Sharp MX-2301N Installation and operating manual

DIGITAL FULL COLOUR MULTIFUNCTIONAL SYSTEM
Safety Guide
Safety Guide
Safety Guide
Before installing this product, be sure to read the
"CAUTIONS" and "INSTALLATION
REQUIREMENTS" sections.
Keep this manual close at hand for reference
whenever needed.
MX-2301NMODEL:
SPECIFICATIONS
INFORMATION ON DISPOSAL
SUPPLIES
INSTALLATION REQUIREMENTS
CAUTIONS
TO THE ADMINISTRATOR OF THE MACHINE
Please see opposite side to access
to "Software Setup Guide" and "Sharpdesk
Installation Guide".
These manuals are combined for environmental protection.

EMC (this machine and peripheral devices)
Caution!
For complete electrical disconnection, pull out the main plug.
The socket-outlet shall be installed near the equipment and shall be easily accessible.
Shielded interface cables must be used with this equipment to maintain compliance with EMC regulations.
Warning:
This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be
required to take adequate measures.
This machine contains the software having modules developed by Independent JPEG Group.
This product includes Adobe
®
Flash
®
technology of Adobe Systems Incorporated.
Copyright© 1995-2007 Adobe Macromedia Software LLC. All rights reserved.
Required in IEC-950 (EN 60 950) - Europe
• The equipment should be installed near an accessible socket outlet for easy disconnection.
Required in Appendix ZB of BS 7002 (En 60 950) — United Kingdom
MAINS PLUG WIRING INSTRUCTIONS
The mains lead of this equipment is already fitted with a mains plug which is either a non-rewireable
(moulded) or a rewireable type. Should the fuse need to be replaced, a BSI or ASTA approved fuse
to BS1362 marked or and of the same rating as the one removed from the plug must
be used.
Always refit the fuse cover after replacing the fuse on the moulded plug. Never use the plug without
the fuse cover fitted.
In the unlikely event of the socket outlet in your home not being compatible with the plug supplied
either cut-off the moulded plug (if this type is fitted) or remove by undoing the screws if a rewireable
plug is fitted and fit an appropriate type observing the wiring code below.
DANGER: The fuse should be removed from the cut-off plug and the plug destroyed immediately
and disposed of in a safe manner. Under no circumstances should the cut-off plug be inserted
elsewhere into a 13A socket outlet as a serious electric shock may occur.
To fit an appropriate plug to the mains lead, follow the instructions below:
IMPORTANT: The wires in this mains lead are coloured in accordance with the following code:
GREEN-AND-YELLOW: Earth
BLUE: Neutral
BROWN: Live
As the colours of the wires in this mains lead may not correspond with coloured markings
identifying the terminals in your plug, proceed as follows:
The wire which is coloured GREEN-AND-YELLOW must be connected to the terminal in the plug
which is marked with the letter E, or by the safety earth symbol Å@, or coloured green or green-
and-yellow.
The wire which is coloured BLUE must be connected to the terminal which is marked with the letter
Nor coloured black.
The wire which is coloured BROWN must be connected to the terminal which is marked with the
letter Lor coloured red.
If you have any doubt, consult a qualified electrician.
WARNING: THIS APPARATUS MUST BE EARTHED.
➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢
➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢
➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣
➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢

1
For the users of the fax function
FAX interface cable and Line cable:
These special accessories must be used with the device.
The Declaration of Conformity can be viewed at the following URL address.
http://www.sharp.de/doc/MX-FXX2.pdf

2
Contents
The products that meet the ENERGY STAR®guidelines carry the logo shown above.
The products without the logo may not meet the ENERGY STAR®guidelines.
Warranty
While every effort has been made to make this document as accurate and helpful as possible, SHARP Corporation makes no
warranty of any kind with regard to its content. All information included herein is subject to change without notice. SHARP is not
responsible for any loss or damages, direct or indirect, arising from or related to the use of this operation manual.
©Copyright SHARP Corporation 2009. All rights reserved. Reproduction, adaptation or translation without prior written permission is
prohibited, except as allowed under copyright laws.
CAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Laser information . . . . . . . . . . . . . . . . . . . . . . . . . . 5
INSTALLATION REQUIREMENTS . . . . . . . . . . . . . 6
SUPPLIES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Storage of supplies. . . . . . . . . . . . . . . . . . . . . . . . . 7
Supply of spare parts and consumables . . . . . . . . 7
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Machine specifications / copier specifications . . . . 8
Continuous copying speeds . . . . . . . . . . . . . . . . . 10
Ambient environment . . . . . . . . . . . . . . . . . . . . . . 10
Acoustic noise emission (measurement according to
ISO7779) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Automatic document feeder specifications. . . . . . 11
Exit tray unit (right tray) specifications . . . . . . . . . 11
Stand/1x500 sheet paper drawer specifications. . 12
Stand/2x500 sheet paper drawer specifications. . 12
Finisher specifications . . . . . . . . . . . . . . . . . . . . . 13
Punch module specifications (for finisher) . . . . . . 14
Printer specifications . . . . . . . . . . . . . . . . . . . . . . 14
Network scanner / Internet Fax specifications . . . 15
Pull scan function (TWAIN) specifications . . . . . . 15
Facsimile specifications . . . . . . . . . . . . . . . . . . . . 16
INFORMATION ON DISPOSAL . . . . . . . . . . . . . . . 17
A. Information on Disposal for Users (private
households) . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
B. Information on Disposal for Business Users. . . 17
TO THE ADMINISTRATOR OF THE MACHINE . . 20
Factory default passwords . . . . . . . . . . . . . . . . . . 20
Forwarding all transmitted and received data to the
administrator (document administration function) 20
For the users of the fax function . . . . . . . . . . . . . . 20
Trademark acknowledgments . . . . . . . . . . . . . . . 21
Note:
• Considerable care has been taken in preparing this manual. If you have any comments or concerns about the manual, please
contact your dealer or nearest authorised service representative.
• This product has undergone strict quality control and inspection procedures. In the unlikely event that a defect or other problem is
discovered, please contact your dealer or nearest authorised service representative.
• Aside from instances provided for by law, SHARP is not responsible for failures occurring during the use of the product or its
options, or failures due to incorrect operation of the product and its options, or other failures, or for any damage that occurs due
to use of the product.
• This manual contains references to the fax function. However, please note that the fax function is not available in some countries
and regions.
Products that have earned the ENERGY STAR®are designed to protect the environment
through superior energy efficiency.

3
CAUTIONS
Symbols in this manual
To ensure safe use of the machine, this manual uses various safety symbols. The safety symbols are classified as explained below.
Be sure you understand the meaning of the symbols when reading the manual.
WARNING Indicates a risk of death or serious injury.
CAUTION Indicates a risk of human injury or property damage.
Meaning of the symbols
The symbol indicates the need for caution. The specific matter that requires caution is indicated inside the symbol (the
symbol at left indicates "caution: high temperature").
The symbol indicates an action that is prohibited. The specific action that is prohibited is indicated inside or beside the
symbol (the symbol at left indicates "disassembly is prohibited").
The symbol indicates an action that is mandatory.
WARNING
Do not make any modifications to this
machine.
Doing so may result in personal injury or
damage to the machine.
Do not insert or remove the power plug with
wet hands.
This may cause electrical shock.
Do not use a flammable spray to clean the
machine.
If gas from the spray comes in contact with
hot electrical components or the fusing unit
inside the machine, fire or electrical shock
may result.
If a thunder storm begins, switch off the main
power and remove the power plug from the
outlet to prevent electrical shock and fire due
to lightning.
Do not remove the machine casing.
High-voltage parts inside the machine may
cause electrical shock.
Be sure to connect the power cord only to a
power outlet that meets the specified voltage
and current requirements. Also make certain
the outlet is properly grounded. Do not use an
extension cord or adapter to connect other
devices to the power outlet used by the machine. Using
an improper power supply may cause fire or electrical
shock.
*For the power supply requirements, see the name
plate in the lower left corner of the left side of the
machine.
If you notice smoke, a strange odor, or other
abnormality, do not use the machine.
If used in this condition, fire or electrical
shock may result.
Immediately switch off the main
power and remove the power plug
from the power outlet. Contact
your dealer or nearest authorised
service representative.
Do not damage or modify the
power cord.
Placing heavy objects on the
power cord, pulling it, or
forcibly bending it will damage
the cord, resulting in fire or
electrical shock.
Do not place a container of water
or other liquid, or a metal object
that might fall inside, on the
machine.
If the liquid spills or the object
falls into the machine, fire or
electrical shock may result. If a piece of metal or water enters the
machine, switch off the main power and
remove the power plug from the power outlet.
Contact your dealer or nearest authorised
service representative. Using the machine in
this condition may result in electrical shock
or fire.

4
CAUTIONS
Do not install the machine on an unstable or
slanted surface. Install the machine on a surface
that can withstand the weight of the machine.
Risk of injury due to the machine falling or
toppling. If peripheral devices are to be installed, do not
install on an uneven floor, slanted surface, or otherwise
unstable surface. Danger of slippage, falling, and toppling.
Install the product on a flat, stable surface that can
withstand the weight of the product. (Weight when various
peripheral devices are installed: approx. 130 kg(287 lbs.))
When the machine is installed, the adjusters
(4) must be lowered to the floor to secure the
machine (prevent it from moving).
Rotate the adjusters in the locking direction until
they are in firm contact with the floor.
If you find it necessary to
reposition the machine due to
rearrangement of your office
layout or other reason, retract
the adjusters from the floor,
turn off the power, and then
move the machine.
(After moving the machine,
lower the adjusters again to
secure the machine.)
CAUTION
When removing the power plug from the
outlet, do not pull on the cord.
Pulling on the cord may cause damage such as
wire exposure and breakage, and may result in
fire or electrical shock.
The fusing unit is hot.
When removing a
misfeed, do not touch the
fusing unit. Take care not
to burn yourself.
When moving the machine, switch off the
main power and remove the power plug from
the outlet before moving.
The cord may be damaged, creating a risk of fire
or electrical shock.
Do not throw toner, a toner container (toner
cartridge), or a waste toner box into a fire.
Toner may fly and cause burns.
Store toner, toner containers (toner
cartridges), and waste toner boxes out of
the reach of children.
If you will not use the machine for a long
time, be sure to remove the power plug
from the outlet for safety.
Do not block the ventilation ports on the
machine. Do not install the machine in a
location that will block the ventilation ports.
Blocking the ventilation ports will cause heat to
build up in the machine, creating a risk of fire.
When loading paper,
removing a misfeed,
performing maintenance,
closing the front and
side covers, and
inserting and removing
trays, take care that your
fingers are not pinched.
Do not install in a location with
moisture or dust.
Risk of fire and electrical shock.
The machine includes the document filing function, which stores document image data on the machine's hard drive. Stored
documents can be called up and printed or transmitted as needed. If a hard drive failure occurs, it will no longer be possible to
call up the stored document data. To prevent the loss of important documents in the unlikely event of a hard drive failure,
keep the originals of important documents or store the original data elsewhere.
With the exception of instances provided for by law, Sharp Corporation bears no responsibility for any damages or loss due to
the loss of stored document data.
Do not look directly at the
light source.
Doing so may damage your
eyes.
Do not install the machine in a location with poor ventilation. Install so
that exhaust from the machine does not directly contact people.
A small amount of ozone is produced within the printer during operation. The
emission level is insufficient to cause any health hazard.
The present recommended long term exposure limit for ozone is 0.1 ppm (0.2 mg/m3)
calculated as an 8 hr. time-weighted average concentration.
However, since the small amount that is emitted may have an objectionable odor, it is
advisable to place the copier in a ventilated area.
Adjuster
Release
Lock
Fusing unit

