RIGHT ANGLE R-STYLE Series User manual

PAGE 1 OF 2
BEFORE BEGINNING
VERSION DATED: 7/20/12
READ ALL THE INSTRUCTIONS
CORDLESS DRILL
TOOLS REQUIRED FOR ASSEMBLY:
STEPS 1 & 2
INSTRUCTION # 52570
#2 PHILLIPS HEAD DRIVER BIT
ITEM # PART # DESCRIPTION QTY.
1 VARIES SCREW HEIGHT ADJUSTABLE BEAM 1
2 VARIES 580 SCREW HEIGHT ADJUSTABLE LEG RIGHT 1
3 VARIES 580 SCREW HEIGHT ADJUSTABLE LEG LEFT 1
4 VARIES R-STYLE™ LEFT WORKSURFACE SUPPORT 1
5 VARIES R-STYLE™ RIGHT WORKSURFACE SUPPORT 1
6 VARIES SCREW HEIGHT ADJUSTABLE MODESTY PANEL 1
7 R-STYLE A 6 x 15 MACHINE SCREW 6
8 50133 10-32 x 1/2 PHILLIPS TRUSS HEAD MACHINE SCREW 6
9 PLATE & SCREW BEAM TIGHTENER PLATE WITH SCREW 1
10 VARIES R-STYLE™ WORKSURFACE 1
11 SOCKETSCREW FOR ADJUSTABLE MODESTY PANEL 1
12 WELD NUT FOR ADJUSTABLE MODESTY PANEL 1
R STYLE™ SCREW HEIGHT ADJUSTABLE WORKSTATION ASSEMBLY INSTRUCTIONS:
STEP 1: SET THE LEFT AND RIGHT LEG ASSEMBLIES 2 AND 3 UPRIGHT ON THE
FLOOR AT THE APPROXIMATE WIDTH OF THE WORKSTATION.
6703 ZINSER ST., SCHOFIELD, WI 54476
PHONE: [phone] FAX: [phone]
.raproducts.com
K&A MANUFACTURING
2
1
3
STEP 2: PLACE THE BEAM 1 ON THE TOPS OF THE COLUMNS 2 AND 3
ENGAGING THE HOOKS ON THE BEAM INTO THE SLOTS ON THE COLUMNS.
STEP 3: PLACE THE LEFT AND RIGHT WORKSURFACE SUPPORTS 4 AND 5 ON
THE TOPS OF THE LEG ASSEMBLIES 2 AND 3 AND ATTACH THEM WITH (3)
MACHINE SCREWS 7 IN EACH LEG.
4
5
STEP 3
7

6703 ZINSER ST., SCHOFIELD, WI 54476
PHONE: [phone] FAX: [phone]
.raproducts.com
VERSION DATED: 7/20/12
K&A MANUFACTURING
5
8
9
9
10
6
3
2
STEPS 4 7
REMOVE (4) SCREWS IN EACH
LEG TO ADJUST HEIGHT
1
4
A
DETAIL A
11
12
PAGE 2 OF 2
STEP 4: PLACE THE WORKSURFACE 10 ON THE WORKSURFACE SUPPORTS 4 AND 5
ALIGNING THE INSERTS IN THE WORKSURFACE WITH THE HOLES IN THE WORKSURFACE
SUPPORTS. ATTACH THE LEG ASSEMBLIES TO THE WORKSURFACE WITH (3) MACHINE SCREWS
8
IN EACH LEG ASSEMBLY.
STEP 5: TIGHTEN THE BEAM 1 BY INSERTING THE MACHINE SCREW 9 THROUGH A HOLE NEAR THE
CENTER BACK SIDE OF THE BEAM. THREAD THE SCREW INTO THE TIGHTENER PLATE
9 AND TIGHTEN.
STEP 6: WITH THE HELP OF AN ASSISTANT, ADJUST THE HEIGHT OF THE WORKSTATION BY REMOVING
(4) SCREWS IN EACH LEG AND RETHREADING THEM INTO THE HOLES AT THE DESIRED HEIGHT.
LEAVE THE SCREWS AT BACK OF THE LEG ASSEMBLIES OUT UNTIL
STEP 7.
STEP 7: ADJUST THE MODESTY PANEL 6 (IF INCLUDED) TO FIT BETWEEN THE LEG ASSEMBLIES 2 AND
3 . ATTACH IT WITH THE (4) BACK ADJUSTING SCREWS IN THE LEG ASSEMBLIES. INSERT THE
SOCKET SCREW 11 THROUGH THE TOP OF THE MODESTY PANEL SECTIONS. THREAD THE SOCKET
SCREW INTO THE WELD NUT 12 AND FULLY TIGHTEN.
STEP 8: LEVEL THE WORKSTATION IF REQUIRED BY TURNING THE LEVELING GLIDES OUT (CLOCKWISE
FROM THE TOP) ON THE LOW CORNERS OF THE UNIT.
