teko Astra-361 Installation instructions

Astra-361
Water Leak Detector
User Instruction*
Sales:
Controlex GmbH
Philosophenweg 31-33
47051 Duisburg,Germany
+49 (0) 203/393 91 188
[e-mail]
www.controlex.eu
Warranty service and
technical support:
TEKO-TD
Prospekt Pobedy str. 19
420138 Kazan, Russia
[phone]
[email protected]z
www.teko.biz
Made in Russia
Rev. 361-v1_0_instr_EN
1 FUNCTION
The detector is designed for detection of water
leak events and sending “Alarm” notification via
two-wire alarm loop (signaling zone) to control
panel or wireless detectors Astra-3321 and
Astra-Z-3345 operating in transmitter mode
(hereinafter “TRA”).
Detector is not designed for distilled water lea-
kage detection.
2 SPECIFICATIONS
Power supply voltage, V.…………from 2,5 to 30
Current consumption, mA, max:
- in stand-by mode with
supply voltage of 2.5 V..............................0,001
- in stand-by mode with
supply voltage of 15 V...............................0,003
- in stand-by mode with
supply voltage of 30 V.................................0,01
- at “Alarm” notification issue........................... 5
Overall dimensions, mm.....................45×13×13
Operating Conditions
Temperature range, °С...............from 0 to + 50
3 DELIVERY SET
Delivery set contains holders and fasteners
(dowel –2 pcs., screw –2 pcs.).
4 INSTALLATION LOCATION
Detector is located on the floor in supposed
place of water accumulation in case of leakage.
5 INSTALLATION PROCEDURE
1) Remove cover
2) Make markings
on the selected
place of installa-
tion using detector
body
3) Replace cover
4)Perform wiring (see par.6)
5)Make operability test (see par. 7)
Mounting holes

6 WIRING
1) Detector connection to control panel (CP)
R1 –resistor (nominal value depends on control
panel type, for Astra-712/x –3,9 kOhm).
2) Detector connection to TRA Astra-3321 or
Astra-3345
ATTENTION! Zone circuit current should not
exceed 50 mA in order to avoid detector dam-
age.
7 OPERABILITY TEST
1) Power CP or TRA up.
2) Check detector operability by simulating
water leakage. Water level should not be lower
than the level of detector contacts.
3) Make sure "Alarm" notification is issued by
CP or TRA (indicator flashes once).
8 WARRANTY
The operation warranty period is 2 years from the date
of operation start-up but no longer than 2 years 6
months from the date of manufacturing subject to the
requirements of Operating Manual.
*For more detailed information refer to detector
Operating Manual available for free from
www.controlex.eu.
TRA
Astra-361
Astra-361
