Skil LL932301 User manual

1-877-SKIL-999 OR www.skiltools.com
WARNING: To reduce the risk of injury, the user must read and understand the
Operator’s Manual before using this product. Save these instructions for future reference.
AVERTISSEMENT : Afin de réduire les risques de blessure, l’utilisateur doit lire et
comprendre le guide d’utilisation avant d’utiliser cet article. Conservez le présent guide
afin de pouvoir le consulter ultérieurement.
ADVERTENCIA : Para reducir el riesgo de lesiones, el usuario debe leer y comprender
el Manual del operador antes de utilizar este producto. Guarde estas instrucciones para
consultarlas en caso sea necesario.
Owner’s Manual
Guide d’utilisation
Manual del propietario
For Customer Service
Pour le service à la clientèle
Servicio al cliente
Model/ Modelo/ Modèle: #LL932301/LL932401
Compact Self-Leveling Cross Line Laser
Compact À Rayon Laser En Croix Et À
Nivellement Automatique
Láser Autonivelante Compacto
De Líneas Cruzadas

2
TABLE OF CONTENTS
General Laser Tool Safety Warnings.................3-4
FCC Statement...................................4-5
Safety Rules For Connecting Power Supply...........5-6
Symbols ........................................7-9
Get to Know Your Laser Tool........................10
Packing List ......................................11
Specications ....................................11
Operating Instructions ..........................12-17
Maintenance......................................18
Trouble Shooting..................................19
Limited Warranty Of Skil Consumer Tools ..........20-21

3
GENERAL LASER TOOL SAFETY WARNINGS
READ ALL INSTRUCTIONS BEFORE USING THE
TOOL!
4.44 Wh
CAN ICES-3(B)/NMB-3(B)
MADE IN CHINA / HECHO EN CHINA
FABRIQUÉ EN CHINE
SERIAL NO.
SERIE NO.
NUMÉRO DE SÉRIE
Model/Modelo / Modèle: LL932401
520nm, OUTPUT < 1mW/CLASS II LASER PRODUCT
3.7V 1200mAh Li-Polymer
COMPLIES WITH 21 CFR PARTS 1040.10 AND 1040.11
PRODUCTO LÁSER CON SALIDA < 1mW. CLASE II,
520 nm, 3,7V 1200mAh polímero de litio
CUMPLE CON LAS SECCIONES 21 CFR 1040.10 Y 1040.11
520 nm, SORTIE < 1 mW/PRODUIT LASER DE CLASSE II
Pile au lithium-polymère de 3,7 V, 1200 mAh
CONFORME AUX NORMES 21CFR ARTICLES 1040.10
ET 1040.11
LASER RADIATION-DO NOT STARE INTO BEAM
RADIACIÓN LÁSER: NO MIRE DIRECTAMENTE EL RAYO
RAYONNEMENT LASER – NE FIXEZ PAS DES YEUX LE
RAYON LASER
CAUTION: Risk of re and burns. Do not open, crush, heat
above 100° C (212° F) or incinerate.
PRECAUCIÓN : Riesgo de incendio y quemaduras. No abra,
triture, permita que esté a mayor temperatura que 100° C
(212 °F) ni incinere.
ATTENTION : Risque d’incendie et de brûlures. N’ouvrez pas
le produit, ne l’écrasez pas, ne le chauffez pas à plus de
100ºC (212°F) et ne l’incinérez pas.
CAUTION/PRECAUCIÓN/ATTENTION
AVOID EXPOSURE/EVITE LA
EXPOSICIÓN/ÉVITEZ
L’EXPOSITION
LASER RADIATION IS EMITTED
FROM THIS APERTURE
LA RADIACIÓN LÁSER SE EMITE
DE ESTA ABERTURA
CET OUTIL PRODUIT UN
RAYONNEMENT LASER
4.44 Wh
CAN ICES-3(B)/NMB-3(B)
MADE IN CHINA / HECHO EN CHINA
FABRIQUÉ EN CHINE
SERIAL NO.
SERIE NO.
NUMÉRO DE SÉRIE
Model/Modelo / Modèle: LL932301
635nm, OUTPUT < 1mW/CLASS II LASER PRODUCT
3.7V 1200mAh Li-Polymer
COMPLIES WITH 21 CFR PARTS 1040.10 AND 1040.11
PRODUCTO LÁSER CON SALIDA < 1mW. CLASE II,
635 nm, 3,7V 1200mAh polímero de litio
CUMPLE CON LAS SECCIONES 21 CFR 1040.10 Y 1040.11
635 nm, SORTIE < 1 mW/PRODUIT LASER DE CLASSE II
Pile au lithium-polymère de 3,7 V, 1200 mAh
CONFORME AUX NORMES 21CFR ARTICLES 1040.10
ET 1040.11
LASER RADIATION-DO NOT STARE INTO BEAM
RADIACIÓN LÁSER: NO MIRE DIRECTAMENTE EL RAYO
RAYONNEMENT LASER – NE FIXEZ PAS DES YEUX LE
RAYON LASER
CAUTION: Risk of re and burns. Do not open, crush, heat
above 100° C (212° F) or incinerate.
PRECAUCIÓN : Riesgo de incendio y quemaduras. No abra,
triture, permita que esté a mayor temperatura que 100° C
(212 °F) ni incinere.
ATTENTION : Risque d’incendie et de brûlures. N’ouvrez pas
le produit, ne l’écrasez pas, ne le chauffez pas à plus de
100ºC (212°F) et ne l’incinérez pas.
CAUTION/PRECAUCIÓN/ATTENTION
WARNING LASER RADIATION. Do not stare into beam.
Class II laser product. Turn the laser beam on only when using this
tool.
Do not remove or deface any product labels.
Avoid direct eye exposure. The laser beam can cause ash
blindness.
Do not operate the tool around children or allow children to operate
the tool.
Do not place the tool in a position that may cause anyone to stare at
the laser beam, whether intentionally or unintentionally.
Do not use on surfaces such as sheet steel that have shiny,
reective surfaces. The shiny surface could reect the beam back at
the operator.

4
Always turn the laser tool off when not in use. Leaving the tool
on increases the risk of someone inadvertently staring into the laser
beam.
Do not attempt to modify the performance of this laser device in any
way. This may result in a dangerous exposure to laser radiation.
Do not attempt to repair or disassemble the tool. If unqualied
persons attempt to repair this product, serious injury may occur. Any
repair required on this laser product should be performed only by
qualied service personnel.
Use of other accessories that have been designed for use with other
laser tools could result in serious injury.
Do not operate the tool outdoors.
Do not place or store tool under extreme temperature conditions.
FCC STATEMENT
The manufacturer is not responsible for radio interference caused
by unauthorized modications to this equipment. Such modications
could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received,
including interference that may cause undesired operation.
Changes or modications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,

5
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
DANGER People with electronic devices, such as
pacemakers, should consult their physician(s)
before using this product. Operation of electrical equipment in close
proximity to a heart pacemaker could cause interference or failure
of the pacemaker.
SAFETY RULES FOR CONNECTING POWER
SUPPLY
WARNING Read and follow all instructions below
before connecting with an external power
supply, such as AC supply or DC mobile power. Failure to follow
all instructions below may result in electric shock, explosion, re
and/or serious personal injury.
Use only an adapter for which output voltage is 5V and output
electricity is ≥0.5A.
Conrm that the adapter suits the AC supply before connecting.
Conrm that the mobile power source has output voltage of 5V and
output electricity of ≥0.5A before connecting.
Keep the adapter clean. Check the adapter, cable and plug before
do connecting. If damage is detected, do not use or repair by
yourself, change the damaged one or get repairs performed by
authorized service personnel, otherwise electric shock may occur.

6
Do not connect with AC supply on easily ammable surfaces (e.g.,
paper, textiles, etc.) or surroundings. The heating of the adapter
during use may pose a re hazard.
Children or persons with physical, sensory or mental limitations
or lack of experience and knowledge are not capable of securely
operating the adapter unless they are being given supervision or
have been instructed by a responsible person.

7
SYMBOLS
Safety Symbols
The purpose of safety symbols is to attract your attention to
possible dangers. The safety symbols and the explanations with
them deserve your careful attention and understanding. The
symbol warnings do not, by themselves, eliminate any danger. The
instructions and warnings they give are no substitutes for proper
accident prevention measures.
WARNING Be sure to read and understand all safety
instructions in this Operator’s Manual, including
all safety alert symbols such as “DANGER,” “WARNING,” and
“CAUTION” before using this tool. Failure to following all instructions
listed below may result in electric shock, re, and/or serious
personal injury.
The denitions below describe the level of severity for each signal
word. Please read the manual and pay attention to these symbols.
This is the safety alert symbol. It is used to
alert you to potential personal injury hazards.
Obey all safety messages that follow this
symbol to avoid possible injury or death.
DANGER DANGER indicates a hazardous situation
which, if not avoided, will result in death or
serious injury.
WARNING WARNING indicates a hazardous situation
which, if not avoided, could result in death or
serious injury.
CAUTION CAUTION, used with the safety alert symbol,
indicates a hazardous situation which, if not
avoided, will result in minor or moderate injury.

8
Damage Prevention and Information Messages
These inform the user of important information and/or instructions
that could lead to equipment or other property damage if they are
not followed. Each message is preceded by the word “NOTICE”, as
in the example below:
NOTICE: Equipment and/or property damage may result if these
instructions are not followed.
IMPORTANT: Some of the following symbols may be used on
your tool. Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate the tool
better and safer.
Symbol Name Designation/Explanation
V Volts Voltage (potential)
A Amperes Current
mW Milliwatt Power
nm nanometer Wavelength
kg Kilograms Weight
min Minutes Time
sSeconds Time
Wh Watt-hours Battery capacity
mAh Milliampere-Hours Battery capacity
Direct current Type or a characteristic of
current
Unlock Icon
Push the mode switch in the
direction of the icon, the tool
will enter the self-leveling
mode and the cross line
laser will be turned on

9
Symbol Name Designation/Explanation
Lock Icon
Push the mode switch in the
direction of the icon, the tool
will be turned off and locked
LED Indicator for
Leveling Status
If the tool is placed exceeds
the self-leveling range
(±4°from horizontal) in self-
leveling mode, or when the
tool is working in manual
leveling mode, it will
illuminate in red.
LED Indicator for
Battery Capacity
The color status varies with
the battery capacity the tool
rests during charging and
normal usage
Laser Button
To turn the compact self-
leveling cross line laser on
and off in manual leveling
mode
CEC Energy Efciency
Logo
CEC certication logo for
battery charging system
Li-ion RBRC seal Designates Li-ion battery
recycling program
Read manual symbol Alerts user to read manual

10
GET TO KNOW YOUR LASER TOOL
This compact self-leveling cross line laser is highly versatile. It can
be hand-held, leveled on a horizontal surface or mounted on the
clamp.
Use the automatic cross line laser for aligning: tiles, wall studding,
windows, doors, etc.
Fig. 1
LED Indicator for
Battery Capacity Laser
Button
1/4”
Threaded
Mounting
Hole on
Bottom
1/4”
Threaded
Mounting
Hole on
Top
Handle USB Charging Cable
Rod
Lock
Icon
Micro USB
Charging
Port
1/4" Screw Platform
Laser
Aperture Mode
Switch
Unlock
Icon
LED Indicator for
Leveling Status
Knob
