Satel PERFECTA 16-WRL Owner's manual

Firmware Version 1.01
Alarm Control Panel
PROGRAMMING
SATEL sp. z o.o.
ul. Budowlanych 66
80-298 Gdańsk
POLAND
tel. [phone]
www.satel.eu
perfecta_p_en 10/17

Before you start programming, please read carefully this manual in order to avoid mistakes
that can lead to malfunction or even damage to the equipment.
SATEL's goal is to continually upgrade the quality of its products, which may result in some
changes of their technical specifications and firmware. The current information on
the introduced modifications is available on our website.
Please visit us:
http://www.satel.eu
Hereby, SATEL sp. z o.o., declares that this control panel is in compliance with the
essential requirements and other relevant provisions of Directive 2014/53/EU. The
declaration of conformity may be consulted at www.satel.eu/ce
Service code: 12345
The following symbols may be used in this manual:
- note,
- caution.

Changes made to the firmware version 1.01
Expansion
modules You can run the identification function from the PERFECTA SOFT
program to detect modules connected to communication bus.
Wireless keypad You can define the time during which the keypad is to work in active
mode after wake-up (“Wake-up” option has been removed and
“Wake-up duration” parameter has been added).
Procedure of battery replacement in the wireless keypad has been
modified (“User can replace PRF-LCD-WRL battery” option has been
removed and “Replace battery” user function has been added).
Entering code After an incorrect code has been entered, the “Wrong code” message
will be displayed on the keypad. The same message will also be
displayed after entering a correct code, when the keypad is blocked.
Arming When viewing the list of problems that prevent arming, the user can
bypass / unbypass zones (provided he/she has appropriate rights).
Listening in You can better customize the listening in to meet the needs of the
users by using the following new options:
“->Listen-in” – defines whether the given telephone can be used to
call the alarm control panel to listen to what is going on in the
premises,
“Listen-in->” – defines whether the telephone user, after the voice
notification message is played, can listen to what is going on in the
premises,
“Answer if partition armed” – defines whether the control panel will
answer the calls at all times or when the indicated partitions are
armed only.
Remote update You cannot edit the messages used by the control panel to provide
information about events associated with firmware updates (message
text is factory preset).

2 PERFECTA SATEL
CONTENTS
1. Introduction......................................................................................................................4
2. Configuring the system by using keypad......................................................................4
2.1 Starting the service mode...................................................................................................... 4
2.2 Starting the service mode “from pins” ................................................................................... 4
2.3 Service mode indication ........................................................................................................ 5
2.4 Navigating through the menu and running functions............................................................. 5
2.4.1 Using the arrow keys ............................................................................................................... 5
2.4.2 Using the number shortcuts ..................................................................................................... 5
2.5 Data editing ........................................................................................................................... 5
2.5.1 Selection from the single-choice list ........................................................................................ 6
2.5.2 Selection from the multiple-choice list ..................................................................................... 6
2.5.3 Entering decimal values........................................................................................................... 6
2.5.4 Entering hexadecimal values ................................................................................................... 6
2.5.5 Programming telephone numbers............................................................................................ 6
2.5.6 Entering names........................................................................................................................ 6
2.6 Hiding the service mode........................................................................................................ 7
2.7 Exiting the service mode ....................................................................................................... 7
3. Configuring the system with the PERFECTA SOFT program .......................................7
3.1 Description of the PERFECTA SOFT program....................................................................... 7
3.1.1 Menu bar in the PERFECTA SOFT program ............................................................................ 8
3.1.2 Side menu................................................................................................................................ 9
3.1.3 Additional menu ..................................................................................................................... 10
3.2 Establishing connection between the program and the control panel ................................. 13
3.2.1 Local connection .................................................................................................................... 13
3.2.2 Remote connection: SATEL server ....................................................................................... 13
3.2.3 Remote connection: PERFECTA>>PERFECTA Soft............................................................ 13
4. Hardware........................................................................................................................14
4.1 Mainboard ........................................................................................................................... 14
4.1.1 Clock ...................................................................................................................................... 14
4.1.2 Times ..................................................................................................................................... 15
4.1.3 Arming.................................................................................................................................... 16
4.1.4 Options................................................................................................................................... 16
4.2 GSM phone ......................................................................................................................... 18
4.2.1 Pre-paid support .................................................................................................................... 20
4.3 Keypad ................................................................................................................................ 20
4.3.1 Options................................................................................................................................... 20
4.3.2 Display and keys.................................................................................................................... 21
4.3.3 Chime..................................................................................................................................... 22
4.3.4 Volume ................................................................................................................................... 22
4.3.5 Wireless keypad PERFECTA 16-WRL / PERFECTA 32-WRL ............................................. 22
4.4 Zone module ....................................................................................................................... 23
4.5 Output module..................................................................................................................... 23
5. Partitions........................................................................................................................24
5.1 Partition parameters ............................................................................................................24
6. Zones..............................................................................................................................25
6.1 Zone parameters and options ............................................................................................. 26
6.2 Zone types........................................................................................................................... 28
6.3 Wireless detector PERFECTA 16-WRL / PERFECTA 32-WRL.......................................... 29
6.3.1 Wireless detectors and zone settings .................................................................................... 29
7. Outputs...........................................................................................................................29
7.1 Output functions .................................................................................................................. 29
7.2 Output parameters and options........................................................................................... 30

