TCS IVX9001-0140 User manual

Product information
Video indoor station
IVX9001-0140

2
Table of contents
Scope of delivery...................................................................................3
Safety instructions................................................................................3
Installation –protective measures.........................................................3
Device overview.....................................................................................4
Indication and operating elements.......................................................5
Intended use..........................................................................................6
Short description...................................................................................6
Mounting and installation .....................................................................7
Install the lower cover...........................................................................7
Installation height...............................................................................7
Installation on flush-mounted socket..................................................7
Set indoor station as end device...........................................................8
Snap-on the upper cover ......................................................................8
Open the device....................................................................................9
5-wire special operation........................................................................9
Commissioning......................................................................................9
Settings................................................................................................10
AS address-dependent image activateion...........................................10
Pre-settings ex works..........................................................................10
Configuration options..........................................................................11
Settings via OSD menus.....................................................................12
Operation .............................................................................................16
Sending a call.....................................................................................18
Switching lights and send control functions......................................21
Automatic function............................................................................21
Setup Intercom.................................................................................22
General information on the conduit in TCS video systems..............23
6-wire operation..................................................................................23
Max. number of IVX9001-0140 in 6-wire operation.............................24
Technical data .....................................................................................25
FAQ.......................................................................................................26
Cleaning...............................................................................................28
Information on disposal......................................................................29
Warranty...............................................................................................29
Service .................................................................................................30

3
Scope of delivery
1 x Video indoor station IVX9001-0140
Product information
User manual
Safety instructions
!
Attention! Mounting, installation, commissioning and repair of
electronic devices have to be carried out only by qualified elec-
tricians. Thus, the standards and instructions for the installation
of systems have to be observed.
For working on systems with main connection of 230 V alternating volt-
age, the safety requirements according to DIN VDE 0100 must be ob-
served.
When installing TCS:BUS systems, the general safety regulations for
telecommunication systems according to VDE 0800 must be observed.
Inter alia:
separated conduit of heavy current and low current lines,
minimum distance of 10 cm in case of a common conduit,
use of separators between heavy and low current lines within shared
cable ducts,
use of standard communication, e.g. J-Y (St) Y with 0.8 mm diameter,
existing lines (modernisation) with deviating cross-sections can be
used in compliance with the loop resistance.
Installation –protective measures
!
With suitable measures to protect against lightning, it has to be en-
sured that a voltage of each 32 V DC is not to be exceeded at the
connections a, b, P, M.

4
Device overview
Menu button
Loudspeaker
Microphone
Image button
Call OFF
button
Function key
Screen
LED red
Door release
button
Speech button
(sensor button)
LED green
Sensor buttons

5
Indication and operating elements
Description
Function
Screen
display of the video image
menu display, OSD
LED red
is ON: call OFF is activated (ring tone mute)
blinks: indication busy voice channel
LED green
is ON: when a voice connection is established,
when call diversion and door release automatic
are activated
Call OFF
button
ring tone mute (if no voice connection is estab-
lished)
end speaking
back in stand-by mode
Menu button
open the main menu
close the main menu
back to the previous menu
Image button
activate image
switch image between different cameras (if
available)
switch OFF the image
upwards in the OSD menu
change parameter in the OSD menu
Function key
send control function 8
for calling the central, if the IVX9001-0140 is
configured for systems with central
dwonwards in the OSD menu
change parameter in the OSD menu
Door release
button
door release during a voice connection
for calling the central, if the IVX9001-0140 is
configured for systems with central
Speech button
accept a call (door call or internal call), speaking
is activated
end speaking
confirm parameter selection, store

6
Intended use
The video indoor station IVX9001-0140 is a video indoor station with
color display for hands-free talking.
The IVX9001-0140 is suitable for the operation in building communica-
tion systems with combined audio / video systems.
The operation is realised via the sensor buttons and the On-Screen-
Display (OSD).
The video indoor station IVX9001-0140 is suitable for surface-mount.
!
The video indoor station is to be installed preferably on a wall outlet
one gang box or a flush-mount socket, as the space for cabling is
limited within the device.
Short description
hands-free talking
13 ring tones, can be programmed by a qualified electrician
door release button
function key
ring tone mute with optical indication LED red
audio and video privacy function as well as an automatic call cut-off
optical signaling of door and internal calls by a green LED
optical indication of door stand-by time, on-service call by a green LED
optical indication when activating door release automatic or call diver-
sion by a green LED
acoustic ring tone distiction in case of two different door calls (door call
AS border ≥0), floor calls and internal calls
adjustable functions in the OSD menu: AS-address, image switch time,
length of call, OSD information, language, microphone sensitivity, con-
versation volume, ring tone volume, color saturation, brightness and
contrast of the video image
send control functions 8 (function key)
button tone can be deactivated
floor video image activation can be realised with an additional FBAS
video input for another camera on terminal C
optional: floor push button can be connected

7
Mounting and installation
Install the lower cover
!
Attention! The video indoor stations have to (de-)installed only volt-
age-free!
!
Ensure not to over-tighten the fastening screws when installing the
lower cover on uneven ground. Over-tightened fastening screws can
deform the lower cover. Thus, you may not be able to snap on the
upper cover or the secure contacting between the lower and upper
cover may be affected.
Installation height
For an optimal viewing angle
we recommend an installation
height of 1,60 m (upper edge of
the device above floor level).
Installation on flush-mounted
socket
Position the flush-mounted
socket below the cable gland.
According to the illustration,
attach the lower cover at the
attachment holes to the flush-
mounted socket or to the wall
with suitable screws.
Lower cover
Position flush-
mounted socket
4 fastening
screws wall
mounting
2 fastening
screws on flush-
mounted socket

8
Connect the lines
Minimise the length of the lines above
the lower cover to place the lines with-
out any problems and to prevent
clamping the lines when snapping-on
the upper cover.
Connect the lines according to the
labeling within the lower cover to the
connection terminal. (The terminal can
be removed from the guide rail.)
Run the lines along the dedicated site.
Ensure that there is no uninsulated or
not connected wire (e.g. cable shield)
in the space for cabling as this could
cause a short-circuit.
a b E P M C V1 V2
Set indoor station as end device
The indoor station is positioned at the
end of a strand or is the only device in
the strand:
Push the slide switch S1 (on the print-
ed circuit board in the upper cover) to
the right. Thus, the matching resistor is
“placed“.
(scope of delivery: “not placed“)
Snap-on the upper cover
Set the upper cover on both latches of
the lower cover (1).
Snap-in the upper cover with slight
pressure (2).
S1

9
Open the device
There is a release mechanism at
the underside of the device. Slight-
ly press into the opening with a
screwdriver.
Now the upper cover can be re-
moved from the underside and
separated from the lower cover.
Lift the upper cover from the two
upper latches.
5-wire special operation
If there are only 5 wires available for
the device, it is possible to operate it
in 5-wire special operation.
Connect the b- and M-wire with one
wire bridge.
Commissioning
!
First install the system completely, then connect it to mains
voltage!
Install the devices of the system completely.
V1 and V2 must not be connected to P-, a- or b-wire. When connect-
ing the video wires V1 (+) and V2 (-) the polarity must be observed.
Check the a-, b- and P-wire against each other for short-circuit.
Switch ON the mains voltage.
Both LEDs are blinking 3 x green. The indoor station is ready for ope-
ration.

10
Settings
AS address-dependent image activation
If there are also front-door stations without camera in combination with
video front-door stations within one systems, the image is not activated if
a call from such a front-door station comes in.
To guarantee this function the possible AS addresses are separated into
two areas:
AS address
0 –47*
reserved for video front-
door stations
image is activated in case
of a door call (of max.16
video front-door stations)
AS address
48 –63*
free, for front-door stations
without camera
image is not activated in
case of a door call
*) The video AS border can be modified only with the configuration software configoTM.
Pre-settings ex works
OSD information
activated
Language
German
Microphone sensitivity
5 (of 8)
Conversation volume
3 (of 8)
Ring tone volume
5 (of 8)
Brightness
4 (of 20)
Contrast
10 (of 20)
Color intensity
14 (of 20)
Length of call
10 to 120 s
Remaining conversation time activa-
tion of the door opener
4 s
Image switch time
60 s
Blinking period of the red LED, BUS
If ”video/speech channel busy“
when pressing the speech button
or the image button
if ”video/speech channel busy“
when a door call comes in (for im-
age activation when busy)
6 s
10 s
3 x blinking
5 x blinking

11
Internal stand-by time
if the indoor station is called
if the indoor station is calling and
waiting for call acceptance
2 min
30 s
Floor door release time
35 s
Timeout OSD
10 bis 120 s
Timeout video image
10 bis 120 s
Configuration options
Function
Menu
Fixed simplex communication
–
Simplex communication to the front-door
station
–
Ring tone volume
x
Ring tones for door calls, internal calls
and floor calls
x
Call diversion
x
Button tone ON / OFF
x
Door release automatic
x
Internal call (max. 10)
x
Control function 8, 9, 10, light switch f.
x
Determine video AS border and
door call AS border
x
Image activation when a floor call comes
in (floor video function)
x
Image switch time
x
Length of call
x
Parallel allocation
x
Set / delete floor door release function
x
Automatic hands-free talking after inter-
nal call ON/ OFF
–
Image settings
x

12
Settings via OSD menu
Setup
the in-
staller
(Operat-
ing level
for the
qualified
electrician
)
This level is permitted for
authorised persons only.
Press the menu button
in stand-by mode to open
the main menu.
Press the image button
or the function key to
select the menu Intercom
settings.
Press simultaneously the
call OFF button and the
image button to get to
the menu Set up Installer.
Main menu
1 Internal call
2 Light and control
3 Automatic function
4 Setup Intercom
Off up Down OK
Set up Installer
1 Ring tone
2 AS address
3 Parameter
4 Internal call
5 System
6 Information on device
Off Up Dwown OK
Setup Intercom
1 Set up User
2 Set up Installer
Off Up Down OK

13
Ring
tone
In the menu ring tone, the
ring tones for door calls from
the front-door station (max.
8), floor calls and internal
calls can be set.
Press the image button
or the function key to
set the ring tones.
When selecting the ring
tone, the ring tone sounds
immediately.
Note:
After you made the settings please
press the speech button to store the
settings and to switch to the next menu
point.
Video AS
border
To one indoor station max. 8
front-door stations can be
allocated:
AS address from 0 to 63:
0 - 47 for video front-door
station, as of 48 for audio
front-door station.
Press the image button
/ function key to change
the AS address.
Press the image button
or the function key to
set the video AS border.
Note:
Store the settings by pressing the
speech button . The next line is
highlighted.
AS address
Door1 AS: 0
Door2 AS: empty
Door3 AS: empty
Door4 AS: empty
Door5 AS: empty
Door6 AS: empty
Door7 AS: empty
Door8 AS: empty
Off Up Down OK
Ring tone
Door1 Tone: Alpha1
Door2 Tone: Alpha2
Door3 Tone: Alpha2
Door4 Tone: Alpha2
Door5 Tone: Alpha1
Door6 Tone: Alpha2
Door7 Tone: Alpha2
Door8 Tone: Alpha2
Internal call: Gong
Floor call: Alpha3
Off Up Down OK

14
Parame-
ter
Image switch time:
The screen switches OFF
after the determined period
of time (flat= 60 s).
Length of call:
The indoor station switches
OFF after the determined
period of time. The time can
be adjusted from 10 to 120 s.
Parallel SN:
Enter the serial number of
the indoor station which
should be displayed when a
call comes in.
Floor camera:
Activate / deactivate if an-
other camera should be con-
nected.
Floor door (opener):
Activate / deactivate
Floor door opener is activated:
By pressing the door release button
the control function 11 is sent.
Can be used to open the floor door.
Call diversion:
Activate / deactivieren
Call diversion SN: Enter the
serial number
Door release automatic:
Activate / deactivate
Note:
Store the settings by pressing the
speech button . The selection symbol
switches over to the next position.
Parameter
Image switch time: 60
Length of call: 45
Parallel call SN: 21
Floor camera: deactivated
Floor door: permitted
Call diversion: permitted
Call diversion SN: 0
Door automatic: deactivated
Off Up Down OK

