Shelters4Less SR1606 User manual

Assembly Instructions
Shelter type: SR1606
SR1606-01-270116-UK
Email : [email protected]
Web : www.shelters4less.co.uk
Tel : [phone]

EXPLODED VIEW
18
16
17
17
16
8
7
1
12
56
9
4
14
13
11
2
3
2
Fittings Bolt set M10
Nut Washer
Black
Cap
T25 T50 AB1210
M10 x 60 mm
25mm
Tech
screw
50mm
Tech
screw
M10 x 100mm
Concrete Bolt
Pack A+B
40 40 80 80 136 66 13
Required 40 40 80 80 76 55 8
Spare
0 0 0 0 60 11 5
ITEM
NO. PART NAME
DRG NUMBER LENGTH
Default/QT
Y.
1 S1 - Full Frame - SR S1
Default
6
2 CB1 Bracket CB1
Default
6
3 JF1 Bracket JF1
Default
8
4 RB1 Bracket RB1
Default
10
5 S1 S1
Default
2
6 JF2 Bracket JF2
Default
4
7 R4 R4
Default
4
8 R5 R5
Default
1
9 ST4 Roof Tie ST4
Default
2
10 JF3 Bracket JF3
Default
1
11 P4 P4
Default
1
12 L1 Bracket L1
Default
8
13 FT1 Bracket FT1
Default
3
14 FT3 Bracket FT3
Default
5
15
Seasling Strip -
2195mm
Sealing Strip
Default
8
16 PCE2 PCE1
Default
2
17 PCC2 PCE1
Default
2
18 RC2 - 4059 RAD - RC1
Default
5
19 2MD 2MD
2110 4
20 40x40 End cap BOUGHT IN ITEM
40 x 40 x
20 10

3
PARTS LIST
ITEM NO.
PART NO.
DESCRIPTION DIMENSION
QTY.
1
S1
FRAME 2000 x 1035
6
2
CB1
BRACKET 110 x 110 x 40 6
3
JF1
BRACKET 220 x 40 8
4
RB1
BRACKET 110 x 50 x 40 10
5
S1 STUB
STUB 140 x 40 x 40 2
6
JF2
BRACKET 130 x 30 4
7
R4
RAFTER 2160 x 40 x 40 4
8
R5
RAFTER 2160 x 40 x 40 1
9
ST4
ROOF TIE 2080 x 40 x 40 2
10
JF3
BRACKET 210 x 40 x 40 1
11
P4
POST 1995 x 40 x 40 1
12
L1
L BRACKET 95 x 45 8
13
FT1
FOOT BRACKET 109 x 100 x 40 3
14
FT3
FOOT BRACKET 109 x 100 x 80 5
15
SS
SEALING STRIP TRIM TO 2205 4
16
PCE1
ROOF PANEL 2205 x 1050 2
17
PCC2
ROOF PANEL 2205 x 1030 2
18
RC1
ROOF STRIP 2205 x 60 5
19
2MD
ROOF TRIM TRIM TO FIT 5
20
EC40
ENDCAP 40 x 40 8

1035
4180
1075
Please note 50mm
Tec Screws are for
roof panels only
CHECK DIMENSIONS
TO ENSURE CORRECT
ALIGNMENT
CF1
JF1
S1
Ensure correct alignment on corners
CB1CB1
Step 1
Assemble S1 frames to make up the main structure using CB1 brackets
for the corners and JF1 brackets for the straight joints.
4

A
R5
R4
RB1
B
DETAIL A
SCALE 1 : 9
S1 STUB
JF2
CB1
JF1
DETAIL B
SCALE 1 : 6
JF1
S1 STUB
CB1
JF2
Step 2
Attach the S1 stubs to the front of the frame using CB1 , JF1 and JF3
brackets, then bolt the R4 and R5 rafters into place using the RB1
brackets and the stubs
5

C
ST4
P4
L1
RB1
L1
ST4
P4
JF3
DETAIL C
SCALE 1 : 4
JF3 ON FRONT
RB1 BELOW
Step 3
Assemble the T-section by joining the two ST4 tie bars using a JF3 bracket
then join the P4 post using two RB1 brackets and attach a L1 bracket to
each end.
6

L1
FT1
FT3
RB1
R4
FT1
FT3
L1
R4
RB1
Step 4
Attach the T-section to the shelter, then fix the R4 rafters in place using
more RB1 brackets on the rear and L1 brackets on the front.
Bolt the FT1 and F3 brackets to the shelter and move it to its final position
before using anchor bolts to secure it to the ground.
7

PCE2
PCE2
PCC2
PCC2
PCE2
PCE2
PCC2
PCC2
SS
Step 5
Stick the sealing strips ( SS ) to the rafters and line up the PCE2 panels with
the outside of the shelter then equally space the PCC2 panels in the gap.
Apply more sealing strips on the top of the roof panels directly above the
strips on the rafters.
8

RC2
2MD
RC2
2MD
Step 6
Screw down the RC2 strips into the rafter with the 50mm tech screws to secure
the roof panels and push the 2MD end caps on the bottom of the panels.
9

995
1044.50 1035 1035 1035
1044.50 1088.40
1048.40
2070 2193
2187
4180
4263 TO FEET HOLES
10
PLAN VIEW
OVERALL DIMENSIONS AND GROUND FIXING POSITIONS
Suggested size for concrete base: 200mm oversized on all four sides.

Notes:
11

12
CONTACT DETAILS:
Email : [email protected]
Web : www.shelters4less.co.uk
Tel : [phone]
Shelters4Less, Unit 3, 2 Lansdowne Crescent, Bournemouth, BH1 1SA
MAINTENANCE:
To ensure your products give you many years of use we recommend that you:
THANK YOU
FOR PURCHASING THIS PRODUCT
Clean panels regularly with soapy water •
Ensure all fittings are tight (for example after a big storm) •
Touch up any exposed metal should it get scratched •
All Parts and Fixings checked by:
Print Name: Signature:
