Polycom SoundPoint IP 650 User manual

Business Voice Systems • Metro Connection Services • Commercial DirecTV • Managed Services • Data
Center
End User Guide
Hosted IP-PBX Phone System
Polycom Model 650 - Handset
Business Voice Systems • Metro Broadband Services • Data Center • Managed IT Services • Commercial DirecTV

3
Table of contents
Table of contents 3
1Introduction –SoundPoint IP 650 Phone 7
1.1 Basic Phone Handset Settings 8
1.2 Soft Keys and Hard Keys9
2Making Calls 10
2.1 Internally 10
2.2 Externally 10
2.3 Redialing Numbers 10
3Answering Calls 11
3.1 Call Waiting (Answering a call when on you are on another call) 11
3.2 Putting an existing call on hold 11
4Forwarding Calls 12
4.1 Introduction 12
4.2 Immediate, Busy and No Answer Call Forwarding using the Handset 13
4.2.1 Enabling 13
4.2.2 Disabling 13
4.2.3 Access Codes 13
4.3 Selective Call Forwarding using the Handset 13
4.4 Remote Access to Call Forwarding 13
5Advanced Call Handling 15
5.1 Transferring Calls15
5.2 Three Way Conference Call 15
5.3 Parking a call (optional feature) 16
5.4 Retrieving a parked call (optional feature) 16
5.5 Enabling Do Not Disturb 17
5.6 Group Pickup 17
5.7 Using Buddy Lists17
5.8 Restarting Your Phone 17
6Voicemail 18
6.1 Setting up Voicemail the first time 18
6.2 Accessing Voicemail 18
6.3 Using the Voicemail system 19
7Using ITS CommPortal (website interface) 20
7.1 Accessing ITS CommPortal 20
7.2 Logging In20
7.3 Using ITS CommPortal 21
7.4 Getting Help 22
7.5 Refreshing a Page 22
7.6 Logging Out 23
8Using ITS CommPortal Dashboard 24

4
8.1 Messages 24
8.2 Missed Calls 25
8.2.1 Call Back 25
8.3 Contacts 26
8.3.1 Calling a Contact 26
8.4 Settings 27
9Messages & Calls 28
9.1 Messages 28
9.1.1 Listen To a Message 29
9.1.2 Deleting a Message 30
9.1.3 Marking a Message as Heard 30
9.1.4 Marking a Message as New 31
9.1.5 Call Back 32
9.1.6 Add Caller to Contacts 32
9.2 Faxes (optional feature) 32
9.3 Missed Calls 33
9.3.1 Add Caller to Contacts 34
9.4 Dialed 34
9.4.1 Add Dialed Number to Contacts 34
9.5 Received 35
9.5.1 Add Number to Contacts 35
10 Contacts 36
10.1 Contact List 37
10.1.1 Searching 37
10.1.2 Add a New Contact 38
10.1.3 Editing a Contact 40
10.1.4 Deleting a Contact 40
10.1.5 Calling a Contact 40
10.1.6 Groups 41
10.2 Speed Dials 43
10.2.1 Adding a Speed Dial 44
10.2.2 Deleting a Speed Dial 45
10.3 Extensions 45
10.4 Short Codes 47
11 Call Manager 48
11.1 Easy Call Manager 49
11.2 Premium Call Manager 50
11.3 Premium Call Manager - Rules Based Routing50
11.4 Premium Call Manager Schedule Based Routing 55
11.5 Premium Call Manager - Special Days (Holidays) 56
12 Additional CommPortal Features 57
12.1 Reminders 57
12.2 Adding Reminders 58
12.3 Deleting Reminders 59
12.4 Comportal Assistant App 59

5
12.5 Call Me App 60
12.6 Click To Dial 60
12.7 Click to Dial - Calling from your Regular Phone 61
12.8 Click To Dial - Calling from Another Number 61
13 Other Hosted IP PBX Features 63
13.1 Business Conference Bridge 63
13.2 How to Use Business Conference Bridge 63
13.3 Moderator Instructions 64
13.4 Participant Instructions 65
13.5 Moderator Commands (telephone key pad) 66
13.6 Moderator Commands - Web Access 67
13.7 Mass Announcement Service 71
13.8 Basic Setup of an Announcement 71

6

7
1 Introduction –
SoundPoint IP 650 Phone
Welcome to your new Polycom Soundpoint IP 650 phone!
This guide will help you get up and running with your new phone as soon as possible.
It tells you how to use your phone handset, the commonly used features and
information on the online web management tool, the ITS Telecom ComPortal.
We’ve also included some of our Hosted IP-PBX system’s optional or advanced
features in this manual of which your company may or may not have included as part
of their service.
If you have any problems or need a more detailed description of the operation of your
phone handset or features, please contact your internal company phone administrator
or your ITS Telecom Business Account Manager.

