SORG Airon 792 User manual

Instructions for use Airon
Instructions for use Airon 1 of 36
2021-06-10 Besondere Menschen, besondere Lösungen.
de
Unique people, unique solutions.
AironAiron
Instructions for use Airon
Instructions for useInstructions for use
EN

2 of 36 Instructions for use Airon 2021-06-10
Impressum
SORG Rollstuhltechnik GmbH + Co. KG
Benzstraße 3-5
68794 Oberhausen-Rheinhausen / Germany
Fon [phone]
Fax [phone]
Mail [email protected]
Web www.sorgrollstuhltechnik.de
Revision status
2021-08-24
Technical status
We reserve the right to make technical chan-
ges and misprints. The images can dier from
the actual individual equipment components.
The handling is to be carried out accordingly.
Gender notice
For better readability, we use the grammati-
cal gender or the male form of the German
language, which is to be understood indepen-
dently of the biological gender. All (person)
designations apply equally to all genders and
do not represent any valuation.
Copyright
All content, especially texts, photographs and
graphics, are protected by copyright. All rights,
including copying, publishing, editing and
translating, are reserved. © by SORG Rollstuhl-
technik GmbH+Co. KG Benzstraße 3-5, 68794
Oberhausen-Rheinhausen / Germany.
You can nd our general terms and con-
ditions on our order order forms and at www.
sorgrollstuhltechnik.de/impressum.

Instructions for use Airon
Instructions for use Airon 3 of 36
2021-06-10
1 Overview of the wheelchair 4
2 General information 5
2.1 Preamble 5
2.2 General information Instructions for use 5
2.2.1 Explanation of symbols 6
2.2.2 Intended use 7
2.2.3 Indication 7
2.2.4 Contraindication 7
2.3 General safety information 8
2.3.1 Loading and transport without occupants 10
2.3.2 Transporting the wheelchair with
occupants in the motor vehicle 10
2.3.3 Other important information 12
3 Handling 14
3.1 Handling drive wheels 14
3.1.1 General information on wheels 14
3.1.2 Tire pressure 14
3.1.3 Thru-axle wheels 14
3.1.4 Double handrim wheels 15
3.2 Handling seat and back unit 16
3.2.1 General information back unit 16
3.2.2 Back with grid 16
3.2.3 Back extension 18
3.3 Handling side panels 19
3.3.1 General information on side panels 19
3.4 Handling pushing aids 20
3.4.1 General information pushing aids 20
3.4.2 Push handles 21
3.5 Handling legrest 22
3.5.1 General information on legrests 22
3.5.2 Fold-up footplate with lock 22
3.6 Handling brake 23
3.6.1 General information about the brake 23
3.6.2 Parking brake 23
3.6.3 Drum brake 25
3.6.4 Compact brake 26
3.7 Handling anti-tipper 27
3.7.1 General information on anti-tipper
protection 27
3.8 Handling headrest 28
3.8.1 General information headrest 28
3.9 Handling of lateral support 29
3.9.1 General information on lateral sup-
ports 29
4Repairs / maintenance / re-use 30
4.1 Repairs 30
4.2 Spare parts 30
4.3 Cleaning 30
4.4 Disinfection 30
4.5 Storage 30
4.6 Lifespan 31
4.7 Reuse 31
4.8 Disposal 31
4.9 Maintenance / inspection 31
5 Technical specications 33
5.1 Data and measurements 33
5.2 Meaning of the labels 34
5.3 Declaration of Conformity 34
6Proof of annual inspection 35
Table of Contents

4 of 36 Instructions for use Airon 2021-06-10
1 Overview of the wheelchair
1 push handles
2 back unit with pillow
3 clothes guards
4 side panel
5 seat cushion
6 protective pads
7 utensil pocket
8 frame
9 caster wheel fork
10 caster wheel
11 footplate (continuous)
12 drive wheel
13 handrim
14 thru axle
15 compact brake
9
10
12
13
14
1 2
34
5
15
8
11
6
Overview Airon
7

