Savant CLI-1WIRE2 User manual

CLI-1WIRE2-00 | 009-1829-00 | 190613
Copyright 2019 Savant Systems, LLC
45 Perseverance Way, Hyannis, MA 02601
Savant.com | 508.683.2500
1 of 2
Top Panel
Left Side Panel
A
Blinking Green RS-485 communications is not estab-
lished. Once powered is applied, it can
take up to 20 seconds to establish com-
munications.
HELPFUL! If communications was
established and subsequently
lost, the LED will stay solid for
about 1 minute before the LED
starts blinking.
.5s1s 1s
Repeat
.5s
Solid Green RS-485 communication is established
and the module is communicating with
thermostat.
BSmart Sensor 1-Wire Inputs - Each 1-wire input supports
connecting up to two 1-wire sensors (CLI-THFM1 ) for a total
of four sensors per module.
C24V AC input - Connect 24V AC to the two ~input ports.
A
RS-485 port - As shown in the image above, the right three
pins connect to the RS-485 connections on the thermostat.
Refer to the RS-485 Connections section for more informa-
tion on wiring.
(1) Sensor Module - (CLI-1WIRE2)
(2) 3 Position Screw Down Plug-In Terminal Block - (028-0736)
(1) 6 Position Screw Down Plug-In Terminal Block (028-0737)
(1) 6 Position Screw Down Plug-In Terminal Block (028-9352)
(1) Product and Regulatory Insert (009-1704)
Box Contents
Specifications
Supported Sensors (available on the Savant Store)
Minimum Supported Release
Climate Config App Version 1.1.2
Regulatory
Safety and
Emissions
FCC Part 15
Contains FCC ID: 2AEHU-MESHTEK-H52
Contains IC: 20059-MESHTEK52
RoHS Compliant
A
C
1-Wire
Status
24VAC
1
+5V
1Wire
Gnd
CLI-1WIRE2-00
S/N:
UID:
SH1180201332
001AAE09DD000065 2
+5V
1Wire
Gnd
~
~
B
A
GndN/C
N/C
N/C B (TX-)
A (TX+)
Temperature and Humidity 1-Wire Smart Sensor - (CLI-THFM1)
Maximum Wiring Distances
RS-485 Up to 1000 feet (304.8 m) cumulative
Power
#24 AWG - 20 feet (6.10 meters)
#20 AWG - 57 feet (17.37 meters)
#18 AWG - 90 feet (27.43 meters)
#16 AWG - 143 feet (43.59 meters)
#14 AWG - 228 feet (69.49 meters)
Power
Input Power 24V AC (19.2 - 28.8V AC)
Max Current Draw 0.1 amps (rms)
Dimensions and Weights
Height Width Depth Weight
CLI-1WIRE2 3.77 inch
(9.58 cm)
3.16 inch
(8.03 cm)
.91 inch
(2.3114 cm)
< 1 lbs
(< .5 kg)
Shipping 6.25 inch
(15.88 cm)
4.8 inch
(12.19 cm)
1.25 inch
(3.175 cm)
< 1 lbs
(< .5 kg)
Environmental
Temperature 32° to 104° F (0° to 40° C)
Humidity 10% to 90% Relative Humidity (non-condensing)
Sensor Module with Two 1-Wire Sensor Interfaces
Quick Reference Guide

CLI-1WIRE2-00 | 009-1829-00 | 190613
Copyright 2019 Savant Systems, LLC
45 Perseverance Way, Hyannis, MA 02601
Savant.com | 508.683.2500
2 of 2
When making connections, follow the guidelines set below to ensure a
safe and secure connection.
Use the diagram below when wiring the 1-Wire smart sensors.
Making Connections
Power Connections
RS-485 Connections
1-Wire Smart Sensor Connections
Refer to the following documents located on the Savant Customer
Community for additional information.
– Multistat Smart Thermostat Deployment Guide (009-1636)
– Multistat Thermostat with Touchscreen (009-1593)
Additional Information
1. With a small slotted screwdriver, turn
the screws on the connector coun-
terclockwise (CCW) until the silver
crimps open enough to slide a wire
into the square slots.
2. Strip back insulation on each wire to
/ inch and insert the stripped wire
into the proper connection.
3. Turn the screw clockwise (CW) until
the crimps tighten around each wire.
Tug on each wire a bit to verify they
are secure.
< 1/8 inch of
bare wire
exposed
Use the diagrams below when making the power connections be-
tween the thermostat and CLI-1WIRE2 climate module.
o
G
AUX OUT AUX IN
RS2 RS1
GND GND
RX- RX+
GND
1-WIRE
5V DC
Y2 Y1
W2 W1
RC RH
TX+
TX-
24C
1-Wire
Status
CLI-1WIRE2-00
S/N:
UID:
SHR184671332
001AAE09CA340065
1
2
+5V
1Wire
Gnd
+5V
1Wire
Gnd
24VAC ~
~
Power can be
daisy-chained
to other modules
24V AC
from HVAC
– Power can be daisy-chained between modules.
– The cable lengths vary depending on the size of the wire. See the
specifications table on page 1 for more information.
– Up to two sensors can be wired per input port with a cumulative
length of 600 feet (182 meters)
– Savant recommends using Cat 5e/6/7 when making connections.
– The table below shows the recommended connections when using
a Cat 5e/6/7 cable.
o
G
AUX OUT AUX IN
RS2 RS1
GND GND
GND
RX- RX+
GND
1-WIRE
5V DC
Y2 Y1
W2 W1
RC RH
TX+
(TX+)
TX-
(TX-)
24C
Left Side View
RS-485 Cable
CLI-1WIRE2
Use the diagrams below when making the RS-485 connections be-
tween the thermostat and CLI-1WIRE2 climate module.
– Max cable length is 1000 feet (304.8 meters).
– Savant recommends using standard RS-485 cable for wire runs.
1-Wire
Status
CLI-THLFM1
Splice up to two
sensors per input
Use Cat 5e/6/7
CLI-THLFM1
CLI-1WIRE2-00
S/N:
UID:
SHR184671332
001AAE09CA340065
1
2
+5V
1Wire
Gnd
+5V
1Wire
Gnd
24VAC
~
~
CLI-THFM1 Cat 5e/6/7 cable Description
Black White/Blue Stripe Gnd
Blue Blue Data
Red Orange +5V DC
