Sony BKM-16R User manual
MONITOR CONTROL UNIT
BKM-16R
OPERATION MANUAL [English]
1st Edition (Revised 3)
2
Before operating the unit, please read this manual
thoroughly and retain it for future reference.
WARNING
To reduce the risk of fire or electric shock, do not
expose this apparatus to rain or moisture.
To avoid electrical shock, do not open the
cabinet. Refer servicing to qualified personnel
only.
This unit has no power switch.
When installing the unit, incorporate a readily accessible
disconnect device in the fixed wiring, or connect the power
plug to an easily accessible socket-outlet near the unit. If
a fault should occur during operation of the unit, operate
the disconnect device to switch the power supply off, or
disconnect the power plug.
Using this unit at a voltage other than 120 V may require
the use of a different line cord or attachment plug, or both.
To reduce the risk of fire or electric shock, refer servicing
to qualified service personnel.
IMPORTANT
The nameplate is located on the bottom.
For the customers in the U.S.A.
This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when
the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instruction manual, may cause
harmful interference to radio communications. Operation
of this equipment in a residential area is likely to cause
harmful interference in which case the user will be
required to correct the interference at his own expense.
You are cautioned that any changes or modifications not
expressly approved in this manual could void your
authority to operate this equipment.
All interface cables used to connect peripherals must be
shielded in order to comply with the limits for a digital
device pursuant to Subpart B of Part 15 of FCC Rules.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
For customers in Canada
This Class A digital apparatus complies with Canadian
ICES-003.
For the customers in Europe
This product with the CE marking complies with the EMC
Directive issued by the Commission of the European
Community.
Compliance with this directive implies conformity to the
following European standards:
• EN55103-1: Electromagnetic Interference(Emission)
• EN55103-2: Electromagnetic Susceptibility(Immunity)
This product is intended for use in the following
Electromagnetic Environment: E4 (controlled EMC
environment, ex. TV studio).
The manufacturer of this product is Sony Corporation, 1-
7-1 Konan, Minato-ku, Tokyo, Japan.
The Authorized Representative for EMC and product
safety is Sony Deutschland GmbH, Hedelfinger Strasse
61, 70327 Stuttgart, Germany. For any service or
guarantee matters please refer to the addresses given in
separate service or guarantee documents.
This apparatus shall not be used in the residential area.
For the customers in Europe, Australia and New
Zealand
WARNING
This is a Class A product. In a domestic environment, this
product may cause radio interference in which case the
user may be required to take adequate measures.
3
Table of Contents
Table of Contents
Features ................................................................................. 4
Available Monitors and Functions ...................................... 5
Location and Function of Parts ........................................... 6
Front Panel..................................................................................6
Rear Panel...................................................................................9
Inserting/Ejecting the “Memory Stick” ............................. 10
Notes on “Memory Stick” ........................................................10
Mounting the Unit in a Rack............................................... 12
Connections ........................................................................ 12
Connecting the Monitor............................................................12
Connecting the Multiple Units with the LAN .......................... 13
Specifications...................................................................... 14
Dimensions.......................................................................... 15
4Features
Features
The BKM-16R is a control unit for the BVM/PVM series
business & professional video monitor. Use it to power
monitors on and set in standby mode, perform menu
operations, and carry out monitor setup and adjustment.
For monitors connectable to this unit and usable functions,
see page 5.
Remote control function (Ethernet control)
The unit controls up to 32 monitors by the Ethernet
(10BASE-T/100BASE-TX) connection. Up to four units
are connected to one monitor in single mode. You can
control individual monitors or monitor groups simply by
entering the monitor ID number or group ID number. You
can also execute the same operation on all connected
monitors, or put all connected monitors into the same setup
and adjustment state.
Setup and adjustment with the “Memory Stick”
You can use a “Memory Stick” to save and load monitor
setup and adjustment data. If your system includes more
than one monitor, you can use the “Memory Stick” to
exchange data between monitors. This makes it easy to put
all monitors in your system into the same setup and
adjustment state.