SATEL PERFECTA 3
7.3 Quick control of outputs .......................................................................................................32
7.4 Wireless siren PERFECTA 16-WRL / PERFECTA 32-WRL................................................ 32
8. Communication .............................................................................................................32
8.1 SATEL server ...................................................................................................................... 33
8.2 Direct connection to PERFECTA SOFT................................................................................ 33
9. Reporting .......................................................................................................................33
9.1 Reporting parameters and options ...................................................................................... 33
9.1.1 Station 1 / Station 2.................................................................................................................34
9.1.2 Test transmissions ..................................................................................................................36
9.1.3 Events selection......................................................................................................................36
10. Messaging......................................................................................................................36
10.1 Parameters and options of the messaging ..........................................................................37
10.1.1 Phones....................................................................................................................................37
10.1.2 AUDIO messaging ..................................................................................................................38
10.1.3 AUDIO messages ...................................................................................................................38
10.1.4 SMS messaging......................................................................................................................38
11. SMS control ...................................................................................................................39
11.1 Parameters and options of SMS control .............................................................................. 39
12. Timers.............................................................................................................................40
12.1 Parameters and options of the timers..................................................................................40
12.1.1 Editing the timer parameters...................................................................................................41
13. Control panel firmware update.....................................................................................41
13.1 Local update ........................................................................................................................ 41
13.2 Remote update .................................................................................................................... 42
13.2.1 Remote update parameters and options ................................................................................42
13.2.2 Procedure of remote update for control panel firmware .........................................................43
14. Users ..............................................................................................................................43
14.1 User schedules .................................................................................................................... 43
14.1.1 Parameters of the user schedule............................................................................................44
14.2 Default functions of keyfob buttons...................................................................................... 45
15. Restoring the factory settings......................................................................................45
15.1 Restoring factory settings from keypad ............................................................................... 45
15.2 Restoring factory settings from PERFECTA SOFT program ................................................ 45
16. Manual update history ..................................................................................................46

4 PERFECTA SATEL
1. Introduction
You can configure the PERFECTA alarm system by using:
a computer running the PERFECTA SOFT program (locally or remotely),
a keypad.
The control panel can be configured when the ACTIVE option is enabled (see USER MANUAL).
As required by the standards, the service access after completion of the installation
has to be limited by the administrators.
Names of parameters and options from the PERFECTA SOFT program are used in this
manual. At the description of each parameter or option, you will find one of the following data
in square brackets:
name of the function which is used for configuring a parameter or option on the keypad,
name of a parameter or option from the keypad.
2. Configuring the system by using keypad
You can configure the alarm system by using functions available in the service mode menu.
When the control panel is running in service mode, tamper alarms are not
generated.
2.1 Starting the service mode
1. Enter the service code (by default: 12345) and press .
2. User menu appears.
3. Press .
4. When the cursor shows the SERVICE MODE function, press .
5. Service mode menu will be displayed (the cursor will show the END SM function).
2.2 Starting the service mode “from pins”
When entering the service mode in the normal way is not possible (the control panel does not
support keypads, does not accept the service code, etc.), you can use the emergency
procedure, so-called, starting “from pins”.
1. Turn off the control panel power supply (first disconnect the AC power, and then the
battery).
2. Put a jumper on the RESET pins on the control panel mainboard.
3. Turn on the control panel power supply (first connect the battery and then the AC power).
4. Wait a few seconds (until LEDs next to the RESET pins stop flashing) and remove the
jumper from the RESET pins. The control panel will enter the service mode. The service
mode menu will be displayed on the wired keypad with the lowest address.
If there is no wired keypad in the alarm system or there is no communication with the
wired keypads (e.g. when the communication bus is shorted), you can get access to
the service mode menu from the wireless keypad with the lowest address. Press any
key on this keypad within 30 seconds of removing jumper from the RESET pins.
The service mode menu will not be displayed, if the DISABLE SERVICE MODE option is
enabled in the control panel. The “Factory settings ? 1=Yes” message will be

SATEL PERFECTA 5
displayed on the keypad with the lowest address. You can press to restore the
factory default settings. The service mode menu will not be displayed until the factory
settings are restored.
2.3 Service mode indication
The service mode is indicated on the keypads by means of the LED. The LED is
steady ON on the keypad on which the service mode menu is displayed, and is flashing on
the other keypads. Additionally, the service mode can be signaled audibly, after the
appropriate option is enabled.
2.4 Navigating through the menu and running functions
To navigate throughout the menu, you can use the arrow keys or number shortcuts. You can
also combine the two methods. The cursor shows the submenu you can enter / function
you can run.
2.4.1 Using the arrow keys
1. Using the and keys, find the required submenu.
2. Press or to open a submenu (use the key to go back to the main menu).
3. Repeat the steps 1 and 2 until the required function is found.
4. Press or to run the function.
2.4.2 Using the number shortcuts
Submenus and functions are numbered (you can find the numbers in the LIST OF SERVICE
FUNCTIONS document).
1. Use the number keys to enter the number (use the key to erase the last digit).
2. The menu item designated by this number will be displayed (use the key to go back
to the main menu).
3. Press or to open a submenu or run a function.
If the cursor indicates END SM and you want to quickly run a function, enter its number and
press or . For example, to run the expander identification function, press
successively .
If the cursor indicates an item different from END SM, entering a digit will add this digit at
the end of the number by which the item displayed in the menu is designated. New digits are
always added at the end of the number displayed (only the END SM function is not
numbered). For example, if the cursor indicates a menu item with the 31 (31.EOL) number,
pressing in turn will display the 3132 (3132.Zn.32 EOL) item, not the 32
(32.SENSITIVITY) item. To display the 32 (32.SENSITIVITY) item, you should press (to
move the cursor down) or (to erase 1 and add 2).
If you remember the submenu/function number and you want to avoid mistakes, press
before entering the number.
2.5 Data editing
The editing method depends on the type of data. Having completed the editing, press
to save the changes. If you want to exit the function without saving the changes, press .

6 PERFECTA SATEL
2.5.1 Selection from the single-choice list
In the lower line of the display, the currently selected item is presented. You can scroll the list
using the and keys.
2.5.2 Selection from the multiple-choice list
In the lower line of the display, one of the items you can choose from is presented. You can
scroll the list using the and keys. The following symbol is situated in the upper
right corner of the display:
– displayed item is selected / option is enabled,
– displayed item is not selected / option is disabled.
Press any number key to change the currently shown symbol for another one.
If you want to see the status of all items (these can be e.g. zones, outputs, options, etc.),
press or . The numbers around the display allow the items to be identified. Use the
and keys to move the cursor. After hovering the cursor over the selected item,
you can change its status by pressing any number key. If you want to restore the previous
way of presentation of the list, press or .
2.5.3 Entering decimal values
To enter digits, use the number keys. Use the and keys to move the cursor. In
some functions, the key deletes the character on the left side of the cursor.
2.5.4 Entering hexadecimal values
To enter digits, use the number keys. To enter the A, B and C characters, use the key,
and to enter D, E and F, use the key (keep pressing the key until the required character
appears). Use the and keys to move the cursor. The key deletes the
character on the left side of the cursor.
2.5.5 Programming telephone numbers
To enter digits, use the number keys. To enter the +, *, # characters, use the key (keep
pressing the key until the required character appears). Use the and keys to move
the cursor. The key deletes the character on the left side of the cursor.
2.5.6 Entering names
The characters that can be entered by using the keys are presented in Table 1. Keep
pressing the key until the required character appears. Long press the key to display the digit
assigned to it.
Shown on the right side in the upper line of the display is information about the letter case:
[ABC] or [abc] (it will be displayed after pressing any key and will be visible for a few seconds
after the last keystroke).
Use the and keys to move the cursor. The key deletes the character on the
left side of the cursor.

SATEL PERFECTA 7
Key Characters available after next keystroke
! ? ' ` " { } $ % & @ \ ^ | # 1
abc2
def3
ghi4
jkl5
mno6
pqrs7
t u v 8
wxyz9
. , : ; + - / = _ < > ( ) [ ] 0
Table 1. Characters available when entering names. The upper case letters are available
under the same keys (to change the letter case, press ).
2.6 Hiding the service mode
You can hide the service mode by using the 09.HIDE SM function. The control panel will
remain in the service mode, but the service mode menu will not be displayed. The function
can be useful e.g. when you have to leave the keypad, but you want to prevent unauthorized
personnel from getting access to the service menu in the meantime. To get access to the
menu again, proceed in the same way as when entering the service mode.
2.7 Exiting the service mode
Keep pressing until the cursor indicates the SM END function, and then press .
3. Configuring the system with the PERFECTA SOFT program
You can download the PERFECTA Soft program from the www.satel.eu website.
Communication between the program and the control panel is encrypted. The control panel
can be programmed locally or remotely. Remote programming is only possible after the
GSM/GPRS communicator settings have been configured (see “GSM phone” p. 18).
3.1 Description of the PERFECTA SOFT program
Access to the program can be password protected (see ““Configuration” window” p. 12).

8 PERFECTA SATEL
Fig. 1. PERFECTA SOFT window when the program is run for the first time.
3.1.1 Menu bar in the PERFECTA SOFT program
The menu bar is displayed in the top part of the program window. Appearance of the menu
bar depends on the contents presented in the window.
Menu bar in the “Projects” tab
Fig. 2. Appearance of the menu bar when the “Projects” tab is displayed.
The search field is displayed on the menu bar. If you want to find a project file, click on the
search field and start entering characters. The current view will be filtered out, based on the
text entered.
Buttons
click, if the files are to be sorted by name (the arrow next to the button indicates
whether the files from A to Z or from Z to A are displayed)
click, if the files are to be sorted by the time they were saved to disk (the arrow next to
the button indicates whether the files are displayed in the descending or ascending
order)
click, if the information about files is to be presented in brief version
click, if the information about files is to be presented in full version
click to display additional menu.

SATEL PERFECTA 9
Appearance of the menu bar when displaying the control panel data
Fig. 3. Appearance of the menu bar after establishing connection with the control panel.
type of alarm control panel and firmware version.
icon displayed when the control panel is running in the service mode.
information about the SIM card used, GSM signal level and operator of the GSM network
used by the communicator.
date and time according to the control panel clock.
information on the way of communication with the alarm control panel:
COMn [n – number of computer COM port] – local connection,
TCP – remote connection (GPRS).
Buttons
click to display the list of troubles. The button is shown when the control panel is
indicating a trouble or trouble memory.
click to write computer clock time to the control panel.
click to establish connection to the control panel. The button is displayed when the
program is not connected to the control panel.
click to finish connection to the control panel. The button is displayed when the
program is connected to the control panel.
click to read data from the control panel.
click to write data to the control panel.
click to display information on the status of partitions, zones, outputs etc. The button
is active after connection to the control panel is established.
click to display additional menu.
3.1.2 Side menu
The side menu is displayed on the left side of the program window. Appearance of the menu
depends on the contents presented in the window.
The side menu before the control panel data are displayed
New – click to display the “New” tab.
Projects – click to display the “Projects” tab.
Import – click to import the file with control panel settings.
Recent – the list of recently opened files. Click on the name of the file to open it.
“New” tab
The tab displays the files with default settings of the PERFECTA control panels.