15
Internal
call (des-
tinations)
Enter the room and serial
number of the indoor station
for internal calls.
Max. 10 internal calls can
be configured.
Press the image button /
function key to change
the room and serial num-
ber. The numbers must be
adjusted individually.
Note:
Store the settings by pressing the speech
button . The selection symbol switches
over to the next position.
System
OSD information:displays
date, time and status etc.,
when a voice and video con-
nections is established.
Language: language setting
OSD (German and others)
MIC Vol:microphone sensitiv-
ity, 8 steps.
SPK Vol: volume of the loud-
speaker, 8 steps.
Function key: CF 8 or lights.
Factory setting
Press the image button
to reset the systems pa-
rameter to the factory set-
tings.
Reset
Note:
Store the settings by pressing the speech
button . The selection symbol switches
over to the next position.
Device
informa-
tion
The information on the device
is available under Device in-
formation.
User Einrichten
OSD Info: Aktiv
Sprache: German
MIC Vol:
Spk Vol:
Funktionstaste:
Werkseinstellung
Reset
Aus Auf Ab OK
Internal call
01: Ro 10000 SN: 00000
02: Ro 0 SN: 0
02: Ro 0 SN: 0
02: Ro 0 SN: 0
02: Ro 0 SN: 0
02: Ro 0 SN: 0
02: Ro 0 SN: 0
02: Ro 0 SN: 0
02: Ro 0 SN: 0
02: Ro 0 SN: 0
Off Up Down OK

16
Operation
To accept a call
Door call
from a
video
front-
door sta-
tion
In case of an incoming call
from a video front-door
station, the screen is au-
tomatically activated and
the video image is dis-
played.
Shortly press the speech
button to speak to the
person who is in front of
the door.
When a voice connection
is established, the LED 2
is ON.
Shortly press the speech
button to end the voice
communication.
Shortly press the door
release button to
open the door.
Door call
from an
audio
front-
door sta-
tion
In case of an incoming call
from an audio front-door
station, a ring tone sounds
at the indoor station. No
video image is displayed.
Shortly press the speech
button to speak with
the person in front of the
door.
Shortly press the speech
button to end the voice
communication.
Press the call-OFF button
to end the voice com-
munication.
Speaking End
End
Remaining time

17
Internal
call from
another
indoor
station
In case of an incoming call
from another indoor sta-
tion, a ring tone sounds at
the indoor station. No vid-
eo image is displayed.
Shortly press the speech
button to speak to the
person at the other indoor
station.
Shortly press the speech
button to end the voice
communication.
Press the call-OFF button
to end the voice com-
munication.
Floor call
When a floor call (from a
floor door) comes in, short-
ly press the speech button
to speak to the person
at the floor door.
Shortly press the speech
button to end the voice
communication.
If the floor door release
function is activated, press
the door release button
to open the floor door
(only possible up to 35
seconds after the call has
come in).
If the floor video function is
activated, the video image
is displayed.
Open End
Floor door

18
Call from
the cen-
tral
In case of an incoming call
from the central, shortly
press the speech button
to speak to the person
at the central.
Shortly press the speech
button to end the voice
communication.
Sending a call
Call a
video
front-
door sta-
tion
In stand-by mode: Press
the speech button to
establish a voice commu-
nication with front-door
station which was con-
nected last.
Shortly press the speech
button to end the voice
communication.
Next End
Front door

19
Send an
internal
call
Press the menu button
in stand-by mode to open
the main menu.
Press the image button
or the function key
to select the menu Internal
call.
If an internal call was con-
figured, e.g. the room or
the serial number of the
call destination is dis-
played on the screen.
Select the call destination
(e.g. facility manager)
Press the speech button
to call another indoor
station.
If there is no internal call
configured:
Display: No internal call.
Call the
central
Press the door release
button or the function
key (depending on your
configuration) to call the
central.
If a call comes in at the
indoor station, press the
speech button to speak
with the person at the cen-
tral.
Shortly press the speech
button to end the voice
communication.
Main menu
1 Internal call
2 Light and control
3 Automatic function
4 Setup Intercom
Off Up Down OK
Internal call
No internal call
Off Up Down OK
Internal call
01: Facility M. SN 12808
02: Ro 12 SN 54987
Off Up Down OK

20
Video surveillance
Video
sur-
veillance
Press the image button
.
If several video front-door
stations or cameras are
connected, you can switch
between these by pressing
the image button
again.
Press the call-OFF button
to switch OFF the im-
age.
The image switches OFF
automatically after the de-
termined period of time ran
out.
Floor
video
To display the floor video
image, confirm the image
button (if the floor vid-
eo function is activated).
Video
front-
door
station
Press the image button
to switch to the image of
the video front-door sta-
tion.
Next End
Front door
Next End
Front door
Next End
Floor door
