TVS Scooty Zest User manual

I
CONTACT(S) FOR SUPPORT
Incase you need any Clarification please contact above Dealer
Or
TVS Motor Company’s Area Offices (flip over for addresses)
Or
Toll Free Number : 1800-258-7111
Email : [e-mail]
Disclaimer : TVS Motor Company or any of its officials / Authorized Main dealer / Authorized Dealer do not ask customers for bank
/ card / wallet details / authentication. In case you face any such claim, please report to the relevant local authorities immediately.

II
CONTACT AT OUR AREA OFFICES
TAMILNADU-1, 3 & 4
1. TVS Motor Company Limited
V Floor, Gee Gee Universal,
No. 2, MC Nichols Road,
Chetpet, Chennai - 600 031.
Phone : [phone]
Email : [e-mail]
[e-mail]
TAMILNADU-2
2. TVS Motor Company Limited
No. 10, 2nd floor,
Shree Shanmugapriya Towers,
Kannuswamy Street,
Behind Hotel Annapoorna,
R S Puram, Coimbatore - 641 002.
Phone : [phone]
Email : [e-mail]
KERALA
3. TVS Motor Company Limited
Ambady Towers, Second Floor,
Door No. 27/631, A6,
Edappally-Pookkattupady Road,
Edappally PO., Cochin - 682 024.
Phone : [phone]
Email : [e-mail]
KARNATAKA-1, 2 & GOA
4. TVS Motor Company Limited
No. 600, Anand Surya, 2nd Floor,
15th Cross, 6th Phase, JP Nagar,
Opp. BMTC Bus Stop,
Bangalore - 560 078.
Phone : [phone]
Email : [e-mail]
[e-mail]
ANDHRAPRADESH -1 & 2
5. TVS Motor Company Limited
Rukumani Towers, First Floor,
No. 3-11-30, Plot No. 11,
Paigha Colony, Behind Anand Theater,
Secunderabad - 500 003.
Phone : [phone]
Email : [e-mail]
[e-mail]
MAHARASHTRA-1 & 2
6. TVS Motor Company Limited
No. 401, 4th Floor, The Chambers,
Plot No. 4/12/3, Near Ganapati Chowk,
Viman Nagar, Pune - 411 014.
Phone : [phone]
Email : [e-mail]
MAHARASHTRA-3 & CHATTISGARH
7. TVS Motor Company Limited
No. 502B, 6th Floor, B Wing,
Shriram Shyam Towers,
Near LIC Square, Sardar,
Nagpur - 440 001.
Phone : [phone]
Email : [e-mail]
[e-mail]
GUJARATH
8. TVS Motor Company Limited
109, Ayna Complex,
Opp. Suvarna Villa Bungalows,
100 ft Thaltej Hebbatpur Road,
Off : S.G. Highway, Thaltej,
Ahmedabad - 380 054.
Phone : [phone]
Email : [e-mail]

III
MADHYA PRADESH-1 & 2
9. TVS Motor Company Limited
No. 211-212, 2nd Floor,
Chinar Incube Business Centre,
Chinar Fortune City,
Near Brindhavan Dhaba,
Hosangabad Road,
Bhopal - 462 026.
Phone : [phone]
Email : [e-mail]
[e-mail]
RAJASTHAN-1 & 2
10. TVS Motor Company Limited
Plot No. 17-18,
2nd Floor of National Motors Building,
Jhotwara Industrial Area,
Jaipur - 302 012.
Phone : [phone]
Email : [e-mail]
[e-mail]
DELHI & HARYANA
11. TVS Motor Company Limited
D-3 & D-4, 2nd Floor,
Sector - 10, Noida,
Uttar Pradesh - 201 301.
Phone : [phone]
Email : [e-mail]
[e-mail]
PUNJAB & CHANDIGARH
12. TVS Motor Company Limited
4th Floor, Royal Business Park,
Chandigarh Ambala Highway,
Zirkapur - 140 603.
Phone : [phone]/465777
Email : [e-mail]
UTTAR PRADESH WEST
13. TVS Motor Company Limited
D-3 & D-4, 2nd Floor,
Sector - 10, Noida,
Uttar Pradesh - 201 301.
Phone : [phone]
Email : [e-mail]
UTTAR PRADESH CENTRAL & EAST
14. TVS Motor Company Limited
1st Floor, Cyber Tower, TC-34/V-2,
Vibhuti Khand, Gomti Nagar,
Lucknow - 226 010.
Phone : [phone]
Email : [e-mail]
[e-mail]
WEST BENGAL
15. TVS Motor Company Limited
Ground Floor & First Floor,
133 A. S. P. Mukherjee Road,
Opp. Tollygunge Police Station,
Kolkatta - 700 026.
Phone : [phone]
Email : [e-mail]
BIHAR
16. TVS Motor Company Limited
N-Plaza, Jamal Road,
P.S. Kotwali,
Patna - 800 001.
Phone : [phone]
Email : [e-mail]

