RIGHT ANGLE R-Style Corner Diagonal 50648 User manual

Version Dated: 9/30/14
Read all the instructions before beginning.
K&A Manufacturing
Hardware Pack # 50648 Page1 OF 2Instruction # 53249
6703 Zinser Street
Schofield, WI 54476
Phone: [phone]
Fax: [phone]
www.raproducts.com
R-Style Corner Diagonal

Page 2 OF 2
K&A Manufacturing
6703 Zinser Street Schofield, WI 54476
Phone: [phone]
Fax: [phone]
www.raproducts.com
Tools Required for Assembly:
Power Driver W/Adjustable Torque
#2 Phillips Head Driver Bit or
#2 Square Head Driver Bit
Tape Measure
Instruction # 53429
ITEM # PART # DESCRIPTION QTY.
1 Varies Corner Diagonal orksurface 1
2 29SL 29SL Post Leg 1
3 51708 M5 x 18mm (7/8") Sq/Ph/ shr Head ood Screw 20
4 800512 2 X 2 orksurface Joiner Plate 4
3
4
Step 1: Lay the worksurface 1on a protected surface with the
pilot holes facing up. Align the holes in the plate at the top of the
post leg 2with the pilot holes at the back corner of the work-
surface. Attach the leg to the worksurface with (4) wood screws
3. Do not over-tighten the screws. Use a low torque setting on
the power driver.
Step 2: Attach (2) joiner plates 4on each edge of the worksurface
1that will butt another worksurface. Center the joiner plates on the
edge of the worksurface 1/2" from the front and back edges. Attach
them with (4) wood screws 3in each joiner plate.
Hardware Pack # 50648
1/2 Size
Full Size
2
4
51708
3
800512
1
3
Steps 1 & 2
