Astra-5131 ver. C
(Curtain-type Lens)
Wireless Optic-Electronic
PIR Motion Detector
User Guide
Manufacturer:
ZAO NTC TEKO
Gafuri str. 71
420108 Kazan, Russia
+7(843) 528-03-69
[email protected]
www.teko.biz
Made in Russia
Rev. 5131sh-v2_2_instr_en
1 FUNCTION
The detector is intended for detection of an intrusion
into a secure space of an enclosed area, forming an
alarm notification and transmitting alarm signal to the
Security Hub via radio.
The detector provides measurement and transmission
via radio:
a) the residual capacity of the battery in operating
Mode 2 (see below) when the capacity value is 30,
20 and 10%.
b) ambient temperature (processed by Centrtal
Control Panel or Security Hub)
The transmission interval is 12 s (with Rtst plug
jumpered) or 60 s (with Rtst plug opened).
2 DETECTION ZONE
3 SPECIFICATIONS
Range of detectable
moving speed, m/sec..............................from 0.3 to 3.0
Wireless coverage range, m.................................... 100
Operating frequency range, MHz ............................ 433
Power supply voltage, V.........................from 2.4 to 3.0
Dimensions, mm........................................85 × 50 × 30
Operating Conditions
Temperature range, °С........................from - 20 to + 50
Relative air humidity, %.......................up to 98 at+ 40 °С
Without moisture condensation
4 DELIVERY SET
Detector delivery set includes: bracket - 1 pc., dowel –
2 pcs., screw –2 pcs., jumper –4 pcs. (installed),
battery (CR 123A, 3V) - 1 pc., user guide –1 copy.
5 OPERATING MODES
Mode
Plug
Jumper
Mode 2* (compatible with
Security Hub)
Mode 1
Rmod
Test signal
transmission
period**
12 sec.
Rtst
60 sec.
Frequency 1 (433,42MHz)
(compatible with Security
Hub)
Frequency 3 (434,42MHz)
Lit
High detectability
Normal detectability
PIR
* Factory setting.
** For Mode 2 only
Setting operating mode of the detector, as well as
LED indication of notifications are provided within
10 minutes after battery insertion!
6 ADDING PROCEDURE
1) Remove detector cover.
2) For operating with Security Hub set Frequency 1
and Mode 2 using jumpers.
3) Start registration on the Security Hub mobile app or
web app. Registration starts for 45-60 sec.
4) Insert battery into the detector.
Make sure that the registration is successful on the
Security Hub mobile app. If registration is unsuccessful,
repeat the procedure.
7 INSTALLATION PLACE
1) It is allowed to install the detector on a wall,
ceiling, in a door/ window opening, in the corner of the
room.
2) Mount the detector on a load-bearing wall or other
load-bearing structural elements.
To eliminate false alarms
It is recommended to close all doors,
air-vents, switch off fans, air-conditioners and other
sources of intense air flows in premises during protec-
tion period.
Not recommended installation places
8 INSTALLATION PROCEDURE
1) Remove the cover
2) Remove the PCB
3a) Mounting on a wall or
ceiling
3b) Mounting in a corner
Attention! For safe extrusion of the caps fix the
detector base on a hard flat surface.
3c) Mounting with a
bracket
4) Install the PCB
5) Install the battery
6) Perform TEST-pass (see p. 9).
9 TEST PASS
1) Install jumper on the PIR plug.
2) Power up the detector (install the battery). LED
flashes once every 2 seconds for a period of not more
than 60 sec.
3) Close the detector cover.
4) After the detector enters the operating mode,
perform a test pass across the protected area at a
speed of 0.3 m/s to determine the sensitivity zone.
At the moment of detection (LED lights up for 1 sec),
stop, mark this position, go back two steps, then con-
tinue moving forward. Repeat the test pass in opposite
direction.
10 WARRANTY
The operation warranty period is 5 years from the date
of operation start-up but no longer than 5 years 6
months from the date of manufacturing subject to the
requirements of Operating Manual.