10 PERFECTA SATEL
“Projects” tab
The tab displays the files saved to the computer disk, containing data of the PERFECTA
control panels.
The side menu after the control panel data are displayed
After the file with control panel data is opened or connection with the control panel is
established, the side menu will display buttons which open the tabs used for configuration of
the control panel settings.
3.1.3 Additional menu
The additional menu is displayed after you click on . Appearance of the menu depends on
the contents presented in the window.
Open – click to display the “Projects” tab.
Save – click to save the control panel data to the computer disk.
Export – click to export the file with control panel data.
Convert – click to convert the control panel data for the needs of another PERFECTA control
panel.
Connection – click to open the “Connection” window.
Configuration – click to open the “Configuration” window.
About – click to display information about the PERFECTA SOFT program.
Licence agreement – click to show the license agreement.
“Connection” window
In the window, you can choose how connection with the control panel is to be established:
if the control panel is to be programmed locally from the computer connected to the
RS-232 (TTL) port on the control panel, select “Local connection”,
if the control panel is to be programmed remotely via GPRS by using the SATEL server,
select “Remote connection: SATEL server”,
if the control panel is to be programmed remotely via GPRS, but the control panel is to
connect directly to the program, select “Remote connection: PERFECTA>>PERFECTA
Soft”.
Local connection
Fig. 4. “Connection” window: local connection settings.

SATEL PERFECTA 11
RS-232 port – COM port of the computer through which communication with the RS-232
(TTL) port of the control panel is to take place.
Panel key – identifier of the control panel. It must be identical to that programmed in the
control panel (see p. 32).
Remote connection: SATEL server
Fig. 5. “Connection” window: settings for establishing connection through SATEL server.
IMEI – individual identification number of the control panel GSM communicator.
ID – individual identification number for the purposes of communication through the SATEL
server (assigned automatically by the SATEL server).
To check the IMEI number and ID number on the keypad, use the 7.IMEI/ID function
(enter the user menu and press in turn).
If the control panel was programmed locally before, the IMEI number and ID number
will be read from the control panel data.
Panel key – identifier of the control panel. It must be identical to that programmed in the
control panel (see p. 32).
Remote connection: PERFECTA>>PERFECTA Soft
TCP/IP port – number of the TCP port used for direct communication between the control
panel and the computer with PERFECTA SOFT program via GPRS.
Panel key – identifier of the control panel. It must be identical to that programmed in the
control panel (see p. 32).
Buttons
OK – click to confirm the changes.
Cancel – click to close window without saving changes.

12 PERFECTA SATEL
Fig. 6. “Connection” window: settings for direct connection via GPRS.
“Configuration” window
Fig. 7. “Configuration” window.
PERFECTA Soft password – if you want to protect the program against unauthorized
access, you can enter the password.
Data files encryption key – if you want the files saved to disk to be additionally encrypted,
enter the file encryption key. Opening the files in another PERFECTA Soft program without
entering the valid key will be impossible.
Data folder – you can choose whether the control panel data files are to be saved to the
default folder or a folder selected by you.
Program language – you can select a program language. The program will restart after the
language is changed
Buttons
Save – click to save changes.
Cancel – click to close window without saving changes.

