RIGHT ANGLE NewHeight 4 Series User manual

Instruction #54549 • Dated: 3/22/2021
NewHeights™ Series 4 Bonita ET Heavy Duty
2-Leg Workstation
Warranty: raproducts.com/warranty
1 of 13

K&A Manufacturing • 800.298.4351 • www.raproducts.com/install 2 of 13
READ ALL INSTRUCTIONS BEFORE USING THIS PRODUCT.
USE THIS PRODUCT ONLY AS INSTRUCTED.
FAILURE TO COMPLY WITH ALL INSTRUCTIONS AND WARNINGS
MAY RESULT IN SERIOUS PROPERTY DAMAGE OR BODILY INJURY.
Basic Safety Instructions
1. Intended Use. This Product is exclusively designed for use as indoor ofce furniture in compliance with all instructions and safety warnings
in the user manual. Any different use, or use extending beyond the intended use, may result in property damage or bodily injury and is
prohibited. This Product should not be used, operated or maintained with additional components not authorized by K&A Manufacturing, Inc.
BY USING THIS PRODUCT OR ANY FEATURE OF THIS PRODUCT, YOU AGREE TO COMPLY WITH ALL PRODUCT TERMS
AND POLICIES, INCLUDING WITHOUT LIMITATION ANY SAFETY WARNINGS AND INSTRUCTIONS, PROVIDED BY
K&A MANUFACTURING, INC. AND ITS AFFILIATES. K&A MANUFACTURING, INC. SHALL ASSUME NO LIABILITY FOR ANY
DAMAGE OR INJURY CAUSED BY USE OF THE PRODUCT A) IN VIOLATION OF ANY SAFETY WARNINGS OR INSTRUCTIONS;
B) NOT AUTHORIZED BY K&A MANUFACTURING, INC.; OR C) BY EVENTS BEYOND K&A MANUFACTURING, INC.’S CONTROL.
DO NOT SIT, STAND OR CRAWL ON OR UNDER THE PRODUCT.
MAKE SURE NO OBSTACLES ARE IN THE PRODUCT’S PATH.
MAKE SURE ALL CORDS ARE LONG ENOUGH TO ACCOMMODATE ANY CHANGE IN HEIGHT.
DO NOT USE ATTACHMENTS NOT RECOMMENDED BY THE MANUFACTURER.
2. Electrical Height Adjustment. The height of this Product may be adjusted electronically. Contact with electrical voltage may cause serious
injury and death. Only use the Product in compliance with these instructions. This Product should not be used in environments with high
levels of humidity or moisture.
KEEP CORDS AND ELECTRICAL COMPONENTS AWAY FROM HEAT AND LIQUIDS.
DO NOT OPEN ANY OF THE COMPONENTS: CONTROL BOX OR KEYPAD.
DO NOT USE WITH A DAMAGED PLUG OR CORD.
DO NOT INSERT ANYTHING INTO ANY SEAM OR OPENING.
3. Setup and Use. This Product should only be used and operated in good condition. When in use, no one should sit, stand or crawl on or
under the Product. There is a danger of crushing, shearing, injury or damage. Keep the entire range of motion of the Product clear of all
obstacles. Devices and object on the Product can tip over, fall or be crushed by the Product.
KEEP HANDS AND FINGERS CLEAR.
KEEP ALL OBSTACLES CLEAR OF THE PRODUCT’S PATH.
4. Users. This Product is not intended for use with children, individuals with restricted physical, sensory or mental capabilities, or individuals
who lack experience or knowledge, unless they are supervised by a person who is responsible for their safety or they have received
instructions from a person who is responsible for their safety concerning how the Product must be used. Children should be closely
supervised to ensure that they do not play with the Product and its height adjustment mechanism to avoid risk of physical injury or
electric shock.
KEEP CHILDREN AWAY FROM THE PRODUCT, ITS CONTROL UNITS, AND KEYPADS.
WARNING
DANGER

K&A Manufacturing • 800.298.4351 • www.raproducts.com/install 3 of 13
E. 5/8” Washer Head Wood Screw x42
F. 1/4”x 5/8” Bolt x4
G. Lock Washer x4
H. 5/8” Wood Screw x4
I. Cord Clip x1
J. M6 x 10mm Bolt x4
K. Star Washer x4
L. Wire Management Channel x1
M. 3/16” Allen Wrench x1
N. 4mm Allen Wrench x1
O. 6mm Hex Rod Wrench x1
Left Leg Right Leg
Tools Required for Assembly
A. Power Driver with Adjustable Torque
B. Tape Measure
C. #2 Phillips Head Driver Bit
D. #2 Square Head Drive Bit (Recommended)
A B C D
Hardware and Tools Included for Assembly (may have extra)
E F G H I
J K
M N O
Bonita Parts
P. Cross Support x1
Q. U-Channel x1
R. Short Hex Rod x2
S. Switch x1
T. Control Box x1
U. Power Cord x1
V. Left Motor x1
W. Right Motorx1
X. Left Leg x1
Y Right Leg x1
P Q
X Y
S
L
R
Note
location
of drive
input hole.
Legs must be in their lowest
position before installation.
V
T
UW

