quadient IS-480 User manual

User Guide
IS-480
Cancelling
Franking machine

Table of Contents
Read this First 11
1.1 What you will find in this Manual ................................................................................3
1.2 Safety Requirements .......................................................................................................5
Meet Your Mailing System 92
2.1 System Layout .................................................................................................................11
2.2 Accessories .......................................................................................................................13
2.3 Control Panel Features .................................................................................................16
2.4 Connections ......................................................................................................................19
2.5 Power Management ......................................................................................................21
Processing Mail 233
3.1 Choosing a Type of Imprint .........................................................................................25
3.2 Preparing and Starting your Work Session ...........................................................27
3.3 Printing [Cancelling] Mail .............................................................................................35
3.4 Printing Incoming Mail with [Received] Mode ......................................................38
3.5 Running [Pass through] Mail ......................................................................................41
3.6 Settings Details ...............................................................................................................44
3.7 Advanced Operations ...................................................................................................52
Managing Accounts and Assigning Rights 554
4.1 Accounting and Assigning Rights Overview .........................................................57
4.2 Selecting an 'Account Mode' .......................................................................................59
4.3 Guidelines to Setup an Account ................................................................................61
4.4 Selecting an Account Mode ........................................................................................66
4.5 Managing Accounts .......................................................................................................67
4.6 Managing Operators .....................................................................................................81
Reports 875
5.1 Reports Overview ...........................................................................................................89
5.2 Generating a Report ......................................................................................................91
5.3 Counter Data ....................................................................................................................93
5.4 Imprint Data .....................................................................................................................95
5.5 Account Data ...................................................................................................................97
| Page 1 | TOC | Jun-24-2022 08:54 |

5.6 System Data ..................................................................................................................101
Online Services 1056
6.1 Online Services Overview ..........................................................................................107
6.2 Connecting to Online Services .................................................................................108
6.3 Uploading Statistics ....................................................................................................111
6.4 System Online Services ..............................................................................................112
Configuring your Mailing System 1137
7.1 Settings Overview ........................................................................................................115
7.2 Logging in / out as the Supervisor ..........................................................................116
7.3 Changing the Display Language ............................................................................118
7.4 Enabling/Disabling Sounds .......................................................................................120
7.5 Display Settings ............................................................................................................122
7.6 System Time-outs and Settings ..............................................................................124
7.7 Imprint Default Settings .............................................................................................127
7.8 Connection Settings ....................................................................................................131
7.9 Time and Date Management ...................................................................................133
Options and Updates 1358
8.1 Options and Updates Process .................................................................................137
8.2 Using the Mailbox ........................................................................................................138
8.3 Managing Options .......................................................................................................141
8.4 Managing Custom Text Messages .........................................................................143
8.5 Managing Slogans .......................................................................................................145
8.6 Managing Cancelling mark .......................................................................................148
Maintaining your Mailing System 1519
9.1 Maintaining the Ink Cartridge ..................................................................................153
9.2 Cleaning the Mail Path ...............................................................................................161
9.3 Touchscreen Calibration ............................................................................................163
9.4 Maintenance Processes .............................................................................................164
Troubleshooting 16510
10.1 Paper Jamming ...........................................................................................................167
10.2 Label Jamming ............................................................................................................171
10.3 Diagnostics and System Data ..............................................................................173
Specifications 17711
11.1 Mail Specifications ....................................................................................................179
| Page 2 | TOC | Jun-24-2022 08:54 |

11.2 Recommended Operating Conditions ................................................................182
11.3 General Mailing Systems Specifications ............................................................183
11.4 Operating Specifications .........................................................................................184
| Page 3 | TOC | Jun-24-2022 08:54 |

| Page 4 | TOC | Jun-24-2022 08:54 |

Read this First1
This section contains important information about safety precautions and environmental
recommendations to operate your equipment in the best possible conditions.
1.1 What you will find in this Manual ............................................3
1.2 Safety Requirements ...................................................................5
How to Disconnect your Mailing System ................................................................8
1
| Page 1 | Read this First | Jun-24-2022 08:54 |

What you will find in this Manual1.1
Section 1: Read this First
Make sure you have read and fully understood the safety requirements
in this section. This section also includes a list of acronyms and symbols
used in the manual.
Section 2: Meet Your Mailing System
System features, reference descriptions of elements and controls, mail
format and how to power your Mailing System off.
Section 3: Processing Mail
Processing mail using the mailing system: choosing a type of task, running
batches, etc.
Section 4: Managing Accounts and Assigning Rights
How you can change accounts as a user, or set up accounts and control
access to the Mailing System as the supervisor.
Section 5: Reports
How you can generate and print out reports for the Mailing System usage,
account usage, etc.
Section 6: Online Services
Using your Mailing System to access Online Services and connect your
system for upgrades.
Section 7: Configuring your Mailing System
All the specifications of your Mailing System you can set up as a user
(temporary settings) or supervisor (default settings).
Section 8: Options and Updates
How to update/upgrade your system and modify the imprint (custom texts
and slogan,...).
Section 9: Maintaining your Mailing System
Changing the ink cartridge and maintaining other system components.
Section 10: Troubleshooting
What to do when a problem occurs: jamming, poor printing etc.
Section 11: Specifications
Detailed specifications of your Mailing System.
3
| Page 3 | | Jun-24-2022 08:54 |
1
Read this First

Symbols
This manual uses the symbols listed below.
Indicates...This symbol...
WARNING: indicates a human safety hazard.
ATTENTION: brings to your attention a risk for equipment or
mail that could result from an action you may perform.
NOTE: remark that explains different scenarios or situations.
TIP: advice to help save you time when processing your mail.
Glossary
This manual uses the acronyms listed below.
DescriptionAcronym
Automatic Label DispenserALD
IDentificationID
Local Area Network: link between computers.LAN
Mixed-Size FeederMSF
Personal ComputerPC
Personal Identification NumberPIN
Postal Security Device (Meter)PSD
4
| Page 4 | Jun-24-2022 08:54 |
1
Read this First

Safety Requirements1.2
Power Connection
Before connection, check whether the Mailing System is suitable for the local AC power
voltage (230V - 50Hz).
THIS SYSTEM MUST BE GROUNDED
• Only connect the power plug to an outlet provided with a
protective ground contact.
• To reduce the risk of fire, use only the power cord supplied
with the Mailing System.
• Do not use ground adaptors.
• Do not use this product on a wet floor or near water.
• In case of liquid spillage, disconnect the power cord from
the outlet and proceed with cleaning.
• Use an outlet located near the system that is easily accessible.
• Do not route the power cord between pieces of furniture or over sharp edges.
• Avoid using outlets controlled by wall switches or shared by other equipment.
• Make sure the mailing system is close enough to the electric outlet that it leaves
plenty of slack on the power supply cord.
Compliance
Energy Star compliance
Your mailing machine is Energy Star compliant: it helps you to save energy and money
while protecting the environment.
5
| Page 5 | | Jun-24-2022 08:54 |
1
Read this First

Environmental compliance
A program is implemented for the recycling of worn mailing machines and machines
at the end of their lifetime. Contribute in a responsible way to the environmental
protection by consulting your retailer internet site, or by contacting him. He will inform
you of the collection and treatment processes of these machines.
CE compliance
Products presented in this guide conform to requirements of applicable directives. For
more details, refer to Declaration Of Conformity available on website or upon request
to your local contact.
This is a class A product. Operation of this equipment in a
residential area is likely to cause interference in which case the
user will be required to correct the interference at his own
expense.
6
| Page 6 | Jun-24-2022 08:54 |
1
Read this First

General Safety
• Before using your Mailing System, thoroughly read the operating instructions.
• To reduce the risk of fire, electric shock and injury to persons, follow normal and
basic safety precautions for office equipment when using your Mailing System.
• To avoid damage, only use approved supplies (ink, tape, cleaners...).
The Mailing System contains moving parts. Keep fingers, long
hair, jewellery, neck ties, loose clothing away from the mail path
at all times.
Follow the additional safety precautions below:
• Do not place lit candles, cigarettes, cigars, etc. on the Mailing System.
•When removing jammed material, avoid using too much force to prevent personal
injury and damaging components.
• When lifting covers, wait for all parts to stop moving before placing hands near
the feeder path or printhead.
• To prevent overheating do not block the ventilation openings or try to stop the
power supply fans.
• Do not remove bolted covers as they enclose potentially hazardous parts that
should only be accessed by a Service Representative.
LAN Connections
Plugging the right jack in the right socket
Your Mailing System uses a LAN (high speed internet connection) to connect to your
customer Online Services.
1
Read this First
7
| Page 7 | Jun-24-2022 08:54 |

Network/PC LAN (8 wires)
Follow the additional precautions below:
• Avoid using your system during an electrical storm; as there may be a risk of
electrical shock from lightning.
• Do not install LAN connectors in a wet location.
• Disconnect the LAN cable from the wall before moving your system.
Disconnecting your Mailing System
How to Disconnect your Mailing System
1. First switch your Mailing System to OFF mode (see How to Turn the Mailing System
to OFF Mode on page 22).
Only unplug the power cord when the Mailing System is in OFF
mode or Sleep mode to avoid keeping the ink cartridge in an
unprotected position where the ink may dry out and become
unusable.
2. Unplug the power cord from the wall outlet.
3. Unplug the LAN cable from its socket as they may still be energized.
8
| Page 8 | Jun-24-2022 08:54 |
1
Read this First

Meet Your Mailing
System
2
Get to know your Mailing System in this section.
2.1 System Layout ............................................................................11
2.2 Accessories ..................................................................................13
2.3 Control Panel Features .............................................................16
2.4 Connections .................................................................................19
2.5 Power Management ..................................................................21
How to Turn the Mailing System to Sleep Mode ................................................22
How to Turn the Mailing System to OFF Mode ..................................................22
9
| Page 9 | Meet Your Mailing System | Jun-24-2022 08:54 |

System Layout2.1
Mailing System Components
Guides envelopes into the feeder.Rear Guide-Wall
Automatically feeds the system with envelopes of
different sizes.
Mixed-Size Feeder
Prints envelopes (or labels) and controls the Mailing
System.
Base
Awake/Sleep button of your Mailing System.Awake/Sleep button
Allows you to control the Mailing System.Control Panel
Stores this User Guide.User Guide Receptacle
Use this slot to store labels horizontally.Label Storage
Beginning of mail transport path.Hopper
Holds large envelopes in place for feeding.Side Guide
Allows you to remove jammed envelopes or labels.Jam Release Handle
Receives mail pieces after processing.Catch Tray
11
| Page 11 | | Jun-24-2022 08:54 |
2
Meet Your Mailing System

Inside the system base
Lift by front side to open.Cover
Prints the postal imprint on envelopes.Ink Cartridge
PSD (Meter) performs all necessary operations to
comply with the postal standards.
Postal Security Device
(PSD)
12
| Page 12 | Jun-24-2022 08:54 |
2
Meet Your Mailing System

Accessories2.2
USB Keyboard (option)
Usage
A USB keyboard can be connected to the mailing system.
This keyboard is a standard personal computer keyboard with an additional touchpad.
It allows the input of data to your mailing system.
To use the numerical keys, ensure that [Num lock] is activated.
You can use the shortcuts listed in the table below
Keyboard use
NAVIGATION KEYS
Validates the current screen.[Enter]OK
Deletes the last character or digit in an entry field.[Backspace]Clear
Deletes the next character or digit in an entry
field.
[Del]Delete
Returns to previous screen or cancels the
selection.
[Esc]Back / Cancel
Moves to the next entry field.[Tab]Change field
Moves the cursor before the character at the left.[Left arrow]Move before
Moves the cursor after the character at the right.[Right arrow]Move after
13
| Page 13 | | Jun-24-2022 08:54 |
2
Meet Your Mailing System

Touchpad use
The touchpad on the keyboard or a USB mouse plugged into the system allow you to
make the same selections or actions as with your finger, using its pointing device.
They allow you to do the same selections or actions as with your finger on the touch
screen.
All the tactile elements can be activated by the pointer.
In addition, it allows you to:
• Exactly position the cursor in an entry field.
• Select a part of the content of an entry field.
Report Printer (option)
A USB printer can be directly connected to the mailing system for printing
mailing-related reports.
For more information about compatible printers that can connect
to your mailing system, please contact technical support.
14
| Page 14 | Jun-24-2022 08:54 |
2
Meet Your Mailing System

Barcode Scanner (option)
This scanner is used:
• To identify accounts through barcodes.
2
Meet Your Mailing System
15
| Page 15 | Jun-24-2022 08:54 |
