Regency ONSCD3624 User manual

Any problems or questions call Regency Ofce Furniture at 1-866-816-9822
IMPORTANT NOTICE:
Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the parts from being scratched.
Check to be sure that you have all parts and hardware.
Remove all wrapping materials, including staples & packing straps before you start to assemble.
Do not tighten all screws/bolts until completely assembled.
Keep all hardware parts out of reach of children.
Organize your parts and hardware. You will need (2) people, a Phillips head screwdriver and a rubber mallet.
HS-E
HS-C
HS-D
DR-B
HS-A: Back Panel
(34” x 23.75” x 1”)
Quantity: 1
HS-D: Foot Bracket
(23.5”D)
Quantity: 2
HS-E: Top Bracket
(23.5”D)
Quantity: 2
Parts :
HS-B
HS-H
HS-G
HS-C: Top Panel
(35.5” x 23.5” x 1”)
Quantity: 1
LT-A: Floating Top
(35.5” x 23.5” x 1”)
Quantity: 1
HS-B: Base Panel
(34” x 23” x 1”)
Quantity: 1
HS-H: Right Side
(23.75” x 23.5” x 1”)
Quantity: 1
HS-G: Left Side
(23.75” x 23.5” x 1”)
Quantity: 1
LT-A
Cam Lock Assembly:
To open Cam, point arrow
toward Cam Pin hole. To
lock Cam, turn clockwise.
Figure 1:
HS-F: Shelf
(34” x 19.75” x 1”)
Quantity: 1
DR-B: Right Door
(23” x 17” x 1”)
Quantity: 1
DR-A: Left Door
(23” x 17” x 1”)
Quantity: 1
DR-A
Storage Cabinet • ONSCD3624 • INSTRUCTIONS
CARTONS: LT3624, PSC3624, SCD3624
Storage Cabinet
Page 1

Any problems or questions call Regency Ofce Furniture at 1-866-816-9822
Hardware :
J: Allen Key
Quantity: 1
P: Insert Covers
Quantity: 8
O: 3/4” Wood Screws
(19mm)
Quantity: 23
N: Shelf Pins
Quantity: 4
R: Glides
Quantity: 4
Q: Cam Caps
Quantity: 9
K: 1.5” Long Bolts
(38mm)
Quantity: 6
L: 3/4” Short Bolts
(19mm)
Quantity: 12
S: Washers
Quantity: 6
T: Handles
Quantity: 2
U: Hinge
Quantity: 4
V: Hinge
Bracket
Quantity: 4
W: Set of Keys
Quantity: 1
X: Latch Screw
(15mm)
Quantity: 2
Y: Lock Latch
Quantity: 1
Z: Door Stop
Quantity: 1
M: Wood Cam Pins
Quantity: 12
Storage Cabinet • ONSCD3624 • INSTRUCTIONS
CARTONS: LT3624, PSC3624, SCD3624
STEP 1 : Insert 2 Wood Cam Pins(M) into Back Panel(HS-A).
Attach Base Panel(HS-B) to Back Panel by inserting Cam
Pins into Cam Locks. Lock Cams(Figure 1).
STEP 2 : Insert 4 Cam Pins(M) into Left Side(HS-G) and
Right Side(HS-H).
HS-A
HS-B
MM HS-G
MM
M
M
HS-H
MM
M
M
Storage Cabinet
Page 2

Any problems or questions call Regency Ofce Furniture at 1-866-816-9822
STEP 3 : Attach Left Side(HS-G) and Right Side(HS-H) to
Back Panel(HS-A) and Base Panel(HS-B) by inserting Cam
Pins into Cam Locks. Lock Cams (Figure 1).
STEP 4 : Insert 2 Glides(R) into each Foot Bracket(HS-D).
HS-G HS-H
R R
HS-D
HS-A
HS-B
STEP 5 : Attach each Foot Bracket(HS-D) by placing 1 Washer(S) between the base and each wood screw hole on Legs (Figure 2).
Then, insert 6 Long Bolts(K) and 6 Wood Screws(O) to attach to Base Panel(HS-B).
O
K
K
K
K
K
K
O
O
O
OKO
KO
KO
S
S
S
Figure 2
HS-D
HS-B
HS-D
O
STEP 6 : Insert 5 Cam Pins(M) into Top Panel(HS-C). STEP 7 : Attach Top Panel(HS-C) to Back Panel(HS-A), Left
Side(HS-G) and Right Side(HS-H) by inserting Cam Pins into
Cam Locks. Lock Cams (Figure 1).
HS-C
M
M
M
M
M
HS-A
HS-C
HS-H
HS-G
Storage Cabinet • ONSCD3624 • INSTRUCTIONS
CARTONS: LT3624, PSC3624, SCD3624
Storage Cabinet
Page 3

Any problems or questions call Regency Ofce Furniture at 1-866-816-9822
STEP 10 : Use 2 Wood Screws(O) to attach each Hinge
Bracket(V) to the sides. The hinge adjustment screw on each
bracket should face toward the back of the unit.
V
V
STEP 12: Attach the Lock Latch(Y) with 2 Latch Screws(X)
and Door Stop(Z) with 1 Wood Screws(O) as shown below.
Z Y
X
OX
STEP 13 : Attach 1 Handle(T) to the Left Door(DR-A) and
Right Door(DR-B).
DR-A
T
STEP 14 : Attach 4 Hinges(U) to the Left Door(DR-A) and
Right Door(DR-B) with 8 Wood Screws(O).
O
O
O
O
O
O
O
O
O
O
U
STEP 8 : Attach Top Brackets(HS-E) to Floating Top(LT-A)
using 6 Short Bolts(L) per Bracket.
STEP 9 : Attach Floating Top(LT-A) to Top Panel(HS-C)
using 6 Long Bolts(K).
LT-A
HS-E
LT-A
KK
HS-C
STEP 11 : Insert 4 Shelf Pins(N) at desired height. Place
Shelf(HS-F). Finish by concealing Cam Locks with Cam
Caps(Q) & Insert Covers(P).
DR-B
T
V
V
Storage Cabinet • ONSCD3624 • INSTRUCTIONS
CARTONS: LT3624, PSC3624, SCD3624
Storage Cabinet
Page 4

Any problems or questions call Regency Ofce Furniture at 1-866-816-9822
STEP 15A : Connect 4 Hinges(U) to Hinge Brackets(V).
STEP 15B: The screw(EA) located on Hinge Bracket(V) interlocks with the opening on Hinges(U) just as screw(EB) located on
Hinges(U) interlocks with the Hinge Bracket(V) opening. Tighten screw(EA) to secure door.
Note: The screw EB is an adjustment for the door position. Turn right to adjust door to center and left to adjust toward the side.
EA EB
V
U
Storage Cabinet • ONSCD3624 • INSTRUCTIONS
CARTONS: LT3624, PSC3624, SCD3624
Storage Cabinet
Page 5
