Shelters4Less SR1561 User manual

Assembly Instructions
Shelter type: SR1561
SR1561-01-310717-UK
Email : [email protected]
Web : www.shelters4less.co.uk
Tel : [phone]

5
3
7
11
1
12
2
10
9
8
4
6
EXPLODED VIEW AND TOOLS
2
Tools required:
Drill/Screwdriver
Mallet
Hack saw
Spanner
Torx bit
ITEM
NO. PART NAME
DRG NUMBER LENGTH
Default/QT
Y.
1 S1 Frame S1
Panel
outside
3
2 S1 Frame S1
Panel
inside
3
3 Post P1
Default
1
4 ST3 ST1
Default
1
5 Bracket CB1
Default
7
6 Bracket JF1
Default
6
7 Bracket SR-RB2-01
Default
8
8 R2 Rafter
Default
3
9 sealing strip
2220 6
10 PCE2 Panel
Default
2
11 RC2 Strip
2220 3
12 Roof Angle
Default
4
13 Bracket FT1
Default
8

3
PARTS LIST
ITEM
NO.
PART
NO.
DESCRIPTION DIMENSION IMAGE
QTY.
1 S1 Frame 2000 x 1035 6
2
P1 Post 2000 1
3 ST1 Roof Tie 1025 1
4 CB1 Bracket 110 x 110 x 40 7
5 JF1 Bracket 220 x 40 6
6 RB2 Bracket 110 x 46 8
7
R2 Rafter 2199 3
8
SS Sealing Strip 2220 6
9 ACE2 Roof Panel 2220 x 1050
2
10
RC2 Roof Strip 2180 3
11 A1 Roof Angle 2100 2
12 FT1 Bracket 109 x 100 8
13 EC40
Plastic
End Cap
40 x 40
12
Fittings Bolt set M10
Nut Washer
Black
Cap
T25 T50 AB1210
M10 x 60mm
25 mm
Tech
screw
50 mm
Tech
screw
M10/12 x 10mm
Concrete Bolt
Pack A
30 30 60 60 72 30 8
Required 14 14 28 28 68 30 8
Spare
16 16 32 32 4 0 0

2110
2110
CB1CB1
CB1
CB1
JF1 JF1
P1
ST1
S1
S1
S1 S1
JF1
IMPORTANT:
Check overall dimensions
to ensure corrct alignment
P1
ST1
S1
S1
S1
CB1 CB1
CB1
JF1
S1
Step 1
Assemble S1 frames to make up the main structure using CB1 brackets
in the corners and JF1 brackets on straight joints. Then attach P1 Post using
one JF1 bracket.
Then attach ST1 Tie bar using a JF1 bracket and one CB1 bracket.
4
GENERAL NOTE:
THE 50 mm TECH
SCREWS ARE
FOR FIXING ROOF
STRIPS
(RC) ONLY

RB2
RB2RB2
RB2
RB2
RB2RB2
RB2
R2
R2
R2
FT1
FT1
FT1
FT1 FT1
1035 1035
Step 2
Move shelter in to its final position, make sure everything is square and
secure to the floor using FT1 foot brackets.
Attach R2 roof rafters using RB2 brackets.
5

SS
SS
SS
SS
SSSS
ACE2ACE2
Step 3
Apply SS sealing strips to the rafters (two per rafter) and line up the ACE2
roof panels to the outside of the shelter, leaving a gap between them.
6

A1
A1
RC2
RC2
RC2
GENERAL NOTE:
THE 50 mm TECH SCREWS
ARE FOR FIXING ROOF STRIPS
(RC) ONLY
Step 4
Apply RC2 strips on top of the panels and use screws to secure them in
place. Then clip on the A1 angle trim to the bottom of the roof panels.
Then fit the Black plastic caps on exposed nuts and bolts. Fit the
square plastic end caps to any open ends of box sections.
7

1035 935
1013 905
989 1035
941 1129
2110
112
77
2209
Ground anchor positions and overall size
Suggested concrete base size: 200mm oversized on all four sides
Scale 1:15
8

NOTES
:
9

NOTES
:
10

NOTES
:
11

12
MAINTENANCE:
To ensure your products give you many years of use we recommend that you:
THANK YOU
FOR PURCHASING THIS PRODUCT
Clean panels regularly with soapy water •
Ensure all fittings are tight (for example after a big storm) •
Touch up any exposed metal should it get scratched •
CONTACT DETAILS:
Email : [email protected]
Web : www.shelters4less.co.uk
Tel : [phone]
Shelters4Less, Unit 3, 2 Landsdowne Crescent, Bournemouth, BH1 1SA
All Parts and Fixings checked by:
Print Name: Signature:
