D7C Expansion Module
for Snom D717, D735, D765, D785 phones
User Manual

2
TABLE OF CONTENTS
Copyright, Trademarks, Legal Disclaimers .......................................................................3
Important information .........................................................................................................4
Safety instructions .................................................................................................................4
Standards conformance ........................................................................................................ 4
SELV (Safety Extra Low Voltage) compliance ..............................................................4
Product specications ........................................................................................................... 5
Disposal of the device ............................................................................................................5
Cleaning ....................................................................................................................................5
Setting up the expansion module ....................................................................................6
Delivery content ......................................................................................................................6
Attaching the footstand ......................................................................................................... 6
Connecting the Snom D7C to a Snom phone .....................................................................7
Connecting two or three D7Cs to a Snom phone ............................................................... 8
Detaching the connector ....................................................................................................... 9
Connecting a wireless headset ............................................................................................ 9
Getting to Know Your Expansion Module ..................................................................... 10
Display Layout .......................................................................................................................10
SmartLabels ..........................................................................................................................11
Function key LEDs ................................................................................................................11
Display appearance settings ..............................................................................................12
Conguring the function keys ....................................................................................... 15
On the phone ..........................................................................................................................15
Font size and text alignment .........................................................................................15
Function settings .............................................................................................................15
On the web interface ............................................................................................................16
Font size and text alignment .........................................................................................16
Function settings .............................................................................................................16
XML provisioning of settings ..............................................................................................17
Function key numbering system .................................................................................. 20
Firmware update ........................................................................................................... 23
Manual update via the phone's web interface ................................................................23
Update via provisioning .......................................................................................................23

3
Snom D7C User Manual Copyright, Trademarks, Disclaimers
Copyright, Trademarks, Legal Disclaimers
© 2021 Snom Technology GmbH
All Rights Reserved.
Snom, the names of Snom products, and Snom logos are trademarks owned by Snom Technology
GmbH. All other product names and names of enterprises are the property of their respective
owners.
Product specications are subject to change without notice.
Snom Technology GmbH reserves the right to revise and change this document at any time, without
being obliged to announce such revisions or changes beforehand or after the fact.
Texts, images, and illustrations and their arrangement in this document are subject to the protection
of copyrights and other legal rights worldwide. Their use, reproduction, and transmittal to third
parties without express written permission may result in legal proceedings in the criminal courts as
well as civil courts.
When this document is made available on Snom’s web page, Snom Technology GmbH gives its
permission to download and print copies of its content for the intended purpose of using it as a
manual. No parts of this document may be altered, modied or used for commercial purposes without
the express written consent of Snom Technology GmbH.
Although due care has been taken in the compilation and presentation of the information in this
document, the data upon which it is based may have changed in the meantime. Snom therefore
disclaims all warranties and liability for the accurateness, completeness, and currentness of the
information published, except in the case of intention or gross negligence on the part of Snom or
where liability arises due to binding legal provisions.

4
Snom D7C User Manual Safety, Disposal, Cleaning of Product
Important information
Please read the instructions on safety and disposal and on how to set up and use the device before
using it and also give them to other users to read or inform those users of their contents. Save this
manual and do not give the device to third parties without it.
Safety instructions
Follow the instructions in this manual and other applicable documentation of the device.
• For use with Snom D717, D735, D765, and D785 only. Do not connect the device to a PC or to other
phones!
• Mount the device only at heights not exceeding 2m.
• If the device is not supplied with power via the USB cable, use only a power adapter expressly
recommended by Snom Technology. Other power supplies may damage or destroy the device,
aect its behavior, or induce noise.
• Avoid placing the cables where people may trip over them or where they may be exposed to
mechanical pressure as this may damage them.
• This device is for indoor use only! NOT FOR OUTDOOR USE!
• Do not install the device in rooms with high humidity (for example, in bathrooms, laundry rooms,
damp basements). Do not immerse the device in water and do not spill or pour liquids of any kind
onto or into the device.
• Do not install the device in surroundings at risk for explosions (paint shops, for example). Do not
use the device if you smell gas or other potentially explosive fumes.
• Do not use the device during thunderstorms. Lightning striking the power grid may cause electric
shocks.
Standards conformance
This device complies with the essential health, safety, and environmental
requirements of all relevant European directives. The declaration of conformity
can be donloaded at https://www.snom.com/conformity.
This device meets the relevant health, safety, and environmental standards of the
United Kingdom.
This device meets the relevant health, safety, and environmental standards of the United States and
Canada.
Unauthorized opening, changing, or modifying the device will cause the warranty to lapse and may
also result in the lapse of CE, FCC, IC, and UK conformity. In case of malfunction contact authorized
service personnel, your seller, or Snom.