This function is available for BVM series monitors (except
BVM-A series) and PVM-L series monitors.
Rack mounting
You can mount the unit in an EIA standard 19-inch rack
with the supplied rack mount brackets and screws.
Assignable function key
Other functions are assigned to the F1 to F16 buttons in the
Controller menu of the monitor.
This function is available for BVM series monitors (except
BVM-A series) and PVM-L series monitors.
5
Available Monitors and Functions
Available Monitors and Functions
For details on how to use each function, refer to the manual of your monitor.
a: available
–: not available
a) Only compatible with monitors of the same series.
b) Some buttons and knobs may not function, depending on the input signal.
For details on limitations with each type of input signal, refer to the manual of your monitor.
c) H/V DELAY function is enabled when either the H DELAY or V DELAY button is pressed.
It is not possible to enable only H DELAY or V DELAY independently.
Monitor BVM-A series BVM series
except BVM-A
PVM-L series PVM series
except PVM-L
Available
function
Setup/adjustment with “Memory Stick” –aa) aa) –
CAPTURE –aa –
Function assignment to function
buttons –ab) ab) –
SCAN aaaa
H DELAY aaa
ac)
V DELAY aaa
ac)
MONO aaaa
APT aaa –
Aperture modification adjustment aaaa
COMB aaa –
CHAR OFF aaa –
COL TEMP aaaa
16:9 aaaa
NATIVE SCAN –aaa
BLUE ONLY aaaa
R, G, B OFF aaa –
MARKER aaaa
Marker display mode setting aaaa
CHROMA UP aaa –
Menu operation aaaa
MONITOR I/O aaaa
Monitor selection aaaa
Display mode setting for the display
window aaa –
MANUAL adjustment buttons and
knobs ab) ab) ab) ab)
Picture adjustment presetting on
MANUAL adjustment knobs aaaa
6Location and Function of Parts
Location and Function of Parts
For functions available with your monitor, see page 5.
Front Panel
aOPERATE lamp
The lamp lights when the unit is turned on.
bMemory Stick insertion slot
The standard and duo type “Memory Stick” is available.
Insert the “Memory Stick” (optional).
When you use a “Memory Stick Micro”, do so after
attaching the M2 adaptor (optional).
For inserting/ejecting the “Memory Stick”, see page 10.
The setting and adjustment data saved in the “Memory
Stick” are only compatible with monitors of the same
series.
It is not possible to load the data stored in the “Memory
Stick” inserted in this slot to a monitor that does not
support the “Memory Stick,” or save the setting/adjustment
data in the “Memory Stick” inserted in this slot to such a
monitor.
cCAPTURE button
Press to capture the 3G/HD-SDI input signal as the still
picture in frame.
dFunction buttons
Press to change the operation conditions for the monitor.
Each time the button is pressed, the LED on the button
turns on and turns off, and the operation conditions are
changed. (The LED may not turn on depending on the
function.)
You can assign other functions to the F1 to F16 buttons.
The button may not function due to the input signal. For
the limitations with each type of signal, refer to the manual
of your monitor.
Factory preset setting
2Memory Stick insertion slot
4Function buttons
5Menu operation buttons
6MONITOR I/1switch
7Numeric keypad
8Monitor selection buttons and lamps
9MANUAL adjustment buttons and knobs
1OPERATE lamp
3CAPTURE button
Note
APT COMB
CHAR
OFF COL
TEMP
16 : 9
NATIVE
SCAN
BLUE
ONLY R OFF G OFF B OFF MARKER
F4 F5 F6 F7
CHROMA
UP
F2 F3 F8
F12 F13 F14 F15
F10 F11 F16
MONO
H
DELAY V
DELAY
SCAN
F9
F1
SCAN button
MONO button APT button
COMB button
CHAR OFF button
COL TEMP button
R, G, B OFF buttons
MARKER button
CHROMA UP
button
BLUE ONLY button
NATIVE SCAN button
16:9 button
H DELAY button
V DELAY button
7
Location and Function of Parts
SCAN button: Press to change the scan size of the picture.
H DELAY button: Press to move the picture horizontally
and display a horizontal sync signal.
The brightness of the picture increases automatically,
which makes it easy to check the sync part.
When the V DELAY button is pressed in H delay
mode, a pulse cross picture is displayed.
V DELAY button: Press to move the picture vertically
and display a vertical sync signal approximately in the
center of the screen.
The brightness of the picture increases automatically,
which makes it easy to check the sync part.
When the H DELAY button is pressed in V delay
mode, a pulse cross picture is displayed.
MONO button: Press to display a monochrome picture.
When the buttons is set to off, the monitor switches
automatically between color and monochrome mode,
depending on the color discrimination of the input
adaptor.
APT button: Press to modify the frequency response.
The degree of modification is set in the menu of the
monitor.
COMB button: Press to turn on the comb filter.
When the button is set to off, the trap·band-pass filter
is selected.
CHAR OFF button: Press to hide the characters from the
monitor during manual adjustment.
COL TEMP button: Press to display the Manual Adjust
menu of the color temperature on the monitor.
16:9 button: Press to change the aspect ratio to 16:9.
When the 2048 × 1080 signal is input, the aspect ratio
is set to 1.896:1. When the button is set to off, the
aspect ratio changes to 4:3 or 2.39:1.
NATIVE SCAN button: Press to display the picture in
native scan mode.
BLUE ONLY button: Press to cut red and green signals
and display only the blue signal as a monochrome
picture. This function is useful for adjusting chroma
and phase, and for checking signal noise.
R, G, B OFF button: Press to cut R (red), G (green), and
B (blue) respectively.
MARKER button: Press to display all markers on the
screen.
The marker display mode is set in the menu of the
monitor.
CHROMA UP button: Press to increase the chroma
setting by 12 dB.
eMenu operation buttons
fMONITOR I/1switch
Each time the switch is pressed, the monitor is turned on or
set in standby mode. When several monitors are connected
to the unit, it is possible to turn on the power of the
specified monitors only, or of all monitors at the same time
or to set in standby mode by setting with the monitor
selection button.
gNumeric keypad
Use to designate the channel number for the input signal to
be monitored, or to enter the setting values with the menus.
Channel number entry method
When selecting a one-digit number, press the button of the
channel number.
When selecting a two-digit number, first press the 0 button,
then press a two-digit channel number.
hMonitor selection buttons and lamps
When multiple monitors are connected by the network
connection, one particular monitor, monitor group or all
monitors are selected by setting the monitor ID number,
Group ID number or ALL.
Display mode of the display window is set in the menu of
the monitor.
UP MENU
DOWN ENTER
MENU button: Displays the monitor menu.
Press again to clear the menu in the main
menu. Each time the button is pressed in
other menu, the menu returns to the upper
level.
UP/DOWN buttons: Move the cursor
upward or downward. In setting mode, the
setting or adjustment value is increased by
pressing UP and decreased by pressing
DOWN.
ENTER button: Changes the item. In setting
mode, confirms the adjustment or setting
value. (Ent button on the numeric keypad
has the same function.)
INPUT
123
Del
4560
789
Ent
Del button: Deletes the entered
values and characters one by one.
Numeric buttons
Ent button: Changes the item. In
setting mode, confirms the
adjustment or setting value.
(ENTER button of the menu
operation buttons has the same
function.)
8Location and Function of Parts
iMANUAL adjustment buttons and knobs
Each time one of these buttons is pressed, the LED on the
button lights in green or turns off. When the corresponding
button is set to on (lit), it is possible to manually adjust the
contrast, brightness (black level), chroma (color saturation)
and phase by turning the corresponding knobs.
