TVS JUPITER GRANDE EDITION User manual

II
TVS Jupiter Grande
INTRODUCINGTHE ALL NEW TVS Jupiter Grande
Staying connected round-the-clock is today more of a necessity than a luxury. And here is a scooter that lets you stay
on the move as well as stay connected, at the same time. The TVS Jupiter Grande Edition. A perfect combination
of new-age styling and technology that allows you to stay connected. With its range of innovative features, the TVS
Jupiter Grande Edition takes the entire riding experience to a whole new level.
For starters, the TVS Jupiter Grande Edition comes with unique connectivity features like Connected Semi Digital
Speedometer and SMARTXONNECT with Bluetooth® connectivity. It also has advanced features like Adjustable
Shock Absorbers, LED Headlamp, Sync Braking System in disc brake. The unique Tech Blue colour together with the
luxurious Cross-Stitched Maroon Seat and Diamond Cut Alloy Wheels just elevates the riding experience.
Stay connected. Stay on the move.

III
III
UNIQUE FEATURES OFTVS Jupiter Grande
CONNECTED SEMI DIGITAL SPEEDOMETER SMARTXONNECT – BLUETOOTH®
CONNECTIVITY
TVS Jupiter Grande features a Semi Digital Speedometer with inbuilt Bluetooth® Connectivity
lets you to connect Android/iOS smartphones to access features like Caller ID and SMS
notification (Android only) on the cluster of your scooter. It is also equipped with many other
innovative features like Digital Fuel Indicator, Digital Odometer, Trip Meter – A, B & F, service
reminder, helmet indication, economy percentage and more.
TVS CONNECT APP
TVS CONNECT smart phone app is available in the Google Play and Apple App Store®for your
TVS JUPITER Grande and it can be installed in your Android/iOS smart phone. To access the
features of your TVS JUPITER Grande's connected instrument cluster like:
• Incoming call alerts in connected instrument cluster.
• Incoming SMS alerts in connected instrument cluster only for saved contacts (Android
only).
• Number of missed calls alerts in the connected instrument cluster.
• Battery status of your smart phone in connected instrument cluster.
• To send auto reply SMS to callers via Android smart phone (Android only).
• To alert user in case of over speeding.
• To generate and store ride reports.
• To sync the connected instrument cluster clock with smart phone clock.

IV
DUAL COLOUR 3D Logo
TVS Jupiter Grande comes with a
premium dual coloured 3D logo.
ALL LED LAMPS
TVS Jupiter Grande comes with a
premium LED headlamp with AHO,
LEDTail lamp & Brake lamp. Efficient
and bright, all LED lamps gives TVS
Jupiter Grande a unique look and
offers better visibility during night
rides.
ADJUSTABLE SHOCK ABSORBER
TVS Jupiter Grande comes with
Adjustable Shock Absorber, a first-
in-the-industry feature. This allows
you to adjust the required level
of hardness / softness as per the
usage requirement at just the push
of a lever.
PREMIUM NEW SEAT
TVS Jupiter Grande comes with
a diamond pattern, Maroon color
premium seat. The ergonomically
designed seat comes with anti-
skid mechanism which offers both
safety and comfort. The seat retains
its shape for a long time making all
your rides, whether short or long,
really comfortable.
PARTIAL CHROME MIRROR
The chrome highlights on the
mirrors enhance the visual appeal of
TVS Jupiter Grande and make it look
more magnificent.
TECH BLUE COLOUR
TVS Jupiter Grande comes in a
unique glossy and elegant colour
– Tech Blue. With its premium
look, the Tech Blue colour adds to
the grandeur and gives a unique
personality to the scooter.

V
V
DIAMOND - CUT ALLOY WHEELS
TVS Jupiter Grande has sporty
diamond cut alloy wheels.
PREMIUM BEIGE INTERIOR
PANELS
Exclusive colours in TVS Jupiter
Grande with premium beige
coloured interior panels give a
unique personality to the scooter
and exhibit a powerful signature of
your stature.
DISC BRAKE*
TVS Jupiter Grande is fitted with
“220 mm Disc“ at the front for
effective braking and safe riding
even at higher speeds.
UNIQUE PASS-BY SWITCH
Pass-by Switch is a feature first time
introduced in scooters ever. It allows
you to easily switch between high
& low beam of the headlamp with
easy press and auto release. It is
helpful especially while overtaking.
Refer page no. 27 for details.
EXTERNAL FUEL FILL
No other Scooter offers you this
unique facility. You can get petrol
filled without even getting out of
your seat.
RETRACTABLE BAG HOOKS
Your scooter has two retractable
Bag Hooks to carry light luggage like
carry bags weighing upto 3 kg.
One hook is located below the
handle bar on the rear panel and the
other one is located on the cover
front below the front end of seat.
* Applicable only for disc brake version