K&A Manufacturing • 800.298.4351 • www.raproducts.com/install 4 of 13
Step 1
• Place the left leg column (X) onto the
worksurface and align with predrilled pilot
holes. Make sure leg is in its lowest position.
• Insert the short hex rod (R) through the
left motor assembly (V) (insert starting at
bracket side of the motor).
• Slide hex rod into left leg drive input hole.
Hex rod should slide all the way into leg.
• If hex rod is not properly aligned with drive
input, slightly rotate the motor 1/6th or
1/3rd of a turn.
Lay the worksurface on a protected surface
with pilot holes facing up.
LEGS MUST BE IN LOWEST POSITION
BEFORE INSTALLING HEX RODS.
Step 2
Hex Rod Wrench
(O) can also be used
to rotate hex rod
O
X
Left
Motor
R
Motor Assembly (V)
Reference below
images for proper
positioning of each
motor.
Faces Front
Faces Leg
FRONT EDGE
• Place the right leg column (Y) onto the
worksurface and align with predrilled pilot
holes. Make sure leg is in its lowest position.
• Insert the short hex rod (R) through the right
motor assembly (W) (insert starting at
bracket side of the motor).
• Slide hex rod into right leg drive input hole.
Hex rod should slide all the way into leg.
• If hex rod is not properly aligned with drive
input, slightly rotate the motor 1/6th or
1/3rd of a turn.
FRONT EDGE
V
W

K&A Manufacturing • 800.298.4351 • www.raproducts.com/install 5 of 13
Step 4
For proper alignment of pre-drilled
holes, rst insert screws at the four
corners of the U-channel. Then,
install the remaining screws.
• Align the U-channel (Q) with the pre-
drilled pilot holes*.
• Make sure the end with the holes
closest the edge faces towards the left
motor.
• Attach U-channel to worksurface with
washer head wood screws (E).
• Do NOT fully tighten until all screws
are installed.
A ED
*Hole placement may vary depending on table width.
XW
Left
Motor
Right
Motor E
W
X
Q
Step 3
Important: Please be aware that 5/8” screws are
provided. If your worksurface is 5/8” or thinner, you
will need to supply your own hardware.
• After hex rod is installed, align motor
brackets and corresponding mounting holes
on each leg column.
• Position lock washers (G) and tighten motor
mounting bolts (F).
F
GF
G
W
F G M
Holes closest to end of
U-channel face left motor.

K&A Manufacturing • 800.298.4351 • www.raproducts.com/install 6 of 13
Step 6
W
X
K
J
• Install bolts and washers (4 sets).
Do NOT fully tighten.
J K
M
Step 5
• Slide cross support (P) over leg
cross support brackets.
W
X
P

K&A Manufacturing • 800.298.4351 • www.raproducts.com/install 7 of 13
Step 8
• Fully tighten bolts in cross support.
Tighten bolts
X
W
For proper alignment,
rst insert screws at the
four corners of each leg
mounting bracket. Then,
install remaining screws.
Step 7
• Align assembled base with the pre-
drilled pilot holes.
• Secure the base to the worksurface
with washer head wood screws (E).
• Do NOT fully tighten until all
wood screws are inserted.
A ED
W
X
E

K&A Manufacturing • 800.298.4351 • www.raproducts.com/install 8 of 13
Step 10
• Mount control box (T) to worksurface
using two wood screws (H).
• For standard install location, align
control box with pre-drilled pilot
holes. However, it can be installed in
any location, wire lengths permitting.
NOTE: Table will NOT operate unless the control box
(T) is screwed tight into the table without any play.
H
W
X
Required Orientation:
Long side of control box must
run parallel to the long side
of the worksurface.
Control
Box
ACH
Required Orientation
Step 9
• Mount control switch (S) to worksurface
using two wood screws (H).
• For standard install location, align switch
with pre-drilled pilot holes.
NOTE: If you have a 4-button programmable switch, please refer
to the installation instructions included with switch.
Upgrade -
Programmable Switch
Standard Switch
ACH
H
S

