PAX A930 User manual

Note: Product images shown may be different than actual product
received
PAX TECHNOLOGY INC.
Quick Setup Guide
PAX TECHNOLOGY INC.
PAX TECHNOLOGY INC.
A930 Wireless POS Terminal
Device Location
9
Locate the device on a countertop, desktop, or tabletop. Keep the
device away from direct sunlight, excessive dust, moisture, and heat.
Avoid locating the device near electrical devices that might introduce
interference such as microwave ovens and blow dryers.
Cleaning the Device
10
WARNING:
Do not use industrial strength or abrasive cleaner as it may damage or
scratch the screen.
Do not immerse terminal in water or liquid.
Do not spray water or cleaner into card reader or ports.
To clean screen, apply distilled water or mild glass cleaner onto a soft,
lint-free cloth and gently wipe screen.
To clean device, apply distilled water or plastic-safe cleaner onto a soft,
lint-free cloth and wipe gently.
Cleaning the Device
11
1) Avoid exposing the device to an excessively hot, humid, dusty,
and/or strong electromagnetic environment.
2) Do not vibrate, shake, or drop the device.
3) Do not plug or unplug any part of the device while it is powered
on. This may cause damage to the internal circuit.
Lithium Ion Battery Usage Tips
12
1) Do not use the battery in direct sunlight or in smoky or dusty
environments.
2) Do not crush the battery or place it in liquid or fire.
3) Discontinue use if the battery is damaged.
4) Consider replacing the battery when the battery life begins to decline.
5) Only use the appropriate battery and charger for the terminal.
6) Overcharging the terminal can degrade the battery. Do not over-use
the battery or charge the battery longer than 24 hours.
7) If the battery is not used often, please recharge the battery every 6
months to avoid shortening the life of the battery.
8) Replace the battery if it has not been used in 2 years.
9) Dispose of used batteries properly.
Humidity.:5%～96% (non-condensing)
Card Readers
5
Magnetic Stripe Card: Place the card in the slot with the stripe facing
left towards the terminal. Swipe the card through the card slot at a
constant speed. The card can be swiped bi-directionally.
Smart Card: Insert the card into the card slot with the chip facing up.
Push the card in the slot as far as it will go.
Contactless Reader: Place contactless card close to the
Contactless area, located on the top of the terminal.
SIM Cards
6
To insert SIM card, open the battery cover on the bottom of the terminal
and take out the battery. Insert SAM/SIM card into the corresponding
SAM/SIM card slot and replace the battery and battery cover.
SD Card
7
To insert SD card, open the battery cover on the bottom of the terminal
and take out battery. Insert Micro SD card into the corresponding Micro
SD card slot. Replace the battery and the battery cover.
Specifications
8
Operating System: PayDroid powered by Android 7.1
CPU: Quad-core Cortex-A53, 1.4 GHz
Memory: 1GB DDR + 8GB eMMC
Display: 5.5” 720 x 1280 IPS Display
Multi-touch Captivate Display
Printer: 2” High speed thermal printer, supports 58 x 40mm paper
Audio: built-in speaker, supports headphone output
Camera: Front camera: 0.3 Megapixel fixed focal camera and
Rear camera: 5 Megapixel autofocus camera with LED flashligh
L-Sensor (Ambient Light Sensor): Automatically adjusts backlight
brightness of main display
Wireless Communication: Bluetooth® wireless technology, Wi-Fi, and
HotSpot Positioning: supports GPS, Glonass, BeiDou, and Galileo
Card Slots: 1 SIM card slot, 1 Micro SD card slot supports up to
128GB,
Magnetic stripe/IC card slot
Magnetic Card Reader: Complies with standard of ISO7810, ISO7811,
ISO7812, 1/2/3 Track
IC Card Reader: Conforms to the standard of ISO7816, EMV 4.3
L1 & L2, PBOC3.01
Contactless Card Reader: Compatible with ISO14443 Type A & B
Working Environment: Temperature: -10℃～50℃ (14℉～122℉)
Storage Environment: Temperature: -20℃～70℃ (-4℉～158℉)
4) There is a risk of explosion if the battery is replaced with an incorrect
type.
5) Please contact PAX technical support for assistance with the device.

P/N:200312000000XXX
PAX TECHNOLOGY INC.
PAX TECHNOLOGY INC.
This document is provided to you for informational purposes
only. All features and specifications are subject to change
without notice. PAX’s name and PAX’s logo are registered
trademarks of PAX Technology Inc. The Bluetooth® word mark
and logos are registered trademarks owned by Bluetooth SIG, Inc.
and any use of such marks by PAX Technology, Inc. is under
license. Other trademarks and trade names are those of their
respective owners.
Responsible Party:
PAX Technology, Inc.
8880 Freedom Crossing Trail
Building 400, 3rd Floor, Suite 300
Jacksonville, FL 32256, USA
Help Desk
1-877-859-0099
www.pax.us
Contents Checklist
Please check the components after unpacking. If any components are
missing, please contact the dealer.
USB Cable
Product Description
Power ON/OFF
Power on: Press and hold the Power button for five seconds until the
LCD screen lights up.
Red indicator: Device is charging
Green indicator: Charging is complete
Red and green indicators flashing alternately: Charging problem
Power off: Press and hold the Power button for three seconds until the
Shutdown menu appears. Tap Shutdown, then click Shutdown again.
“Shutting” appears on the screen when the terminal is turning off.
Battery charging
User can charge the battery with the power adapter and the charging
status will be displayed on the LCD screen.
Printer Paper
4
To install the paper:
1.Press printer cover button
(see page 2 for location) and
open cover.
Power
3
Smart Card Reader
LCD Display
Front Camera
Power Button
Volume-
Volume+
RF Indicator
Audio Jack
USB
Rear Camera
Base connection
pogo pin
Battery Cover
Speaker
Light Sensor
Magnetic Card Slot
Printer Cover
SIM1 card slot
SAM2/SIM2 card slot
SAM1 card slot
TF card slot
Front View
Left Side View Right Side View
Rear View
SIM and SD Card Slots
2.Insert paper roll with end facing
up and extending out of A930.
3.Gently snap printer cover closed.
To tear the paper, press the paper downward along the cutter and
pull it to the left or right along the cutting edge.
