Shelters4Less SR1601 User manual

Assembly Instructions
SR1601-06-151118-S4L
Shelter Type: SR1601
Email : [email protected]
Web : www.shelters4less.co.uk
Tel : [phone]

13
2
1
15
9
16
8
12
11
10
6
4
3
14
7
?
2
EXPLODED VIEW
Spanner
Torx bit
Tools required:
Drill/Screwdriver
Mallet
Hack saw

PARTS LIST
3
Fittings Bolt set M10
Nut Washer
Black
Cap
T25 T50 AB1210
M10 x 60
25mm
Tech
screw
50mm
Tech
screw
M10 x 100
Concrete Bolt
Pack A
30 30 60 60 72 30 8
Required 22 22 49 49 32 18 5
Spare
8 8 11 11 40 12 3
ITEM NO. PART NO. DESCRIPTION DIMENSION IMAGE QTY.
1 S1 FRAME 2000x1035 2
2 S3 FRAME 2000x517 2
3 JF1 BRACKET 220x40 2
4 CB1 BRACKET 110x110 4
5 RB1 BRACKET 110x46 4
6 R3 RAFTER 1130 3
7 L3 BRACKET 73x38 2
8 L1 BRACKET 95x45 4
9 B2 BEAM 2100 1
10 SS Sealing Strip TRIM TO 1075 1 ROLL
11 PCE1 ROOF PANEL 1150x1050 2
12 RC1 ROOF STRIP 1130 3
13 2MD ROOF EDGE TRIM TO SUIT 3
14 FT1 FOOT 109x100x40 2
15 FT3 FOOT 109x100x80 3
16 EC40 END CAP 40x40 5

ENSURE CORRECT
ALIGNMENT ON
BOTH SIDES
4
ENSURE CORRECT
ALIGNMENT ON
BOTH SIDES
517
2110
557
Check dimensions to ensure
correct alignment
S1
S1
S3
S3
FT1
FT3
FT3
FT3
FT1
CB1
JF1
JF1
CB1 CB1
Step 1
Assemble main frame using S1 and S3 welded Frames. Join the frames
using CB1 brackets in the corners and JF1 brackets for the flat joints.
Then move the shelter to its final position, attach FT1 foot brackets and
use the concrete bolts to secure it to the ground.
GENERAL NOTE:
THE 50mm TECH SCREWS ARE
FOR FIXING ROOF STRIPS
(RC) ONLY

RB1
RB1RB1
RB1
L3
L3
R3
R3
R3
5
RB1
RB1RB1
RB1
R3
R3
R3
L3
Step 2
Attach R3 rafters using RB1 brackets at rear and L3 brackets in
the centre.

Step 3
Attach L1 brackets to R3 rafters. Then attach B2 tie bar.
B2
L1
L1L1
L1
R3
6
L1
L1
L1
B2
L1

RC1
RC1
RC1
PCE1
PCE1
2MD
2MD
SS
SS
SS
SS
7
PCE1
PCE1
RC1
RC1
RC1
2MD
2MD
Step 4
Apply sealing strips to R3 rafters then put the PCE1 Panels on top,
apply more sealing strips on top of the panels and secure down with
RC1 strips, screwed into the rafters with 50mm Tech screws . Then
attach the 2MD edge trim.
NOTE: Sealing Strip
to be attached to
rafters as below.

34.7
561
2193 HOLE CENTERS ON FEET
477
1139
2110
60
1035
PLAN VIEW
Suggested size for concrete base: 200mm
oversized on all four sides
8

Notes:
9

Notes:
10

Notes:
11

12
CONTACT DETAILS:
Email : [email protected]
Web : www.shelters4less.co.uk
Tel : [phone]
Unit 3, 2 Lansdowne Crescent, Bournemouth, BH1 1SA
MAINTENANCE:
To ensure your product gives you many years of use we recommend that you:
THANK YOU
FOR PURCHASING THIS PRODUCT
Clean panels regularly with soapy water •
Ensure all fittings are tight (for example after a big storm) •
Touch up any exposed metal should it get scratched •
All Parts and Fixings checked by:
Print Name: Signature:
