INSTALLATION MANUAL
1st Edition
RGB SQ PROCESSOR BOARD
HKSR-5803SQ
ADVANCED HQ PROCESSOR BOARD
HKSR-5803HQ

HKSR-5803SQ/5803HQ
!WARNING
This manual is intended for qualified service personnel only.
To reduce the risk of electric shock, fire or injury, do not perform any servicing other than that
contained in the operating instructions unless you are qualified to do so. Refer all servicing to
qualified service personnel.
!WARNUNG
Die Anleitung ist nur für qualifiziertes Fachpersonal bestimmt.
Alle Wartungsarbeiten dürfen nur von qualifiziertem Fachpersonal ausgeführt werden. Um die
Gefahr eines elektrischen Schlages, Feuergefahr und Verletzungen zu vermeiden, sind bei
Wartungsarbeiten strikt die Angaben in der Anleitung zu befolgen. Andere als die angegeben
Wartungsarbeiten dürfen nur von Personen ausgeführt werden, die eine spezielle Befähigung
dazu besitzen.
!AVERTISSEMENT
Ce manual est destiné uniquement aux personnes compétentes en charge de l’entretien. Afin
de réduire les risques de décharge électrique, d’incendie ou de blessure n’effectuer que les
réparations indiquées dans le mode d’emploi à moins d’être qualifié pour en effectuer d’autres.
Pour toute réparation faire appel à une personne compétente uniquement.

1-1 (E)
HKSR-5803SQ/5803HQ
Section 1
Installation
Purpose of this manual
This manual is an installation manual of RGB SQ Proces-
sor Board HKSR-5803SQ and Advanced HQ Processor
Board HKSR-5803HQ.
This manual is intended for system and service engineers,
so describes information regarding installation.
Related manual
Besides this installation manual, the following manual is
available for HKSR-5803SQ and HKSR-5803HQ.
.Maintenance Manual (available on request)
This manual describes the information for the mainte-
nance of this unit and the information that premises the
parts level service.
If this information is required, please contact your local
Sony Sales Office/Service Center.
1-1. Specifications
General
HKSR-5803SQ
Dimensions (w/h)
SQ-20 Board: 155 x90 mm
Mass SQ-20 Board: approx. 70 g
Power requirements +3.3 V dc: 840 mA
+1.5 V dc: 1800 mA
Power consumption approx. 5.5 W
HKSR-5803HQ
Dimensions (w/h)
DLP-27 Board: 155 x90 mm
Mass DLP-27 Board: approx. 70 g
Power requirements +3.3 V dc 850 mA
+1.5 V dc: 1800 mA
Power consumption approx. 5.5 W
1-2. Installation Overview
Components
HKSR-5803SQ is composed of the following items:
.SQ-20 Board
.Hexagonal support 7 mm (4 pcs)
.PSW2.6 x5.8 (8 pcs)
.Installation manual
HKSR-5803HQ is composed of the following items:
.DLP-27 Board
.Hexagonal support 7 mm (4 pcs)
.PSW2.6 x5.8 (8 pcs)
.Installation manual
Applicable models
SRW-5800
Installations of HKSR-5803SQ or HKSR-5803HQ
The HKSR-5803SQ comprises the SQ-20 board.
Mount the SQ-20 board on the HPR-22 board.
The HKSR-5803HQ comprises the DLP-27 board.
Mount the DLP-27 board on the HPR-22 board.
Attach and adjust the HKSR-5803SQ or HKSR-5803HQ
properly, following the procedures in Section 1-3 and later.

1-2 (E) HKSR-5803SQ/5803HQ
1-3. Installation Procedure
1. Turn off the power of the VTR.
2. Fully loosen the two fixing screws, and then slide the
two knobs on the upper lid (front) assembly each to the
inside. (Move the knobs to the outside to fix the upper
lid (front) assembly.)
3. Remove the upper lid (front) assembly in the arrow
direction.
Knob
Knob
Upper lid (front) assembly
Fixing screw
Removal
Installation
4. Fully loosen the two fixing screws, and then remove
the upper lid (rear) assembly in the arrow direction.
5. Raise the eject levers of the HPR-22 board in the
arrow direction, and then pull out the board slowly
upward.
Fixing screw
Upper lid (rear)
assembly
Protrusion
Square hole
Fixing screw
HPR-22 board
Eject lever
Eject lever

1-3 (E)
HKSR-5803SQ/5803HQ
HPR-22 board
SQ-20 board
or
DLP-27 board
PSW2.6 x5.8
(Supplied accessory)
PSW2.6 x5.8
(Supplied
accessory)
PSW2.6 x5.8
(Supplied
accessory)
PSW2.6 x5.8
(Supplied
accessory)
Hexagonal
supports (7 mm)
(Supplied
accessory)
Hexagonal
supports (7 mm)
(Supplied
accessory)
HPR-22 board
PSW
2.6 x6
PSW
2.6 x6
PSW2.6 x6
Shield plate
6. Remove the six screws to detach the shield plate from
the HPR-22 board.
7. Attach four 7 mm hexagonal supports (accessory) to
the HPR-22 board with four screws (accessory).
8. Connect the SQ-20 board or DLP-27 board to the
HPR-22 board and secure it with four screws (accesso-
ry).
Shield plate
HPR-22 board PSW2.6 x6
PSW
2.6 x6
PSW
2.6 x6
9. Reattach the shield plate to the HIF-22 board with six
screws.

1-4 (E) HKSR-5803SQ/5803HQ
EXIT
OPTION BOARD INFORMATION
HKSR-5001 Board –––––––––
HKSR-5802 Board –––––––––
HKSR-5803 Board
INSTALLED (SQ)
OPTION INFO
FUNC
INFO
DIAG
F1
F2
F3
F4
ALT F5 F6 F7 F8 F9 F10
DIAG
F1
F2
F3
F4
ALT F5 F6 F7 F8 F9 F10
ROM
VER
ERR
LOG
OPTION
INF MAINTE
EXEC EXIT
OPERATION 1105HOURS[ 1105H]
DRUM RUNNING
238HOURS[ 238H]
TAPE HOURS
153HOURS[ 153H]
THREADING 4048TIMES[
4048T]
MAINTENANCE INFORMATION DISPLAY
1-4. Confirming Identification of
Optional Board
Confirmation Procedure
1. On the HOME menu, press the DIAG button while
pressing the [SFT] (shift) key.
The MAINTENANCE INFORMATION menu
appears.
2. Press [F5] (OPTION INF).
The OPTION INFORMATION menu appears.
3. Check that “INSTALLED (SQ)” (HKSR-5803SQ) or
“INSTALLED (HQ)” (HKSR-5803HQ) is displayed
for the HKSR-5803 board.
n
For more information on the maintenance mode, refer to
Section 3 of the VTR Maintenance Manual Volume 1.
HPR-22 board
Eject lever
Eject lever
<Top view>
SS
APR
FC
HPR-22 board
DVP
HIF
MY
HPR
EQ
10. Securely insert the HPR-22 board into the “HPR” slot
to tightly connect the board to the connector on the
motherboard, while pressing down the two eject
levers.