When the corresponding button is set to off, the picture
adjustment preset value set in the menu of the monitor is
applied.
It is possible to set the preset value for each knob in the
menu of the monitor.
The PHASE knob is also used to enter the setting values in
the menus of the monitor.
The button and knob may not function due to the input
signal. For the limitations with each type of signal, refer to
the manual of your monitor.
SINGLE
SINGLE
REMOTE
GROUP
ALL
GROUP ALL
SINGLE button: Selects
single connection mode.
The designated monitor is
connected remotely.
The monitor ID number is
displayed on all connected
monitors when the button is
held pressed.
GROUP button: Selects
group connection mode.
The monitor of the designated
group is connected remotely.
The group ID number is
displayed on all connected
monitors when the button is
held pressed.
ALL button: Selects all
connection mode.
All monitors are connected
remotely.
Lamps: The lamp
corresponding with the
pressed button flashes and
lights after recognizing the
monitor.
Display window: Displays the
selected ID number or ALL. The
display flashes until the remote
connection is completed. “---” is
displayed when the monitor and
controller are in 1 to 1 connection
(PEER TO PEER mode
connection).
PHASE CHROMA BRIGHT CONTRAST
MANUAL MANUAL MANUAL MANUAL
PHASE
button and
knob
CHROMA
button and
knob
BRIGHT
button and
knob
CONTRAST
button and
knob
Note
9
Location and Function of Parts
Rear Panel
aLAN (10/100) connector (10BASE-T/100BASE-TX)
Connect to the LAN (10/100) connector of the monitor by
using the SMF-700 or the cable supplied with the controller
attachment stand such as BKM-37H. Or connect to the
network or the LAN (10/100) connector of the monitor by
using a 10BASE-T/100BASE-TX LAN cable (shielded-
type, optional).
CAUTION
• For safety, do not connect the connector for peripheral
device wiring that might have excessive voltage to this
port. Follow the instructions for this port.
• When you connect the LAN cable of the unit to
peripheral device, use a shielded-type cable to prevent
malfunction due to radiation noise.
• To connect the unit to the LAN (10/100) connector of the
monitor in 1 to 1 connection (NETWORK switch is set
to PEER TO PEER), use a straight (shielded-type) cable.
• The connection speed may be affected by the network
system.
bDC 5V/12V IN connector (male)
Connect to the DC 5V OUT connector of the monitor by
using the SMF-700 or the cable supplied with the
controller attachment stand such as BKM-37H. Or connect
the output cable of the supplied AC adaptor.
cNETWORK switch
LAN: To connect to the network.
PEER TO PEER: To connect to the LAN (10/100)
connector of the monitor in 1 to 1 connection.
1LAN (10/100) connector
2DC 5V/12V IN connector
3NETWORK switch
10 Inserting/Ejecting the “Memory Stick”
Inserting/Ejecting the
“Memory Stick”
This product has a slot that can take both standard size and
Duo size. All products with a slot such as this are equipped
with a system which automatically measures the size of an
inserted medium. For this reason, both the standard-size
“Memory Stick”/“Memory Stick PRO” and smaller
“Memory Stick Duo”/“Memory Stick PRO Duo” can be
used with this product without a Memory Stick Duo
adaptor.
When an M2 adaptor is attached, you can use a “Memory
Stick Micro” (“M2”)1).
Proceed as illustrated to insert and eject an optional
“Memory Stick”.
See each menu of the monitor for information about
operations on “Memory Stick” data.
1) “M2” is an abbreviation for “Memory Stick Micro”.
Do not eject the “Memory Stick” while data is being saved
or loaded.
To insert the “Memory Stick”
• “Memory Stick Duo”/“Memory Stick PRO Duo” can be
used without a Memory Stick Duo adaptor.
• When you use a “Memory Stick Micro”, do so after
attaching the M2 adaptor (optional).
• When the “Memory Stick Micro” is inserted without the
M2 adaptor, the “Memory Stick Micro” may not be
removed from the unit.
• Be sure to insert the “Memory Stick” in the correct
direction. Forcing the “Memory Stick” in the wrong way
may damage it.
• Insert only the “Memory Stick” into the Memory Stick
insertion slot. Attempting to insert other objects into the
Memory Stick insertion slot may damage the product.
To eject the “Memory Stick”
Notes on “Memory Stick”
Available types of “Memory Stick”
• “Memory Stick”, “Memory Stick PRO”, “Memory Stick
Duo”, “Memory Stick PRO Duo” and “Memory Stick
Micro” are used for this model.
• The data displayed on this unit is not protected by the
MagicGate copyright protection technology because this
model is not compliant with the “MagicGate” standard.
• Although an operation check of this product has been
performed with a “Memory Stick” of up to 8 GB, please
note that operation is not guaranteed for every type of
“Memory Stick”.
Note on data read/write speed
Data read/write speed may vary depending on the
combination of the “Memory Stick” and “Memory Stick”
compliant product you use.
What is MagicGate?
MagicGate is copyright protection technology developed
by Sony Corporation.
Before using a “Memory Stick”/“Memory
Stick PRO”
Note
Notes
Memory Stick insertion slot
Insert the “Memory Stick” facing
the arrow mark upward.
1Confirm that the access lamp does
not flash.
2Press the “Memory Stick”,
and it is ejected.
Write-protect tab
labeling position
Terminal
Rear Front
11
Inserting/Ejecting the “Memory Stick”
Before using a “Memory Stick Duo”/
“Memory Stick PRO Duo”
Before using a “Memory Stick Micro”
Attach the M2 adaptor to the “Memory Stick Micro” to
insert into the slot of the unit.
• You cannot record or erase data when the write-protect
tab on the “Memory Stick” is set to LOCK.
• Image data may be damaged in the following cases:
– If you remove the “Memory Stick,” or turn the power
off when the access lamp is lit or flashing
– If you use a “Memory Stick” near static electricity or
a magnetic field
• When writing in the memory area, do not put strong
pressure on the pen.
• We recommend backing up important data.
• Do not attach anything other than the supplied label to
the “Memory Stick” labeling position.
• Attach the label so that it does not stick out beyond the
labeling position.
• Carry and store the “Memory Stick” in its case.
• Do not touch the connector of the “Memory Stick” with
anything, including your finger or metallic objects.
• Do not strike, bend, or drop the “Memory Stick.”
• Do not disassemble or modify the “Memory Stick.”
• Do not allow the “Memory Stick” to get wet.
• Do not use or store the “Memory Stick” in a location that
is:
– Extremely hot, such as in a car parked in the sun
– Under direct sunlight
– Very humid or subject to corrosive substances
• Do not insert multiple “Memory Stick” cards at the same
time. This may cause damage to the product.
• When you use “Memory Stick Duo”/“Memory Stick
PRO Duo” with this product, be sure to insert it in the
right direction. Inserting it in the wrong direction may
cause damages to the product.
• “Memory Stick Duo”/“Memory Stick PRO Duo”/
“Memory Stick Micro” and M2 adaptor should be kept
away from small children to prevent them from
accidentally swallowing it.
• If the “Memory Stick Micro” attached to the M2 adaptor
is attached to the Memory Stick Duo adaptor and inserted
in the slot, the “Memory Stick Micro” may not function.
• Use the machine and application corresponding to the
“Memory Stick” for initialization of the “Memory
Stick”. When Windows Explorer is used for
initialization, a format error is caused and the “Memory
Stick” is not usable for the monitor.
• When the data in the folder for the application software
is copied or edited with the function of Windows, the
data may not be reproduced.
Windows is a registered trademark of Microsoft
Corporation in the United States and/or other countries.
Notes
Terminal
Write-protect tab
Use an object with
a pointed end to
set the switch.
Rear Front
“Memory Stick”, “Memory Stick PRO”, “Memory Stick
Duo”, “Memory Stick PRO Duo”, “Memory Stick
Micro”, “M2” and are trademarks or registered
trademarks of Sony Corporation.
It is against the copyright law to use any audio or picture
you recorded without prior consent of the copyright
holder. Accordingly, “Memory Stick” with content
protected image or data can be only used within the law.
12 Mounting the Unit in a Rack / Connections
Mounting the Unit in a
Rack
To mount the unit in an EIA standard 19-inch rack, use the
supplied rack mount brackets and screws.
1
Remove the five feet from the bottom of the unit.
2
Attach the rack mount brackets to each side of the unit
with the rack mount attachment screws.
3
Screw the rack mount brackets to the rack to mount the
unit. (Use the commercially available screws that
match the size of the rack’s holes.)
Connections
The illustrations of the monitor used in this manual are
BVM-E250.
Note on connecting the cable to the DC 5V/12V
IN connector
Be sure to plug the female connector of the cable into the
DC 5V/12V IN connector on the unit.
Connect the connector to the shape of the DC 5V/12V IN
connector.
Connecting the Monitor
Rack mount bracket
BKM-16R (this unit)
Rack mount attachment screws
Rack
Plug the female
connector.
BKM-16R
(this unit)
LAN (10/100) connector
DC 5V OUT
connector
DC 5V/12V IN
connector
LAN (10/100)
connector
SMF-700, etc.
Monitor
NETWORK switch
tSet to PEER TO
PEER.
NETWORK switch
tSet to PEER TO PEER.
13
Connections
1
Turn off the MAIN POWER switch of the monitor
before connecting the units.
2
Set the NETWORK switch of the monitor and the unit
to PEER TO PEER.
3
Connect the LAN (10/100) connector of the monitor
and the LAN (10/100) connector of the unit by using
the SMF-700 or the cable supplied with the controller
attachment stand such as BKM-37H, or a 10BASE-T/
100BASE-TX straight LAN cable (shielded-type,
optional).
When an optional LAN cable is connected, use a
shielded-type cable to prevent a malfunction due to
noises.
4
Connect the DC 5V OUT connector of the monitor and
the DC 5V/12V IN connector of the unit by using the
SMF-700 or the cable supplied with the controller
attachment stand such as BKM-37H.
Or connect the output cable of the AC adaptor supplied
with the unit to the DC 5V/12V IN connector of the
unit.
Connecting the Multiple Units with
the LAN
The unit controls up to 32 monitors. Up to four units are
connected to one monitor in single mode.
The unit cannot control monitors in another subnetwork.
1
Turn off the MAIN POWER switch of the monitor
before connecting the units.
2
Connect to the network by using a 10BASE-T/
100BASE-TX cable (shielded-type, optional).
• When an optional LAN cable is connected, use a
shielded-type cable to prevent a malfunction due to
noises.
• We recommend to use an optional switching hub
with auto selection function (AUTO MDI/MDI-X)
of a straight/cross cable.
When the switching hub without auto selection
function is used, connect the monitor and switching
hub with the straight cable, and the unit and
switching hub with the cross cable.
Note
Note
Notes
BKM-16R
(this unit)
Monitor
LAN (10/100)
connector
DC 5V/12V IN
connector
LAN (10/100)
connector
Switching hub
(recommended: with
AUTO MDI/MDI-X
function)
Monitor
LAN (10/100)
connector
AC adaptor (supplied
with this unit)
NETWORK switch
tSet to LAN.
NETWORK switch
tSet to LAN.
14 Specifications
3
Connect the output cable on the AC adaptor supplied
with the unit to the DC 5V/12V IN connector of the
unit.
When the multiple units are connected, set for the LAN
in the menu of the monitor before setting the
NETWORK switch to LAN.
4
Set the NETWORK switches of each monitor and the
unit to LAN.
For connection, also refer to the manual of the connected
monitor.
