Saxby Lighting Scoop Rectangular Recessed Manual

Scoop Rectangular
Recessed
78542
Instruction leaflet
Care and Safety
• We recommend cleaning with a soft dry cloth. Do not use solvents or abrasive cleaners as these could damage
the finish.
• For your safety, always switch off the supply before cleaning.
Iss1 29/10/2018
WWW.saxbylighting.com Saxby lighting. BH23 3PE
Wiring
Check that...
You have correctly identified the wires.
•
•
The connections are tight.
• No loose strands have been left out of the connection
block.
Having correctly identified the wiring from your existing
light fitting, pull the wire through the hole and connect
to the connection block inside the LED driver in the
following way:
This unit is double insulated and must not be earthed. If
there are any incoming earth cables, they must be joined
together and well insulated with good quality insulation
tape. This is to ensure earth continuity throughout your
property.

Thank you for purchasing this light fitting. Please read the instructions carefully before use to ensure safe and
satisfactory operation of this product. Please retain these instructions for future reference.
Warning
Technical data
Please read these instructions carefully before
commencing any work.
This system contains non-replaceable parts and
cannot be serviced. If damage occurs the part
shouldbe scrapped.
The external flexible cable or cord of this luminaire
cannot be replaced . if the cord is damaged, the
luminaire must be destroyed.
This unit must be fitted by a competent and
qualified electrician.
Check the pack and make sure you have all of the
parts listed.
To prevent electrocution switch off at mains supply
This light fitting must be connected to a fused circuit.
before installing or maintaining this fitting.
Ensure other persons cannot restore the electrical
supply without your knowledge.
Install in accordance with IEE Wiring regulations
and current Building Regulations.
Supply
Bulb Type:
Voltage: 240 V~, 50 Hz
LED (35W) COB / 4000K
The light source of this luminaire is not replaceable; when the light source reaches its end of life
the whole luminaire shall be replaced.
Conformity with all relevant EC Directive requirements.
Waste electrical products should not be disposed of with household waste.
Please recycle where facilities exist.Check with your Local Authority or
local store for recycling advice.
Luminaires not suitable for covering with thermally insulating material.
The power supply is Double Insulated and does not require connection to an Earth circuit.
Minimum distance from lighted objects (0.5 metres)
Installation
Existing fittings must be completely removed before installation of a new product. Before removing the
existing fitting, carefully note the position of each set of wires.
• The ceiling surface must be flat and smooth to ensure a good fit.
• Note that the power needs to be isolated/switched off at the fuse board.
• Plan the desired layout of these fittings carefully, ensuring the cables will reach the distances between
the LED Driver and each light fitting. Ensure that there is adequate ventilation for theLED Driver.
•Cut a mounting hole 13 x 22cm in the ceiling taking care not to foul any pipes, mains cables or
joists beneath the surface.
Fig 1. (Recessed) Fig 2. (Wall)
•It is always recommended to cut the hole slightly smaller than the size specified, and then file the hole
until the recessed unit fits snugly.
•Push the spring clips upwards and fit into the ceiling hole, then push the unit up until firmly in position,
ensuring that no cables are trapped.
•Ensure that the product is sitting properly in the hole.
•It can also be used as a wall light, using the supplied screws to mount the light on the wall. See Fig 2.
•Switch on. Your light is now ready for use.
See wiring
• The minimum ceiling void depth is 90mm. when more than one downlight is installed, the minimum
distance between units is 500mm. the unit must be located a minimum distance of 50mm from a joist.
IP20
0,5
If replacing an existing fitting, make a careful note
of the connections.
2
3
4
5
13 X 22cm
As a wall light, it is recommended
to stick the drive on the back
of the product.
1
