teko Astra-MA User manual

Astra-MA
Addressable mark
User guide
Manufacturer:
ZAO NTC TEKO
420108, Russia, Kazan,
Gafuri str., 71
Tel.:[phone]
[email protected]
www.teko.biz
Made in Russia
Rev. MA-v1_2_instr_en
1 FUNCTION
•Addressable Mark Astra-MA (further Astra-MA) is
designed to receive notifications via two program-
mable alarm loops (AL) from non-addressable devices
with a “dry contact” output and to transmit notifications
via Signaling Line Circuit (SLC) through Astra-A RPA
(RPA) into Astra-812 Pro or Astra-8945 Pro (version
5_0 and above) Control Panels.
• Astra-MA does not provide connection of detectors
with loop power supply.
• Astra-MA provides programming of AL from the PKM
Astra Pro.
• Astra-MA provides monitoring of the operability of a
fire-type AL for open and short circuit.
• Astra-MA is powered from the RPA through the SLC
power circuit.
02 SPECIFICATIONS
Power supply voltage, V................................ 7,0 - 27,6
Consumption, mA not more…...................................0,5
Maximum length SLC interface, m………………. 1000
AL Parameters (terminals +Z1-,+Z2-):
Short circuit current, mA, not more…………………….1
AL wire resistance, Ohm, not more…………………..50
AL integration time, ms…………………….70/300/500
AL resistance of different types and states,
kOhm………………………………………...see manual
Dimensions, mm…………………………… …87x54x28
Operating Conditions
Temperature range, °С.......................from - 30 to + 55
Relative air humidity, %......................up to 93 at +40°С
without moisture condensation
3 DELIVERY SET
Delivery set includes: fastening parts (dowels - 2,
screws - 2), resistor 3.9 kOhm –2.
4 INDICATION
STATUS
LED
Control
Panel
Fire / alarm/
AL fault
-
+
Opening
-
+
Power failure
(below 7.5V)
3 times flashes with a
period of 25 sec.
+
Testing (via
ASTRA-942)*
1 time flash for 2 sec.
+
Registration
(via ASTRA-
942)*
1 time flash for 2 sec.
-
“*” - service indication used during commissioning
and Astra-MA maintenance
“+” - a notification is issued
“-” –a notification is not issued
5 INSTALLATION PROCEDURE
1) Push the cover latch out of the groove in the
base. Remove the cover. (pic. A)
pic. A pic. B
2) Bend back the hooks on the base. Remove the PCB.
(pic. B)
3) Make a markup at the selected installation location
according to the attached base. (pic. C)

pic. C pic. D
4) Connect the SLC power cables and the SLC
data cables coming from Astra-A RPA and AL through
the holes for cable entering in the device base. Rec-
ommended cable type –KPSNG (A) -FRLS 2 × 2 ×
0.5. Maximum length of the cable connected to AL –
150m.
5) Fix the Astra-MA base on the selected surface.
6) Return the PCB to its place. (pic. e.)
e.
7) Connect the cables to the terminals according to the
table:
Terminal
Function
А, В
Input for connecting the Data line SLC
«+», «-
»
Input for connecting the power line SLC
Z1, Z2
Input for AL
8) Close the Astra-MA cover.
9) Perform an Astra-MA registration in RPA (see
section 6).
10) Perform an Astra-MA setup according to the Rec-
ommendations built into the PKM Astra Pro or Pconf-
Pro program. Astra-MA setting from the Astra-812 Pro"
is not available.
11) Launch a test (section 8).
6ADDING TO THE SYSTEM
Registration of Astra-MA in the RPA is carried out using
the “Astra-942" Laser Pointer (ASTRA-942) and sup-
plied separately.
1) Connect the Extender RPA to the Control Panel via
RS-485 interface.
2) Register the RPA in the Control Panel according to
the user guide of Astra-812 Pro or the manual built-in
the Configuration module of the PKM Astra Pro or
Pconf-Pro PC. (See www.teko.biz)
3) Remove the Astra-MA cover by pushing the сover
latch out of the groove in the base.
4) Check the connection of cables to the terminals on
the Astra-MA PCB ("+", "-", A and B) from the RPA.
5) Start Registration mode of devices in the Extender in
the Control Panel in accordance with the Instructions.
Themode takes 60 sec. to register one device.
6) Start the registration mode on Astra-MA using Astra-
942. Illuminate the Astra-MA indicator from the ASTRA-
942 button for at least 1 sec. The Astra-MA indicator
should turn on for 2 sec.
WARNNING!
Running registration for several detectors at one
and the same time is forbidden.
7) Registration running check:
In case of successful registration, you will see
“Astra-MA” in the setting module program in As-
tra Pro PKM or Pconf-Pro, or “Astra-MA is regis-
tered” on the screen of the Astra-812 Pro.
In case of unsuccessful registration you will need
to repeat actions from 5) to 7).
7REMOVING FROM THE SYSTEM
Removing Astra-MA from the RPA’s memory can be
held via installation PKM program module Astra Pro,
Pconf-Pro or Astra-812 Pro menu.
8 TESTING
Run a testing mode with using the Astra-942:
- Press the top Astra-
942 button
- Irradiate the Astra-
MA indicator for a
second. Astra-MA
indicator will switch
on for 10 sec.
A test notification will be recorded in the event log of
Control Panel, Astra Pro PKM or Pconf-Pro.
9WARRANTY
The operation warranty period is 5 years from the date
of operation start-up, but no longer than 5 years 6
months from the date of manufacturing subject to the
requirements of User guide.