8
1.1 Basic Phone Handset Settings
Selecting the Ring Type
You can select different ring types to distinguish lines or to distinguish your phone from
your neighbor’s phone.
To change the incoming ring type:
1. Press Menu button.
2. Select Settings > Basic > Ring Type.
3. Use the Up and Down arrows to select the desired ring type.
To hear the selected ring type, press the Play soft key.
4. Press the Select soft key to change to the selected ring type.
5. Press to return to the idle display.
Muting the Microphone
During a call, press . The Message Waiting Indicator turns red and a microphone
on the screen indicates that the other party (or parties) cannot hear you.
Microphone Mute applies to all modes: Handset, Headset, and Speakerphone. You
can still hear all other parties while mute is enabled.
To turn off Microphone Mute, press again.
Adjusting the Volume
Press to adjust receiver volume during a call. And pressing these
keys in the idle state also adjusts the ringer volume.
Managing Call Lists
Your Polycom 55/560 phone maintains local lists of missed, received, and placed calls.
Each list can contain 100 entries.
Press the following to access missed, received, and placed call lists.
Down Arrow = Missed Calls
Left Arrow = Received Calls
Right Arrow = Placed Calls
Manage each call list by doing the following:
• To edit the phone number, press the Edit soft key.
• To return the call, press the Dial soft key.
• To view information about the call, press the More soft key followed by the Info soft
key.
Note: If you are in a Business Group, you will need to edit the number and enter a 9
before the phone number.

9
1.2 Soft Keys and Hard Keys
Your Polycom 650 Phone has two main type of “keys” that are used to control the
basic and advance functions of your handset. These are defined below.
Soft Key
Keys that control the commands of your LED display on your Polycom phone handset
Hard Key/Button
The numbered buttons or word labeled buttons on your Polycom phone handset

10
2 Making Calls
2.1 Internally
To call another person in your business lift the handset and dial the other person’s
extension. This is typically a 3, 4 or 5 digit number, and may begin with #.
See “Quick Reference Information” in the front of this manual for your
company’s phone numbers and employee extension list.
2.2 Externally
You can place a call outside of your business in many ways using your SoundPoint IP
650 phone:
Lift the handset and dial the phone number. (Depending on your phone system you
may need to dial 9 or other code at the beginning of the phone number to place an
external call.)
Use the speakerphone. Press the “speak icon”button, then dial the number.
Use the headset (must have headset plugged into phone). Press “headset icon”
button, and then dial the number.
“Hot Dialing” Dial the number, then choose a method you will use to speak to the
calling party. (See above)
2.3 Redialing Numbers
To redial the last call placed from your phone:
1. Press
A call is attempted to your last placed call is attempted.

11
3 Answering Calls
When you are not in another call, you can answer a call in these ways:
Use the handset. Pick up the handset.
Use the speakerphone. Press the “speaker phone”icon button.
Use the headset. Press the “headset icon”button.
3.1 Call Waiting (Answering a call when on
you are on another call)
(Must have this feature enabled with your phone service)
If you have an active call, and an incoming call arrives on the same line,
you may hear a call waiting tone (stutter tone). You will see the second incoming
caller’s information appear on the graphic display.
Press the “Hold”soft key to put the original call on hold.
Press the “Answer”soft key to answer the new call.
Note: The original call is placed on hold at this time. After the call has ended -press
“Resume” soft key or “Hold” soft key again to continue with the original call.
3.2 Putting an existing call on hold
You can put a call on hold by pressing the Hold key. You may now replace the
handset without cutting the caller off. You can also now make another call while the
first call is on hold.
To retrieve the call, press Hold key again or the Resume soft key to retrieve the call.
The registered line icon appears as the line indicator.

12
4 Forwarding Calls
The easiest and most flexible way of configuring Call Forwarding is using the
Call Manager within the online ITS Fiber CommPortal. Instructions for using
Call Manager and the CommPortal begin on page 20.
To access the CommPortal go to: https://myfeatures.itstelecom.net
If your company has the ITS Fiber CommPortal Assistant software installed,
the CommPortal Assistant overrides the Call Forwarding from the phone.
Instructions for using the CommPortal Assistant are on page 60.
The section below provides instructions on how to set up Call Forwarding
using your Polycom 650 handset.
4.1 Introduction
Your Polycom 650 phone system supports a number of different types of Call
Forwarding.
Immediate (sometimes called Unconditional) Call Forwarding is where all calls
are forwarded to a number of your choice. This can either be to your voicemail
(which is the default) another extension in your business or an external number.
Busy Call Forwarding forwards all calls that are received when you are already
on the phone.
No Answer (sometimes called Delay) Call Forwarding forwards all calls when
you do not answer them after a certain delay.
Selective Call Forwarding forwards calls from certain numbers to another
number.

13
4.2 Immediate, Busy and No Answer Call
Forwarding using the Handset
4.2.1 Enabling
To use your handset to enable Immediate, Busy or No Answer Call Forwarding dial the
access code for the type of call forwarding you want to enable followed by the number
you wish to forward calls to. (See chart below)
For example, to use immediate call forwarding to forward all calls to extension 1004,
you would dial *721004. Depending on the configuration of your phone system this
may set up a courtesy call to the number you are forwarding calls to. The system will
only enable call forwarding if this courtesy call is answered.
4.2.2 Disabling
To disable call forwarding dial the disable code for that type of call forwarding.
4.2.3 Access Codes
Type of forwarding
Enable Code
Disable Code
Immediate/Unconditional
*72
*73
Busy
*90
*91
No Answer/Delay
*92
*93
4.3 Selective Call Forwarding using the
Handset
The Selective Call Forwarding feature can be configured by dialing *63. This feature
provides voice prompts to help you with setting it up.
4.4 Remote Access to Call Forwarding
You phone system also supports setting up Call Forwarding remotely using any phone.
To use this feature, follow these steps:
1. Dial the remote access to call forwarding number.

14
2. Enter your full 10-digit phone number followed by #.
3. Enter your remote access to call forwarding PIN followed by #. Note that this PIN
is different from your CommPortal password.
4. Enter the access code of the call forwarding service you wish to configure.
5. If you are enabling call forwarding the system will then provide a broken dialtone.
Enter the number you would like calls forwarded to.

15
5 Advanced Call Handling
5.1 Transferring Calls
A call can be transferred in one of two ways:
Consultative transfer
The person to whom you want to transfer the call, answers their phone before you
transfer the call or hang up. You can consult with them before completing the transfer.
1. During a call, press the Transfer button or the Transfer soft key.
Note: The active call is placed on hold.
2. Enter the phone number or extension to which you want to transfer the call.
3. After the party answers (and you speak to the party), press Transfer button or the
Transfer soft key.
Note: You can cancel the transfer before the call connects by pressing the Cancel soft
key.
Blind transfer
The call is automatically transferred after you dial the phone number of the party to
whom you want to transfer the call.
1. During a call, press Transfer button or the Transfer soft key.
2. Press the Blind soft key.
3. Enter the phone number to which you want to transfer the call. At this point, the call
is connected to the phone number to which you are transferring them.
Note: If you are transferring to an extension, dial the extension then press the Send
softkey.
5.2 Three Way Conference Call
To conference a third person into a regular two-way phone call, follow these steps.
1. Call the first person.
2. Press the Confrnc button or Confrnc soft key to create new call.
3. Dial the second person you want to join your call. Note: the original call is placed
on hold.

16
4. When the second person answers, press the Confrnc button or Confrnc soft key
again to join all parties on the call.
5. To add another person to the call, follow steps 2-4 again. Note: the first and
second persons are put on hold.
5.3 Parking a call (optional feature)
Parking a call places the call on hold in a “park orbit” so that the call can be retrieved
from another phone. Depending on your phone type, there are two ways of parking a
call.
1. If you have keys on your phone for parking calls, when in a call press the key of
the park orbit where you want the call parked. The call will now be parked and you
may now replace the handset.
2. If your phone doesn’t have dedicated call park keys, follow these steps:
Initiate call transfer by pressing the Transfer key (snom or Polycom phones)
or the Xfer key (Aastra phones).
Dial the Call Park access code *53.
Listen to the park orbit number where the call will be parked.
Complete the call transfer by pressing Transfer or Xfer again.
If you have keys on your phone for parking calls these keys will indicate via a light or
icon when a call is parked against that orbit.
5.4 Retrieving a parked call (optional
feature)
Depending on your phone type, there are two ways of retrieving a parked call.
1. If you have keys on your phone for parked calls, pick up the handset and press the
key of the park orbit where the call is parked.
2. If you don’t have dedicated call park keys lift the handset and dial the Call Retrieve
access code *54 followed by the park orbit number.
For example, to retrieve a call parked on orbit 1, you should dial *541.

17
5.5 Enabling Do Not Disturb
To prevent the phone from ringing (from incoming calls), you can select Do Not
Disturb.
Confrnc button or Confrnc soft key while Do Not Disturb is enabled are logged in the
“Missed Calls”
To disable Do Not Disturb:
Press Do Not Disturb button again.
5.6 Group Pickup
To pick up an incoming call within a Business Group dial *30.
5.7 Using Buddy Lists
A buddy list is a list of users/devices whose status or “presence” you can monitor.
Users update their presence setting (for example, “Be right back”,” Busy”, or “Out to
lunch”), and you can view their status in real-time from your phone. We (ITS) can set
this up. This cannot be done by the phone.
5.8 Restarting Your Phone
You may need to restart your phone from time to time so your phone can accept a new
configuration or for troubleshooting proposes.
To restart the phone:
1. Press
2. Select Settings > Basic > Restart Phone. (seen
on the LED panel)
3. “Are you sure?” -appears on the graphic display.
4. If you still want to restart your phone, press the Yes soft key. And the restart
process begins.

18
6 Voicemail
ITS Fiber’s Hosted IP-PBX Voicemail can be managed using your Polycom
phone handset or our online voice management interface called, ITS Fiber
CommPortal. The information here in section 7 refers to using the voicemail
system from your Polycom phone or accessing it from another phone.
Directions for using the online ITS Fiber CommPortal are in Section 8.
6.1 Setting up Voicemail the first time
The first time you access you voicemail box you will be asked to set up your mailbox,
and record your name and a greeting to be played by callers.
You must do this first time set up from your place of business (the location of your
subscribed phone service).
1. Dial *98
2. Follow the audio prompts to create your new PIN (personal identification number)
3. Follow the audio prompts to record your name and Voicemail greeting.
4. Your new Voicemail is now ready.
6.2 Accessing Voicemail
When you have one or more unheard voice messages waiting, your Polycom phone
will display a flashing light.
To listen to your messages from your office phone:
1. Pick up the handset and press the Messages button.
2. Press Select soft key, then the Connect soft key.
3. Follow the audio prompt to key in your PIN followed by the # sign if you have the
PIN activated. (You have the option to disable the login function.)
4. Follow the audio prompts to listen to your messages.

19
To retrieve your Voicemail from a phone other than the Polycom phone
connected to your service number:
1. Call 772-597-8642
2. Enter your ten-digit phone number followed by the # sign.
3. When prompted, enter your PIN followed by the # key.
4. If you have new messages, you will be notified.
5. Press 1 to listen to your messages
6. After hearing any messages, follow audio prompts to select options in the Main
Menu.
6.3 Using the Voicemail system
The voicemail system is menu driven, so listen to the voice prompts and then press the
keys on your phone to select which option you would like.
Once you become familiar with the system there is no need to wait until the voice
prompts have played before pressing a key –you can interrupt the announcements to
speed up your experience.
Main Menu Key Options
The most commonly used mailbox commands are as follows.
To listen to your voice messages from the main menu:
Press 1
To listen to your other messages from the main menu:
Press 1 1
To save a message once you’ve listened to it:
Press 2
To delete a message once you’ve listened to it:
Press 3
To change your mailbox settings from the main menu:
Press 4
To cancel the current operation:
Press *
To go back to the previous menu:
Press *
To finish entering digits, or recording an announcement:
Press #

20
7 Using ITS CommPortal
(website interface)
CommPortal provides a web interface to your phone settings and gives you access to:
view recent calls or missed calls
view and listen to your voicemail messges
set up a contact list
change your phone and phone system’s settings.
7.1 Accessing ITS CommPortal
To access the ITS CommPortal go to:
https://myfeatures.itstelecom.net
CommPortal is supported on Windows 2000, Windows XP, Windows 2003 and
Windows Vista, Windows 7 using the following browser versions:
Internet Explorer 8.1
Mozilla Firefox 2.0 (Mac/Apple)
Chrome
Safari
JavaScript must be enabled on your browser.
7.2 Logging In
To log into ITS CommPortal :
1. Enter your 10 digit phone number (ex. 7725551212) in Number/Username box
2. Enter your Password.
(FIRST TIME LOGIN –PLEASE CONTACT ITS FIBER AT [e-mail] or
772-597-3423 FOR YOUR INITIAL ACCOUNT PASSWORD. You may change it to
your own after the first-time login.)
