RIGHT ANGLE R-Style T-Base Table User manual

Instruction #51930 • Dated: 07/10/2019 1 of 4
R-Style T-Base Table Assembly Instructions
Warranty: raproducts.com/warranty

K&A Manufacturing • 800.298.4351 • www.raproducts.com/install 2 of 4
E. 8mm x .75 Thread Screw x16
F. 5/8” Wood Screw x12
G. 5mm Allen Wrench x1
H. Beam x1
I. Center Hinge x1
J. Left Hinge x1
K. Right Hinge x1
L. Left Leg x1
M. Right Leg x1
Tools Required for Assembly
A. Power Driver with Adjustable Torque
B. Tape Measure
C. #2 Square Head Drive Bit (Recommended)
D. #2 Phillips Head Driver Bit (Recommended)
A B DC
Hardware, Tools and Parts Included for Assembly (may have extra)
E F G
H I
J K
L M

K&A Manufacturing • 800.298.4351 • www.raproducts.com/install 3 of 4
M
L
Step 1
• Lay the beam on a protective surface with the
insert channels facing up.
• Place one of the leg assemblies over the main
beam sliding the insert into the hollow leg
assembly. The leg assemblies are interchangeable.
• Insert the screws into the leg and fully tighten.
Do this to both legs.
Step 2
• Set the left and right hinges on the main beam.
• Attach four screws through the hinges and into the
main beam.
E
K
H
J
E G
EE
E
A C
E

K&A Manufacturing • 800.298.4351 • www.raproducts.com/install 4 of 4
Step 3
• Set the hinge mechanism onto the
main beam and attach with four
machine screws.
Step 5
E
Get help lifting
heavy items.
Step 4
• Lay the worksurface onto a protected
surface with the pilot holes facing up.
• Attach the worksurface to the mechanism
and both hinges with wood screws.
F
A C F
E
A C I
