Teknik Barrister Home 3 Drawer Chest 5418702 User manual

NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
Barrister Home 3 Drawer Chest
Barrister Home Collection | Model 5418702
For things 'n such.
Teknik
www.teknikoffice.co.uk

Table of Contents Assembly Tools Required
3
4
5-18
19-21
22-24
25-26
27
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
Pae 2
Short Screwdriver
Use of a TV that is too heavy or lare is hazardous. A TV that is too
heavy will create a risk of a tip-over that can cause severe injury
or death. A TV that is too lare for the available space miht be
accidentally pushed or bumped o the furniture, or subject to tip-over.
• Check the size and weiht of your TV. Compare it to the diaram to
the riht – before you begin assembly!
• This Sauder unit is desined for use with televisions weihin less
than 50 pounds. Never use with a TV that weihs more.
• The size of the television, front-to-back and side-to-side, must fit
within the space defined in the diaram.
• Never place the front ede of the TV past the front ede of the TV
support shelf (or stop moldin – if equipped)
• Never allow the sides of the TV to extend past the side edes of
the TV support surface.
• If the TV has a CRT picture tube, the picture tube cone may extend
past the rear of the support shelf.
• Be sure to apply the warnin label as instructed in the last assembly
step. The label provides important safety related information.
WARNING
!
50 lbs.
50 lbs.
16-3/4"
16-3/4"
36-1/2"
36-1/2"
Tape Measure

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the ede
to help distinuish similar parts from each other. Use this part identification to help identify similar parts.
A RIGHT END (1)
B LEFT END (1)
C TOP (1)
D BOTTOM (1)
E BACK (1)
F BRACE (2)
G BASE (1)
H DRAWER FRONT (3)
I RIGHT BASE (1)
J LEFT BASE (1)
K FRONT MOLDING (1)
N RIGHT MOLDING (1)
O LEFT MOLDING (1)
D26 DRAWER RIGHT SIDE (3)
D27 DRAWER LEFT SIDE (3)
D189 DRAWER BACK (3)
D994 DRAWER BOTTOM (3)
M64 DRAWER BRACE (3)
Now you know
our ABCs.
Pae 3
N
O
A
B
C
D
E
F
G
H
I
J
K
M64
D994
D26
D27
D189
F

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
Pae 4
WARNING
Never use this furniture with a TV that is
too large or too heavy. Severe injury or
death can occur.The TV and furniture
will be unstable and may tip.
-The TV must less than 50 lbs.
-The base of the TV must be able to sit
completely on this shelf.
Refer to instruction book for complete
safety information.
Note: This is a permanent label. Do not
try to remove. Surface will be damaged.
08/05 2 6 9 2 2 0 269220
WARNING LABEL - 1
1L
(Refer to Step 13 for proper
location and application)
35AA UNIVERSAL CABINET RAIL - 6 35AC DRAWER RIGHT - 3 35AD DRAWER LEFT - 3
METAL BRACKET - 7
4G
BLACK 9/16" LARGE HEAD SCREW - 14
1S
SILVER 1-1/8" FLAT HEAD SCREW - 7
10S
BLACK 1-1/4" FLAT HEAD SCREW - 4
7S
BLACK 7/8" MACHINE SCREW - 12
37S
3S GOLD 5/16" FLAT HEAD SCREW - 24
METAL PIN - 4
1R
MOLDING
CONNECTOR - 2
19F
10A SLIDE CAM - 6
NAIL - 30
1N
HIDDEN CAM - 15
1F CAM DOWEL - 15 2F
30S BLACK 1-9/16" FLAT HEAD SCREW - 15
KNOB - 12
71K

Step 1
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratchin your unit or the floor.
å Push fifteen HIDDEN CAMS (1F) into the ENDS (A and B),
BOTTOM (D), BRACES (F), and DRAWER BRACES (M64).
Then, insert the metal end of a CAM DOWEL (2F) into
each HIDDEN CAM.
Pae 5
Arrow
1F
2F
(15 used)
Arrow
1F
2F
Do not tihten the HIDDEN CAMS in this step.
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
A
B
D
F
M64
F
M64
M64

Step 2
Pae 6
å Fasten the UNIVERSAL CABINET RAILS* (35AA) to the
ENDS (A and B). Use twelve GOLD 5/16" FLAT HEAD
SCREWS (3S) throuh holes #1 and #3.
å *patent pendin lide system
GOLD 5/16" FLAT HEAD SCREW
(12 used in this step)
3S
3
2
1
1
2
3
A
1
2
31
2
3
3
2
13
2
1
Glide end
Glide end
Finished ede
Surface with
HIDDEN CAMS
B
Surface with
HIDDEN CAMS
Finished ede
Remember:
Rihty tihty.
Lefty loosey.