IV
ORISSA & JHARKHAND
17. TVS Motor Company Limited
No. 303, 3rd Floor,
Creative Plaza, Rasulgarh,
Bhubaneshwar - 751 010.
Phone : [phone]
Email : AO.Bhubaneshwar@tvsmotor.
com
NORTH EAST STATES
18. TVS Motor Company Limited
147, Udayan, Ganesh Guri,
Opp. Punjab National Bank,
R G B. Road, Guwahati - 781 005.
Phone : [phone]
Email : [e-mail]

V
ZEST for POWER
Next-Gen 110cc CVTi ENGINE
Your scooter is powered by a Next
Gen 110cc CVTi ECO Tuned Fuel
Injection technology engine.
Your scooter also has Best in class
Power-to-weight ratio with Best in
class pickup. It makes your scooter
smooth and zip through traffic with
ease.
ZEST for STYLE
Your scooter comes in vibrant
colour ensuring you always arrive
in style.
BACK-LIT SPEEDOMETER
Your scooter comes with a stylish
back-lit speedometer,
LEAF-SHAPED MIRROR
The leaf-shaped mirrors enhance
the style quotient of your scooter.
Style comes with performance
as these mirrors can be adjusted
easily. You can adjust them up-
down, forward-backward and
rotate as well, for enhanced
visibility & safety.
LED TAIL LAMP CUM BRAKE
LAMP
Your scooter has an LED tail lamp
that makes it look stylish at night
also.
TWILIGHT LAMP
Your scooter has twin twilight
lamps located on the front panel,
for you to choose your stylish
lighting on the go.
NEW TEXTURED FLOORBOARD
Your scooter comes with a stylish
textured floor board.
UNIQUE FEATURES OF TVS SCOOTY ZEST

VI
STAINLESS STEEL MUFFLER
GUARD
The stainless steel muffler guard
on your scooter not only protects
you from hot muffler but also adds
a dash of style to its sporty looks.
SPORTY DOUBLE STITCHED
SEAT
PAINTED SWITCH PANEL
ZEST for COMFORT
RIGHT ERGONOMICS
Your Scooter comes with right
weight of 103 kgs for easy handling
and zippier rides. Also, Right Seat
height of 760 mm on your scooter
ensures good ground reachability
while adding safety.
FRONT TELESCOPIC SHOCK
ABSORBERS & REAR DOUBLE
RATED HYDRAULIC MONO-
SHOCK SPRING SUSPENSION
Your scooter comes with superior
suspension that enhances ride
comfort even when you ride over
potholes, bumps or bad roads.
WIDE COMFORTABLE SEAT
A wide comfortable seat ensures
that your posture while riding is
relaxed and your pillion is seated
comfortably too.
ABS BODY
The ABS body of your scooter is
tough and ensures comfort while
riding.

VII
ZEST for CONVENIENCE
LARGEST UNDER-SEAT
STORAGE (UTILITY BOX)
Your scooter has the largest 19 litre
under-seat storage space to carry
your bags, books, and belongings.
TUBELESS TYRE
Your scooter has tubeless tyres for
enhanced convenience. You can
run the vehicle for a few more kms
even after the tyre is punctured.
EaZy® CENTRE STAND
The patented EaZy® Centre Stand
of your scooter reduces the effort
required to place the scooter on
stand.
SYNCHRONIZED BRAKING
TECHNOLOGY (SBT)
Synchronized braking technology
reduces the stopping distance,
While keeping the stability intact.
PARKING BRAKE (REAR BRAKE
LOCK)
The parking brake is another unique
safety feature which protects your
scooter from falling when it is
parked on a slope.
MFR HEADLAMP
Your scooter has a “Multi Focal
Reflector” – the bright headlamp
with a ‘Halogen bulb’ for better
visibility in the dark.
RETRACTABLE BAG HOOK
Your scooter has a retractable bag
hook to carry light luggage, like
carry bags weighing up to 3 kgs.
The hook is located below the
handle bar.
UNDER-SEAT LUGGAGE HOOK
For more convenience, another
luggage hook is located just under
the seat of your scooter.

VIII
HELMET HOOK
Your scooter has one helmet
hook under the seat assembly to
conveniently place the helmet.
EASY KICKSTART
The kick lever in your scooter is
designed such that the vehicle can
be kick-started while you’re seated
on the vehicle.
HUGGER FENDER
The hugger fender in your scooter
keeps the engine protected &
helps to save the pillion rider from
mud splashes.
SMART PHONE CHARGER
Your scooter has a Smart phone
changer enable to charge your
mobile phone when you are
traveling. The utility box light which
lights up the utility box whenever
the seat is open.
LED DAY TIME RUNNING LAMP
(DRL)
DRL increase the conspicuity
of the vehicle during daylight
condition “Drive with safety and
style“. Refer page no. 15 for details
ZEST for MILEAGE
BEST IN CLASS MILEAGE
Your scooter is not only packed
with features but also it is easy
on your pocket. Its best-in-class
mileage ensures you spend lesser
on fuel and save more pocket
money.

IX
ECONOMETER®
Your speedometer has an
ECONOMETER® which indicates
whether you are riding in Economy
Mode or Power mode. This unique
feature of your scooter enables to
manage your scooter fuel efficiency.
LONG-IDLING INDICATOR
The long-idling indicator reminds
you to switch off the ignition while
waiting at signals or when your
scooter is idle, thus helping you to
save fuel
ACCESSORIES FOR YOUR
VEHICLE
OPEN FRONT GLOVE BOX*
An open front glove box is supplied
as an accessory for your scooter. It is
specially designed to accommodate
a 1 litre bottle.
FOLDABLE PILLION SIDE FOOT
REST*
The foldable pillion side foot rest is
supplied as an accessory for your
scooter.
* Accessory will be charged extra

X
Dear TVS Scooty Zest Owner,
Congratulations and welcome to the world of fun and exciting rides with your TVS Scooty Zest.
You‘ve made a smart decision, choosing to ride ahead on the brand new TVS Scooty Zest. You‘ll find that it meets all
your needs by striking the perfect balance between power, style, comfort, convenience and mileage.
The stylish new TVS Scooty Zest is crafted especially for you. Its 110cc CVTi engine gives you awesome pick-up and
zippy rides.
The TVS Scooty Zest is also easy to ride – with the right height and the right weight; it offers you the perfect balance
of speed and stability, so it‘s easy to handle on busy roads. With the least turning radius, it is easy to manoeuvre as
well.
The benefits of TVS Scooty Zest don‘t end there. With its largest under-seat storage of 19 litres, it gives you the all
the space to carry your world with you.
This manual explains in detail, the many features, benefits and operations of your TVS Scooty Zest. Do read through
your manual carefully, it will help you get the best out of your vehicle, and keep it going strong for years to come.
To ensure reliable performance, we urge you to get your TVS Scooty Zest serviced only at TVS Motor Company
Authorised Main Dealers / Authorised Dealers at regular intervals as specified by your service provider.
We wish you zippy, comfortable, safe and exciting trips for years to come! Get ready to zip ahead with Zest!
TVS MOTOR COMPANY LIMITED
FOREWORD

XI
All information, illustrations, photographs and specifications contained in this owner’s manual are based on the latest
product information available at the time of this publication. TVS Motor Company Limited may, however, incorporate
modifications or improvements on its vehicles at any time without notice, and therefore, in such events it is possible
that the relevant part of the owner’s manual does not apply to your vehicle.
Prior permission of TVS Motor Company Limited is required for quoting, copying or reproducing any part of this
owner’s manual.
Accessories shown in the picture may not be part of the standard equipment.
Your scooter is provided with a day time running lamp (DRL). The DRL glows automatically once the ignition is turned ON and
continues to glow till the head lamp is switched ‘ON’.
Revision 1, Jan 2021
NOTICE

XII
Operating this vehicle safely is an important responsibility of the rider. To help you make decisions on safety, we
have provided necessary operating procedure and other information in this manual. This information alerts you on
potential hazards that could hurt you or others. Since it is not possible to warn you about all the hazards associated
with operating or maintaining the vehicle, you must use your own judgement.
You will find important safety information in following form in this manual.These words carry the following connotations:
Disregarding this message might result in injury to the rider or deadly accidents.
This message indicates special procedures or precautions to be followed to avoid damage to the vehicle.
This message provides further clarification for clear understanding of any particular information.
SAFETY INFORMATION

XIII
CONTENTS
RUNNING-IN INFORMATION 01
SAFE RIDING TIPS 02
KNOW YOUR TVS Scooty Zest 06
RIDING YOUR TVS Scooty Zest 23
MAINTENANCE 27
WARRANTY AND SERVICES 48
TECHNICAL SPECIFICATIONS 53
EXPRESS SERVICE 56
EXPERT ON WHEELS 57
PICKUP AND DROP 58
GENERAL INFORMATION 59

1
The first 1000 km is a crucial part for the life of your scooter. Proper running-in operation during this period helps in
ensuring a maximum life and smooth performance of your scooter.
The reliability and performance of your scooter depends on the special care and restraint exercised during the running-
in period. It is especially important that you avoid operating the engine in high speed (RPM), which could expose the
engine parts to excessive stress. Maximum recommended speed during the running-in is:
Maximum 50 kmph speed upto 1000 km (vary the engine speed for better mating of parts).
The first free service at 500 ~ 750 km is most important. During running-in period all the engine components and
other parts will have set in. All adjustments to be restored, all fasteners to be tightened. Engine and transmission
oil to be replaced. Timely performance of the first free service will ensure optimum service life and performance
from the engine.
RUNNING-IN INFORMATION
Replacing the engine and transmission oil during first free service is most important for better life of engine. Always use TVS
TRU4 SKUUTA oil (SAE10W30 API-SL, JASO MB) for better performance and life.

2
SAFE RIDING TIPS
SAFE RIDING RECOMMENDATIONS
Any two wheeler riding requires some precautions to be taken to ensure the safety of the rider, pillion and other road
users. These precautions are:
Familiarise yourself with newTVS Scooty Zest
Riding skill and your mechanical knowledge form the foundation of safe riding practices. We suggest you to practice
riding TVS Scooty Zest in a low-traffic condition until you are thoroughly familiar with your vehicle and its controls.
Remember practice makes you perfect.
Riding apparel
Loose, fancy clothing can be uncomfortable and unsafe when riding a two-wheeler. Choose good quality two wheeler
riding apparel.
Know your limits
Ride within the boundaries of your own skill at all times. Knowing these limits and staying within the limits will help
you avoid accidents.
Two wheeler safety starts with wearing a good quality helmet. One of the most serious injuries that can happen is a head
injury. Always wear an ISI approved helmet that should fit your head comfortably and securely. You should also have good
quality goggles to protect your eyes and help your vision.
To prevent or minimize accident, never consume alcohol or drugs before or during the operation of your vehicle. Even minimal
consumption of these will affect the rider’s ability to control the vehicle.

3
Posture
Proper vehicle riding starts with proper posture.
1. Keep your elbows relaxed and flexible.
2. Sit and adjust yourself on seat so that arms and
shoulders are relaxed
3. Look widely instead of gazing at one point.
Cornering
When cornering, centrifugal force works in a direction
perpendicular to the direction in which the vehicle
is moving. Centrifugal force increases in proportion
with speed and radius of the corner.
During cornering, reduce speed so as to lessen the
effects of centrifugal force. By all means, avoid abrupt
application of brake or sudden steering.
Braking
For safe riding, it is very important to master the
braking techniques.
1. Close / release the throttle.
2. Hold the vehicle upright as you apply the brake.
3. Progressive application of brake is safer.
4. Apply both the brakes. ‘SBT’ provides
additional braking even when ‘Only Rear
brake’ is applied, But applying ‘Both the
brakes’ helps you to use the full potential of
the brakes.
5. Riding down hills, while cornering and wet roads
close throttle and come to a slower speed to
avoid the loss of control over the vehicle due to
skidding.
One-hand riding is dangerous. Keep both hands firmly
on the handle bar and both feet securely on the floor
board. Under no circumstances should both the hands
be removed from the handle bar, as it is very dangerous.
Avoid use of mobile phones while riding as it could
lead to fatal accident.
Slow down to a safe speed before negotiating a corner.
If this is the first time that you are riding a vehicle of
this type, we suggest that you practice on a safe, open
area to thoroughly familiarise with the operation of the
vehicle.

4
Causes for poor braking
1. If the brake shoes or drum are worn out or if there
is water or oil on them, sufficient friction does not
develop and brakes do not work well.
2. Even when the brake works normally, if the road
surface is wet or the tyre surface is worn-out,
tyres do not take a firm hold on the surface,
increasing the stopping distance.
3. Approximately 60% braking effect is from front
brake. Non-usage of front brake causes poor
braking.
As the vehicle speed increases, the stopping distance
also increases progressively. Be sure that, you have
sufficient distance between you and the vehicle or
obstruction ahead of you.
Using only the front or rear brake is dangerous and can
cause skidding and loss of control. Apply both the
brakes together and with great care on a wet road or
other slippery surfaces. Any abrupt braking on slippery
or irregular roads can cause loss of rider control.
ACCESSORY INSTALLATION AND SAFETY TIPS
Use extreme caution while selecting and installing
the accessories for your scooter.
The addition of unsuitable accessories can lead to
unsafe operating conditions. Your friendly Dealer
will assist you in selecting quality accessories and
installing them correctly.
While selecting the accessories, make sure the
accessories should not obstruct lighting, steering,
suspension level and ground clearance.
Additional electrical equipments and controls
should not exceed the specified electrical system
load of the vehicle (capacity of battery and
magneto).

5
EMISSION CONTROL
All the TVS vehicles are tested in the factory for
optimum fuel efficiency and CO levels. If the vehicle
needs any adjustments, please consult nearest
TVS Motor Company Authorised Main Dealer or
Authorised Dealer.
While adequate care is exercised at the factory
to ensure that the emissions are within the limits,
it is essential for the owner to always maintain the
scooter in good condition by getting it periodically
checked and serviced by TVS Motor Company
Authorised Main Dealer / Authorised Dealer so
that the emission and fuel consumption levels are
maintained as per norms.
Crankcase emission control system
The engine of new TVS Scooty Zest is equipped with
a closed crankcase system to prevent discharging
crankcase emissions into the atmosphere. Blow-by
gas is returned to the combustion chamber through
the air cleaner and the fuel system.
Evaporative Emission Control System
TVS Scooty Zest is equipped with an evaporative
emission control system which consists of a canister
and associated piping. This system prevents the
escape of fuel vapors from the fuel tank.
Your vehicle is tested and certified for emission
which meets BS VI emission norms and is valid for
initial 12 months from the date of purchase. Get
your vehicle certified by the Government authorised
emission testing station every year (after initial 12
months of usage).
If there is any abnormal jerk, startability issue are felt in
the vehicle or noise due to sudden escape of gas during
opening of fuel tank cap, immediately report to the TVS
Motor Company Authorised Main Dealer / Authorised
Dealer.

6
VEHICLE IDENTIFICATION NUMBER
The frame and engine serial numbers are the only means of identifying your vehicle from others of the same model
and type. They are also required to assist your Dealer for ordering parts or referring to special information.
KNOW YOUR TVS Scooty Zest
The frame serial number is stamped on the frame, at
the rear end below the seat assembly. Open the seat
assembly to read the frame number.
The engine serial number is stamped on the left side of
the engine, at the bottom, near center stand mounting.
See bottom to read serial number.
Frame number
Engine number
Control key number
Please fill the above boxes now for future reference

7
LOCATION OF PARTS - HANDLE BAR
1. Retractable bag hook
2. Horn switch
3. Turn signal lamp switch
4. Rear brake lever
5. Parking brake (rear brake lock)
6. Rear view mirror L
7. High/low beam switch
8. Speedometer assembly
9. Rear view mirror R
10. Front brake lever
11. Throttle grip
12. Lights ON/OFF switch
13. Electric starter switch
14. Ignition cum steering lock
15. Glove box*
8 9
1
4
7
6
* Accessory will be charged extra
5
3
2
10
11
12
13
14
15