5
CAUTIONS
Laser information
Wave length 790 nm ±10 nm
Pulse times
(North America and Europe)
4.6 µs ±4.6 ns /7 mm
Output power Max 0.6 mW (LD1+LD2)
Caution
Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.
This Digital Equipment is CLASS 1 LASER PRODUCT (IEC 60825-1 Edition 1.2-2001)
For Europe:
CLASS 1 LASER PRODUCT
LASER KLASSE 1
LUOKAN 1 LASERLAITE
KLASS 1 LASERAPPARAT

6
INSTALLATION REQUIREMENTS
The performance of the machine is affected by the ambient conditions of the installation location. Do not install in the
following locations:
Locations that are excessively hot, cold,
humid, or dry (near heaters, humidifiers, air
conditioners, etc.)
The paper will become damp and condensation may form
inside the machine, causing misfeeds and dirty output.
☞Ambient environment (page 10)
If the location has an ultrasonic humidifier, use pure water for
humidifiers in the humidifier. If tap water is used, minerals
and other impurities will be emitted, causing impurities to
collect on the inside of the machine and create dirty output.
Near a wall
Be sure to allow the required space around the machine for
servicing and proper ventilation. (The machine should be no
closer than the distances indicated below from walls. The
indicated distances are for the case when a saddle finisher
and large capacity paper tray are not installed.)
Dusty locations
If dust enters the machine, dirty output and machine failure
may result.
Locations exposed to direct sunlight
Plastic parts may become deformed and dirty output may
result.
Locations with ammonia gas
Installing the machine next to a diazo copy machine may
cause dirty output.
Locations subject to vibration.
Vibration may cause failure.
CAUTION:
Do not install the machine in a location
with poor air circulation.
A small amount of ozone is created inside the machine during
printing. The amount of ozone created is not sufficient to be
harmful; however, an unpleasant odor may be noticed during
large copy runs, and thus the machine should be installed in a
room with a ventilation fan or windows that provide sufficient
air circulation. (The odor may occasionally cause headaches.)
* Install the machine so that people are not directly
exposed to exhaust from the machine. If installed near a
window, ensure that the machine is not exposed to direct
sunlight.
45cm
(17-23/32")
30cm
(11-13/16")
30cm
(11-13/16")
The machine includes a built-in hard drive. Do not subject the machine to shock or vibration. In particular, never
move the machine while the power is on.
• The machine should be installed near an accessible power outlet for easy connection.
• Connect the machine to a power outlet which is not used for other electric appliances. If a lighting fixture is connected to the
same outlet, the light may flicker.

7
SUPPLIES
Standard supplies for this product that can replaced by the user include paper, toner cartridges, and staple cartridges for
the finisher.
Be sure to use only SHARP-specified products for the toner cartridges, finisher staple cartridge, and transparency film.
Storage of supplies
Proper storage
1. Store the supplies in a location that is:
• clean and dry,
• at a stable temperature,
• not exposed to direct sunlight.
2. Store paper in the wrapper and lying flat.
3. Paper stored in packages standing up or out of the wrapper may curl or become damp, resulting in paper misfeeds.
Storing toner cartridges
Store a new toner cartridge box horizontally. Do not store it standing on end. If stored standing on end, the toner may not
distribute well even after shaking the cartridge vigorously, and will remain inside the cartridge without flowing out.
Staple cartridge
The finisher requires the following staple cartridge:
MX-SCX1
Approx. 5000 per cartridge x 3 cartridges
Supply of spare parts and consumables
The supply of spare parts for repair of the machine is guaranteed for at least 7 years following the termination of
production. Spare parts are those parts of the machine which may break down within the scope of the ordinary use of
the product, whereas those parts which normally exceed the life of the product are not to be considered as spare parts.
Consumables too, are available for 7 years following the termination of production.
For best copying results, be sure to use only Sharp Genuine Supplies which are designed,
engineered, and tested to maximize the life and performance of Sharp products. Look for the
Genuine Supplies label on the toner package.
GENUINE SUPPLIES

