Savant CLI-PTAC1K1 User manual

CLI-PTAC1K1-00 | 009-1806-00 | 190613
Copyright 2019 Savant Systems, LLC
45 Perseverance Way, Hyannis, MA 02601
Savant.com | 508.683.2500
1 of 2
Top Panel
Left Side Panel
A
Blinking Green RS-485 Communications is not estab-
lished. Once power is applied, it can take
up to 20 seconds to establish communi-
cations.
HELPFUL! If communications was es-
tablished and subsequently lost,
the LED will stay solid for about 1
minute before it starts blinking.
.5s1s 1s
Repeat
.5s
Solid Green RS-485 communication is established.
Module is communicating with thermo-
stat.
B
Climate Relays - The relay outputs on this module operate
similar to the relays of the same name on the thermostat.
Connect the relay outputs (W1, W2, Y1, etc) to the appropri-
ate connection on the PTAC equipment. Refer to the Relay
Connections diagram section when making the connections.
Climate Relay LEDs - The LEDs associated with each relay
will light when the relay is energized and be o when relay is
in its idle state.
C10K - Input port for a 10KΩtype temperature sensor. Any of
the sensors listed in the Supported Sensors section are sup-
ported on this input.
D
C / R Inputs - Connect 24V AC between the R and C termi-
nals. The voltage connected between these two terminals
will power the climate module and supply voltage to all relay
outputs See the Power Connections section below for more
information.
A
RS-485 Port - As shown in the image above, the right three
pins connect to the RS-485 terminals on the thermostat. Re-
fer to the RS-485 Connections section for more information
on wiring.
(1) HVAC PTAC Relay Module - (CLI-PTAC1K1)
(2) 3 Position Screw Down Plug-In Terminal Block - (028-0736)
(1) 6 Position Screw Down Plug-In Terminal Block - (028-0737)
(1) 6 Position Screw Down Plug-In Terminal Block - (028-9352)
(1) Product and Regulatory Insert (009-1706)
Box Contents
Specifications
Environmental
Temperature 32° to 104° F (0° to 40° C)
Humidity 10% to 90% Relative Humidity (non-condensing)
Power
Input Power 24V AC (19.2 - 28.8V AC)
Max Current Draw 0.2 amps (rms)
Maximum Wiring Distances
RS-485 Up to 1000 feet (304.8 meters) cumulative
Power
#24 AWG - 20 feet (6.10 meters)
#20 AWG - 57 feet (17.37 meters)
#18 AWG - 90 feet (27.43 meters)
#16 AWG - 143 feet (43.59 meters)
#14 AWG - 228 feet (69.49 meters)
Minimum Supported Release
Climate Config App Version 1.1.2
Regulatory
Safety and
Emissions
FCC Part 15
Contains FCC ID: 2AEHU-MESHTEK-H52
Contains IC: 20059-MESHTEK52
RoHS Compliant
Dimensions and Weights
Height Width Depth Weight
CLI-PTAC1K1 3.77 inch
(9.58 cm)
3.16 inch
(8.03 cm)
.91 inch
(2.31 cm)
< 1 lbs
(< .5 kg)
Shipping 6.25 inch
(15.88 cm)
4.8 inch
(12.19 cm)
1.25 inch
(3.18 cm)
< 1 lbs
(< .5 kg)
A
B
PTAC
Status W1
W2
Y1
CLI-PTACC1K1-00
S/N:
UID:
SHP180601332
001AAE09CA340065 Y2
G
O
C
R
10K
+
D
C
A
GndN/C
N/C
N/C B (TX-)
A (TX+)
Remote Temperature Sensor - Flush Mount (SST-TEMP1)
Outdoor Remote Temperature Sensor (SST-0TEMP1)
PLENOM Remote Sensor - Commercial (CLI-PLEN1C)
PLENOM Remote Sensor - Residential (CLI-PLEN1R)
SLAB Remote Sensor (CLI-SLAB1)
Supported Sensors (available on the Savant Store)
Relay Module for PTAC with One 6-Port Climate Relay and One 10K Thermistor Input
Quick Reference Guide

CLI-PTAC1K1-00 | 009-1806-00 | 190613
Copyright 2019 Savant Systems, LLC
45 Perseverance Way, Hyannis, MA 02601
Savant.com | 508.683.2500
2 of 2
Relay Connections
10K Remote Sensor Connections
RS-485 Connections
Making Connections
Power Connections
Refer to the following documents located on the Savant Customer
Community for additional information.
– Multistat Smart Thermostat Deployment Guide (009-1636)
– Multistat Thermostat with Touchscreen QSG (009-1593)
Additional Information
1. With a small slotted screwdriver, turn
the screws on the connector counter-
clockwise (CCW) until the silver crimps
open enough to slide a wire into the
square slots.
2. Strip back insulation on each wire to
/ inch and insert the stripped wire
into the proper connection.
3. Turn the screw clockwise (CW) until
the crimps tighten around each wire.
Tug on each wire a bit to verify they
are secure.
< 1/8 inch of
bare wire
exposed
When making connections, follow the guidelines set below to ensure a
safe and secure connection.
Use the diagrams below when making connections between the relay
outputs and the connections at the HVAC equipment.
Use the diagrams below when making connections between the 10K
remote sensor port and a 10K remote sensor.
Use the diagrams below when making the power connections be-
tween the thermostat and the CLI-PTAC1K1 climate module.
o
G
AUX OUT AUX IN
RS2 RS1
GND GND
RX- RX+
GND
1-WIRE
5V DC
Y2 Y1
W2 W1
RC RH
TX+
TX-
24C
PTAC
Status W1
W2
Y1
CLI-PTAC1K1-00
S/N:
UID:
SHR180601332
001AAE09CA340000
Y2
G
O
10K
C
R
+
Power can be
daisy-chained
to other modules
24V AC
from HVAC
– Power should only be connected across terminals C and R as
shown in the diagram above. The input power across the C and R
terminal supplies the voltage to power the module as well as all the
climate relays.
– Power can be daisy-chained between modules.
– The cable lengths vary depending on the size of the wire. See the
specifications table on page 1 for more information.
– There is no polarity to the 10K temperature sensors.
– Minimum size wire = #24 AWG.
– Maximum cable length = 500 feet (182meters).
– A twisted pair is recommended (E.G. cat 5e/6/7)
– All 10K type temperature sensors available through Savant are sup-
ported. See the Supported Sensors section.
– Use only HVAC approved cabling to make the connections.
– The CLI-PTAC1K1 also supports PTAC Heat Pump type installations.
– Savant recommends using standard RS-485 cable for wire runs.
– Max cable length is 1000 feet (304.8 meters).
o
G
AUX OUT AUX IN
RS2 RS1
GND GND
GND
RX- RX+
GND
1-WIRE
5V DC
Y2 Y1
W2 W1
RC RH
TX+
(TX+)
TX-
(TX-)
24C
Left Side View
RS-485 Cable
CLI-PTAC1K1
Use the diagrams below when making the RS-485 connections be-
tween the thermostat and CLI-PTAC1K1 climate module.
PTAC
Status W1
W2
Y1
CLI-PTAC1K1-00
S/N:
UID:
SHR180601332
001AAE09CA340000
Y2
G
O
10K
C
R
+
10K Remote
Sensor
W1 1st Stage
Heat
2nd Stage
Heat
PTAC SYSTEM CONNECTIONS
Compressor
1st Stage
Compressor
2nd Stage
Fan Relay
Reversing
Valve
W2
Y2
Y1
G
O
PTAC
Status W1
W2
Y1
CLI-PTAC1K1-00
S/N:
UID:
SHR180601332
001AAE09CA340000
Y2
G
O
10K
C
R
+