Specifications
Input/Output
LAN (10BASE-T/100BASE-TX) connector
RJ-45 × 1
DC 5V/12V IN Circle 4-pin (male) × 1
General
Power requirements
BKM-16R
DC IN: 5 V, 1.1 A (supplied by the
connected monitor)
DC IN: 12 V, 0.5 A (supplied by the
connected AC adaptor)
AC adaptor (MPA-AC2)
AC IN: 100 - 240 V, 50 - 60 Hz
DC OUT: 12 V, 3 A
Current consumption
5 V DC, 1.1 A/12 V DC, 0.5 A
Power consumption
Approx. 6 W
Peak inrush current
(1) Power ON, current probe method:
20 A (100 V), 60 A (240 V)
(2) Hot switching inrush current,
measured in accordance with
European standard EN55103-1:
10 A (230 V)
Operating temperature
0 °C to 35 °C (32 °F to 95 °F)
Recommended: 20 °C to 30 °C (68 °F to
86 °F)
Operating humidity
0% to 90% (no condensation)
Storage/transport temperature
– 10°C to + 40°C (14°F to 104°F)
Storage/transport humidity
0% to 90%
Operating/storage/transport pressure
700 hPa to 1060 hPa
Mass Approx. 2.1 kg (4 lb 10 oz)
Supplied accessories
AC adaptor (MPA-AC2) (1)
AC power cord (1)
Rack mount brackets (2)
Rack mount attachment screws (4)
Function labels (2)
Operation Manual (1)
CD-ROM (1)
Using the CD-ROM Manual (1)
Design and specifications are subject to change without
notice.
Note
Note
15
Dimensions
Dimensions
Unit: mm (inches)
Front
Top
Side
1) When using this hole, use a screw which can be inserted into the unit to
a depth of 6 to 9 mm (1/4to 3/8inches).
Notes
• Always make a test recording, and verify that it was
recorded successfully.
SONY WILL NOT BE LIABLE FOR DAMAGES
OF ANY KIND INCLUDING, BUT NOT
LIMITED TO, COMPENSATION OR
REIMBURSEMENT ON ACCOUNT OF
FAILURE OF THIS UNIT OR ITS RECORDING
MEDIA, EXTERNAL STORAGE SYSTEMS OR
ANY OTHER MEDIA OR STORAGE SYSTEMS
TO RECORD CONTENT OF ANY TYPE.
• Always verify that the unit is operating properly
before use. SONY WILL NOT BE LIABLE FOR
DAMAGES OF ANY KIND INCLUDING, BUT
NOT LIMITED TO, COMPENSATION OR
REIMBURSEMENT ON ACCOUNT OF THE
LOSS OF PRESENT OR PROSPECTIVE
PROFITS DUE TO FAILURE OF THIS UNIT,
EITHER DURING THE WARRANTY PERIOD
OR AFTER EXPIRATION OF THE
WARRANTY, OR FOR ANY OTHER REASON
WHATSOEVER.
424
(16 3/4)44
(1 3/4)
14.8
(19/32)
156.5
(6
1
/
4
)
93.5
(3
3
/
4
)
6
(
1
/
4
)
37
(1
1
/
2
)
368
(14
1
/
2
)
5.3
(
7
/
32
)
13.1
(
17
/
32
)
4-M4
1)
34.5
(1
3
/
8
)
22
(
7
/
8
)
51.5
(2
1
/
8
)
90
(3
5
/
8
)
18
(
23
/
32
)
The material contained in this manual consists of information
that is the property of Sony Corporation and is intended solely
for use by the purchasers of the equipment described in this
manual.
Sony Corporation expressly prohibits the duplication of any
portion of this manual or the use thereof for any purpose other
than the operation or maintenance of the equipment
described in this manual without the express written
permission of Sony Corporation.
Sony Corporation
BKM-16R (WW)
3-213-868-14(1) © 2008
Table of contents
Other Sony Control Unit manuals
