TOORX CSX70 User manual

Ed : 09/17 Rev : 00
INSTRUCTION

- 2 -
A
C
B
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
U
W
V
S
T
1
1
4
33
2 2
1
1
1 F 1 F 1
1
1
1
1 1
X
3
4
67
8
9
10
11
13
1212 4
13
14
15
15
15
15
17
18
17
18
17
19
23
20 20
21
21
21
21
22
21
35
34
25
2627
28
28
28
28
29
29
29
29 3030
30
30
30
30
30
30
31
31
16
14
32
33
24
W
Y
Z
Z
5
5
5
AA
7
36
37

- 3 -
PARTS LIST
NUMBER
DESCRIPTION
QUANTITY
A
JOINT BASE
1
B
JOINT TUBE
1
C
RIGHT BASE
1
D
UPRIGHT FRAME
2
E
ADJUSTMENT TUBE
2
F
AXES
6
G
STRAIGHT BEAM
2
H
GUIDE ROD
4
I
TOP JOINT TUBE
1
J
TOP CROSS BEAM
1
K
JOINT BEAM
1
L
JOINT ROD
1
M
ADJUSTABLE PULLEY BLOCK
4
N
PULLEY BLOCK
4
O
SWIVEL PULLEY BLOCK (I)
2
P
SWIVEL PULLEY BLOCK (II)
2
Q
SWIVEL PULLEY BLOCK (III)
4
R
SWIVEL PULLEY BLOCK (IV)
2
S
TOP PLATE
2
T
WEIGHT PLATE
18
U
SELECTOR ROD
2
V
SECURE BUSHING
2
W
CLOTH SUPPORT
4
X
STIRTUP CABLE HANDLE (NT0450)
90
2
Y
BUSHING
4
Z
CLOTH SHELL
4
AA
LEFT BASE
1
1
BIG PULLEY
30
2
SMALL PULLEY
4
3
RUBBER DONUT
4
4
BUSHING
16
5
PULLEY PROTECTION
32
6
FAST PIN
2
7
HOOK
4
8
PIN
2
9
CABLE (I)
2
10
CABLE (II)
2
11
CABLE (III)
2
12
HEX HEAD BOLT M8*16
4
13
HEX HEAD BOLT M10*16
12
14
HEX HEAD BOLT M8*30
6
15
HEX HEAD BOLT M10*50
20
16
NUT M12
2
17
HEX HEAD BOLT M10*55
5

- 4 -
18
HEX HEAD BOLT M10*60
4
19
HEX HEAD BOLT M10*70
2
20
HEX HEAD BOLT M10*75
4
21
HEX HEAD BOLT M10*80
10
22
HEX HEAD BOLT M10*85
2
23
HEX HEAD BOLT M10*70
1
24
SQUARE NECK BOLT M10*95
4
25
HEX HEAD BOLT M10*95
4
26
R-WASHER 8
2
27
BIG WASHER 8
2
28
R-WASHER 10
16
29
WASHER 10
100
30
LOCK NUT M10
48
31
LOCK NUT M8
6
32
BIG WASHER-12
2
33
LARGEST PULLEY
2
34
SQUARE NECK BOLT M10*90
4
35
HEX HEAD BOLT M10*140
4
36
CHAIN
1
37
FOOT RING
1

- 5 -
ASSEMBLY INSTRUCTIONS
STEP 1
AA
A
B
C
D
H
O
P
F
E
17
29 30
17 18 29
30
29
15 29 30
1
12
27
4
24
28
30
1
4
13
1
15 29
30
13
6
14 31
14
31
1
2129
30
21 29
30
L
12 26
34
5
5
5
W
5
1. Attach right base (C) and left base (AA) to joint base (A) with (17), (29) and (30).
2. Attach joint tube (B) to right base (C) and left base (AA) with (17), (18), (29) and (30).
3. Attach swivel pulley block I (O) to joint base (A) with (4), (12) and (27).
4. Attach upright frame (D) to right base (C) and left base (AA) with (34), (28) and (30), and attach
guide rod (H) and cloth support (W) to right base (C) and left base (AA) with (24).
5. Attach swivel pulley block II (P) to adjustment tube (E) with axes (F), (4), (29) and (13), then slide
adjustment tube (E) down upright fame (D), secure it with (6).
6. Attach joint rod (L) to joint base (A) with (12) and (26).
NOTE: The pulley with pulley protection don’t install temporarily, until the cable to wear.

- 6 -
STEP 2
1
21 30
134FQ 30
15
J
23
29
30
29
14 31
1729
L
K
W
Y
32
5
28
19 28
D
I
G
2122
25
182120
35
20
29
33
28
22
111
T
S
16
HV
U
8
3
15 29 1
R
30
7. Slide rubber donut (3) onto guide rod (H).
8. Slide weight plate (T) onto guide rod (H), insert selector rod (U) into weight plate (T) with pin (8).
9. Slide top plate (S) onto guide rod (H), attach secure bushing (V) to selector rod (U), and attach swivel
pulley block IV (R) with (16) and big washer (32) to selector rod (U) as shown.
10. Attach joint beam (K) to straight beam (G) with big pulley (1) and (21), (29) and (30).
11. Attach straight beam (G) to upright frame (D) and bushing(Y), cloth support (W), guide rod (H) with
(25), (35) and (28).
12. Attach top joint tube (I), big pulley (1), largest pulley (33) and small pulley (2) to straight beam (G)
with (18), (20), (21), (22), (29) and (30) as shown.
13. Attach swivel pulley block III (Q) to top cross beam (J) with axes (F), bushing (4), (29) and (13).
14. Attach top cross beam (J) to top joint tube (I) and joint beam (K) with (17), (19), (28) and (29) as
shown.
15. Attach joint rod (L) to top cross beam (J) with (23) and (29).

- 7 -
CABLE 1
a
b
c
d
ef
g
h
i
j
k
14 31 1
9
1
33
1
2 2
1
1
1
#9 cable: from a→b→c→d→e→f→g→h→i→j→k

- 8 -
CABLE 2
l
m
n
o
1431
10 1
1
1
#10 cable: from l→m→n→o

- 9 -
CABLE 3
q
r
s
t
14
31 p
11
1
1
1
1
#11 cable: from p→q→r→s→t