SATEL PERFECTA 13
3.2 Establishing connection between the program and the control panel
Establishing connection is possible, if an identical PANEL KEY has been programmed in
the control panel and in the program, except for the control panel with factory settings.
3.2.1 Local connection
1. Connect the control panel RS-232 (TTL) port with the computer port (for example, by
means of the USB-RS converter offered by SATEL).
2. Open the file with control panel data (the file with default settings (“New” tab) or the file
saved on the computer disk (“Projects” tab)).
3. Configure the settings required to establish local connection (see ““Connection” window”
p. 10).
4. Click on the menu bar.
5. A window will open with information that connection has been established and a prompt to
read the data.
6. Click “Yes”.
3.2.2 Remote connection: SATEL server
The PERFECTA SOFT CONN.VIA SATEL SERVER ALLOWED option must be enabled in
the control panel (see “SATEL server: p. 33). By default, this option is disabled.
1. Open the file with control panel data (the file with default settings (“New” tab) or the file
saved on the computer disk (“Projects” tab)).
2. Configure the settings required to establish connection via GPRS through the SATEL
server (see ““Connection” window” p. 10).
3. Click on the menu bar.
4. A window will open with information that connection has been established and a prompt to
read the data.
5. Click “Yes”.
3.2.3 Remote connection: PERFECTA>>PERFECTA Soft
The computer running the PERFECTASOFT program must have a public IP address.
1. Open the file with control panel data (the file with default settings (“New” tab) or the file
saved on the computer disk (“Projects” tab)).
2. Configure the settings required to establish direct connection via GPRS (see
““Connection” window” p. 10).
3. Click on the menu bar.
4. The program will wait for connection being established by the control panel. The control
panel will make an attempt to establish connection after starting the function from the
keypad or receiving an SMS message.
Establishing connection after the function is started from the keypad
Address of the computer running the PERFECTA SOFT program and the number of
port used for communication must be programmed in the control panel (see “Direct
connection to PERFECTA SOFT” p. 33).
1. Ask the authorized user to start the PERFECTA SOFT function (the function is available in
user menu).

14 PERFECTA SATEL
2. After the control panel connects to the computer, a window will open with information that
connection has been established and a prompt to read the data.
3. Click “Yes”.
Establishing connection after receiving SMS message
A control command, after receiving of which the control panel will make an attempt to
establish connection, must be programmed in the control panel (see “Direct
connection to PERFECTA SOFT” p. 33).
The SMS message can be sent from a phone whose number is saved on the control
panel (see “Phones” p. 37).
1. Send an SMS message with the following content to the number of SIM card currently
used by the control panel:
xxxx (“xxxx” – control command that initiates establishing connection with the
PERFECTA SOFT program) – the control panel is to connect to the computer whose
address has been programmed in the control panel,
xxxx=aaaa:p= (“xxxx” – control command that initiates establishing connection with the
PERFECTA SOFT program; “aaaa” – address of the computer running the PERFECTA
SOFT program; “p” –TCP port) – the control panel is to connect to the computer whose
address has been given in the SMS message and use for communication the TCP port
given in the SMS message.
2. After the control panel connects to the computer, a window will open with information that
connection has been established and a prompt to read the data.
3. Click “Yes”.
4. Hardware
The control panel has a built-in GSM/GPRS communicator. To the control panel
communication bus, you can connect additional devices that will be needed in the alarm
system (keypads, zone modules and output module). The PERFECTA 16-WRL /
PERFECTA 32-WRL control panel also supports wireless keypads.
4.1 Mainboard
4.1.1 Clock
Dayligth saving time [061.DST] – the control panel can automatically adjust the clock
settings due to a change from the summer time to the winter time and vice versa. The
following correction schemes are available:
– no correction,
– according to the European Union rules,
– according to the United States' rules,
– correction by 1 hour according to dates,
– correction by 2 hours according to dates.
Summer time from [062.Summer from] / Winter time from [063.Winter from] – if the control
panel clock is to be corrected by 1 or 2 hours according to dates, you should enter the
dates (day, month) after the clock is changed to the summer time (moved forward) or to
the winter time (moved back).

