RIGHT ANGLE R-Style Custom C Leg Base with Side Stationary... User manual

Instruction #54092 • Dated: 07/31/2018 1 of 5
R-Style Custom C Leg Base with Side Stationary Pedestal
Assembly Instructions
Warranty: raproducts.com/warranty

K&A Manufacturing • 800.298.4351 • www.raproducts.com/install 2 of 5
D. M6 x 15 Phillips Head Machine Screw x6
E. 10 x 5/8” Wood Screw x12
Tools Required for Assembly
A. Power Driver with Adjustable Torque
B. #2 Phillips Head Driver Bit
C. #2 Square Head Drive Bit
A B
Hardware Included for Assembly (may have extra)
D E
F. Right Leg x1
G. Modesty Panel x1
H. Pedestal x1
Parts
F G
H
C

K&A Manufacturing • 800.298.4351 • www.raproducts.com/install 3 of 5
Step 2
G
F
• Attach the modesty panel to
the leg with three machine
screws and fully tighten.
Step 1
• Lay the worksurface on a
protected surface with the
pilot holes facing up.
D
A B
D

K&A Manufacturing • 800.298.4351 • www.raproducts.com/install 4 of 5
Step 4
• Attach the leg to the worksurface with
three screws. Pilot holes are provided. F
Step 3
• Attach the modesty panel to the pedestal with
three machine screws and fully tighten.
H
D
A C
A B
D
E
E

K&A Manufacturing • 800.298.4351 • www.raproducts.com/install 5 of 5
Step 6
• Attach the modesty panel to
the worksurface with three wood
screws. Pilot holes are NOT
provided. Screws are self driving
G
Step 5
• Slide the drawers out of the pedestal.
• Attach the pedestal to the worksurface
with six wood screws. Pilot holes
are provided.
H
E
A C E
E
A C E
