RIGHT ANGLE R-Style 52822 User manual

R-Style Hanging Modesty
Page1 OF 2
Panel Purchased Bracket
K&A Manufacturing
Instruction # 52816
www.raproducts.com
Read all the instructions before beginning.
Version Dated: 12/1/14
6703 Zinser Street
Schofield, WI 54476
Phone: [phone]
Fax: [phone]
Hardware Pack # 52822

4
the bracket. Fully tighten the screws. Repeat
through the holes in the modesty panel and into
Step 1: Lay the modesty panel 1on a protected
surface with the flanges facing up. Place the
right hand bracket 2against the right hand side
of the modesty panel with the top flange facing
the inside of the panel and flush with the top
flange of the modesty panel. See Detail A.
Attach the bracket with (2) machine screws 4
1
2
1
2
3
Workstation Base Not
Shown for Clarity
Page 2 OF 2
K&A Manufacturing
6703 Zinser Street Schofield, WI 54476
Phone: [phone]
Fax: [phone]
www.raproducts.com
Tools Required for Assembly:
Power Driver W/Adjustable Torque
#2 Phillips Head Driver Bit or
#2 Square Head Driver Bit
Tape Measure
ITEM PART DESCRIPTION QTY.
1 Varies R-Style Modesty Panel 1
2 52917 or 52918 Hanging Modesty Panel Bracket Set 1
3 51708 M5 X 18MM Sq/Ph/Wshr Head Wood Screw 4
4 NA Machine Screw (Comes With Bracket Hardware) 4
Step 1 with the left hand bracket on the
left hand side of the modesty panel.
Step 2: With the help of an assistant,
center the modesty panel and bracket
assembly on the underside of the work-
surface at the location you desire and
attach the brackets with (4) wood
screws 3.
Detail A
Step 1
Step 2
Instruction # 52816