K&A Manufacturing • 800.298.4351 • www.raproducts.com/install 9 of 13
Step 12
• Plug the control switch, motor, and power cables
into the control box (T).
• Plug power cable into outlet.
• With the desk still upside down, test your Bonita to
check if assembly was successful.
• Hold the down arrow on the control switch
until desk no longer moves to complete “reset
mode.”
• Once table is in lowest position, push up arrow.
• If the desk legs move properly, installation was
a success. Now, you can ip desk right-side up
and begin use.
Have accessories to add? Install them
while before you ip your Bonita right-
side up to make the process easier.
Control Box End View
Power
Cable
Motor Cable
Switch
Cable
Step 11
• Install wire management (L) and cord
clip (I) to organize the cords and cables
with washer head wood screws (E).
• Pilot holes are not provided.
• See cable mounting diagram on next
page for help.
A E
L
I
Mount the wire management channel (L) with
adhesive strips AND two wood screws (E). Insert one
screw on at edge of each side of the wire management
channel to penetrate plastic and worksurface.
L
W
X
E
I

K&A Manufacturing • 800.298.4351 • www.raproducts.com/install 10 of 13
Cable Routing Diagram
Cable Routing Diagram
For the safety of the user and the workstation; the control box contains an internal sensor that is
sensitive to movement, vibration, and collision. For faultless operation, ensure all cables, electronics,
and accessories are cable managed and secured. Excessive load or weight must be distributed evenly.
Failure to follow these guidelines may cause intermittent functionality.
Caution:
*For tables 48” or smaller, the wire management can be moved.
Switch
Switch Cable
Cord Clip
Control Box
Motor
Cable
Motor
Use Wire Management
Channel to hold extra
lengths of cable*
Power Cable
MotorMotor Cable

K&A Manufacturing • 800.298.4351 • www.raproducts.com/install 11 of 13
Save for Reference
Standard Switch
Start Up Procedure:
• Plug the power cord into a standard 110V receptacle. A power surge protector
is recommended.
• Press the down arrow until the worksurface reaches its lowest position.
• The workstation is ready for use.
• If the table is not functioning normally or has lost power, perform the reset procedure.
Reset Procedure:
• Unplug the unit from the wall for 10 seconds.
• Clear all obstructions from the travel path of the desk.
• Plug the unit back in the wall.
• Press and hold the down arrow key until the table reaches its lowest position.
Add Container Stops:
• Move the table to the upper or lower desired height.
• Rapidly press 4 times. You will hear a musical tone.
• Rapidly press 2 times. A musical tone plays two times.
- To add the upper container stop press A musical tone plays two times.
- To add the lower container stop press A musical tone plays two times.
Remove Container Stops:
• Move the table to the upper or lower preset height.
• Rapidly press 4 times. You will hear a musical tone.
• Rapidly press 2 times. A musical tone plays two times.
- To delete the upper container stop press You will hear a musical tone.
- To delete the lower container stop press You will hear a musical tone.
Troubleshooting:
If you are having any problems with the operation, contact RightAngle Products at 800.298.4351
or [e-mail]
If the leg assemblies are at uneven heights, it is usually caused by an improperly installed hex rod. Disassemble one
of the leg assemblies from the worksurface and make sure both ends of the hex rod are properly engaged in the hex
drives near the top of the leg assemblies.
Note

K&A Manufacturing • 800.298.4351 • www.raproducts.com/install 12 of 13
Start Up Procedure:
• Plug the power cord into a standard 110V receptacle. A power surge protector
is recommended.
• Press the down arrow until the worksurface reaches its lowest position.
• The workstation is ready for use.
• If the table is not functioning normally, or has lost power,
perform the reset procedure.
Reset Procedure:
• Unplug the unit from the wall for 10 seconds.
• Clear all obstructions from the travel path of the desk.
• Plug the unit back in the wall.
• Press and hold the down arrow key until the table reaches its lowest position
See Packaged Instructions for Programmable Options
Optional Programmable Switch (full instructions packaged with switch)

K&A Manufacturing • 800.298.4351 • www.raproducts.com/install 13 of 13
If the table is unresponsive, uneven, or not functioning properly, perform a manual reset.
User settings are not reset in this process.
There are three methods to reset a workstation:
Reset Method A
1. Clear all obstructions from the travel path of the workstation
2. Disconnect the power to the control box for 30 seconds.
3. Reconnect the power
4. Press and hold the until the workstation has reached its lowest possible position.
Reset Method B (4 button programmable switch required)
1. Clear all obstructions from the travel path of the workstation
2. Quickly press UP + UP + UP + UP to enter the menu mode.
3. P01 is displayed and you will hear a musical tone.
4. Press the to navigate the menu.
5. Navigate to the P09 display
6. Press the button to enter or accept
7. Press and hold the until the workstation has reached its lowest possible position.
The workstation is now ready to operate
Reset Method C - 2 Button Switch
1. Clear all obstructions from the travel path of the workstation
2. Quickly press UP + UP + UP + UP to enter the menu mode.
3. You will hear a musical tone.
4. Press UP + UP + UP +
5. You will reach the limit adjustment menu and hear four musical tones.
6. Press and hold the until the workstation has reached its lowest possible position.
The reference is re-calibrated, the table should be leveled and the height indication should be correct.
Mechanical Reset Mode
