Savant® Super Pro Host (SVR-7100S) Quick Reference Guide
Box Contents
(1) Super Pro Host [SVR-7100S]
(1) Power Cord
(1) Magic Mouse 2
(1) Magic Keyboard w/Numeric Keypad
(1) USB-C to Lighting Cable
(2) Rack Rails (ships in a separate box)
(1) Quick Reference Guide [this document]
Specifications
Environmental
Temperature 50° to 95° F (10° to 35° C)
Humidity 5% to 95% Relative Humidity (non-condensing)
Dimensions and Weights
Height 8.67 in (22.02 cm)
Width 18.98 in (48.20 cm)
Depth 21.24 in (53.95 cm)
Weight 38.8 lbs (17.6 kg)
Rack Space 5U
Minimum Rack Depth 24.00 in (60.96 cm)
Power
Input Power 100-240V AC 50/60Hz, single phase
Maximum Power 1280W at 108–125V or 220–240V
1180W at 100–107V
Memory
RAM 32 GB
Compliance
Safety and
Emissions
FCC Part 15 CE C-Tick
RoHS Compliant
Minimum Supported Release
Savant OS da Vinci 9.3.2
Mounting
The SVR-7100S comes with rack rails. To install these
rails scan the QR code to the right or visit the Apple
Support website and search for Install Mac Pro into a
rack to review the article to install the Host.
Additional Documentation
For additional information, refer to the following documents on the
Savant Customer Community at Savant.com
–Savant Super Pro Host Deployment Guide (009-1633-xx)
Front Panel
EDC
B
A
ASlide Rail
Locks
Depress both at the same time to allow the
Host to slide out on the rails.
BHandles Used as handholds to assist in pulling the Host
alone the rack rails.
CThunderbolt 3 (2) Thunderbolt 3.
(Reserved for future use)
DPower LED Illuminates White when host is powered On.
EPower Button
Power On: Press while powered O.
Power O: Press and hold while powered On
until power LED goes out.
Side Panel
BA
A
Slide
Mounting
Points
Mounting points for the included rack rails.
B
Component
Access Latch
Latch on both sides to remove the component
access cover.

Super Pro Host Quick Reference Guide | 009-1981-00 45 Perseverance Way, Hyannis, MA 02601
Copyright 2020 Savant Systems, Inc | 200922 2 of 2 Savant.com | 508.683.2500
Rear Panel
G
FE
DC
BA
APower LED Illuminates White when host is powered On.
B
Power Input 100-240V AC 50/60Hz
CEthernet
(2) 8-pin RJ-45 port 10/100/1000 Base-T auto-
negotiating port.
IMPORTANT! For Savant configuration, the right
port is the only supported network connection.
The port on the left is blocked to avoid
confusion.
DHDMI Output (2) 19-pin type A HDMI female.
(Reserved for future use)
EAudio Output 3.5 mm (1/8 in) Audio output. Audio output
supports analog and optical connections.
FThunderbolt 3 (2) Thunderbolt 3.
(Reserved for future use)
GUSB (2) USB 3.0 Type A.
(Reserved for future use)
Network Requirements
Savant requires the use of commercial grade network equipment
throughout the network to ensure the reliability of communication
between devices. Connect all Savant devices to the same local
area network (LAN) or subnet as the host. Savant recommends
not implementing any type of trac or packet shaping in your
network topology for the Savant devices as this may interfere with
performance
IMPORTANT! Use of the Host Wi-Fi connection may result in
control or connectivity issues.
Network Configuration
To ensure that the IP Address will not change due to a power outage,
Savant recommends using DHCP reservation within the router. By
using this method, static IP Addresses for all devices can be managed
from a single UI, avoiding the need to access devices individually.
Setting DHCP reservation varies from router to router. Refer to the
documentation for the router to configure DHCP reservation.
Network Changes
After connecting to a new network, changing routers, or if the IP
Address range is changed in the current router, Savant recommends
the following steps. This will reset any IP connection and ensure that
the host is communicating with the network correctly.
Hot Plug the Ethernet (LAN) Connection
1. Disconnect the Ethernet (LAN) connection from the host.
2. Wait 15 seconds and then reconnect.