5
Snom D7C User Manual Safety, Disposal, Cleaning of Product
SELV (Safety Extra Low Voltage) compliance
Safety status of Input/Output connections comply with SELV requirements.
Product specications
• Safety: IEC 62368-1
• Connectors:
◦1 attached USB 2.0 cable with USB standard type A plug;
◦1 USB port, type A, USB 2.0
◦1 x 5V DC jack
• Power: Via attached USB cable. A power adapter (available separately) is needed for the second
module which also supplies power to the third module via USB cable. The third module may also
need a power adapter if a USB device is connected to its USB port.
◦EU/AU: Ten Pao, model S018BAM0500200, SnomPN 00004393
Phihong, model PSM10R-050
◦US: Ten Pao, model S018BAM0500200, SnomPN 00004446
Phihong, model PSM10R-050
SIL, model SSA-050200US
Disposal of the device
This device is subject to European Directive 2012/19/EU and may not be disposed of with
general household garbage.
If you do not know where you may dispose of the device at the end of its lifespan, contact
your municipality, your local waste management provider, or your seller.
For countries outside the European Union: Disposal of electrical and electronic products in countries
outside the European Union should be done in line with local regulations. Please contact local
authorities for further information.
Cleaning
To clean the device, use an anti-static cloth. Please avoid cleaning liquids as they might damage the
surface or internal electronics of the device.

6
Snom D7C User Manual Setting up the expansion module
Setting up the expansion module
Delivery content
Quick
Installation
Guide
D7C
AB
B
C
◦Base unit with attached USB cable with type A plug
◦Footstand
◦Connectors: 1 x type A, 2 x type B, 1 x type C
◦Quick Installation Guide
Attaching the footstand
1. Place the top of the grooves on the footstand (Fig. 1) below the slideguides on the back of the
device (Fig. 2). For the upright position, the short "legs" of the footstand must be attached to the
device; for the more horizontal position, use the long ones.
2. Push the footstand upwards onto the slideguides (Fig. 3) until they lock in place (Fig. 4).
Fig. 1 Fig, 2 Fig. 3 Fig. 4
3. Place the device on an even, horizontal surface.

7
Snom D7C User Manual Setting up the expansion module
Connecting the Snom D7C to a Snom phone
The connectors are marked A, B, and C. Connectors A and B are used to attach the footstands of D7C
and the phone, connector C is used to connect the footstands of two D7Cs:
◦A: connecting to D717, D735, and D765.
◦B: connecting to D785. There is also a smaller plate marked B to connect the D7C and the
D785 more securely.
◦C: connecting a D7C to another D7C.
You can connect up to three Snom D7Cs to one of the supported Snom phones. The rst expansion
module is supplied with power by the phone via the module's USB cable. The second module is
supplied with power by one of the separately available power adapters. The third expansion module
is supplied with power by the second module via the third module's USB cable.
Note: In some cases, e.g. if you connect a device requiring a lot of power to the USB
port of the D7C, you may also need to attach a power adapter to the third and the rst
module in the daily-chain.
1. Place a soft cloth on the desktop so that the display does not get scratched or otherwise damaged
if you lay the device down.
2. Attach the respective footstand to the D7C expansion module and to the phone.
3. Place the USB cable of the D7C into the cable guide (Fig. 1).
Fig. 1
4. Connect the expansion module to the phone, as shown in Fig. 2. If the phone has two USB ports
(Fig. 3), either one can be used.
Fig. 2 Fig. 3
Cable guide

8
Snom D7C User Manual Setting up the expansion module
5. Holding the D7C and the connector backside up, push the connector against the footstand of
the DC7 (Fig. 4). If it does not snap securely into place, push the three levers on the connector
towards the footstand of the D7C until you hear each one click into place (Fig. 5).
Fig. 4 Fig. 5
6. Push the other side of the connector against the footstand of the phone. If it does not snap
securely into place, push the three levers on the connector towards the footstand of the phone
until you hear each one click into place.
7. D785 only. Place a soft cloth on the desktop and turn phone and D7C backside up. On either side
of the small plate marked B there is a ridge (Fig. 6) that ts into the slideguides on the footstands.
Insert the ridges into the slideguides of the footstands of phone and D7C and slide the connector
down toward the tips of the "legs" (Fig. 7).
Fig. 6 Fig. 7
Connecting two or three D7Cs to a Snom phone
Do not use a USB hub (Fig. 8). If the phone has more than one USB port, do not connect expansion
modules to more than one port (Fig. 9). The D7Cs must be daisy-chained. If they are not, the phone
will not be able to identify the function keys on the modules, rendering them inoperable.
Fig. 8 Fig. 9
1. Connect the modules to each other rst. If a module is connected to the phone already, connect
the second and third module to each other.
2. Important note: Attach a power adapter (available separately) to the second module and to a wall
outlet before connecting the daisy-chain to the phone or the second / second and third module to
the D7C already connected to the phone (Fig. 10).
Slide guide

9
Snom D7C User Manual Setting up the expansion module
If a USB device like a speakerphone or conferencing device is connected to the third module in the
chain, it may also need a power adapter that must be connected to a power outlet.
Step 3
Step 2
Phone
Module 1Module 2Module 3
Step 1
Fig. 10
3. After the modules have been connected to the phone, their LEDs will light up briey, then turn o,
indicating that the function keys are now ready for use..
Detaching the connector
Push the three levers on the respective side inward to detach the connector from the footstand.
Connecting a wireless headset
On phones with a single USB port, the USB port on the expansion module can be used to connect a
wireless headset via its USB adapter. If two or three expansion modules are daisy-chained, insert
the USB adapter of the wireless headset into the USB port on the last module in the chain,
If the Snom phone has two USB ports, the USB adapter of the wireless headset can be inserted into
the USB port on the expansion module or into the free USB port on the phone.

10
Snom D7C User Manual Getting to know your D7C
Getting to know your D7C
The function keys on the expansion module(s) are congured and work like function keys/SmartLabel
keys with LEDs on the phone itself. The settings are stored on the phone and will remain stored there
when the expansion module is disconnected; if the expansion module is replaced by another module,
the settings will by used by that module. For more information on the available functions and on how
to program and use the keys, please refer to the phone's manual, chapter "Programming the Function
Keys". You can download the manual at https://service.snom.com -> Desk Phones.
Display layout
DND
O 
Extension
1234
Extension
1235
Intercom
Mary
Park
Speed dial
123456789012
Line
Free
Line
Free
Line
Free
Line
Free
Line
Free
Line
Free
Line
Free
Line
Free
Line
Free
Line
Free
Extension
1236
Extension
1244
Extension
1240
Intercom
Tom
Speed dial
123890145672
Speed dial
123456733654
Line
Free
Line
Free
Line
Free
Line
Free
Line
Free
Line
Free
Line
Free
Line
Free
Line
Free
Line
Free
Fig. 1 Fig. 2
The module has 16 function keys with LED and a page key for scrolling through the three
function key pages. A eld on the display screen is allocated to each key, and the text can be left-
aligned, as shown in Fig. 1, or right-aligned, as shown in Fig. 2. The blue line at the bottom of the
screen indicates which page is on-screen (Fig. 3).
Page indicator
DND
O 
Extension
1234
Extension
1235
Intercom
Mary
Park
Speed dial
123456789012
Line
Free
Line
Free
Line
Free
Line
Free
Line
Free
Line
Free
Line
Free
Line
Free
Line
Free
Line
Free
Extension
1236
Extension
1244
Extension
1240
Intercom
Tom
Speed dial
123890145672
Speed dial
123456733654
Line
Free
Line
Free
Line
Free
Line
Free
Line
Free
Line
Free
Line
Free
Line
Free
Line
Free
Line
Free
Extension
1236
Extension
1244
Extension
1240
Intercom
Tom
Speed dial
123890145672
Speed dial
123456733654
Line
Free
Line
Free
Line
Free
Line
Free
Line
Free
Line
Free
Line
Free
Line
Free
Line
Free
Line
Free
Page 1 Page 2 Page3
Fig. 3
LED key
Fkey separator
Fkey label
Page key

11
Snom D7C User Manual Getting to know your D7C
SmartLabels
In the default setting, icon and name of the function type are shown in the label area (Fig. 1 and 2,
example 1).
◦When no text has been entered in the Label eld and the Number eld is empty, the label area on
the display shows the function type (example 1).
◦When a text is entered in the Label eld, it is displayed instead of the function type (example 2, 4,
and 5).
◦When a value is entered in the Number eld and the Label eld is empty, the value is added as
a second line to the function type in the top line (example 3).
◦ If you want two lines of character strings to be displayed, for example a name and a phone
number for an extension setting, enter them in the Label eld with the <br> tag between them
(example 5).
Extension
Extension
Extension
Joe Miller
[email protected]
[email protected] Joe Miller<br>1236
Extension
Extension
Joe Miller
[email protected]
1
2
3
4
5
Fig. 1
DND
O 
DND
On
Extension
Joe Miller
Extension
1236
Joe Miller
Joe Miller
1236
Line
Free
Extension
1234
Extension
1234
Extension
1234
Extension
1234
Free
Line
Free
Line
Free
Line
Free
1
2
3
4
5
Fig. 2
Depending on the function mapped onto the key, its allocated display area will show the context
information when the key event occurs or when the key is pressed; it will revert to the idle content
when the key event has ended or when the key is pressed again.
Extension idle
Extension ringing
Extension busy
DND
O 
DND
On
Extension
Joe Miller
Extension
1236
Joe Miller
Joe Miller
1236
Line
Free
Extension
1234
Extension
1234
Extension
1234
Extension
1234
Free
Line
Free
Line
Free
Line
Free
Fig. 3
Function key LEDs
Depending on the function mapped onto the key, the LEDs on the key will light up when the key event
occurs or when the key is pressed; they will go out when the key event has ended or when the key is
pressed again.
Note: The label is a convenience for the user. It has no
eect on the functioning of the key. Examples 1 and 2
are not valid extension settings because no Number
value has been set.
DND
O 
DND
On
Extension
Joe Miller
Extension
1236
Joe Miller
Joe Miller
1236
Line
Free
Extension
1234
Extension
1234
Extension
1234
Extension
1234
Free
Line
Free
Line
Free
Line
Free
DND
O 
DND
On
Extension
Joe Miller
Extension
1236
Joe Miller
Joe Miller
1236
Line
Free
Extension
1234
Extension
1234
Extension
1234
Extension
1234
Free
Line
Free
Line
Free
Line
Free

12
Snom D7C User Manual Getting to know your D7C
Display appearance settings
The D7C comes with four standard background themes (UI color themes) that can be selected on
the phone and on the phone's web interface (Fig. 1 to 4); the default is the "light" theme at Fig. 1.
The color of label separators, text, and symbols is adjusted automatically for best readability on the
background.
Per provisioning only, you can also specify the URL to a custom background image to be used instead
(Fig. 5 and 6). For custom backgrounds with a light background or a mixed background like Fig. 5 you
may also need to set the industrial UI color theme to improve the readability of the text.
Fig. 1–light Fig 2–dark Fig. 3–colorful Fig. 4–industrial Fig. 5 Fig. 6
The intensity of the backlight can be adjusted separately for periods of activity and inactivity. When
the device has been inactive for a specied number of seconds, it will automatically switch the
backlight intensity to idle mode.
Settings on the phone
UI color theme
1. Press to open the Settings menu of the phone that the module is connected to.
2. Select Preferences and press .
3. Select Display and press .
4. Select Expansion Modules and press .
5. Select Appearance and press .
6. Select the module if more than is connected to the phone.
7. Select a theme and press to save and return to the Expansion Modules menu.

13
Snom D7C User Manual Getting to know your D7C
Backlight
1. Press to open the Settings menu of the phone that the module is connected to.
2. Select Preferences and press .
3. Select Display and press .
4. Select Expansion Modules and press .
5. Select Backlight on activity or Backlight when idle and press .
6. Press the right or left arrow on the navigation key or the function key underneath or in the
function key line to decrease or increase the backlight's intensity.
7. Press to save and return to the Expansion Modules menu.
Note: The timer for returning the backlight to idle mode is set on the web interface.
Settings on the web interface
UI color theme
1. Open the web interface of the phone.
2. Click Preferences in the menu on the left side of the window.
3. Click the Appearance tab.
4. Scroll down to UI Color Theme and select a theme from the drop-down menu.
5. Click Apply and Save.
Custom image
1. Open the web interface of the phone.
2. Click Preferences in the menu on the left side of the window.
3. Click the Appearance tab.
4. Scroll down to Expansion Module Interface Elements and enter the URL to a custom image.
Image size must be 480 by 1280 pixels, and the le size should be below 2MB. If the image does
not conform to these specications, the current UI color theme will be instead used instead.
5. Click Apply and Save.

14
Snom D7C User Manual Getting to know your D7C
Backlight
1. Open the web interface of the phone.
2. Click Preferences in the menu on the left side of the window.
3. Click the Display tab.
4. In the USB Expansion Module section, enter a value from 0 to 15 in the text elds of backlight on
activity and backlight when idle., The defaults are 15 (highest intensity) for backlight on activity
and 8 for backlight when idle. Enter 0 to turn the backlight o.
5. Enter a time period in seconds in the text eld of Dim after (s). Valid values are integers from 1 to
2147483647. The default is 20 seconds.
6. Click Apply and Save.

15
Snom D7C User Manual Conguring the function keys
Configuring the function keys
The function keys on the expansion module are congured and work like the SmartLabel keys with
LEDs on the D717, D735, and D785 and the function keys with LEDs on the D765. The settings are
stored on the respective phone and remain stored there when the expansion module is disconnected.
They are not shown in the phone's settings when no expansion module is connected. If the expansion
module is replaced by another module, the settings will by used by that module.
The keys on the D7C are freely programmable function keys. See the phone's manual, chapter
Conguring the function keys, for the description of the settings and how to congure them. You can
download the manual at https://service.snom.com +.
Conguration on the phone
Font size and text alignment
The font size of the upper (MainText) and lower (SubText) text lines can be adjusted separately.
DND
O 
DND
On
Extension
Joe Miller
Extension
1236
Joe Miller
Joe Miller
1236
Line
Free
Extension
1234
Extension
1234
Extension
1234
Extension
1234
Free
Line
Free
Line
Free
Line
Free
1. Press to open the Settings menu of the phone that the module is connected to.
2. Open the Preferences menu.
3. Open the Display menu.
4. Open the Expansion Modules menu.
5. Open Appearance.
6. Select the UXMC expansion module.
7. Select the font size for the top line (Maintext size) and the bottom line (Subtext size). The defaults
are XL and S, respectively.
8. Select the text alignment. The default is left-aligned.
9. Press for 3 seconds to return to the idle screen.
Function settings
1. Press to open the Settings menu of the phone that the module is connected to.
2. Open the Preferences menu.
3. Open the Fkeys menu.
4. Select the UXMC expansion module.
5. Select Page 1, 2, or 3, respectively, by scrolling to the respective page and pressing .
6. Select a key and press to open the Key # Function menu. The selected key ashes yellow if the
SmartLabel key page with the key to be congured is on-screen (press to page).
Main Text
Sub Text

16
Snom D7C User Manual Conguring the function keys
7. The default for Context is Active, i.e., all congured identities whose status is "active".
a. If you want to restrict the functionality to a congured identity, select Context and press .
b. Select the identity from the menu and press . The following prompts depend on the selected
functionality.
8. Select Type and press . Use / to scroll to a functionality on the list and press . The
information you will then be prompted to enter depends on the selected functionality.
9. In our example, the functionality is Extension. Press to select and return to the Key # function
menu where Number has been added to the menu below "Type".
10. Select Number and press .
11. Enter the extension number and press .
12. The Label is optional. See "SmartLabels" on page 11 for more information. Enter a name or
other descriptive text and press , or press without entering data to save.
13. Press briey to return to the Key # Function menu; press for 3 seconds to return to the idle
screen.
Conguration on the web interface
Font size and text alignment
1. Open the web interface of the phone.
2. Click Preferences in the menu on the left side of the window.
3. Click the Appearances tab.
4. Scroll down to Expansion Module Font Options and select font size and text alignment from the
respective drop-down menus. The defaults are XL for Main Text and S for Sub Text size, and left-
aligned for the text alignment.
5. Click Apply and Save.
Function settings
1. Open the web interface of the phone.
2. Click Function keys in the menu on the left side of the window. The keys on the three pages of
each module are numbered consecutively from 1–48 on each module:
◦Page 1: 1–16
◦Page 2: 17–32
◦Page 3: 33–48

17
Snom D7C User Manual Conguring the function keys
9.12.2020 D7C_config_1.png
https://mail.google.com/mail/u/0/#inbox/CllgCHrdkvGJQplKkpgwkjKZwnJTKkDbnwtQkXxJfmXVKFcshldksCQkTCLJhhBBkhphQbjjTNB?projector=1&messagePartId=0.1 1/2
3. Click the Key Assignment tab, if necessary.
4. Scroll down to Expansion Keys and the expansion module you want to congure.
5. Under Context of the key you want to congure, select "Active" or one of the congured identities
from the drop-down list. The default is "Active", i.e., the congured key is available for all
congured identities on the phone.
6. Under Type, select "Extension" from the drop-down list.
7. In the Number text eld, enter the phone number whose calls you want to monitor and pick up.
8. Optional: In the Label text eld, enter a name or descriptive text. See "SmartLabels" on page 11
for more information.
9. Click Apply and Save.
XML provisioning of settings
The XML tags of the function keys are an exception from the general rules for XML mass provisioning
of settings for Snom phones because the tag for each key species the exact settings for that
particular key. The format is as follows:
<fkey idx="n" context="active" label="x" default_text="$name $state" perm="">argument</fkey>
Example:
<fkey idx="33" context="active" short_label_mode="text" short_label="" short_default_
text="!!$(::)!!$(generate_via_conditional_label_short)" label_mode="icon_text" icon_type="" reg_
label_mode="icon_text" label="" lp="on" default_text="!!$(::)!!$(generate_via_conditional_label_full)"
perm="" c="1" cslm="1" clm="1">dest &lt;sip:[email protected];user=phone&gt</fkey>
For more information on function key types, see https://service.snom.com/display/wiki/
Function+Key+Types. For more information on valid values and defaults, see the individual settings
at https://service.snom.com/display/wiki/Settings.

18
Snom D7C User Manual Conguring the function keys
• Parameter fkey idx. The unique identier of the function key when connected to a particular
phone model.
NOTE: The fkey idx of a particular key depends on the number of function keys on the
phone, the number of expansion modules connected to the phone, and the position of
the module in the daisy chain. For your convenience, we have prepared a table of the
numbering system; please see "Function key numbering system" on page 20.
• Parameter context. This setting species the identity (account) that can use the key. The default
is Identity 1. Valid settings:
◦All active identities (accounts) registered on the phone: Setting "active".
◦One identity specied by its number. Example: Setting "1" for Identity 1.
• Parameter label. The label (name, etc.) to be shown on the expansion module's display. On the
Function Keys page of the phone's web interface this is the string entered in the text eld of
Label. See "SmartLabels" on page 11.
Examples for an extension setting.
◦label="Joe Miller" displays
DND
O 
DND
On
Extension
Joe Miller
Extension
1236
Joe Miller
Joe Miller
1236
Line
Free
Extension
1234
Extension
1234
Extension
1234
Extension
1234
Free
Line
Free
Line
Free
Line
Free
.
◦label="Joe Miller<br>1236" displays two lines:
DND
O 
DND
On
Extension
Joe Miller
Extension
1236
Joe Miller
Joe Miller
1236
Line
Free
Extension
1234
Extension
1234
Extension
1234
Extension
1234
Free
Line
Free
Line
Free
Line
Free
• Parameter default_text. Optional attribute that can be any string. When the parameter label is
not set for a key, the value of default_text will be displayed as the key's label on the display of
the D7C (see "Display layout" on page 10). You can dene an arbitrary xed text or use $name,
$state, and $type to insert dynamic information. The default value is "$name $state".
◦ $name: Inserts the label or, if label is not set, the extension/phone number supplied as the
key's argument.
◦ $state: Inserts the key's state (free, busy, etc.) when functions like line or extension are
mapped onto the key.
◦$type: Inserts the key type.
• Parameter perm. Valid values are:
- perm="!": The settings of the key can be changed by mass provisioning, but only if the
end user has not made changes to the conguration on the phone itself or on its web
interface.
- perm="&", perm="R", perm=" ": The settings of the key are Read Only and cannot be
changed by the end user.
- perm="$", perm="RW", perm="": The settings of the key can be changed by mass
provisioning; any end user congurations will be overwritten on reboot.
• Argument.
◦ The default is line. Example:
<fkey idx="19" context="1" label="" default_text="$name $state" perm="">line</fkey>.
◦Examples for other functions:
NOTE: These settings depend on the requirements of the PBX.
- Extension: <fkey idx="19" context="1" label="Mary" default_text="$name $state"
perm="">dest sip:[email protected];user=phone</fkey>
- Speed dial:
<fkey idx="20" context="1" label="Mary/cell" default_text="$name $state" perm="">speed

19
Snom D7C User Manual Conguring the function keys
9175550240</fkey>
- Multicast: <fkey idx="21" context="1" label="Announcements 2nd oor" default_
text="$name $state" perm="">multicast 239.255.255.232:5555</fkey>
- Intercom: <fkey idx="22" context="1" label="Intercom Mary" default_text="$name $state"
perm="">icom sip:[email protected];user=phone</fkey>
- Forwarding all incoming calls: <fkey idx="23" context="1" label="Fwd all to Mary"
default_text="$name $state" perm="">redirect sip:[email protected];user=phone</
fkey>
- Transferring call: <fkey idx="24" context="1" label="Transfer" default_text="$name
$state" perm="">transfer</fkey>

20
Snom D7C User Manual Function key numbering system
Function key numbering system
Denitions
fkey idx: XML mass provisioning
PUI: Phone user interface (Settings > Preferences > Fkeys)
WUI: Web user interface (Function Keys page). The keys on the three pages of each module
are numbered consecutively on each module:
Page 1: 1–16
Page 2: 17–32
Page 3: 33–48
9.12.2020 D7C_config_1.png
https://mail.google.com/mail/u/0/#inbox/CllgCHrdkvGJQplKkpgwkjKZwnJTKkDbnwtQkXxJfmXVKFcshldksCQkTCLJhhBBkhphQbjjTNB?projector=1&messagePartId=0.1 1/2
D717
• SmartLabel keys on phone
◦fkey idx: 0–2
◦PUI: 1–3
◦WUI: P1–P3
• D7C expansion module 1
Page 1 fkey idx 3–18 PUI 4–19
Page 2 fkey idx 19–34 PUI 20–35
Page 3 fkey idx 35–50 PUI 36–51
• D7C expansion module 2
Page 1 fkey idx 51–66 PUI 52–67
Page 2 fkey idx 67–82 PUI 68–83
Page 3 fkey idx 83–98 PUI 84–99
• D7C expansion module 3
Page 1 fkey idx 99–114 PUI 100–115
Page 2 fkey idx 115–130 PUI 116–131
Page 3 fkey idx 131–146 PUI 132–147
