Target DSMFDESKES User manual

© 2019 Target. The Bullseye Design is a trademark of Target Brands, Inc. All rights reserved.
>>
console
desk
assembly instructions
style # DSMFDESKES (espresso)
dpci # 249-14-0045
tcin # 13864635
style # DSMFDESKWH (white)
dpci # 249-14-4544
tcin # 52701885
style # DSMFDESKBR (rustic)
dpci # 249-14-4545
tcin # 52701892

2
Congratulations on your latest Target purchase.
Now what? Don’t start sweating over this box of parts. This will be easy. We did the hard work for you.
All you need to do is follow our simple instructions and you’ll be on your way to transforming your
room in no time. Good luck—though we’re condent you won’t need it.
before you begin
1. Check for damaged or missing parts. Call 1-855-MYTGTHOME (855-698-4846) to order missing supplies.
2. Use the carton as a working surface to prevent product damage during assembly.
3. Read through and review assembly steps.
4. Gather all tools prior to assembly.
tools needed

3
table of contents
introduction 2
hardware 4
parts list 5
assembly 6-9
QUESTIONS? Just call 1-855-MYTGTHOME (855-698-4846) for parts and service. For faster service, have the style number and dpci number ready when calling.

4
hardware
(H1) x 14
short bolt
(H2) x 2
long bolt
(H3) x 16
lock washer
(H4) x 16
washer
(H5) x 1
allen wrench
(H6) x 2
wooden dowel
(H7) x 1
38mm at head screw
(H8) x 1
15mm truss head screw
(H9) x 1
wall anchor
(H10) x 1
wall strap
(H11) x 2
5/8” washer

5
exploded diagram
ITEM DESCRIPTION QUANTITY
A rear center leg 1
B front center leg 1
C side leg 2
D shelf assembly 2
E top panel 1
F side assembly 1

6
step 1: attach rear and front center legs to shelf assemblies
(H1) x 4
short bolt
(H3) x 4
lock washer
(H4) x 4
washer
(H5) x 1
allen wrench
1.1. Do not over tighten bolts.

7
step 2: attach side legs
(H1) x 4
short bolt
(H3) x 4
lock washer
(H4) x 4
washer
2.1. Do not over tighten bolts.

step 3: attach side assembly and top panel
(H1) x 6
short bolt
(H2) x 2
long bolt
(H3) x 8
lock washer
(H4) x 8
washer
(H6) x 2
wooden dowel
3.1. Carefully tap small wooden dowels into place. Leave 1/2” of the dowels sticking out.
3.2. Do not over tighten bolts.
8
Carefully tap small wooden dowels into place. Leave 1/2” of the dowels sticking out.

step 4: install anti-tip kit
(H7) x 1
38mm at head
screw
(H8) x 1
15mm truss
head screw
(H9) x 1
wall anchor
(H10) x 1
wall strap
(H11) x 2
5/8” washer
Position against wall
Mark position of strap hole on wall
Drill 1/4” hole
Tap in wall anchor
Fasten anti-tip strap with wall screw
provided
9
(H7)
(H9)
(H11)
(H11)
(H8)
(H10)
Mark position of strap hole on wall
Fasten anti-tip strap with wall screw
provided

WARNING
Serious or fatal crushing injuries can occur
from furniture tip-over. To help prevent
tip-over:
• Install tip-over restraint provided.
• Place heaviest items in the lowest drawers.
• Do not set TV's or other heavy objects
on top
of this product, unless the product is
specifically designed
to accommodate them.
• Never allow children to climb or hang
on drawers,
doors, or shelves.
• Never open more than one drawer at a time.
(OR)
• Do not defeat or remove the drawer interlock
system.
Use of tip-over restraints may only reduce,
but not eliminate, the risk of tip-over.
This is a permanent label. Do not remove.
1. This unit has been designed for the weight shown. Exceeding this recommended weight could result in
excessive “sagging” of the top. Extreme overloading can cause failure of the top and possible injury.
2. Furniture Care Instructions: Dust with a clean, lint-free cloth. Use a spray furniture polish as needed.
10
75 lbs.
25 lbs.
25 lbs.
QUESTIONS? Just call 1-855-MYTGTHOME (855-698-4846) for parts and service. For faster service, have the style number and DPCI number ready when calling.
