Saxby Lighting Flexline Kit Manual

Instruction leaflet
Flexline Kit
52305, 52306
Waste electrical products should not be disposed of with household waste. Please recycle where facilities
exist. Check with your Local Authority or retailer for recycling advice.
Recycling advice
Commissioning
place.
V2 16/04/2021
WWW.saxbylighting.com Saxby lighting. BH17 7BY
For your safety, always switch off the power supply before changing lightbulbs, or cleaning.
Safety information

Thank you for purchasing this light fitting. Please read the instructions carefully before use to ensure safe and
satisfactory operation of this product. Please retain these instructions for future reference.
Warning
The power supply is Double Insulated and does not
require connection to an Earth circuit.
The LED strips are Safety Extra Low Voltage and
must not be earthed.
Please read these instructions carefully before
commencing any work.
This unit must be fitted by a competent and qualified
electrician.
Install in accordance with IEE Wiring regulations and
current Building Regulations.
This system operates at Safety Extra Low Voltage
(12V), via a LED driver. Never connect the light fittings
directly to the mains without using a LED driver.
Ensure that the supplied LED driver is used.
The mains plug must be situated indoors (e.g. house,
garage, shed) in order to protect it from the elements.
Do not exceed the LED driver load. LED drivers may
require a minimum load to operate.
Always disconnect the LED driver from the mains
when installing or maintaining this system.
This system contains non-replaceable parts and
cannot be serviced. If damage occurs the part should
be scrapped.
This product cannot be dimmed.
This product is rated at IP20
Waste electrical products should not be disposed of
with household waste. Please recycle where facilities
exist. Check with your local authority or retailer for
recycling advice.
Specification
Dimensions : 8.0mm wide, 2.5mm high, 5m long
Voltage : 240V ~ 50Hz
LED Voltage : 12V d.c.
Lumens : 1260 lm
Layout
which can be stuck to most surfaces.
of 100mm or multiples of 100mm.
ensuring the cables will reach the distance between
the power supply and the Flexline LED position.
cause a hazard. Position cables and Flexline LED's
away from areas where they may be at risk from
being cut, trapped or damaged.
conduit or plastic trunking.
Basic Installation
Specification
The Kit should contain:
indoor mains outlet socket that the system will
connect to. Do not plug-in at this stage.
ensure that the cable can reach when in the desired
position.
lengths, by unplugging the four pin connectors. To
shorten the flexline to a specific length, then it can
be done in multiples of 100mm. Look for the line on
the strip with four copper pads, as shown below.
anywhere else on the strip as this will cause the
Flexline strip to stop working. Please note that once
cut, these strips can only be rejoined by soldering.
connector on the Flexline strip observing the correct
polarity (align arrows as shown below).
