RIGHT ANGLE 48 HALF MOON ON R-STYLE User manual

4
DETAIL A
6
BEFORE BEGINNING
STEP 1
READ ALL THE INSTRUCTIONS
LEVELING GLIDE
1
A
PAGE 1 OF 2
. ATTACH THE JOINER PLATES TO THE WORKSURFACE
, (2) IN EACH JOINER PLATE. NO PILOT HOLES
VERSION DATED: 9/27/11
USING (4) WOOD SCREWS 6
LEVEL
#2 SQUARE HEAD DRIVER IT
AS SHOWN ELOW IN DETAIL . ATTACH THE JOINER PLATES
#2 PHILLIPS HEAD DRIVER IT OR
PLATE. NO PILOT HOLES ARE PROVIDED.
CORDLESS DRILL
TOOLS REQUIRED FOR ASSEMBLY:
ARE PROVIDED. SEE DETAIL A. DO NOT OVER-TIGHTEN THE SCREWS. USE A
LOW TORQUE SETTING ON THE DRILL.
INSTRUCTION # 527 2
STEP 2: CENTER (2) JOINER PLATES
TO THE WORKSURFACES USING (4) WOOD SCREWS
4 ON THE END EDGES OF OF THE 24"
, (2) IN EACH JOINER
WORKSURFACES 2 THAT WILL UTT THE STRAIGHT EDGE OF THE HALF MOON
WORKSURFACE 3
6
R-STYLE (2) 24" DEEP AND (1) 48" HALF MOON WORKSTATION ASSEMBLY
INSTRUCTIONS:
STEP 1: AFTER ASSEM LING THE 24" DEEP WORKSTATIONS 1 , CENTER (2)
JOINER PLATES 4 ON ONE OF THE WORKSTATIONS IN THE LOCATIONS SHOWN
ELOW LEFT IN STEP 1
ITEM # PART # DESCRIPTION QTY.
1 VARIES R-STYLE WORKSTATION 24" DEEP 2
2 VARIES 24" DEEP WORKSURFACE 2
3 10143 48x24 HALF MOON WORKSURFACE 1
4 800512 2 X 2 WORKSURFACE JOINER PLATE 4
5 29SL 29SL POST LEG 2
6 51708 M5 x 18mm SQ/PH/WSHR HEAD WOOD SCREW 24
6703 ZINSER ST., SCHOFIELD, WI 54476
PHONE: [phone] FAX: [phone]
.raproducts.com
K&A MANUFACTURING
DETAIL
4
6
STEP 2
2

6703 ZINSER ST., SCHOFIELD, WI 54476
PHONE: [phone] FAX: [phone]
.raproducts.com
VERSION DATED: 9/27/11
K&A MANUFACTURING
PAGE 2 OF 2
STEP 3: PLACE THE HALF MOON WORKSURFACE 3 ON A PROTECTED SURFACE WITH THE PILOT HOLES FACING
UP. ALIGN THE HOLES IN ONE OF THE POST LEGS 5 WITH THE PILOT HOLES ALONG THE CURVED EDGE OF THE
WORKSURFACE. ATTACH THE POST LEG TO THE WORKSURFACE USING (4) WOOD SCREWS
6 . SEE DETAIL C.
REPEAT STEP 3 WITH THE OTHER POST LEG.
STEP 4: WITH THE HELP OF AN ASSISTANT, SET THE 24" DEEEP WORKSTATIONS 1 UPRIGHT. SLIDE THE ACKS OF
THE WORKSTATIONS TOGETHER IN THEIR FINAL LOCATION. WORKING FROM THE ENDS OF THE WORKSTATIONS,
FASTEN THEM TOGETHER USING (4) WOOD SCREWS 6 , (2) IN EACH JOINER PLATE 4 .
STEP 5: SET THE HALF MOON WORKSTATION UPRIGHT RESTING THE WORKSURFACE ON THE JOINER PLATES 4
AT THE ENDS OF THE 24" DEEP WORKSTATIONS. FASTEN THE HALF MOON WORKSTATION TO THE 24" DEEP
WORKSTATIONS WITH (4) WOOD SCREWS 6 , (2) IN EACH JOINER PLATE.
STEP 6: LEVEL THE WORKSTATIONS IF NECESSARY Y TURNING THE LEVELING GLIDES OUT (CLOCKWISE FROM
THE TOP) AT THE LOW CORNERS OF THE UNITS.
STEPS 4 & 5
C
5
3
LEVELING
GLIDE
STEP 3
E
D
1
3
4
DETAIL D
6
4
DETAIL E
6
5
DETAIL C
6