VI
TUBELESS TYRES
Another important unique feature
in your scooter is “Tubeless Tyres”.
Tubeless tyres reduce the chances
of getting punctured. Even if there
is a puncture, sudden leakage of air
is avoided, thereby provide better
safety and convenience. It is also
very easy to repair the punctured
tyres.
TELESCOPIC FRONT & GAS
FILLED REAR SHOCKS
Your Scooter has Motorcycle-like
‘Telescopic Front Suspension’ for
extreme comfort and Gas Filled
Shock Absorber in the rear for
excellent riding comfort even on bad
roads.
ECONOMETER®
Your speedometer has
ECONOMETER® which indicates
whether you are riding in Economy
Mode or Power mode.This is unique
feature of your scooter which
guides you to ride your scooter fuel
efficiently. Refer page no. 12 for
details.
LOW FUEL INDICATOR
‘Low Fuel Indicator’ is yet another
unique feature of your scooter which
indicates you to refill the fuel, when
the fuel in the tank goes below
minimum safe level. Refer page no.
13 for details.

VII
VII
PATENTED E-Z CENTRE STAND
E-Z Centre Stand of your scooter
reduces the effort required to place
the scooter on stand. Refer page no.
31 for operating procedure.
LED TAIL LAMP-CUM-BRAKE
LAMP
Your scooter has a LED Tail Lamp-
cum-Brake Lamp for better visibility
and stylish looks.
PARKING BRAKE (REAR BRAKE
LOCK)
‘Parking Brake’ is another unique
safety feature which protects your
scooter from falling due to wheel
rotation when it is parked with the
side stand on a slope. Refer page
no. 27 for details.
SYNCHRONISED BRAKE SYSTEM
(SBS)
Synchronised Brake System
reduces the stopping distance,
while keeping the stability intact.
IGNITION LOCK WITH SECURITY
SHUTTER
Security Shutter on the ignition lock
is a unique feature for an additional
safety of your scooter.
Security shutter protects the use of
key other than the original supplied
along with your vehicle. Refer page
no. 10 for operating procedure.
UNDER-SEAT STORAGE (UTILITY
BOX)
Your scooter has a 37 litre under-
seat storage space to carry your
luggage belongings, full face helmet
etc., refer page no. 33 for details.

VIII
HELMET HOOKS
Your scooter has two helmet hooks
under the seat assembly at the
front end of utility box to secure
your helmet. Refer page no. 34
for details.
INTELLIGENT TCI
Your scooter’s fuel efficient engine
uses Intelligent TCI inbuilt with
variable timing modes, makes sure
that you get the best from your
engine.
AUTO FUEL COCK
Your scooter has an ‘Auto Fuel
Cock’ which supplies the fuel
based on the engine suction. It is
not necessary to switch the fuel
cock 'ON' and 'OFF' manually.
SEAT-CUM-FUEL TANK CAP
LOCK
Your scooter has a ‘Dual lock’ for
opening the seat assembly and
fuel tank cap. You can open the
fuel tank cap without even getting
down from the scooter, refer page
no. 29 & 32 for operating
procedure.

IX
IX
ACCESSORIES FOR YOUR
VEHICLE
SMART PHONE CHARGER**
Smart phone charger is supplied
as an optional accessory for your
scooter. Location for fixing the
socket is provided inside the utility
box.
Contact nearest TVS Motor
Company Authorised Main Dealer
or Authorised Dealer for fixing the
socket. Refer page no. 29 for
usage details.
INDICATOR BUZZER**
Your scooter has an electronic
buzzer which alerts you that the
turn signal indicators are ‘ON’.
This buzzer comes as a mandatory
accessory.
** Mandatory and optional accessory will be charged extra

X
Dear TVS Jupiter Grande Owner,
Thank you for choosing the TVS Jupiter Grande, a scooter equipped with class-leading features that offer connectivity,
style, comfort, convenience, mileage, power, space and safety. As a proud owner of this scooter, you are now part of
the TVS Jupiter family that is over 3-million strong.
With the TVS Jupiter Grande, the riding experience enters a whole new dimension. Experience the combination of
advanced technology and new-age styling features, one that is unique to the scooter you own now.
This manual explains everything you need to know about your TVS Jupiter Grande. Kindly read it carefully and follow
the instructions to enjoy years of safe riding. To ensure reliable performance, we urge you to get your TVS Jupiter
Grande serviced only at TVS Motor Company Authorised Main Dealer / Authorised Dealer at specified regular periodic
intervals.
We welcome you once more to a world of comfortable and easy riding.
TVS MOTOR COMPANY LIMITED
FOREWORD

XI
XI
Take time to familiarize yourself with your TVS Jupiter Grande and its performance characteristics.
This Owner‘s Manual contains a host of useful information. Please take the time to read this manual before you ride
your new TVS Jupiter Grande. Get familiarised with the operation of your scooter for maximum safety and pleasure.
The better you know your vehicle, the more pleasure you will experience riding your new vehicle. Ensure that anyone
else riding your TVS Jupiter Grande does the same.
All information, illustrations, photographs and specifications contained in this owner’s manual are based on the latest
product information available at the time of this publication. TVS Motor Company Limited may, however, incorporate
modifications or improvements on its vehicles at any time without notice, and therefore, in such events it is possible
that the relevant part of the owner‘s manual does not apply to your vehicle.
Prior permission of TVS Motor Company Limited is required for quoting, copying or reproducing any part of this
owner’s manual.
Accessories shown in the picture may not be part of the standard equipment.
Pictures shown in this manual are of TVS Jupiter Grande drum brake model unless specified.
Your scooter is provided with always glowing head lamp.The head lamp glows automatically once the engine is
started.
Note
Revision 0, Aug 2019
NOTICE

XII
Operating this vehicle safely is an important responsibility of the rider. To help you make decisions on safety, we
have provided necessary operating procedure and other information in this manual. This information alerts you on
potential hazards that could hurt you or others. Since it is not possible to warn you about all the hazards associated
with operating or maintaining the vehicle, you must use your own judgment.
You will find important safety information in following form in this manual.These words carry the following connotations:
Disregarding this message might result in injury to the rider or deadly accidents.
Warning
This message indicates special procedures or precautions to be followed to avoid damage to the vehicle.
Caution
This message provides further clarification for clear understanding of any particular information.
Note
SAFETY INFORMATION

XIII
XIII
Running-in information 01
Safe riding tips 02
Know your TVS Jupiter Grande 06
Riding your TVS Jupiter Grande 36
Maintenance 40
Technical specifications 65
CONTENTS

1
1
The first 1000 km is a crucial part of your scooter. Proper running-in operation during this period helps in ensuring a
maximum life and smooth performance of your scooter.
The reliability and performance of your scooter depends on the special care and restrain exercised during the running-
in period. It is especially important that you avoid operating the engine in high speed (RPM), which could expose the
engine parts to excessive stress. Recommended speed during the running-in is:
Maximum 50 km/h speed upto 1000 km (vary the engine speed for better mating of parts).
The first free service at 500 ~ 750 km is most important. During running-in period all the engine components and
other parts will have set in. All adjustments to be restored, all fasteners to be tightened. Engine cum transmission oil
to be replaced. Timely performance of the first free service will ensure optimum service life and performance from
the engine.
RUNNING-IN INFORMATION
Replacing the engine cum transmission oil during first service is most important for better life of engine. Always use TVS
TRU4 SKUUTA oil (SAE 10W30 API-SL, JASO MB) for better performance and life.
Caution

2
SAFE RIDING TIPS
SAFE RIDING RECOMMENDATIONS
Any two wheeler riding requires some precautions to be taken to ensure the safety of the rider, pillion rider and other
road users. These precautions are:
Familiarise yourself with newTVS Jupiter Grande
Riding skill and your mechanical knowledge form the foundation of safe riding practices. We suggest you to practice
riding TVS Jupiter Grande in a low-traffic condition until you are thoroughly familiar with your vehicle and its controls.
Remember practice makes you perfect.
Riding apparel
Loose, fancy clothing can be uncomfortable and unsafe when riding a two-wheeler. Choose good quality two wheeler
riding apparel.
Know your limits
Ride within the boundaries of your own skill at all times. Knowing these limits and staying within them will help you
avoid accidents.
Two wheeler safety starts with wearing a good quality helmet. One of the most serious injuries that can happen is a
head injury. Always wear an ISI approved helmet that should fit your head comfortably and securely. You should also have
good quality goggles to protect your eyes and help your vision.
To prevent or minimize accident, never consume alcohol or drugs before or during the operation of your vehicle. Even minimal
consumption of these will affect the rider’s ability to control the vehicle.
Warning

3
3
Posture
Proper vehicle riding starts with proper posture.
1. Keep your elbows relaxed and flexible.
2. Sit and adjust yourself on seat so that arms and
shoulders are relaxed.
3. Look widely instead of gazing at one point.
One-hand riding is dangerous. Keep both hands firmly
on the handle bar and both feet securely on the floor
board. Under no circumstances should both the hands
be removed from the handle bar, as it is very dangerous.
Avoid use of mobile phones while riding as it could
lead to fatal accident.
Slow down to a safe speed before negotiating a corner.
If this is the first time that you are riding a vehicle of this
type, we suggest that you practice on a safe, open area
to become thoroughly familiar with the operation of the
vehicle.
Warning
Cornering
When cornering, centrifugal force works in a direction
perpendicular to the direction in which the vehicle
is moving. Centrifugal force increases in proportion
with speed and the radius of the corner.
During cornering, reduce speed so as to lessen the
effects of centrifugal force. By all means, avoid abrupt
application of brake or sudden steering.
Braking
For safe riding, it is very important to master the
braking techniques.
1. Close / release the throttle.
2. Hold the vehicle upright as you apply the brake.
3. Progressive application of brake is safer.
4. Apply both the brakes.
5. Riding down hills, while cornering and wet roads
close throttle and come to a slower speed to
avoid the loss of control over the vehicle due to
skidding.

4
Causes for poor braking
1. If the brake shoes/pads or drum/disc are worn
out or if there is water or oil on them, sufficient
friction does not develop and brakes do not work
well.
2. Even when the brake works normally, if the road
surface is wet or the tyre surface is worn-out,
tyres do not take a firm hold on the surface,
increasing the stopping distance.
3. Approximately 60% braking effect is from front
brake. Non-usage of front brake causes poor
braking.
As the vehicle speed increases, the stopping distance
also increases progressively. Be sure that, you have
sufficient distance between you and the vehicle or
obstruction ahead of you.
Using only the front or rear brake is dangerous and can
cause skidding and loss of control. Apply both the
brakes together and with great care on a wet road or
other slippery surfaces. Any abrupt braking on slippery
or irregular roads can cause loss of rider control.
Warning
ACCESSORY INSTALLATION AND SAFETYTIPS
Use extreme caution while selecting and installing
the accessories for your scooter.
The addition of unsuitable accessories can lead to
unsafe operating conditions. Your friendly Dealer
will assist you in selecting quality accessories and
installing them correctly.
While selecting the accessories, make sure the
accessories should not obstruct lighting, steering,
suspension level and ground clearance.
Additional electrical equipments and controls
should not exceed the specified electrical system
load of the vehicle (capacity of battery and
magneto).

5
5
EMISSION CONTROL
All the TVS vehicles are tested in the factory for
optimum fuel efficiency and CO levels. Do not
disturb the Carburettor settings as this may lead
to higher fuel consumption and also higher CO
levels.
If the vehicle needs any adjustments, please consult
nearest TVS Motor Company Authorised Main Dealer
or Authorised Dealer.
While adequate care is exercised at the factory to
ensure that the emissions are within the limits, it is
essential for the owner to always maintain the scooter
in good condition by getting it periodically checked
and serviced by TVS Motor Company Authorised
Main Dealer / Authorised Dealer so that the emission
and fuel consumption levels are maintained as per
norms.
Your vehicle is tested and certified for emission
which meets BS IV emission norms and is valid for
initial 12 months from the date of purchase. Get
your vehicle certified by the Government authorised
emission testing station every year (after initial 12
months of usage).
Note

6
VEHICLE IDENTIFICATION NUMBER
Serial numbers of both frame and engine are required for vehicle identification. They are also required to assist your
Dealer for ordering parts or referring to special information.
KNOW YOUR TVS JUPITER GRANDE
The frame serial number is stamped on the frame, at
the rear end below the seat assembly. Open the seat
assembly to read the frame number.
The engine serial number is stamped on the left side of
the engine, at the bottom, near center stand mounting.
See bottom to read serial number.
Frame number
Engine number
Control key number
Please fill the above boxes now for future reference

7
7
LOCATION OF PARTS - VEHICLE LEFT SIDE
1. Rear brake adjusting nut
2. Kickstarter lever
3. Effortless easy center stand
4. Side stand*
5. Pillion foot rest L
6. Front wheel axle
7. Seat cum fuel tank cap lock
8. Pillion handle
* Mandatory and optional accessory will be charged extra
