Teknik 5424152 User manual

www.teknikoffice.co.uk
For all your
newfangled gadgetry.
Mediterranean Shaker Style Desk
Model 5424152
Teknik

Part Identification
Hardware Identification
Assembly Steps
Troubleshooting
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
Assembly Tools RequiredTable of Contents
2-3
4
5-27
28
37-38
39
A RIGHT END (1)
B LEFT END (1)
C RIGHT UPRIGHT (1)
D LEFT UPRIGHT (1)
D48 RIGHT DRAWER SIDE (2)
D49 LEFT DRAWER SIDE (2)
D151 DRAWER BACK (2)
D953 DRAWER BOTTOM (2)
E3 TOP (1)
F BOTTOM (2)
G OUTER BOTTOM (4)
H2 LARGE BACK (1)
I SMALL BACK (2)
J BRACE (1)
K RIGHT FRONT LEG (2)
L LEFT FRONT LEG (2)
M RIGHT REAR LEG (1)
N LEFT REAR LEG (1)
O RIGHT MIDDLE REAR LEG (1)
P LEFT MIDDLE REAR LEG (1)
Q DRAWER FRONT (2)
R TOP MOLDING (1)
S BOTTOM MOLDING (4)
T BOTTOM SIDE MOLDING (4)
U END MOLDING (2)
Page 2
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
Part Identification
Scissors
Masking Tape

Now you know
our ABCs.
Part Identification
A
B
C
D
E3
F
F
G
G
G
G
H2
I
I
J
K
K
L
L
M
N
O
P
Q
Q
R
S
S
S
S
T
T
T
T
U
U
D151
D953
D953
D151
Page 3
D48
D49
D49
D48

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
SILVER 1/2" MACHINE SCREW - 2
38S
BLACK 9/16" LARGE HEAD SCREW - 14
1S
BLACK 2" PAN HEAD SCREW - 4
66S
CAM COVER - 4
19P
3S GOLD 5/16" FLAT HEAD SCREW - 16
BLACK 9/16" FLAT HEAD SCREW - 4
32S
CAM SCREW - 44
8F WOOD DOWEL - 4 15F
HIDDEN CAM - 72
1F CAM DOWEL - 28 2F
100K KNOB SET - 2
FILE DRAWER FRONT
BRACKET - 4
10G
FILE GLIDE - 2
4B
Page 4
FILE ROD - 2
7B
(EXTENSION SET SHOWN SEPARATED)
EXTENSION RAIL - 4
35MA EXTENSION SLIDE - 4 35MC
METAL
BRACKET - 3
4G
30S BLACK 1-9/16" FLAT HEAD SCREW - 8
CORD CLIP - 4
4P
HIDDEN WIRELESS Qi COMPATIBLE CHARGER by
EGGTRONIC - Item 425905 (sold separately)
p
o
w
e
r
e
d
b
y
E
G
G
T
R
O
N
I
C
p
o
w
e
r
e
d
b
y
E
G
G
T
R
O
N
I
C
p
o
w
e
r
e
d
b
y
E
G
G
T
R
O
N
I
C
p
o
w
e
r
e
d
b
y
E
G
G
T
R
O
N
I
C

Step 1
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å Push twenty-eight HIDDEN CAMS (1F) into the ENDS (A
and B), UPRIGHTS (C and D), and BOTTOMS (F and G).
Then, insert the metal end of a CAM DOWEL (2F) into
each HIDDEN CAM.
Page 5
F
F
G
G
G
G
A
B
C
D
Arrow
1F
2F
(28 used)
Arrow
1F
2F
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
Do not tighten the HIDDEN CAMS in this step.

Step 2
Page 6
I
I
A
B
C
D
T
T
T
T
S
S
S
S
H2
Arrow
Arrow
1F
The arrow in the HIDDEN
CAM must point toward the
hole in the edge of the board.
Hole
1F
Arrow
å Push forty-four HIDDEN CAMS (1F) into the ENDS (A and B),
UPRIGHTS (C and D), BACKS (H2 and I), and MOLDINGS (S and T).
(44 used)

Step 3
Page 7
å Turn forty-four CAM SCREWS (8F) into
the LEGS (K, L, M, N, O, and P).
K
K
L
L
M
N
O
P
8F
8F
8F
(44 used)

å Turn four BLACK 9/16" FLAT HEAD SCREWS (32S) into
the ENDS (A and B) until the shoulders of the SCREWS
rest on the surfaces of the ENDS.
å Slide the END MOLDINGS (U) onto the ENDS (A and B).
Line up the grooves in the MOLDINGS over the heads of
the SCREWS in the ENDS.
å NOTE: The MOLDINGS should be centered on the ENDS.
Step 4
Page 8
Shoulder
BLACK 9/16" FLAT HEAD SCREW
(4 used in this step)
32S
A
B
U
U
Surface with grooves
Some assembly
(and snacks) required.
Apply pressure with your hands
as you guide the MOLDINGS over
the SCREWS and onto the ENDS.

å Fasten the LEGS (K and M) to a BOTTOM SIDE
MOLDING (T) and the RIGHT END (A). Tighten six
HIDDEN CAMS.
å Fasten the LEGS (L and N) to a BOTTOM SIDE
MOLDING (T) and the LEFT END (B). Tighten six
HIDDEN CAMS.
Step 5
Page 9
A
T
K
M
Surface with
HIDDEN CAMS
1
2
B
T
L
N
Surface with
HIDDEN CAMS
These surfaces
must be even.
U U
These holes
must be here.
These holes
must be here.
LEFT END ASSEMBLY RIGHT END ASSEMBLY

å Fasten the LEGS (L and O) to a BOTTOM SIDE
MOLDING (T) and the UPRIGHT (C). Tighten six
HIDDEN CAMS.
å Fasten the LEGS (K and P) to a BOTTOM SIDE
MOLDING (T) and the LEFT UPRIGHT (D). Tighten
six HIDDEN CAMS.
Step 6
Page 10
D
T
K
P
Surface with
HIDDEN CAMS
C
T
L
O
Surface with
HIDDEN CAMS
These surfaces
must be even.
These holes
must be here.
These holes
must be here.

å Separate the EXTENSION SLIDES (35MC) from the EXTENSION RAILS (35MA) as shown in the enlarged diagram below.
Be prepared, the parts are greasy.
å Fasten the EXTENSION RAILS (35MA) to the ENDS (A and B) and UPRIGHTS (C and D). Use eight GOLD 5/16" FLAT
HEAD SCREWS (3S).
å NOTE: For each EXTENSION RAIL, turn a SCREW into the hole shown in the enlarged diagram. Then, slide the inner cartridge of
the EXTENSION RAIL in to find the other hole that lines up with the hole in the END or UPRIGHT. Turn a SCREW into this hole.
Step 7
Page 11
Open end
Open end
Open end
Open end
GOLD 5/16" FLAT HEAD SCREW
(8 used in this step)
3S
A
B
C
D
LEFT END ASSEMBLY
RIGHT END ASSEMBLY
Push the black lever in and pull the SLIDE from the RAIL.
35MA
35MC

å Insert a WOOD DOWEL (15F) into each short edge of a BOTTOM (F).
å Lay two OUTER BOTTOMS (G) next to the BOTTOM (F) as shown.
å Fasten two BOTTOM MOLDINGS (S) to the BOTTOMS (F and G). Tighten
six HIDDEN CAMS.
å NOTE: Be sure the WOOD DOWELS insert into the BOTTOM MOLDINGS.
å Repeat this step for the remaining BOTTOMS (F and G) and
BOTTOM MOLDINGS (S).
Step 8
424152 www.sauder.com/servicesPage 12
S
S
F
G
G
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
Edge with CAM DOWELS
Edge with CAM DOWELS
15F
15F
Start Tighten
Arrow
Minimum
190 degrees
Caution
Risk of damage or
injury. HIDDEN CAMS
must be completely
tightened. HIDDEN
CAMS that are not
completely tightened
may loosen, and parts
may separate. To
completely tighten:
Arrow
Maximum
210 degrees
BOTTOM ASSEMBLY
(4 used in this step)

å Fasten the MIDDLE REAR LEGS (O and P) to the LARGE
BACK (H2). Tighten four HIDDEN CAMS.
å Fasten the BRACE (J) to the MIDDLE REAR LEGS (O and P).
Use four BLACK 2" PAN HEAD SCREWS (66S).
å NOTE: You should start each SCREW a few turns before
completely tightening any of them.
Step 9
Page 13
Arrow
Minimum
190 degrees
Maximum
210 degrees
Surface with HIDDEN CAMS
O
P
J
H2
Unfinished edge
66S
BLACK 2" PAN HEAD SCREW
(4 used in this step)
66S
For support, place packing
foam and magazines here.

å Fasten the SMALL BACKS (I) to the
MIDDLE REAR
LEGS (O and P). Tighten four HIDDEN CAMS.
å Fasten a BOTTOM assembly to the LEGS (L and O)
and BOTTOM SIDE MOLDING (T). Tighten four
HIDDEN CAMS.
å Fasten the remaining BOTTOM assembly to the
LEGS (K and P) and BOTTOM SIDE MOLDING (T).
Tighten four HIDDEN CAMS.
Step 10
Arrow
Minimum
190 degrees
Maximum
210 degrees
Page 14
For support, place packing
foam and magazines here.
For support, place packing
foam and magazines here.
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
K
L
T
T
BOTTOM ASSEMBLY
BOTTOM ASSEMBLY
Surface with
HIDDEN CAMS
Surface
with
HIDDEN
CAMS
O
P
I
I
Finished edge
Finished edge

StepStep 11
å Fasten the LEFT END ASSEMBLY to the SMALL
BACK (I) and BOTTOM ASSEMBLY on the left end
of your unit. Tighten six HIDDEN CAMS.
å Fasten the RIGHT END ASSEMBLY to the SMALL
BACK (I) and BOTTOM ASSEMBLY on the right end
of your unit. Tighten six HIDDEN CAMS.
Arrow
Minimum
190 degrees
Maximum
210 degrees
Page 15
LEFT END ASSEMBLY
RIGHT END ASSEMBLY
BOTTOM ASSEMBLY
BOTTOM ASSEMBLY
I
I

Step
å NOTE: You will need someone's help in this step.
å Fasten the TOP (E3) to the ENDS (A and B) and
UPRIGHTS (C and D). Tighten eight HIDDEN CAMS.
å Fasten three METAL BRACKETS (4G) to the TOP
MOLDING (R). Use three BLACK 9/16" LARGE
HEAD SCREWS (1S).
å NOTE: Be sure the BRACKETS are even with the edges
of the MOLDING.
å Fasten the TOP MOLDING (R) to the TOP (E3). Use
three BLACK 9/16" LARGE HEAD SCREWS (1S)
through the METAL BRACKETS on the MOLDING (R)
and into the holes in the TOP (E3).
Step 12
Page 16
E3
Arrow
Minimum
190 degrees
Maximum
210 degrees
Surface with holes
These holes must be here.
A
B
C
D
BLACK 9/16" LARGE HEAD SCREW
(6 used in this step)
1S
4G
R
R

Step 16
1
3
2
å Pull the DRAWER FRONT BRACKETS (10G) apart and slide them into the grooves in the DRAWER SIDES (D48
and D49). You may need to gently tap them in with a hammer.
å NOTE: The DRAWER FRONT BRACKETS are marked "RH" and "LH" for easy identification.
å Fasten the DRAWER FRONT (Q) to the DRAWER FRONT BRACKETS (10G). Use four BLACK 9/16" LARGE
HEAD SCREWS (1S).
å Slide the DRAWER BOTTOM (D953) into the
grooves in the DRAWER SIDES (D48 and D49)
and DRAWER FRONT (Q).
å Fasten the DRAWER BACK (D151) to the DRAWER
SIDES (D48 and D49). Use four BLACK 1-9/16" FLAT HEAD
SCREWS (30S). Repeat this step for the other drawer.
BLACK 9/16" LARGE HEAD SCREW
(8 used in this step)
1S
D48
D48
D48
D953
D151
D49
D49
D49
Q
Be sure the DRAWER
BOTTOM inserts into the
DRAWER FRONT groove.
Be sure the
DRAWER
BOTTOM
inserts into
the DRAWER
BACK groove.
With the palm of
your hand, tap
the DRAWER
BOTTOM down
into the groove.
Tap down with your
screwdriver and hammer.
D49
10G
Q
Unfinished
surface
30S
Start each screw a few turns before
completely tightening any of them.
BLACK 1-9/16" FLAT HEAD SCREW
(8 used in this step)
Page 24

Step 17
Page 25
å Fasten the EXTENSION SLIDES (35MC) to the DRAWER
SIDES (D48 and D49). Use four GOLD 5/16" FLAT HEAD
SCREWS (3S) through holes #1 and #3.
å Fasten a KNOB SET (100K) to the DRAWER FRONT (Q).
Use a SILVER 1/2" MACHINE SCREW (38S).
å Repeat this step for the other drawer.
D48
D49
100K
Q
SILVER 1/2" MACHINE SCREW
(2 used for the KNOB SETS)
38S
1
1
2
2
3
3
GOLD 5/16" FLAT HEAD SCREW
(8 used in this step)
3S
(4 screws per drawer)
Open end
Open end

Page 26
Step 18
D48
D49
å Push a FILE GLIDE (4B) onto the RIGHT DRAWER SIDE (D48).
å Slide the FILE RODS (7B) into the FILE GLIDE (4B) on the
RIGHT DRAWER SIDE (D48).
å Slide another FILE GLIDE (4B) onto the other end of the
FILE RODS (7B), then press this FILE GLIDE over the
LEFT DRAWER SIDE (D49).
å Repeat this step for the other drawer.
Insert the FILE RODS into the holes
of your choice in the FILE GLIDES,
depending on your file sizes.
4B
7B
7B
4B
Almost time to
celebrate! With a nap.

Page 27
Step 19
å Carefully stand your unit upright.
å To insert the drawers into your unit, line up the EXTENSION SLIDES on the drawer with the EXTENSION RAILS on the unit
and push the drawer into the unit until the drawer is fully inserted. The drawers will push in hard until it is all the way in,
then it will slide in and out easier.
å Using your hammer, gently tap a CAM COVER (19P) onto each HIDDEN CAM.
å If you purchased and installed the HIDDEN WIRELESS Qi COMPATIBLE CHARGER by EGGTRONIC, plug it into an outlet
in your wall. To charge your phone, place it on the WIRELESS CHARGING SPOT STICKER. See the next page, if needed,
for troubleshooting.
å NOTE: Please read the back pages of the instruction booklet for important safety information.
å This completes assembly. Clean with a damp cloth. Wipe dry.
To cover HIDDEN CAMS
19P
25 lbs.
25 lbs.
70 lbs.
(4 used)
A sticker will be on the left or right
if you installed the optional Hidden
Wireless Qi Compatibility Charger
by Eggtronic (purchased separately).
30 lbs.
30 lbs.
