RIGHT ANGLE R-Style Beam User manual

Instruction #54126 • Dated: 05/22/2018 1 of 3
R-Style Beam Assembly Instructions
Warranty: raproducts.com/warranty
Failure to comply with or observe all assembly, safety, and operation instructions
and warnings regarding the use of this product may result in serious property
damage or bodily injury.
Make sure no obstacles are in the desk’s path and all cords are of appropriate length for the
desk. Always maintain a 1” clearance around the table to prevent pinching.
Never assemble (or disassemble) the table or components with the table plugged into a
power outlet. This product is for use on a nominal 120-volt circuit and has a grounding plug.
Make sure that the product is connected to an outlet having the same conguration as the
plug. No adapter should be used with this product.

K&A Manufacturing • 800.298.4351 • www.raproducts.com/install 2 of 3
R-Style Beam #54126
Step 1
A
A B
Remove and place beam
into slots on leg columns.
Detail A
E. M6 x 1/2” Machine Screw x4
F. 10 x 5/8” Round Washer Wood Screw x6
G. 3/16” x 3/4” Wood Screw x3
H. M6 x 9/16” Black Machine Screw x2
I. 5/64” x 1 3/8” Plate x2
Tools Required for Assembly
A. Power Driver with Adjustable Torque
B. #2 Phillips Head Driver Bit
C. #2 Square Head Drive Bit
D. Level
A B C
Hardware Included for Assembly (may have extra)
E F G H I
D

K&A Manufacturing • 800.298.4351 • www.raproducts.com/install 3 of 3
R-Style Beam #54126
Step 2
Step 3 Optional Stability Panel
• Install the machine screws
into the legs and panel hardware.
H
I
A B C
F G
H
Spread beam to align holes
at top of legs with inserts
in worksurface.
G
F
• Install wood screws.
• Install machine screws and
plate for nal adjustment.
IH
I
A B C
HIE
F
Detail F
E
