Profile Design RZ3 User manual

RZ3 Drink Bottle Cage
1
RZ3 DRINK BOTTLE CAGE
REVISION 01-12-08-2023

RZ3 Drink Bottle Cage
1
Thank you for purchasing this Profile Design Drink Bottle Cage. These instructions apply to the RZ3.
Note to Dealers: If you install this product for the consumer, please provide him/her with this owner’s manual after installation.
If anything is missing from the bottle kit please contact your dealer.
WARNING: Periodically check the Cage for damage, particularly for cracks or scratches in the surface that could lead to degradation and weakening
of the base material. Replace your Aerobar if you notice any damage from use or accident.
Please read these instructions thoroughly before attempting to install this item. Proper installation is required for compliance with Profile Design's
warranty policy. If you are not familiar with installation of bicycle accessories, please seek the assistance of your local Profile design dealer by logging
on to www.profile-design.com and using "dealer search" or by calling Profile Design's customer service number p.# 888.800.5999.
Tools and materials required:
Your Drink Bottle Cage kit should contain:
• Grease such as Finishline Premium Grease
• Screwdriver
• HSF 880 Bottle with top cap
• Straw with bite valve
• Aerodrink BTA bracket
INTRODUCTION

RZ3 Drink Bottle Cage
2
01 02
03 0504
COMPONENT LIST
Part.# Part Description
Bottle - RZ3
Cap - RZ3
Cage
Bolt - M5x14 BHB
600216
B206
414251
313598
275673 Washer
QTY.
Req.
1
1
1
2
2
Ref.#
1
2
3
4
5

RZ3 Drink Bottle Cage
3
PART DRAWINGS
100 mm
54 mm
220 mm
510ml (17.3oz)

RZ3 Drink Bottle Cage
4
-40°C+75°C
PRODUCT SPECIFIC SETUP LIMITATIONS
WARNING
Please noted, If you want to put it in the dishwasher, please
make sure that the temperature is maintained at a heat-
resistant temperature. If not, we haven't recommended to put
it in the dishwasher.

RZ3 Drink Bottle Cage
5
INSTALLATION INSTRUCTIONS HOW TO USE
1. Make sure there are no any bolts or the hydration system in the bike frame. If yes,
please help to remove them.
2. Apply grease to the M5x14 (2) bolts.
3. Use the bolts and washers to attach the cage to the frame.
4. Put the bottle in the cage.
1. Praise the cap off by inserting your fingers under the removal tab.
2. Fill the bottle with your choice of fluid.
3. Reinstall the cap by first lining up the bottle and cap, then pressing firmly.
* Torque the bolts to a maximum of 3Nm.
Filling the bottle

RZ3 Drink Bottle Cage
6
RL
1. When pulling the bottle from the cage twist it to one side first. 2. To put the bottle back in the cage – first ensure the bottom corner is engaged, then push the bottle
down into the clips.
Warning: Pulling the bottle directly upwards risks cracking the cage.
Using the bottle

RZ3 Drink Bottle Cage
7
• Profile Design Worldwide Two Year Limited Warranty.
• Profile Design, LLC (distributor) warrants to the original retail purchaser ("you") that the Profile Design product for which you received
this warranty is free from defects in material and workmanship for (2) two years from the date of original retail purchase. For more
details on this warranty, its exclusions and/or how to make a claim under the warranty please call +1 310.747.0085 extension 161 or visit
www.profile-design.com/pages/warranty
WARRANTY POLICY

RZ3 Drink Bottle Cage
8
2677 El Presidio Street
Long Beach, CA 90810
Ph: 310-884-7756
w
ww.profile-design.com
© Profile Design LLC