8
SPECIFICATIONS
Machine specifications / copier specifications
* First copy out time is measured with original on the document glass in full ready condition with fuser at operating temperature and
mirror motor at operating speed in each of black and white mode and colour mode, actual time may vary based on environment
conditions.
Name Digital Full Colour Multifunctional System MX-2301N
Type Desktop
Photoconductive type OPC drum
Printing method Electrophotographic system (laser)
Developer system Dry-type two-component magnetic brush development
Fusing system Heat rollers
Scanning resolution
Document glass
Black and white scanning: 600 x 300 dpi (factory default values),
600 x 400 dpi, 600 x 600 dpi
Colour scanning:600 x 600 dpi (factory default values)
Reversing single pass
feeder (automatic
document feeder)
Black and white scanning: 600 x 400 dpi (factory default values), 600 x 600 dpi
Colour scanning:600 x 600 dpi (factory default values)
Printing resolution 600 x 600 dpi
Scanning gradation 256 levels
Printing gradation Equivalent to 256 levels
Original sizes / types Max. A3 (11" x 17") / sheets, bound documents
Copy sizes Maximum: A3W (12" x 18") Minimum: A5R (5-1/4" x 5-3/4")
Print margins Leading edge / trailing edge: total 8 mm (21/64") or less,
near edge / far edge: total 4 mm ±2 mm (11/64" ±3/32") or less
Warm-up time 60 seconds or less (This may vary depending on the ambient conditions.)
First-copy time*
Colour copy time: 8.9 seconds or less
Black and white copy time: 6.0 seconds or less
(Portrait feeding of A4 (8-1/2" x 11") sheets. This may vary depending on the state of machine.)
Copy ratios
Variable: 25% to 400% in increments of 1%, total 376 increments (25% to 200% when the automatic
document feeder is used)
Fixed presets:
25%, 50%, 70%, 81%, 86%, 100%, 115%, 122%, 141%, 200% and 400% for AB sizes ;
25%, 50%, 64%, 77%, 100%, 121%, 129%, 200% and 400% for inch sizes
.
Two reduction ratios and two enlargement ratios can be stored.
Continuous copy 999 copies
Automatic document
feeder
See "Automatic document feeder specifications".
Tray 1 / Tray 2
Paper sizes: A3, B4, A4, A4R, B5, B5R, A5R, 11" x 17", 8-1/2" x 14", 8-1/2" x 13-1/2",
8-1/2" x 13-2/5", 8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R, 7-1/4" x 10-1/2"R,
5-1/2" x 8-1/2"R, 8K, 16K, 16KR
Paper weight: Plain paper (60 g/m2to 105 g/m2(16 lbs. to 28 lbs.)), heavy paper (106 g/m2to
209 g/m2(28 lbs. bond to 110 lbs. index))
Paper capacity: Plain paper (80 g/m2(21 lbs.)) 500 sheets, heavy paper 200 sheets
Paper types: SHARP-recommended plain paper, recycled paper, coloured paper, and heavy paper

9
SPECIFICATIONS
Machine specifications / copier specifications (Continued)
* Type A connectors are located on the front of the machine and on the right side of the machine at the back (total of two connectors);
however, the connectors cannot be used simultaneously. Only one of the connectors can be used. If you need to change the
connector that is used, contact your service technician.
To receive power supplied from a type A connector, the total current consumption of the connected device should not exceed
500 mA.
Bypass tray
Paper sizes: A3W, A3, B4, A4, A4R, B5, B5R, A5R, envelopes, 12" x 18", 11" x 17", 8-1/2" x 14",
8-1/2" x 13-1/2", 8-1/2" x 13-2/5", 8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R,
7-1/4" x 10-1/2"R, 5-1/2" x 8-1/2"R, 8K, 16K, 16KR (Includes automatic paper size
detection function. Entry of paper sizes up to 297 mm x 432 mm (11-5/8" x 17") is
possible.)
Paper weights:
Thin paper (55 g/m2to 59 g/m2(15 lbs. to 16 lbs.)), plain paper (60 g/m2to 105 g/m2(16 lbs. to
28 lbs.)), heavy paper (106 g/m2to 256 g/m2(28 lbs. bond to 140 lbs. index)),
envelopes (75 g/m2to 90 g/m2(20 lbs. to 24 lbs.))
Paper capacity: Standard paper 100 sheets
Paper types:
SHARP-recommended plain paper, recycled paper, coloured paper, heavy paper, thin paper,
transparency film, envelopes (Monarch, Com-10, DL, C5)
Duplex module
Paper sizes: A3, B4, A4, A4R, B5, B5R, A5R, 11" x 17", 8-1/2" x 14", 8-1/2" x 13", 8-1/2" x 11",
8-1/2" x 11"R, 5-1/2" x 8-1/2"R, 8K, 16K, 16KR
Paper weight: Plain paper (60 g/m2to 105 g/m2(16 lbs. to 28 lbs.)), heavy paper (106 g/m2to
209 g/m2(28 lbs. bond to 110 lbs. index))
Paper types: SHARP-recommended plain paper, recycled paper, coloured paper, and heavy paper
Output tray (Center tray)
Output method: Face-down output (A3W and 12" x 18" paper can be output to right tray, or finisher)
Output capacity: 500 sheets (using SHARP-recommended A4 or 8-1/2" x 11" paper)
(The maximum number of sheets that can be held varies depending on ambient conditions in the
installation location, the type of paper, and the storage conditions of the paper.)
Tray full sensor: Yes
Interface port
LAN connectivity: 10Base-T / 100Base-TX / 1000Base-T
USB connectivity:
Type A connector supports USB 2.0*
Compatibility requirements of USB memory
Memory capacity : Max. 32 GB
Disk Format : FAT32 only
Type B connector supports USB 2.0 (Hi speed)
Required power supply Local voltage ±10% (For the power supply requirements, see the name plate in the lower corner of
the left side of the machine.)
Power consumption 220-240V: 1.84 kW / 100-127V: 1.44 kW
Dimensions
620 mm (W) x 670 mm (D) x 950 mm (H) (24-13/32" (W) x 26-3/8" (D) x 37-25/64" (H))
Weight
Approx. 116 k g (255.8 lbs.)
Overall dimensions 970 mm (W) x 670 mm (D) (38-3/16" (W) x 26-3/8" (D)) (when bypass tray is extended)

10
SPECIFICATIONS
Continuous copying speeds*
* Copy speed during output of the second copy and following copies when performing continuous one-sided copying of the same
page (excluding offset output) using plain one-sided paper from a tray other than the bypass tray.
Model MX-2301N
Copy ratio 100% / Reduced / Enlarged
Copy mode Colour copying Black and white copying
A3, 11" x 17", 8K
12 copies/min. 12 copies/min.
B4, 8-1/2" x 14",
8-1/2" x 13"
14 copies/min. 14 copies/min.
A4, B5, 8-1/2" x 11", 16K
23 copies/min. 23 copies/min.
A4R, B5R, A5R,
8-1/2" x 11"R,
7-1/4" x 10-1/2"R,
5-1/2" x 8-1/2"R, 16KR
16 copies/min. 16 copies/min.
Ambient environment
85%
(Humidity)
60%
20%
10˚C
(54˚F)
30˚C
(86˚F)
35˚C (Temperature)
(91˚F)

11
SPECIFICATIONS
Acoustic noise emission (measurement according to ISO7779)
Automatic document feeder specifications
* Scanning in mono 2 mode of one side only is possible in fax and scan send modes. However, when the resolution is 600 x 600 dpi
in Internet fax mode, the maximum length is 800 mm (31-31/64"). When the resolution is 400 x 400 dpi or 600 x 600 dpi in scan
mode, a long original cannot be scanned.
Exit tray unit (right tray) specifications
* The maximum number of sheets that can be held varies depending on ambient conditions in the installation location, the type of
paper, and the storage conditions of the paper. Envelopes, tab paper, and glossy paper cannot be output.
Sound power level LwA
Printing mode (continuous printing) 6.5 B
Standby mode 5.7 B
Sound pressure level LpA (actual measurement)
Printing mode Bystander positions Colour: 50 dB (A) Black and white: 50 dB (A)
Operator positions Colour: 50 dB (A) Black and white: 50 dB (A)
Standby mode Bystander positions 24 dB (A)
Operator positions 22 dB (A)
Original sizes
A3 to A5, 11" x 17" to 5-1/2" x 8-1/2", long paper
(max. width 297 mm (11-5/8") x max. length 1000 mm* (39-23/64"), scanning in mono 2 mode of
one side only is possible in fax and image scan modes)
Original weight
One-sided 35 g /m
2
to 128 g /m
2
(9 lbs. to 32 lbs.) (Original weights from 35 g /m
2
(9 lbs.) to 49 g /m
2
(13 lbs.) require the use of slow scan mode.)
Two-sided 50 g /m
2
to 105 g /m
2
(13 lbs. to 28 lbs.)
Capacity 100 sheets (80 g/m2(21 lbs.)) Maximum stack height of 13 mm (33/64")
Model MX-TRX1
Output method Face-down output
Output capacity* 100 sheets (using SHARP-recommended A4 or 8-1/2" x 11" paper)
Dimensions
When tray is folded up:
289 mm (W) x 405 mm (D) x 52 mm (H) (11-3/8" (W) x 15-61/64" (D) x 2-3/64" (H))
When tray is extended:
419 mm (W) x 405 mm (D) x 52 mm (H) (16-1/2" (W) x 15-61/64" (D) x 2-3/64" (H))
Weight Approx. 0.93 kg(2 lbs.)

12
SPECIFICATIONS
Stand/1x500 sheet paper drawer specifications
Stand/2x500 sheet paper drawer specifications
Model MX-DEX6
Paper sizes A3, B4, A4, A4R, B5, B5R, 11" x 17", 8-1/2" x 14", 8-1/2" x 13-1/2", 8-1/2" x 13-2/5", 8-1/2" x 13",
8-1/2" x 11", 8-1/2" x 11"R, 7-1/4" x 10-1/2"R, 8K, 16K, 16KR
Paper weight Plain paper (60 g/m2to 105 g/m2(16 lbs. to 28 lbs.)), heavy paper (
106 g /m
2
to 209 g /m
2
( 28 lbs.
bond to 110 lbs. index)
)
Paper capacity 500 sheets (80 g/m2(21 lbs.)) x 1 tray
Paper types SHARP-recommended plain paper, recycled paper, and coloured paper
Automatic paper size
detection
When "Auto-AB" detection is selected:
A3, B4, A4, A4R, B5, B5R, 216 mm x 330 mm (8-1/2" x 13")
When "Auto-Inch" detection is selected:
11" x 17", 8-1/2" x 14", 8-1/2" x 11", 8-1/2" x 11"R, 7-1/4" x 10-1/2"R
Power supply Supplied from the machine
Dimensions 720 mm (W) x 670 mm (D) x 303 mm (H) (28-11/32" (W) x 26-3/8" (D) x 11-15/16" (H))
(including adjuster)
Weight Approx. 20 kg(44.1 lbs.)
Model MX-DEX7
Paper sizes A3, B4, A4, A4R, B5, B5R, 11" x 17", 8-1/2" x 14", 8-1/2" x 13-1/2", 8-1/2" x 13-2/5", 8-1/2" x 13",
8-1/2" x 11", 8-1/2" x 11"R, 7-1/4" x 10-1/2"R, 8K, 16K, 16KR
Paper weight Plain paper (60 g/m2to 105 g/m2(16 lbs. to 28 lbs.)), heavy paper (
106 g /m
2
to 209 g /m
2
( 28 lbs.
bond to 110 lbs. index)
)
Paper capacity 500 sheets (80 g/m2(21 lbs.)) x 2 tray
Paper types SHARP-recommended plain paper, recycled paper, and coloured paper
Automatic paper size
detection
When "Auto-AB" detection is selected:
A3, B4, A4, A4R, B5, B5R, 216 mm x 330 mm (8-1/2" x 13")
When "Auto-Inch" detection is selected:
11" x 17", 8-1/2" x 14", 8-1/2" x 11", 8-1/2" x 11"R, 7-1/4" x 10-1/2"R
Power supply Supplied from the machine
Dimensions 720 mm (W) x 670 mm (D) x 303 mm (H) (28-11/32" (W) x 26-3/8" (D) x 11-15/16" (H))
(including adjuster)
Weight Approx. 23.5 kg(51.9 lbs.)

13
SPECIFICATIONS
Finisher specifications
*1 The maximum number of sheets that can be held varies depending on ambient conditions in the installation location, the type of
paper, and the storage conditions of the paper.
*2 Up to 10 envelopes can be output.
*3 The height of the sheets must not exceed 71 mm (2-51/64").
*4 The height of the sheets must not exceed 35.5 mm (1-13/32").
*5 The maximum number of sheets for stapling assumes a paper weight of 90 g/m2(24 lbs.) and includes two cover sheets of
106 g/m2to 256 g/m2(28 lbs. bond to 140 lbs. index).
Model MX-FNX9
Paper sizes
A3W, A3, B4, A4, A4R, B5, B5R, A5R, envelopes, 12" x 18", 11" x 17", 8-1/2" x 14",
8-1/2" x 13-1/2", 8-1/2" x 13-2/5", 8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R, 7-1/4" x 10-1/2"R,
5-1/2" x 8-1/2"R, 8K, 16K, 16KR
Paper weight
Thin paper (55 g /m
2
to 59 g /m
2
(15 lbs. to 16 lbs.)) plain paper (60 g /m
2
to 105 g /m
2
(16 lbs. to 28 lbs.))
heavy paper (106
g /m
2
to 256 g /m
2
(28 lbs. bond to 140 lbs. index)) , envelopes (75 g /m
2
to 90 g /m
2
(20 lbs. to 24 lbs.))
Modes Non-staple, staple
Allowed paper sizes for
offset
A3, B4, A4, A4R, B5, 11" x 17", 8-1/2" x 14", 8-1/2" x 13-1/2", 8-1/2" x 13-2/5", 8-1/2" x 13",
8-1/2" x 11", 8-1/2" x 11"R, 8K, 16K
Offset distance 30 mm (1-3/16")
Tray capacity*1
Non-stapling*2:
500 sheets*3(A4, A4R, B5, B5R, A5R,
8-1/2" x 11", 8-1/2" x 11"R, 7-1/4" x 10-1/2"R,
5-1/2" x 8-1/2"R, 16K, 16KR)
250 sheets*4(A3W, A3, B4, 12" x 18", 11" x 17",
8-1/2" x 14", 8-1/2" x 13-1/2", 8-1/2" x 13-2/5",
8-1/2" x 13", 8K)
Stapling*5:
30 sets or 500 sheets*3(A4, A4R, B5,
8-1/2" x 11", 8-1/2" x 11"R, 16K, 16KR)
30 sets or 250 sheets*4(A3, B4, 11" x 17",
8-1/2" x 14", 8-1/2" x 13-1/2", 8-1/2" x 13-2/5",
8-1/2" x 13", 8K)
Power supply Supplied from the machine
Dimensions 440 mm (W) x 595 mm (D) x 205 mm (H) (17-21/64" (W) x 23-27/64" (D) x 8-5/64" (H))
(When tray is folded up)
Weight Approx. 13 kg(28.7 lbs.)
Overall dimensions when
attached to machine
1060 mm (W) x 670 mm (D) (41-23/32" (W) x 26-3/8" (D)) (When tray is extended)
Stapler section
Allowed paper sizes for
stapling
A3, B4, A4, A4R, B5, 11" x 17", 8-1/2" x 14", 8-1/2" x 13-1/2", 8-1/2" x 13-2/5", 8-1/2" x 13",
8-1/2" x 11", 8-1/2" x 11"R, 8K, 16K, 16KR
(Three stapling positions: one staple at bottom left corner, one staple at top left corner, and two
staples.)
Maximum number of
sheets for stapling*5
50 sheets (A4, A4R, B5, 8-1/2" x 11", 8-1/2" x 11"R, 16K, 16KR)
30 sheets (A3, B4, 11" x 17", 8-1/2" x 14", 8-1/2" x 13-1/2", 8-1/2" x 13-2/5", 8-1/2" x 13", 8K)
(30 sheets when the sheets are the same width but different lengths.)
Note:
Special media such as transparency film and label sheets cannot be stapled or punched.

14
SPECIFICATIONS
Punch module specifications (for finisher)
Printer specifications
*1 When the PS3 expansion kit is installed and the machine is used as a PostScript printer.
*2 Barcode font kit is required.
*3 Supported operating systems are Windows 2000 / XP / Vista.
Model MX-PNX1A MX-PNX1B MX-PNX1C MX-PNX1D
Hole punching 2 holes 2 holes or 3 holes 4 holes 4 holes, broad width
Allowed paper sizes for
punching
A3, B4, A4, A4R, B5,
B5R, 11" x 17",
8-1/2" x 14",
8-1/2" x 13-1/2",
8-1/2" x 13-2/5",
8-1/2" x 13",
8-1/2" x 11",
8-1/2" x 11"R,
7-1/4" x 10-1/2", 8K,
16K, 16KR
2 holes:
8-1/2" x 14",
8-1/2" x 13-1/2",
8-1/2" x 13-2/5",
8-1/2" x 13",
8-1/2" x 11"R,
7-1/4" x 10-1/2"
3 holes:
11" x 17", 8-1/2" x 11",
A3, A4
A3, A4 A3, B4, A4, A4R, B5,
B5R, 11" x 17",
8-1/2" x 14",
8-1/2" x 13-1/2",
8-1/2" x 13-2/5",
8-1/2" x 13",
8-1/2" x 11",
8-1/2" x 11"R,
7-1/4" x 10-1/2"
Punchable paper weights
55 g/m2to 128 g/m2(16 lbs. to 32 lbs.)
Power supply Supplied from finisher
Dimensions 105 mm (W) x 518 mm (D) x 170 mm (H) (4-9/64" (W) x 20-25/64" (D) x 6-45/64" (H))
Weight Approx. 3.5 kg(7.7 lbs.)
Type Built-in
Continuous printing speed
Same as continuous copying speed (When printing same document continuously on A4
(8-1/2" x 11") plain paper in non-offset mode, excluding processing time.)
Printing resolution 600 x 600 dpi
Printer driver type PCL6, PostScript 3 compatible*1
Supported protocols TCP/IP, IPX/SPX, NetBEUI, EtherTalk*1
Supported client PC
operating systems
See "VERIFYING SYSTEM REQUIREMENTS" in the Safety Guide / Software Setup Guide.
Fonts PCL6 80 European fonts, 28 barcode fonts*2, 1 bitmap font
PostScript 3 compatible*1136 European fonts
Interface port LAN connectivity: 10Base-T / 100Base-TX / 1000Base-T
USB connectivity: Supports USB 2.0 (Hi speed)*3
Memory Standard system memory: 512 MB
Print area Entire page excluding margin of 4.2 mm (11/64") at each edge. The actual print area may vary
depending on the printer driver and the software application.

15
SPECIFICATIONS
Network scanner / Internet Fax*1specifications
*1 Internet fax expansion kit is required.
*2 Total number of all destinations (Scan to E-mail, Scan to FTP, Scan to Desktop, Scan to Network folder, Internet Fax, Fax, and
Group)
Pull scan function (TWAIN) specifications
Type Built-in
Scanning resolution (dpi)
100 x 100, 200 x 200, 300 x 300, 400 x 400, 600 x 600
Internet Fax: 200 x 100, 200 x 200, 200 x 400, 400 x 400, 600 x 600 (200 x 100, 200 x 200 when file
type is TIFF-S) Halftone can be selected for resolutions other than 200 x 100 dpi.
Scanning speed
Colour (A4 / 8-1/2" x 11")One-sided: 50 pages/min. (200 x 200 dpi),
Two-sided: 16 pages/min. (200 x 200 dpi)
Black and white (A4 / 8-1/2" x 11") One-sided: 50 pages/min. (200 x 200 dpi),
Two-sided: 16 pages/min. (200 x 200 dpi)
Interface port LAN connectivity: 10Base-T / 100Base-TX / 1000Base-T
Supported protocols TCP/IP (IPv4)
File formats
Colour
(including greyscale)
File types: TIFF, JPEG, PDF, Encrypted PDF, XPS
Compression ratio: High / Medium / Low
Black and white File types: TIFF, PDF, Encrypted PDF, XPS
Compression modes: None / Medium (G3) / High (G4)
Internet Fax
(black and white only)
File types: TIFF-FX (TIFF-F, TIFF-S)
Compression modes: Medium (G3) / High (G4)
Remarks
Number of one-touch keys for
storing destinations*2
Maximum number of keys: 999
Number of destinations that can be
stored in a group (1 key)*2
Maximum number of destinations in one group (1 key): 500
Scan destinations Scan to E-mail / Scan to FTP / Scan to Desktop / Scan to
Network Folder
Supported protocol TCP/IP (IPv4)
Supported client PC
operating systems
Windows 2000 / XP / Server 2003 / Vista / Server 2008
Colour modes Full Colour, Greyscale, Mono Diffusion, Mono 2 gradation
Resolution settings
75 dpi, 100 dpi, 150 dpi, 200 dpi, 300 dpi, 400 dpi, 600 dpi
(The resolution can be specified by entering a numerical value from 50 to 9600 dpi. However, when
a high resolution is specified, it is necessary to reduce the scanning area.)
Scanning area Maximum: A3 (11" x 17")

16
SPECIFICATIONS
Facsimile specifications
*1 Transmission speed is for an A4 or 8-1/2" x 11" document with approximately 700 characters at standard resolution (8 x 3.85
lines/mm) sent in high speed mode (33.6 kbps (JBIG) or 14.4 kbps). This is only the time required to transmit the image
information; the time required to send protocol signals is not included. Actual transmission times will vary depending on the
contents of the document, the receiving machine type, and telephone line conditions.
*2 Total number of all destinations (Scan to E-mail, Scan to FTP, Scan to Desktop, Scan to Network folder, Internet Fax, Fax and
Group)
Model MX-FXX2
Applicable telephone line Public switched telephone network, PBX
Scanning resolution
(supports ITU-T
standards)
8 x 3.85 lines/mm (Standard), 8 x 7.7 lines/mm (Fine, Fine-Halftone), 8 x 15.4 lines/mm (Super Fine,
Super Fine - Halftone), 16 x 15.4 lines/mm (Ultra Fine, Ultra Fine - Halftone)
Transmission speed 33.6 kbps down to 2.4 kbps Automatic fallback
Compression method MH / MR / MMR / JBIG
Transmission modes Super G3, G3 (the machine can only send faxes to and receive faxes from machines that support G3
or Super G3)
Input document size
AB sizes: A3, B4, A4, A4R, B5, B5R, A5, 216 mm x 340 mm, 216 mm x 343 mm
Inch sizes: 11" x 17", 8-1/2" x 14", 8-1/2" x 13-2/5", 8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R,
5-1/2" x 8-1/2"
Long originals (max. width 297 mm (11-45/64") x max. length 1000 mm (39-23/64") can be
transmitted using the automatic document feeder. Scanning one side is possible.)
Paper sizes A3, B4, A4, A4R, B5, B5R, A5R (11" x 17", 8-1/2" x 14", 8-1/2" x 13-2/5", 8-1/2" x 13", 8-1/2" x 11",
8-1/2" x 11"R, 5-1/2" x 8-1/2"R)
Transmission time *1Approx. 2 seconds (Super G3 mode/33.6 kbps, JBIG)
Approx. 6 seconds (G3 ECM mode/14.4 kbps)
Power supply Supplied from the machine
Dimensions 192 mm (W) x 52 mm (D) x 215 mm (H) (7-9/16" (W) x 2-3/64" (D) x 8-15/32" (H))
Weight Approx. 1.0 kg(2.2 lbs.)
Remarks
Extension telephone connection Possible (1 telephone)
Number of one-touch keys for storing
destinations*2
Maximum number of keys: 999
Number of destinations that can be stored in a
group (1 key)*2
Maximum number of destinations in one group
(1 key): 500
Timer transmission Yes
Program function Yes (48 programs)
F-code transmission Supported (SUB/SEP (sub-address) and SID/PWD
(passcode) signals can be transmitted / received)
Image memory 8 MB standard

17
INFORMATION ON DISPOSAL
A. Information on Disposal for Users (private households)
1. In the European Union
Attention: If you want to dispose of this equipment, please do not use the
ordinary dust bin!
Used electrical and electronic equipment must be treated separately and in
accordance with legislation that requires proper treatment, recovery and
recycling of used electrical and electronic equipment.
Following the implementation by member states, private households within the
EU states may return their used electrical and electronic equipment to
designated collection facilities free of charge*. In some countries* your local
retailer may also take back your old product free of charge if you purchase a
similar new one.
*) Please contact your local authority for further details.
If your used electrical or electronic equipment has batteries or accumulators,
please dispose of these separately beforehand according to local
requirements.
By disposing of this product correctly you will help ensure that the waste
undergoes the necessary treatment, recovery and recycling and thus prevent
potential negative effects on the environment and human health which could
otherwise arise due to inappropriate waste handling.
2. In other Countries outside the EU
If you wish to discard this product, please contact your local authorities and ask for the correct method of disposal.
For Switzerland: Used electrical or electronic equipment can be returned free of charge to the dealer, even if you don't
purchase a new product. Further collection facilities are listed on the homepage of www.swico.ch or www.sens.ch.
B. Information on Disposal for Business Users.
1. In the European Union
If the product is used for business purposes and you want to discard it:
Please contact your SHARP dealer who will inform you about the take-back of the product. You might be charged for the
costs arising from take-back and recycling. Small products (and small amounts) might be taken back by your local
collection facilities.
For Spain: Please contact the established collection system or your local authority for take-back of your used products.
2. In other Countries outside the EU
If you wish to discard of this product, please contact your local authorities and ask for the correct method of disposal.
Attention: Your product is
marked with this symbol. It
means that used electrical
and electronic products
should not be mixed with
general household waste.
There is a separate
collection system for these
products.

18