SATEL PERFECTA 15
Clock correction [065.RTC adjust.] – if accuracy of the control panel clock is insufficient, its
settings can be automatically corrected (by up to ±127 seconds per week).
When testing the clock for accuracy, the synchronization function must be disabled.
Time synchronization
NTP server [NTP server time] – if this option is enabled, the control panel clock is
synchronized with the time server.
GSM network [GSM network time] – if this option is enabled, the control panel clock is
synchronized with the time of GSM network operator.
If the NTP SERVER and GSM NETWORK options are enabled at the same time,
synchronization with the GSM network time has priority. The clock will only be
synchronized with the time server if synchronization with the GSM network time fails.
Time zone [064.Timezone] – difference between the universal time (UTC) and the zone time.
The parameter is required, if the control panel clock is to be synchronized.
Fig. 8. “Mainboard” tab.
4.1.2 Times
AC loss report delay [123.Max.AC loss] – time during which the control panel must be
without AC power before the trouble is reported. A delay in reporting the trouble prevents
sending information about short-time voltage decays, having no effect on normal operation
of the system.
Keypad's alarm time [124.Al.duration] – duration of alarm signaling on keypads.

16 PERFECTA SATEL
Hide arm state indication after [125.Suppr.arm] – time counted from the moment of
partition arming, after which the LED on keypad indicating the partition armed status goes
off. If value 0 is programmed, the LED will be ON always when the partition is armed.
4.1.3 Arming
Prevent arming if not ready [Check if ready] – if this option is enabled, the control panel will
perform a check during arming for any problems that may prevent arming the system.
These include:
– a zone with enabled PRIORITY option is violated in the partition,
– the 3. INSTANT, 4. DOUBLE KNOCK, 5. 24H BURGLARY, 7. 24H PANIC, 8. 24H PANIC SILENT,
9. 24 MEDICAL or 10. 24H FIRE type zone is violated in the partition,
– the 3. INSTANT, 4. DOUBLE KNOCK, 5. 24H BURGLARY, 7. 24H PANIC, 8. 24H PANIC SILENT,
9. 24 MEDICAL or 10. 24H FIRE type zone or a zone with enabled PRIORITY option is
bypassed in the partition,
– there is a tamper in the partition,
– there is a trouble in the system.
The control panel checks the conditions twice:
before starting the arming procedure – the control panel will not start the arming
procedure, if any problems occur (the keypad provides a forced arming option – see
USER MANUAL),
after finishing the exit delay countdown – the system will not be armed (the arming
procedure will end in failure), if there are any problems, which did not occur before
starting the exit delay countdown.
Arm even if not ready after exit delay [Arm ExDly w.trbl] – if this option is enabled, the
control panel will not check conditions after finishing the exit delay countdown (it will only
check the conditions before starting the arming procedure). The option is available, when
the PREVENT ARMING IF NOT READY option is enabled.
Do not arm if battery trouble [BAT low = no arm] – if this option is enabled, forced arming
will be impossible in the event of battery trouble. The option is available, when the
PREVENT ARMING IF NOT READY option is enabled.
Do not arm if tampered [Tamper = no arm] – if this option is enabled, forced arming will be
impossible in the event of tamper. The option is available, when the PREVENT ARMING IF NOT
READY option is enabled.
4.1.4 Options
Service Mode beep [SM sounds] – if this option is enabled, the service mode will be audibly
signaled on the keypad.
Signal trouble state in partial arming [Trbl.in part.arm] – if this option is enabled, the
LED on the keypad goes off after both partitions are fully armed. If the option is disabled,
the LED goes off after just one of the partitions is armed in any mode.
Lock after three incorrect codes [3wrng.codes=blk.] – if the option is enabled, after
entering an incorrect code three times, the keypad will be blocked for 90 seconds. Entering
an invalid code again will prolong the locking.
Entering an invalid code three times may trigger alarm (cf. the keypad ALARM 3
INCORRECT CODES option).
Trouble memory [Troubles memory] – if this option is enabled, the control panel will also
provide information about troubles that do not exist any more. You can clear the trouble
memory by using keypad (when exiting the trouble review function), PERFECTA SOFT
program or PERFECTA CONTROL application.