å Tap two MOLDING CONNECTORS (19F) into the notches
in the MOLDINGS (K, N, and O).
Step 3
Pae 7
Use your hammer to tap the MOLDING CONNECTORS (19F) into the notches in the MOLDINGS.
Flat end
Flat end
19F
N
O
K
19F
Unfinished surface
Unfinished surface
Unfinished surface

Step 4
å Fasten the TOP (C) to the MOLDINGS (K, N, and O). Use
seven SILVER 1-1/8" FLAT HEAD SCREWS (10S).
å NOTE: Do not overtihten the SCREWS into the TOP.
N
O
C
K
Finished surface
Finished surface
Surface
with holes
Finished surface
SILVER 1-1/8" FLAT HEAD SCREW
(7 used in this step)
10S
Do not overtihten
the SCREWS (10S).
Lon curved ede
Pae 8

StepStep 5
å Fasten the RIGHT END (A) to the RIGHT MOLDING (N).
Tihten two HIDDEN CAMS.
å NOTE: The foam support needs to be at least 1-1/4" thick.
A
N
O
K
Pae 9
Finished ede
Surface
with
HIDDEN
CAMS
Do not stand the unit upriht without the
BACK fastened. The unit may collapse.
Caution
Start Tighten
Arrow
Minimum
190 derees
Caution
Risk of damae or
injury. HIDDEN CAMS
must be completely
tihtened. HIDDEN
CAMS that are not
completely tihtened
may loosen, and parts
may separate. To
completely tihten:
Arrow
Maximum
210 derees
For support, place
packin foam and
maazines here.
1-1/4" thick

Step
å Insert four METAL PINS (1R) into the ends of the BRACES (F).
å Fasten the BRACES (F) to the RIGHT END (A). Tihten two
HIDDEN CAMS.
å NOTE: Be sure the METAL PINS in the BRACES insert into
the holes in the RIGHT END.
Step 6
Pae 10
A
F
F
Surface with HIDDEN CAMS
Surface with HIDDEN CAMS
1R
(4 used)
Arrow
Minimum
190 derees
Maximum
210 derees
Ede with HIDDEN CAMS
Foam support

Step
Pae 11
Step 7
å Fasten the BOTTOM (D) to the RIGHT END (A). Tihten
two HIDDEN CAMS. Arrow
Minimum
190 derees
Maximum
210 derees
A
D
Surface with HIDDEN CAMS
These holes must be here.
For support, place packin
foam and maazines here.
If you're doin this to
help a friend, don't
leave without a bite.

Step
å Fasten the LEFT END (B) to the BOTTOM (D), BRACES (F),
and LEFT MOLDING (O). Tihten six HIDDEN CAMS.
å NOTE: Be sure the METAL PINS in the BRACES insert into
the holes in the LEFT END.
å NOTE: Use the Short Screwdriver for the HIDDEN CAMS in
the BRACES.
Step 8
Arrow
Minimum
190 derees
Maximum
210 derees
B
Surface without HIDDEN CAMS
DF
F
Finished ede
Pae 12
O

å Fasten seven METAL BRACKETS (4G) to the ENDS (A and B) and BOTTOM (D). Use seven BLACK 9/16" LARGE
HEAD SCREWS (1S).
å NOTE: Be sure the edes of the METAL BRACKETS are even with the edes of the ENDS and BOTTOM.
å Fasten the BASES (I and J) to the ENDS (A and B). Use four BLACK 1-1/4" FLAT HEAD SCREWS (7S).
å Fasten the BASE (G) to the ENDS (A and B) and BOTTOM (D). Use seven BLACK 9/16" LARGE HEAD SCREWS (1S)
throuh the METAL BRACKETS and into the BASE.
Step 9
B
A
D
G
I
J
BLACK 9/16" LARGE HEAD SCREW
(14 used for the METAL BRACKETS)
1S 4G
(7 used)
BLACK 1-1/4" FLAT HEAD SCREW
(4 used in this step)
7S
Flat ede
Pae 13
Flat ede
4G
4G

Step 10
å Unfold the BACK (E) and lay it over your unit.
å Make equal marins alon all four edes of the BACK (E).
Push on opposite corners of your unit if needed to make
it "square".
å Fasten the BACK (E) to your unit usin the NAILS (1N).
Do not stand the unit upriht without the
BACK fastened. The unit may collapse.
Caution
NAIL
(30 used in this step)
1N
E
Pae 14

Step 11
Pae 15
å Insert the DRAWER SIDES (D26 and D27) at an angle
into the slot at each end of the DRAWER FRONT (H). å Slide the DRAWER BOTTOM (D994) into the
grooves in the DRAWER SIDES (D26 and D27) and
DRAWER FRONT (H).
å Fasten the DRAWER BRACE (M64) to the DRAWER
FRONT (H). Tighten one HIDDEN CAM. å Fasten the DRAWER BACK (D189) to the DRAWER
SIDES (D26 and D27) and DRAWER BRACE (M64). Use
five BLACK 1-9/16" FLAT HEAD SCREWS. (30S). Repeat
this step for the other DRAWERS.
12
34
Be sure the DRAWER
BOTTOM inserts into the
DRAWER FRONT roove.
With the palm of your hand, tap the
DRAWER BOTTOM down into the roove.
Groove
Arrow
Maximum
210 derees
Minimum
190 derees
H
H
H
D27
D26
D27
D994
D26
D26
D27
D189
Unfinished
surface
Be sure the
DRAWER
BOTTOM
inserts into
the DRAWER
BACK roove.
30S
Start each screw a few turns before
completely tihtenin any of them.
BLACK 1-9/16" FLAT HEAD SCREW
(15 used in this step)
The tabs should insert freely
into the slots. Gently tilt the
DRAWER SIDES side to side
until the tabs slip into the slots.
M64
M64
Surface with
HIDDEN CAM

Step 12
Pae 16
å Insert a SLIDE CAM (10A) into the DRAWER SIDES (D26 and D27).
å Fasten a DRAWER RIGHT (35AC) to the DRAWER RIGHT SIDE (D26) and a DRAWER LEFT (35AD) to the DRAWER LEFT
SIDE (D27). Use four GOLD 5/16" FLAT HEAD SCREWS (3S) throuh holes #1 and #2.
å NOTE: The screw head in the CAM must be visible throuh the slotted hole in the SLIDE.
å NOTE: The parts are marked "DRAWER RIGHT" and "DRAWER LEFT" for easy identification.
å NOTE: The lides are not intended to rotate.
å Fasten four KNOBS (71K) to the DRAWER FRONT (H). Use four BLACK 7/8" MACHINE SCREWS (37S).
å Repeat this step for the other drawers.
Screw head - turn CAM to line up holes in
the SLIDES with holes in DRAWER SIDES
10A
10A
1
2
1
2
H
D26
D27
BLACK 7/8" MACHINE SCREW
(12 used for the KNOBS)
37S
GOLD 5/16" FLAT HEAD SCREW
(12 used in this step)
3S
(4 screws per drawer)
Glide end
Glide end
71K

å Carefully stand your unit upriht.
å To insert the drawers into your unit, tip the front of the drawer down
and drop the lides on the drawer behind the lides on the unit. Lift the
front of the drawer up and slide it into the unit.
å Apply the WARNING LABEL (1L) to the TOP (C). You should be able to
read the label when the TV is removed from the unit. When the TV is in
place, it should hide the label. Peel o the backin and apply the label
as shown in the diaram.
å NOTE: This is a permanent label intended to last for the life of the
product. Once applied, do not try to remove it.
Step 13
Pae 17
50 lbs.
30 lbs.
30 lbs. each
WARNING
Never use this furniture with a TV
that is too lare or too heavy. Severe
injury or death can occur. The TV and
furniture will be unstable and may tip.
-The TV must weih less than 50 lbs.
-The base of the TV must be able to
sit completely on this shelf.
Refer to instruction book for
complete safety information.
Note: This is a permanent label. Do
not try to remove. Surface will be
damaged.
08/05 2 6 9 2 2 0 269220
1L
Pro Tip: Lift with your
les. And, you know,
your arms.
C

Step 14
Pae 18
å To make adjustments to the drawers, loosen SCREW #2 in the SLIDES a 1/4 turn, then turn the CAM clockwise or
counter-clockwise. Notice how the drawer raises or lowers as you turn the CAM. The hiher the screw in the oblon hole,
the hiher your drawer front will be. The lower the screw, the lower the drawer front. By adjustin the drawers this way, it
will help the DRAWER FRONTS line up better when closed. Tihten the SCREW when finished with adjustments.
å NOTE: Please read the back paes of the instruction booklet for important safety information.
å This completes assembly. Clean with your favorite furniture polish or a damp cloth. Wipe dry.
The hiher the screw in the oblon hole,
the hiher your drawer front will be. The
lower the screw, the lower the drawer front.
Cam
Loosen screw #2 a 1/4 turn, turn the cam a 1/4 turn
maximum in both the clockwise and counter-clockwise
directions to make adjustments, and then tihten screw #2.

WARNING
Please use your furniture correctly and safely. Improper use can cause safety hazards,
or damae to your furniture or household items. Carefully read the following chart.
Look out for: What can happen: How to avoid the problem:
• Overloaded dresser drawers and
shelves. • Risk of injury. • Top-heavy furniture can tip over.
• Overloaded drawers and shelves can
break.
• Never exceed the weiht limits shown in
the instructions.
• Work from bottom to top when loadin
shelves and drawers. Place the heavier
items on the lower shelves or in lower
drawers.
• Children climbin on furniture.
• A child may try to reach a toy or other
object by climbin on furniture.
• Risk of injury or death.
• A child climbin on a piece of furniture
can make it top-heavy and cause it to tip
over.
• Never allow children to climb on or play
with furniture. Do not place toys, food, etc.
on the top shelves or upper drawers.
• Placin TVs on furniture items that are
not desined to support a television is
hazardous.
• Risk of injury or death. TVs can be
heavy and the location of the picture tube
tends to make TVs unbalanced and prone
to tippin forward.
• This product is not desined to
support a television.
• Improperly movin furniture that is
not desined and equipped with casters. • Furniture can tip over or break if improperly moved.
• Physical injury. Furniture can be very
heavy.
• Unload drawers and shelves from top to
bottom before movin the furniture.
• Do not push furniture, especially on a
carpeted floor. Have a friend help you lift
the unit and set it in place.
• This unit must be positioned aainst a
wall.
