RIGHT ANGLE NewHeights Storage Bin User manual

Instruction # 52710
www.raproducts.com
Version Dated: 8/25/15
Read all the instructions before beginning.
Page1 OF 3
K&A Manufacturing
6703 Zinser Street
Schofield, WI 54476
Phone: [phone]
Fax: [phone]
NewHeights™ Storage Bin
Installation Instructions

Page 2 OF 3
K&A Manufacturing
6703 Zinser Street Schofield, WI 54476
Phone: [phone]
Fax: [phone]
www.raproducts.com
Tools Required for Assembly:
Power Driver W/Adjustable Torque
3/16" Hex Head Driver Bit or
Allen Wrench
Tape Measure
Hardware Is Drawn
Actual Size
Instruction # 52710
5231452354
ITEM # PART # DESCRIPTION QTY.
1 52059 5/8" Shorty Pl g 2
2 800542 NewHeights/NewGas Storage Bin Assembly 1
3 52314 M8-1.25 x 8mm B tton Head Socket Screw 2
4 52354 M8 x 1.25 Offset Weld N t 2
43
Step 1: Lay the workstation on a protected surface with the back facing up. Remove
the (2) shorty plugs 1from the leg bracket to get access to the screws holding the leg
assembly to the column assembly. Loosen the screws and slide the leg assembly off
the column. Set these parts aside for reassembly later.
Step 2: Insert (2) socket screws 3through the holes in the back of the storage bin 2.
Thread (2) weld nuts 4onto the socket screws. The projections on the weld nuts must
face the bin. Slide this assembly into the groove in the column assembly until the bin
is where you want it. Fully tighten the screws.
Step 3: Reattach the leg assembly in the reverse order of disassembly.
4
an unassembled workstation, do these
If you are receiving the storage bin with
steps before you attach the legs.
3
2
1
Steps 1-3

4
2
3
Column
Cover
The rest of the workstation
is not shown for clarity.
6703 Zinser Street Schofield, WI 54476
www.raproducts.com
Instruction # 52710
Fax: [phone]
Phone: [phone]
Page 3 OF 3
K&A Manufacturing
To install the storage bin on a NewHeights
leg assembly:
Step 1: Raise the workstation to its highest level.
Remove the column cover from the top of the
outer column and raise it high enough to get
access to the groove at the front.
Step 2: Insert (2) socket screws 3through the holes
in the back of the bin 2. Thread (2) weld nuts 4
onto the socket screws. The projections on the weld
nuts must face the bin. Do not fully tighten.
Step 3: Slide the weld nuts 4into the groove in the
front of the leg assembly until the bin 2is where you
want it. Fully tighten the socket screws.
Step 4: Replace the column cover.
