION
If the tube adapter is disconnected while the knee joint is operational, an error message is output. To prevent this
error message, the knee joint must be switched off before the tube adapter is disconnected (see Page27).
18 | Ottobock
Preparation for Use
Kenevo 3C60/3C60=ST

7.1.3 Bench alignment in alignment apparatus
INFORMATION
The alignment recommendations must be observed in order for the prosthesis to function correctly.
INFORMATION
Before beginning the alignment, the prosthesis must be put into alignment mode using the adjustment software.
Only in alignment mode is the knee joint automatically locked in the flexion direction to allow for static alignment to
be carried out correctly.
INFORMATION
The patient's gait pattern shall change as he/she becomes accustomed to the prosthesis.
Therefore it is recommended to complete the entire adjustment procedure again about two weeks after the initial
fitting.
A correct bench alignment (e.g. using the 743A200 PROS.A. Assembly alignment apparatus) ensures that the user
can benefit from all the advantages of the product. If the L.A.S.A.R. Assembly alignment apparatus (743L200) is
available, it can be used as well. The position of the residual limb must be taken into account when positioning the
socket connector. Plumb lines in the frontal and sagittal planes (drawn from the hip joint's centre of rotation and
marked during plaster cast taking and trial fitting of the check socket) will facilitate correct positioning of the lamin
ation anchor or socket adapter.
Position the middle of the foot (MF) approx. 30mm/1.18inch
anterior to the alignment reference line (A). This applies to all
foot components that are recommended for use with the product,
independently of the previous alignment specifications in the
instructions for use of those feet!
Noting the alignment recommendation of the foot component,
add 5mm to the effective heel height (shoe heel height – sole
thickness in the forefoot area) and set the outward rotation of the
foot.
Place the alignment reference point (=knee axis) approx. 0-5
mm/0-0.19inch anterior to the alignment reference line.
Take into account the knee-ground distance and outward rotation
of the knee (the adapter insert provides for a rotation of approx.
5°). Recommended sagittal positioning of the alignment refer
ence point: 20 mm/0.79inch above the medial tibial plateau.
Connect the foot and knee joint using a tube adapter. To do so,
tilt the joint in the correct position and set the required tube
length.
Mark the lateral centre of the socket with a centred, proximal dot
and a distal dot. Mark a line through both points from the edge to
the end of the socket.
Now position the socket such that the alignment reference line
passes through the proximal centre mark.
Adjust the socket flexion to 3° – 5°, but take the individual situ
ation (e.g. hip joint contractures) and the ischial tuberosity-to-
ground distance into account.
Connect the socket and modular knee using adapters.
7.1.4 Static alignment optimisation
Static alignment can be substantially improved using the L.A.S.A.R. Posture (743L100=*). In order to achieve
adequate safety while simultaneously providing easy swing phase initiation, please proceed with alignment as fol
lows:
Ottobock | 19Kenevo 3C60/3C60=ST
Preparation for Use

To determine the load line, have the patient (with shoes) stand on
the force measuring plate with the prosthetic side and on the
height compensation plate with the other leg.
The prosthesis side must be sufficiently loaded (>35% body
weight). Note the weight display on the L.A.S.A.R. Posture.
Optimise the alignment solely by changing the plantar flexion.
Only make adjustments to the distal and proximal setscrews of
the socket adapter on the prosthetic foot, so that the load line
(laser line) runs approx. 30mm/1.18inch in front of the align
ment reference point (= knee axis) for the knee joint.
7.1.5 Dynamic alignment optimisation
After adjusting the product with the adjustment software, perform dynamic optimisation during trial walking. Often,
the following aspects have to be observed and adapted, if necessary:
• Socket flexion position by verifying step length symmetry (sagittal plane)
• Adduction position of the socket and M-L positioning of the socket adapter (frontal plane)
• Rotation position of the knee joint axis and outward rotation of the prosthetic foot (transversal plane)
7.1.6 Torque values of the screw connections
CAUTION
Incorrectly secured screws
Falling due to breakage of load-bearing components caused by screw connections coming loose.
►After completing all settings, the set screws in the tube adapter must be secured before they are tightened to
the specified torque.
►The screws in the clamp bracket must not be secured but only tightened to the specified torque.
Using the 710D4 torque wrench, tighten the corresponding screws alternately in several cycles until the specified
torque is reached.
Screw connection Torque
Tube adapter on prosthetic foot 15Nm/133lbf. In.
Clamp bracket on knee joint 7Nm/62lbf. In.
Fitting for short residual limb
Rotation adapter or sliding adapter
15Nm/133lbf. In.
Fitting for long residual limb
Lamination anchor with threaded connector
10Nm/89lbf. In.
20 | Ottobock
Preparation for Use
Kenevo 3C60/3C60=ST