SATEL PERFECTA 17
SMS notifications confirming ev. [Messaging events] – if this option is enabled, information
about sending SMS notification is saved in the event log.
Zone restore events [Restore events] – when this option is enabled, information about zone
restore is saved in the event log, if zone triggered alarm.
Limit number of events [Events limitat.] – if the option is enabled, events from the same
source are saved into the event log 3 times only. This option does not apply to the alarms
from zones.
Grade 2 [Grade 2] – if the option is enabled, the system operates in accordance with the EN
50131 standard requirements for Grade 2, i.e.:
– the keypad does not audibly signal alarms and troubles,
– the LEDs on the keypad indicates alarms only after the user enters the code and
presses ,
– the LED on the keypad goes off after just one of the partitions is armed in any
mode,
– the flashing LED in keypad means that there is a trouble in the system, some zones
are bypassed, or there has been an alarm,
– the keypad does not display alarm messages,
– the keypad display cannot be switched over to the zone status presentation mode,
– the quick arming from keypad (without entering the code) is not available,
– new access codes in the system must be composed of at least 5 digits,
– partial entering of the code is interpreted as entering an incorrect code,
– the keypad will be blocked after entering an incorrect code three times (cf. BLOCK AFTER
THREE INCORRECT CODES option),
– during arming, the control panel checks for problems that prevent arming (cf. PREVENT
ARMING IF NOT READY option),
– ARM EVEN IF NOT READY AFTER EXIT DELAY, DO NOT ARM IF BATTERY TROUBLE and DO NOT
ARM IF TAMPERED options are interpreted as disabled,
– control panel gives information about past troubles (cf. TROUBLE MEMORY option),
– loss of communication with SATEL server will not be reported (cf. DO NOT REPORT A
SATEL SERVER PROBLEM option),
– tamper of zone or expander can only be signaled by the external siren when the
partition to which the zone or expander belong is armed,
– the number of alarms from the 7. 24H PANIC and 8. 24H PANIC SILENT zones is not limited
(AUTO-RESET 3 option is ignored),
– arming is impossible, if the 6. 24H TAMPER zone is violated (cf. PRIORITY option),
– the warning alarm feature is enabled and the warning alarm is being signaled for at
least 30 seconds (cf. WARNING TIME),
– countdown of ENTRY DELAY, DELAY and DELAY ACTIVATION TIME is running for up to 45
seconds,
– AC loss report delay can be up to 60 minutes.
Tamper alarm on internal sirens [Tmp.on int.siren] – if this option is enabled, the
1. INTERNAL SIREN output is additionally activated after triggering tamper alarm.
Tamper alarm on external sirens [Tmp.on ext.siren] – if this option is enabled, the
1. EXTERNAL SIREN output is additionally activated after triggering tamper alarm.
Backlight off on AC loss [No AC=no bcklght] – if the option is enabled, the backlight in
hardwired keypads is automatically switched off in case of 230 V AC power loss.

18 PERFECTA SATEL
Disable Service Mode [Block SM] – if this option is enabled, the emergency procedure of
entering the service mode (“from pins”) is not available (it can only be used if factory
default settings of the control panel are restored).
Do not report a SATEL server problem [No SATEL trouble] – if this option is enabled, loss
of communication with the SATEL server will not be reported.
Do not report wireless system jamming [No jamm. trouble] – if this option is enabled,
jamming of the wireless system will not be reported.
4.2 GSM phone
SIM 1 [SIM1] / SIM 2 [SIM2] – if this option is enabled, the given SIM card is supported by the
control panel. Disable the option, if the given card is not to be used. Disabling the option
will prevent unnecessary reporting of troubles related to that card.
PIN [612.PIN / 622.PIN] – PIN code of the SIM card.
If a wrong PIN code is programmed, a trouble will be reported after using it. After 255
seconds the control panel will retry to use the PIN code. After the third attempt to use
a wrong PIN code, the SIM card will be blocked. To unblock the card, enter the PUK
code.
Fig. 9. “GSM phone” tab.