Instructions for use Airon
Instructions for use Airon 5 of 36
2021-06-10
2 General information
2.2 General information Instructions for use
These instructions for use contain safety and handling instructions that are required for correct
use of the product.
Your wheelchair will be delivered according to the conguration requested by the specialist re-
tailer. Please check with your specialist retailer that your wheelchair is fully functional before you
use it for the rst time.
All settings, adjustments, repairs and the annual inspection that go beyond these operating inst-
ructions must be carried out by a qualied specialist retailer.
Our service booklet can be called up for further information at www.sorgrollstuhltechnik.de.
The user and specialist dealer must have read and understood these instructions prior to com-
missioning. These instructions for use contain all equipment variants of the product. Let your
specialist advisor instruct you on level ground and with the support of an attendant in the safe
handling of the wheelchair and your individual equipment variants .
Visually impaired people can nd these operating instructions as PDF and audio les on our
website www.sorgrollstuhltechnik.de.
If you have any questions or comments, please contact your specialist dealer or our team (+49
7254 9279-0).
Please keep these instructions for use in a safe place. All annual inspections carried out must be
documented by the specialist retailer.
2.1 Preamble
Welcome to the SORG family - thank you very much for the trust you have placed in us and for
choosing our product.
This wheelchair has been individually made to measure for your unique needs.
In order to be able to use the wheelchair in everyday life, you will receive the fol-
lowing instructions for use and adjustment, which you can use without tools. Please follow these
instructions and handle the wheelchair carefully so that you can enjoy it for as long as possible.
If you have any questions about this or any other product, please do not hesitate to contact us.
We hope you enjoy your SORG product.
Your SORG team

6 of 36 Instructions for use Airon 2021-06-10
2 General information
WARNING! Warnings for perso-
nal safety issues, of the utmost
importance
CORRECT safety-relevant setting
/ handling
WRONG Adjustment / handling
PROHIBITED
Reference to additional / further
reading.
Set or adjust the angle
Open / close
Turn clockwise
Turn counterclockwise
Steps to be performed at the
same time
Steps to be performed in se-
quence
Steps to be performed on both
sides
Handling
(A); (B)
1. 1.
1. 2.
;
2x2x
Push / pull / insert / move / re-
move
Push in a certain direction
Important detail / element
Correct or proper setting / use
Inadmissible or incorrect setting
/ use
Reference from text to detail
Perspective
View from above
Side view
Viewing angle from below
Front view
Rear view
Attach part
Remove part
2.2.1 Explanation of symbols

Instructions for use Airon
Instructions for use Airon 7 of 36
2021-06-10
2 General information
8
km/h
The wheelchair is only used to transport the person for whom it has been adapted by a qualied
specialist dealer.
In the case of children or persons with impaired ability to act, the parents or authorized caregi-
vers must ensure that the information in the instructions for use is followed.
The largely safe use of the aid is only possible on level, rm and dry ground with the anti-tip
activated with the help of an attendant.
Any use going beyond this harbors a variety of dangers that can only be assumed at the
user's own responsibility. This presupposes sucient competence in recognizing and avoiding
hazards and the safe handling of the aid by the user as necessary! Particular attention must be
paid to the increased risk potential in wet conditions, ice, loose ground, slopes, obstacles, pro-
ximity to water, road trac, too narrow spaces, etc.
Only use the wheelchair for its intended purpose. Any improper use harbors considera-
ble dangers and leads to the expiry of product liability.
Due to the large variety of combinations for seat and wheel position, settings may be
possible that are related to the safety and application area.
2.2.3 Indication
2.2.4 Contraindication
The use is suitable, among other things, with the following functional impairments:
• In the case of abolished or severely restricted usability of the lower extremities.
• In the case of non-compensable, signicant reduction in the performance of the heart
and lungs.
• Balance disorders.
• Ataxias.
• Partial or complete inability to walk (e.g. due to illnesses; accidents, paralysis or amputa-
tions, damage to the brain or also due to congenital deformities).
The wheelchair must not be used for:
• Inability to sit.
The wheelchair may only be used with an accompanying person if:
• Insucient or no vision.
We assume no liability for damage to persons or objects under the circumstances
described above..
2.2.2 Intended use
Airon is a light, manoeuvrable active wheelchair for indoor and outdoor use.

8 of 36 Instructions for use Airon 2021-06-10
2 General information
-10 to + 41°C
30 - 70%
x y
Do not use the footplate to get in and
out. The wheelchair could tip forward.
x >700 mm
y > x + 50 mm
!
Before every journey, check:
• Frame, back tubes, add-on parts and accessories for visible damage, bends, cracks or
missing / loose screws,
• Wheels / thru axles on tight t,
• sucient tire pressure, tire prole,
• Functionality of the brakes,
• tight t of the angle adjustment elements / eccentric clamps,
• rm closure of the seat plate / back / foot plate,
• Functionality of the anti-tipper / seat and back straps,
• whether all previously dismantled parts are rmly plugged in and locked again.
Entry and exit may only be carried out with the parking brake and anti-tipper activated.
When dismantling the parts / accessories listed below, the risks listed as examples may
arise:
• Pillows: poor hygiene / pressure points
• Headrest: Missing headrest or loss during transport
• Drive wheels: loss of back (use of wheelchair not possible)
• Fixed back extension: loss or missing headrest during transport
• Leg supports: Loss or lack of positioning of the legs
There is a risk of injuries (e.g. crushing) on all rotating, rotatable or foldable parts, also
during adjustment and repair work as well as during transport.
2.3 General safety information
Risk of tipping over and rollover

Instructions for use Airon
Instructions for use Airon 9 of 36
2021-06-10
2 General information
max 7°
90°
Conquer stairs only with the help of experienced helpers. To do this, the anti-tipper must
be deactivated. Always carry the wheelchair by the frame, never by the seat shell, the pull-out
push handles / push bar, the legrest and / or the footplate (s)!
90°
90°
max 7°/ 12% max 7°/ 12%
We generally recommend using the anti-
tipper device.
Inclines, slopes and obstacles
The anti-tipper must be deactivated
when driving down on edges.

10 of 36 Instructions for use Airon 2021-06-10
2 General information
Make the desired pack size and secure the wheelchair and all dismantled parts with adequate
load securing. Basically, the wheelchair is suitable for transport (land / air). Find out about suita-
ble load securing measures before transporting the wheelchair.
Carrying points:
• Stabilizing bar with the back folded down
• Frame cross members at the front and rear
• front frame tubes left / right
• but not on the footplates.
2.3.1 Loading and transport without occupants
2.3.2 Transport of the wheelchair with occupants in the vehicle
Due to their purpose, wheelchairs can never achieve the stable properties of a seat sys-
tem that is permanently mounted in the vehicle. Whenever possible, we recommend using a
xed vehicle seat to transport a person in the vehicle.
Only wheelchairs that have successfully passed a crash test according to ISO
7176-19 may be used as a seat in a motor vehicle. Successfully tested wheelchairs
are marked with the symbol for the attachment point on the attached label.
The Airon has been successfully tested according to ISO 7176-19 and is
therefore approved as a seat in a motor vehicle if you have the necessary
restraint devices.
Please check whether your wheelchair is custom-made and therefore may not
be used as a seat in a motor vehicle. In this case the symbol for the fastening point
is missing from the rating plate and the wheelchair is provided with a warning,
represented by the negated symbol for the fastening point.
Further information can be found in the crash test brochure at www.sorgrollstuhltechnik.de/
downloadportal.
We can recommend the following manufacturers of restraint systems:
• SORG-Retaining eyelets on the wheelchair
• AMF-BRUNS GmbH & Co.KG
• Q‘Straint Europe
How to remove and re-attach the drive wheels can be seen in chapter 3.1.3.
How to fold the back can be found in chapter 3.2.

Instructions for use Airon
Instructions for use Airon 11 of 36
2021-06-10
2 General information
(2)
(1)
90°
(B)
(A)
(3)
(4)
(D)
(C)
(2)
(1)
When using the wheelchair as a seat in the motor vehicle, only use the places
marked with the symbol for the attachment point. These are usually located in the
back left and right (1) and front left and right. (2)
Attachment points / methods for transportation in motor vehicles
The wheelchair must be attached using a
vehicle-anchored 4-point wheelchair restraint
system in accordance with ISO 10542. These
can be snap hooks, S-shaped hooks or snap
fasteners. The wheelchair restraint system
must be securely attached and used in ac-
cordance with the manufacturer's instructions
for use. (3A+B)
In order to reduce the risk of head and
upper body injuries as much as possible,
the user must also be secured with a xed
lap belt (4C) approved for transport in ac-
cordance with ISO 10542 and a vehicle-an-
chored shoulder belt (4D).
If the wheelchair is equipped with a back angle adjustment or seat tilt, it must be ensured
that the occupant sits in an upright position with a back angle of 90 ° during transport (3).
Legrests that can be swiveled up must be set to the lowest position.
The seat belts must not be twisted during use or passed over components and thus kept
away from the body. They have to be tight and tight without compromising user comfort. The
lap belt buckle must be between the pelvic bones (as centrally as possible). The buckle tongues
on the lap belt for fastening the shoulder belt should be on the outside of the pelvis, if possible.
All belts used for transport must be checked for damage at regular intervals.
A headrest approved for transport must be used.
According to ISO 7176-19, the wheelchair may only be used as a forward-facing seat in
motor vehicles. No transport with side orientation!
After a collision, immediately contact your specialist retailer to check the chassis, frame
and brakes and have any damage repaired by a professional.

12 of 36 Instructions for use Airon 2021-06-10
2 General information
> 42°C
°C
In addition, actuate the existing braking devices on the wheelchair to transport the
wheelchair in the vehicle.
The wheelchair must not be exposed to excessive moisture or come into contact with salt
water.
The standard-compliant resistance to ignition in textile materials has been tested and en-
sured. Nevertheless, there is a risk of ignition of the ame-retardant textile components. Keep
sources of ignition away from the wheelchair.
2.3.3 Other important information
Pelvic safety devices (pelvic belts as a positioning aid) are optionally available for wheelchair
conguration via the SORG order forms or by ordering using spare parts catalogs. Installation is
carried out by your specialist retailer.
Assembled seat cushions are equipped with an anti-slip fabric on the underside.
Seat molded parts are secured against slipping by means of a Velcro connection in combination
with the seat cover or seat plate.
In individual cases it can happen that the product interacts with electromagnetic elds (e.g. theft
protection of shops). This poses no danger for the user and / or the companion.
Due to the wide range of setting options, not all limit values can be complied with for all pos-
sible congurations in accordance with the Regulation (EU) on the technical specications for
interoperability with regard to the accessibility of the Union's rail system for people with disabi-
lities and people with reduced mobility.
In the event of incidents with the wheelchair, please contact your specialist retailer or us as the
manufacturer. Product recalls etc. are published on our website www.sorgrollstuhltechnik.de.
There you will also nd the respective contact person.
Corrosion protection
The product is already designed for corrosion protection when the materials are selected (e.g.
plastic, aluminum, stainless steel). All materials at risk of corrosion are surface treated and thus
protected.
The wheelchair must be dried thoroughly if it gets wet.
Aluminum components: frame, caster wheel forks, back, legrest, seat support, handrims
Steel components: back angle adjustment
Stainless steel components: handrims

Instructions for use Airon
Instructions for use Airon 13 of 36
2021-06-10
2 General information
Lifespan
Use beyond the specied service life leads to an increase in the residual risks and should
only be carried out after careful, qualied consideration by the operator. If the service life is
reached, the user or a responsible person should contact the specialist retailer. There you can
get information about the possibility of processing the product.
Combination with products from other manufacturers
The wheelchair may only be combined with the additional electrical drives approved by the
manufacturer. Restrictions or adjustments as well as the cultivation itself are incumbent on the
provider of the additional system or the authorized specialist trade. Please ask the manufactu-
rer of the additional drives for the requirements.
In the combination of a wheelchair and an additional electric drive, particular loads occur
which can lead to damage to the wheelchair. Approach obstacles slowly and overcome them
carefully so that little force is exerted on the caster wheel, drive wheel and the wheelchair as a
whole.

14 of 36 Instructions for use Airon 2021-06-10
After each insertion, pull at least once to test whether the quick-release axle is engaged. It
must no longer be possible to pull the wheels outwards.
3.1 Handling drive wheels
(1) (2)
(2)
(A)
1. 1.
(1)
(1)
The braking of the wheels on the handrims creates frictional heat.
3.1.2 Tire pressure
3.1.1 General information on wheels
Handrim covers can stretch in the heat and detach from the handrim.
3.1.3 Thru-axle wheels
Remove:
Insert:
You can nd the appropriate operating pres-
sure on
the tire casing - usually 3-10 bar. (1)
If you have a at tire, please contact your
specialist retailer.

Instructions for use Airon
Instructions for use Airon 15 of 36
2021-06-10
3.1 Handling drive wheels
(4)
(3a)
90°
1.
2.
(1)
(3b)
(1) (2b)
(2a)
(2)
2x2x
2x2x
2x2x
3.1.4 Double handrim wheels
Insert:
Remove: Proceed in reverse order

16 of 36 Instructions for use Airon 2021-06-10
3.2 Handling seat and back unit
3.2.1 General information back unit
Check that the back is rmly seated after every change.
With an angle-adjustable backrest from a setting of> 90 °, it is essential to activate the anti-
tipper. The head must be supported during the back angle adjustment (e.g. by a headrest).
Activate the angle adjustment only with activated brakes.
(3a)
Adjust:
(3b)
1.
2.
3.2.2 Back with grid
Always activate the anti-tipper before using a new back angle position.
(1) (2)

Instructions for use Airon
Instructions for use Airon 17 of 36
2021-06-10
3.2 Handling seat and back unit
(2)
(1)
1.
2.
Folding down (raise: proceed in reverse order):

18 of 36 Instructions for use Airon 2021-06-10
3.2 Handling seat and back unit
(1) (2)
(3) (4)
3.2.3 Back extension
Pulling out (lower: Proceed in the reverse order)):
The retractable back extension is not suitable as a headrest in a motor vehicle!

Instructions for use Airon
Instructions for use Airon 19 of 36
2021-06-10
3.3 Handling side panels
3.3.1 General information on side panels
Remove plug-in side panels:
(1) (2)
2x2x
Attaching the plug-in side panels: Proceed in the reverse order:
(2)
(1)

20 of 36 Instructions for use Airon 2021-06-10
3.4 Handling pushing aids
(1) (2a) (2b)
Increase elasticity Reduce tension
(4a) (4b)
(3)
3.4.1 General information pushing aids
All height-adjustable pushing aids are intended exclusively for pushing the occupant in
his wheelchair - not to carry.
Children cannot assess the swivel range of protruding pushing aids and can injure others
while playing. It is advisable to fold in or dismantle the pushing aids for such purposes.
Before each use of the pushing aids, check the tight lock and the functionality of the
eccentric clamps. It must not be possible to move the pushing aids in the retainer when the
eccentric clamp (s) are in the closed position.
Adjusting the eccentric clamp:
